Image preview - the first page of the document
>> Download Samsung SGH-N625 service manual documenatation <<
Text preview - extract from the document
DUAL BAND Mobile
ELECTRONICS
Cellular Phone
SGH-N625
SERVICE Manual
DUAL BAND Mobile Cellular Phone CONTENTS
1. Exploded Views and Parts List
2. PCB Diagrams
3. Electrical Parts List
4. Block Diagrams
5. Flow chart of trouble shooting
ELECTRONICS
Samsung Electronics Co.,Ltd.
Printed in Korea
08/2002 Rev 1.0
GH68-03123A
1. Exploded Views and Parts List
1-1 Main
1-2 Main Parts List
1-3 Travel Adapter
1-4 Travel Adapter Parts List
1-5 Test Jig
1-5-1 Test Jig
1-6 normal EAR Microphone
1-7 Data Kit
2. PCB Diagrams
2-1 Main Top
2-2 Main Bottom
3. Electrical Parts List
3-1 Main Parts List Top
3-2 Main Parts List Bottom
4. Block Diagrams
4-1 Main Base Band
4-2 Main RF
4-2-1 RF Tx Part
4-2-2 RF Rx Part
5. Flow chart of trouble shooting
5-1 Power ON
5-2 Initial
5-3 Charging Part
5-4 Sim Part
5-5 Microphone Part
5-6 Speaker Part
5-7 Key Data Input
5-8 Ring Indicator
5-9 Back Light
5-10 Melody Part
5-11 GSM Receiver
5-12 GSM Transmit
5-13 DCS Receiver
5-14 DCS Transmit
1. Exploded Views and Parts List
1-1 Main (SGH-N625)
1
2
3
4
6
5 8
7 9
10 11
12
14
15
16
13
17
18
19
Exploded Views and Parts List 1-1
1-2 Main Parts List
NO SEC CODE DESCRIPTION Q'TY REMARK
1 GH75-02239A FRONT COVER 1
2 3001-001199 SPEAKER 1
3 GH59-00240B MIC 1
4 GH72-03376D KEYPAD 1
5 GH59-00282A KEY PCB 1
6 GH73-00923A LCD COVER 1
7 GH75-01490A KEY-VOLUME 1
8 GH82-00114A MAIN PBA 1
9 GH07-01336A LCD 1
10 GH73-00893A CONNECTOR COVER 1
11 GH73-03213B SILELD COVER 1
12 3001-001267 SPEAKER 1
13 GH75-01471B REAR COVER 1
14 GH31-00033A MOTOR 1
15 GH73-00892A MOBILE CAP 1
16 GH42-00212A ANTENNA 1
17 6001-001634 SCREW 5
18 GH73-00891A SCREW CAP 1
19 GH43-00435B BATTERY 1
1-2 Exploded Views and Parts List
1-3 Travel Adapter
A
1-4 Travel Adapter Parts List
TYPE SEC CODE REMARK
A GH44-00171A
1-5 Test Jig
TEST JIG GH80-10508A
Exploded Views and Parts List 1-3
TEST JIG CABLE GH39-00079A
RF JIG CABLE GH39-00094A
DM CABLE GH39-00143B
1-4 Exploded Views and Parts List
1-5-1 Test Jig
DC
POWER
SUPPLY
8922 or 8960
WIRELESS COMMVNCATIONS
TEST SET
RF JIG CABLE
TE
ST
J IG
232 CABLE
TEST JIG CABLE
1-6 Normal EAR Microphone
NORMAL EARPHONE GH59-0033aA
1-7 Data Kit
DATA KIT GH39-00078A
Exploded Views and Parts List 1-5
2. PCB Diagrams
2-1 Main Top
2-1 PCB Diagrams
2-2 Main Bottom
2-2 PCB Diagrams
3. Electrical Parts List
3-1 Main Parts List Top
NO Reference SEC Code Part Description Vendor Part No
1 C100 2404-001105 "C-TA,CHIP;10UF/6.3V" TCSCS0J106MPAR
2 C101 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
3 C102 2203-000233 "C-CERAMIC,CHIP;C101J,100PF,50V" GRP1555C1H101JD01E
4 C129 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
5 C151 2203-005482 "C-CERAMIC,CHIP;C104K,100NF,10V" GRP155R61A104KA01E
6 C202 2404-001101 "C-TA,CHIP;1UF/16V" TAJR105M016R
7 C203 2404-001101 "C-TA,CHIP;1UF/16V" TAJR105M016R
8 C204 2404-001101 "C-TA,CHIP;1UF/16V" TAJR105M016R
9 C205 2404-001101 "C-TA,CHIP;1UF/16V" TAJR105M016R
10 C206 2404-001101 "C-TA,CHIP;1UF/16V" TAJR105M016R
11 C207 2203-005061 "C-CERAMIC,CHIP;C104Z,100NF,16V" CL05F104ZONC
12 C208 2203-005061 "C-CERAMIC,CHIP;C104Z,100NF,16V" CL05F104ZONC
13 C209 2203-005061 "C-CERAMIC,CHIP;C104Z,100NF,16V" CL05F104ZONC
14 C210 2203-005061 "C-CERAMIC,CHIP;C104Z,100NF,16V" CL05F104ZONC
15 C211 2203-000604 "C-CERAMIC,CHIP;C223K,22NF,25V" CL10B223KANC
16 C215 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
17 C400 2203-005061 "C-CERAMIC,CHIP;C104Z,100NF,16V" CL05F104ZONC
18 C401 2203-005061 "C-CERAMIC,CHIP;C104Z,100NF,16V" CL05F104ZONC
19 C409 2203-002443 "C-CERAMIC,CHIP;C331K,330PF,50V" CL05B331KBNC
20 C410 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
21 C411 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
22 C413 2203-003054 "C-CERAMIC,CHIP;C090C,9PF,50V" GRP1555C1H9R0DZ01E
23 C414 2203-000386 "C-CERAMIC,CHIP;C150J,15PF,50V" GRP1555C1H150JZ01E
24 C430 2203-000438 "C-CERAMIC,CHIP;C102K,1NF,50V" GRP155R71H102KA01E
25 C431 2203-005061 "C-CERAMIC,CHIP;C104Z,100NF,16V" CL05F104ZONC
26 C432 2404-001086 "C-TA,CHIP;4.7UF/6.3V" TESVSPOJ475M8RTJ
27 C433 2203-005061 "C-CERAMIC,CHIP;C104Z,100NF,16V" CL05F104ZONC
28 C434 2203-005483 "C-CERAMIC,CHIP;C683K,68NF,10V" GRP155R61A683KA01E
29 C437 2203-000233 "C-CERAMIC,CHIP;C101J,100PF,50V" GRP1555C1H101JD01E
30 C440 2203-005482 "C-CERAMIC,CHIP;C104K,100NF,10V" GRP155R61A104KA01E
31 C442 2203-005061 "C-CERAMIC,CHIP;C104Z,100NF,16V" CL05F104ZONC
32 C443 2404-001086 "C-TA,CHIP;4.7UF/6.3V" TESVSPOJ475M8RTJ
33 C450 2203-000854 "C-CERAMIC,CHIP;C390J,39PF,50V" GRP1555C1H390JZ01E
34 C451 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
35 C499 2203-000714 "C-CERAMIC,CHIP;C332K,3.3NF,50V" CL05B332KBNC
36 C502 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
37 C503 2203-003054 "C-CERAMIC,CHIP;C090C,9PF,50V" GRP1555C1H9R0DZ01E
38 C504 2203-005503 "C-CERAMIC,CHIP;C1801J,180PF,25V" CL05C181JANC
3-1 Electrical Parts List
NO Reference SEC Code Part Description Vendor Part No
39 C505 2203-000233 "C-CERAMIC,CHIP;C101J,100PF,50V" GRP1555C1H101JD01E
40 C506 2203-000233 "C-CERAMIC,CHIP;C101J,100PF,50V" GRP1555C1H101JD01E
41 C507 2203-000233 "C-CERAMIC,CHIP;C101J,100PF,50V" GRP1555C1H101JD01E
42 C508 2203-000233 "C-CERAMIC,CHIP;C101J,100PF,50V" GRP1555C1H101JD01E
43 C510 2203-005503 "C-CERAMIC,CHIP;C1801J,180PF,25V" CL05C181JANC
44 C511 2203-000812 "C-CERAMIC,CHIP;C330J,33PF,50V" GRP1555C1H330JZ01E
45 C512 2203-000812 "C-CERAMIC,CHIP;C330J,33PF,50V" GRP1555C1H330JZ01E
46 C513 2203-000812 "C-CERAMIC,CHIP;C330J,33PF,50V" GRP1555C1H330JZ01E
47 C514 2203-000812 "C-CERAMIC,CHIP;C330J,33PF,50V" GRP1555C1H330JZ01E
48 C515 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
49 C516 2203-000812 "C-CERAMIC,CHIP;C330J,33PF,50V" GRP1555C1H330JZ01E
50 C517 2203-000812 "C-CERAMIC,CHIP;C330J,33PF,50V" GRP1555C1H330JZ01E
51 C518 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
52 C519 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
53 C520 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
54 C521 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
55 C522 2203-000812 "C-CERAMIC,CHIP;C330J,33PF,50V" GRP1555C1H330JZ01E
56 C523 2203-000812 "C-CERAMIC,CHIP;C330J,33PF,50V" GRP1555C1H330JZ01E
57 C524 2203-000812 "C-CERAMIC,CHIP;C330J,33PF,50V" GRP1555C1H330JZ01E
58 C525 2203-000812 "C-CERAMIC,CHIP;C330J,33PF,50V" GRP1555C1H330JZ01E
59 C526 2203-005061 "C-CERAMIC,CHIP;C104Z,100NF,16V" CL05F104ZONC
60 C527 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
61 C528 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
62 C529 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
63 C530 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
64 C531 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
65 C532 2203-005480 "C-CERAMIC,CHIP;C333K,33NF,10V" GRP155R71A333KA01E
66 C537 2203-003054 "C-CERAMIC,CHIP;C090C,9PF,50V" GRP1555C1H9R0DZ01E
67 C538 2203-005480 "C-CERAMIC,CHIP;C333K,33NF,10V" GRP155R71A333KA01E
68 C539 2203-000812 "C-CERAMIC,CHIP;C330J,33PF,50V" GRP1555C1H330JZ01E
69 C540 2203-000812 "C-CERAMIC,CHIP;C330J,33PF,50V" GRP1555C1H330JZ01E
70 C541 2203-005481 "C-CERAMIC,CHIP;C473K,47NF,10V" GRP155R71A473KA01E
71 C542 2203-003054 "C-CERAMIC,CHIP;C090C,9PF,50V" GRP1555C1H9R0DZ01E
72 C544 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
73 C545 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
74 C547 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
75 C548 2203-003054 "C-CERAMIC,CHIP;C090C,9PF,50V" GRP1555C1H9R0DZ01E
76 C549 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
77 C550 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
78 C551 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
79 C552 2203-000812 "C-CERAMIC,CHIP;C330J,33PF,50V" GRP1555C1H330JZ01E
80 C553 2404-001162 "C-TA,CHIP;F950G476MAAJZTQ2" F950G476MAAJZTQ2
Electrical Parts List 3-2
NO Reference SEC Code Part Description Vendor Part No
81 C560 2203-003054 "C-CERAMIC,CHIP;C090C,9PF,50V" GRP1555C1H9R0DZ01E
82 C561 2203-000386 "C-CERAMIC,CHIP;C150J,15PF,50V" GRP1555C1H150JZ01E
83 C591 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
84 C617 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
85 C633 2203-005446 "C-CERAMIC,CHIP;C2R7B,2.7PF,50V" GRP1555C1H2R7BZ01E
86 C657 2203-001221 "C-CERAMIC,CHIP;C821K,820PF,50V" CL05B821KBNC
87 C659 2203-000233 "C-CERAMIC,CHIP;C101J,100PF,50V" GRP1555C1H101JD01E
88 C660 2203-000233 "C-CERAMIC,CHIP;C101J,100PF,50V" GRP1555C1H101JD01E
89 C661 2203-000995 "C-CERAMIC,CHIP;C470J,47PF,50V" GRP1555C1H470JZ01E
90 C666 2203-000438 "C-CERAMIC,CHIP;C102K,1NF,50V" GRP155R71H102KA01E
91 C667 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
92 C668 2203-000995 "C-CERAMIC,CHIP;C470J,47PF,50V" GRP1555C1H470JZ01E
93 C672 2203-000438 "C-CERAMIC,CHIP;C102K,1NF,50V" GRP155R71H102KA01E
94 C680 2203-005234 "C-CERAMIC,CHIP;C1R2C,1.2PF,50V" CL05C1R2CBNC
95 C701 2203-001101 "C-CERAMIC,CHIP;C682K,6.8NF,25V" GRP155R71E682KA01E
96 D100 0401-001033 "DIODE-SWITCHING;MCL4154,25V,200mA" MCL4154
97 F200 2901-001116 "FILTER-EMI SMD;50V,0.3A,-,470PF,2" NFM21CC471R1H3D
98 F201 2901-001116 "FILTER-EMI SMD;50V,0.3A,-,470PF,2" NFM21CC471R1H3D
99 F203 2901-001116 "FILTER-EMI SMD;50V,0.3A,-,470PF,2" NFM21CC471R1H3D
100 L200 2703-001752 INDUCTOR-SMD;LL1005-FH39NJ LL1005-FH39NJ
101 L500 2703-001752 INDUCTOR-SMD;LL1005-FH39NJ LL1005-FH39NJ
102 L604 2703-002201 INDUCTOR-SMD;CIH05T33NJNC CIH05T33NJNC
103 L624 2703-001206 INDUCTOR-SMD;LL1608-FH4N7S LL1608-FH4N7S
104 LED201 0601-001543 LED;HL500-F01-SS HL500-F01-SS
105 OSC401 2801-004112 "CRYSTAL-SMD;19.68MHZ,10PPM,28-ACF" TSX-8A
106 OSC500 2801-004025 "CRYSTAL-UNIT;0.032768MHz,20ppm,28" FC-255
107 Q200 0504-001012 TR-SMALL SIGNAL;DTC114YE DTC114YE
108 Q201 0501-002011 TR-SMALL SIGNAL;2SD2114KT146V 2SD2114KT146V
109 Q202 0504-001012 TR-SMALL SIGNAL;DTC114YE DTC114YE
110 Q203 0504-001012 TR-SMALL SIGNAL;DTC114YE DTC114YE
111 Q400 0501-000162 TR-SMALL SIGNAL;2SA1576FRT106 2SA1576A-R-T106
112 Q600 0504-001058 TR-SMALL SIGNAL;RN4985-TE85L RN4985-TE85L
113 Q601 0504-001058 TR-SMALL SIGNAL;RN4985-TE85L RN4985-TE85L
114 Q603 0504-001012 TR-SMALL SIGNAL;DTC114YE DTC114YE
115 Q650 0504-001042 TR-SMALL SIGNAL;BCR10PN BCR10PN
116 R100 2007-000157 "R-CHIP;47K,5%" RC1005J473CS
117 R101 2007-000140 "R-CHIP;1K,5%" RC1005J102CS
118 R202 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
119 R203 2007-000172 "R-CHIP;10,5%" RC1005J100CS
120 R204 2007-000172 "R-CHIP;10,5%" RC1005J100CS
121 R205 2011-001344 "R-NETWORK;100ohm,5%,1/16W,L,CHIP," EXB28V101JX
122 R206 2007-000138 "R-CHIP;100,5%" RC1005J101CS
3-3 Electrical Parts List
NO Reference SEC Code Part Description Vendor Part No
123 R207 2011-001344 "R-NETWORK;100ohm,5%,1/16W,L,CHIP," EXB28V101JX
124 R208 2007-000170 "R-CHIP;1M,5%" RC1005J105CS
125 R209 2007-000566 "R-CHIP;220K,5%" RC1005J224CS
126 R210 2007-000138 "R-CHIP;100,5%" RC1005J101CS
127 R211 2007-001301 "R-CHIP;68,5%" RC1005J680CS
128 R212 2007-000139 "R-CHIP;220,5%" RC1005J221CS
129 R213 2007-000172 "R-CHIP;10,5%" RC1005J100CS
130 R214 2007-000172 "R-CHIP;10,5%" RC1005J100CS
131 R215 2007-000140 "R-CHIP;1K,5%" RC1005J102CS
132 R217 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
133 R400 2007-000148 "R-CHIP;10K,5%" RC1005J103CS
134 R401 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
135 R403 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
136 R404 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
137 R405 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
138 R406 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
139 R407 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
140 R409 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
141 R412 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
142 R422 2007-000170 "R-CHIP;1M,5%" RC1005J105CS
143 R423 2007-001119 "R-CHIP;680,5%" RC1005J681CS
144 R432 2007-001325 "R-CHIP;3.3K,5%" RC1005J332CS
145 R438 2007-000775 "R-CHIP;33K,5%" RC1005J333CS
146 R439 2007-007090 "R-CHIP;11K,5%" ERJ2GEJ113X
147 R440 2007-001244 "R-CHIP;91K,5%" RC1005J913CS
148 R500 2007-007317 "R-CHIP;2.2K,1%" MCR01MZSF2201
149 R501 2007-007317 "R-CHIP;2.2K,1%" MCR01MZSF2201
150 R502 2007-007317 "R-CHIP;2.2K,1%" MCR01MZSF2201
151 R503 2007-007317 "R-CHIP;2.2K,1%" MCR01MZSF2201
152 R504 2007-007318 "R-CHIP;1K,1%" RK73H1ETP1001F
153 R506 2007-007318 "R-CHIP;1K,1%" RK73H1ETP1001F
154 R507 2007-007318 "R-CHIP;1K,1%" RK73H1ETP1001F
155 R508 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
156 R509 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
157 R510 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
158 R511 2007-007318 "R-CHIP;1K,1%" RK73H1ETP1001F
159 R512 2007-000157 "R-CHIP;47K,5%" RC1005J473CS
160 R513 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
161 R514 2007-000148 "R-CHIP;10K,5%" RC1005J103CS
162 R518 2007-000148 "R-CHIP;10K,5%" RC1005J103CS
163 R519 2007-000148 "R-CHIP;10K,5%" RC1005J103CS
164 R520 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
Electrical Parts List 3-4
NO Reference SEC Code Part Description Vendor Part No
165 R521 2007-000152 "R-CHIP;20K,5%" RC1005J203CS
166 R523 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
167 R524 2007-000157 "R-CHIP;47K,5%" RC1005J473CS
168 R525 2007-000139 "R-CHIP;220,5%" RC1005J221CS
169 R526 2007-000168 "R-CHIP;470K,5%" RC1005J474CS
170 R527 2007-002796 "R-CHIP;510,5%" MCR01MZSJ511
171 R528 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
172 R529 2007-000157 "R-CHIP;47K,5%" RC1005J473CS
173 R530 2007-002796 "R-CHIP;510,5%" MCR01MZSJ511
174 R531 2007-000139 "R-CHIP;220,5%" RC1005J221CS
175 R532 2007-000141 "R-CHIP;2.2K,5%" RC1005J222CS
176 R533 2007-000141 "R-CHIP;2.2K,5%" RC1005J222CS
177 R535 2007-000148 "R-CHIP;10K,5%" RC1005J103CS
178 R536 2007-000148 "R-CHIP;10K,5%" RC1005J103CS
179 R538 2007-007981 "R-CHIP;180K,1%" ERJ2RKF1803X
180 R540 2011-001345 "R-NETWORK;10Kohm,5%,1/16W,L,CHIP," EXB28V103JX
181 R541 2007-007488 "R-CHIP;75K,1%" MCR01MZSF7502
182 R542 2007-000170 "R-CHIP;1M,5%" RC1005J105CS
183 R543 2007-007771 "R-CHIP;0,5%" RC1005J000CS
184 R544 2007-000170 "R-CHIP;1M,5%" RC1005J105CS
185 R545 2007-000169 "R-CHIP;510K,5%" RC1005J514CS
186 R547 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
187 R587 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
188 R590 2007-000148 "R-CHIP;10K,5%" RC1005J103CS
189 R599 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
190 R617 2007-007698 "R-CHIP;5.1K,1%" MCR01MZSF5101
191 R618 2007-007142 "R-CHIP;10K,1%" RK73H1ETP1002F
192 R619 2007-007142 "R-CHIP;10K,1%" RK73H1ETP1002F
193 R622 2007-001311 "R-CHIP;270,5%" RC1005J271CS
194 R623 2007-007311 "R-CHIP;22K,1%" MCR01MZSF2202
195 R625 2007-001301 "R-CHIP;68,5%" RC1005J680CS
196 R626 2007-001301 "R-CHIP;68,5%" RC1005J680CS
197 R628 2007-007307 "R-CHIP;150,1%" MCR01MZSF1500
198 R629 2007-007142 "R-CHIP;10K,1%" RK73H1ETP1002F
199 R630 2007-001301 "R-CHIP;68,5%" RC1005J680CS
200 R631 2007-001301 "R-CHIP;68,5%" RC1005J680CS
201 R634 2007-000148 "R-CHIP;10K,5%" RC1005J103CS
202 R639 2007-000148 "R-CHIP;10K,5%" RC1005J103CS
203 R641 2007-000148 "R-CHIP;10K,5%" RC1005J103CS
204 U100 1203-002077 IC;LP2985AIM5-3.3 LP2985AIM5-3.3
205 U200 0504-001058 TR-SMALL SIGNAL;RN4985-TE85L RN4985-TE85L
206 U401 0801-002540 IC;NC7SZ19P6X NC7SZ19P6X
3-5 Electrical Parts List
NO Reference SEC Code Part Description Vendor Part No
207 U410 1109-001204 IC;LRS1383 LRS1383
208 U413 0801-002727 "IC-CMOS LOGIC;27WZ04,INVERTER,SOT" NL27WZ04DFT2
209 U430 1204-001811 IC;YMU759-QE2 YMU759-QE2
210 U501 1205-001881 "IC-COMM. CONTROLLER;VP40575,BGA,1" VP40575
211 U502 1001-001145 IC;MAX4599EXT-T DG9411DL
212 U506 1202-001036 IC;TC75W56FK-TE12L TC75W56FK-TE12L
213 U520 1103-001262 IC;AT24C512C1-10CI-2.7 AT24C512C1-10CI-2.7
214 U611 1209-001354 "IC-ETC, LINEAR;HD155173NPEL,QFP,2" HD155173NPSEL
215 U635 0505-001423 TR-SMALL SIGNAL;FDG6323L FDG6323L
216 V500 1405-001082 "VARISTOR;5.6V,20A,1x0.5x0.6mm,TP" VC040205X150R
217 V507 1405-001082 "VARISTOR;5.6V,20A,1x0.5x0.6mm,TP" VC040205X150R
218 V508 1405-001082 "VARISTOR;5.6V,20A,1x0.5x0.6mm,TP" VC040205X150R
219 V509 1405-001082 "VARISTOR;5.6V,20A,1x0.5x0.6mm,TP" VC040205X150R
Electrical Parts List 3-6
3-2 Main Parts List Bottom
NO Reference SEC Code Part Description Vendor Part No
1 A1 GH61-00026A "SPRING ETC-ANT.CONTACT;SGH-N620,B" -
2 C105 2404-001105 "C-TA,CHIP;10UF/6.3V" TCSCS0J106MPAR
3 C106 2203-005061 "C-CERAMIC,CHIP;C104Z,100NF,16V" CL05F104ZONC
4 C107 2203-005065 "C-CERAMIC,CHIP;C105Z,1UF,10V" CL10F105ZPNC
5 C108 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
6 C109 2404-001105 "C-TA,CHIP;10UF/6.3V" TCSCS0J106MPAR
7 C110 2203-005061 "C-CERAMIC,CHIP;C104Z,100NF,16V" CL05F104ZONC
8 C111 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
9 C112 2404-001105 "C-TA,CHIP;10UF/6.3V" TCSCS0J106MPAR
10 C113 2404-001239 "C-TA,CHIP;100UF/6.3V" F950J107MBAAQ2
11 C114 2404-001105 "C-TA,CHIP;10UF/6.3V" TCSCS0J106MPAR
12 C115 2404-001239 "C-TA,CHIP;100UF/6.3V" F950J107MBAAQ2
13 C116 2203-005065 "C-CERAMIC,CHIP;C105Z,1UF,10V" CL10F105ZPNC
14 C117 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
15 C118 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
16 C119 2404-001105 "C-TA,CHIP;10UF/6.3V" TCSCS0J106MPAR
17 C120 2203-005061 "C-CERAMIC,CHIP;C104Z,100NF,16V" CL05F104ZONC
18 C121 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
19 C122 2203-005065 "C-CERAMIC,CHIP;C105Z,1UF,10V" CL10F105ZPNC
20 C123 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
21 C124 2404-001105 "C-TA,CHIP;10UF/6.3V" TCSCS0J106MPAR
22 C125 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
23 C126 2404-001231 "C-TA,CHIP;47UH/6.3V" 595D476X06R3A2T
24 C127 2203-005065 "C-CERAMIC,CHIP;C105Z,1UF,10V" CL10F105ZPNC
25 C128 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
26 C190 2203-005065 "C-CERAMIC,CHIP;C105Z,1UF,10V" CL10F105ZPNC
27 C200 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
28 C201 2203-001153 "C-CERAMIC,CHIP;C680J,68PF,50V" GRP1555C1H680JD01E
29 C217 2203-005061 "C-CERAMIC,CHIP;C104Z,100NF,16V" CL05F104ZONC
30 C300 2203-005061 "C-CERAMIC,CHIP;C104Z,100NF,16V" CL05F104ZONC
31 C302 2203-005061 "C-CERAMIC,CHIP;100nF,+80-20%,16V," CL05F104ZONC
32 C306 2203-005061 "C-CERAMIC,CHIP;C104Z,100NF,16V" CL05F104ZONC
33 C316 2404-001020 "C-TA,CHIP;10UF/10V" T491A106M010AS
34 C317 2404-001105 "C-TA,CHIP;10UF/6.3V" TCSCS0J106MPAR
35 C318 2203-005061 "C-CERAMIC,CHIP;C104Z,100NF,16V" CL05F104ZONC
36 C320 2203-005065 "C-CERAMIC,CHIP;C105Z,1UF,10V" CL10F105ZPNC
37 C491 2203-005065 "C-CERAMIC,CHIP;C105Z,1UF,10V" CL10F105ZPNC
38 C492 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
39 C533 2203-005444 "C-CERAMIC,CHIP;C030B,3PF,50V" GRP1555C1H3R0BZ01E
40 C534 2203-000330 "C-CERAMIC,CHIP;C120J,12PF,50V" GRP1555C1H120JZ01E
41 C554 2203-000330 "C-CERAMIC,CHIP;C120J,12PF,50V" GRP1555C1H120JZ01E
42 C555 2203-005444 "C-CERAMIC,CHIP;C030B,3PF,50V" GRP1555C1H3R0BZ01E
3-7 Electrical Parts List
NO Reference SEC Code Part Description Vendor Part No
43 C600 2203-000438 "C-CERAMIC,CHIP;C102K,1NF,50V" GRP155R71H102KA01E
44 C601 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
45 C602 2203-000278 "C-CERAMIC,CHIP;C100D,10PF,50V" GRP1555C1H100JZ01E
46 C604 2203-001259 "C-CERAMIC,CHIP;C080D,8PF,50V" GRP1555C1H8R0DZ01E
47 C605 2203-005055 "C-CERAMIC,CHIP;C5R6C,5.6PF,50V" GRP1555C1H5R6CZ01E
48 C607 2203-000278 "C-CERAMIC,CHIP;C100D,10PF,50V" GRP1555C1H100JZ01E
49 C608 2203-000233 "C-CERAMIC,CHIP;C101J,100PF,50V" GRP1555C1H101JD01E
50 C609 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
51 C611 2203-000995 "C-CERAMIC,CHIP;C470J,47PF,50V" GRP1555C1H470JZ01E
52 C612 2203-001259 "C-CERAMIC,CHIP;C080D,8PF,50V" GRP1555C1H8R0DZ01E
53 C615 2203-000438 "C-CERAMIC,CHIP;C102K,1NF,50V" GRP155R71H102KA01E
54 C618 2203-000654 "C-CERAMIC,CHIP;C271K,270PF,50V" GRP155R71H271KD01E
55 C619 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
56 C620 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
57 C621 2203-000278 "C-CERAMIC,CHIP;C100D,10PF,50V" GRP1555C1H100JZ01E
58 C622 2203-000438 "C-CERAMIC,CHIP;C102K,1NF,50V" GRP155R71H102KA01E
59 C623 2203-000233 "C-CERAMIC,CHIP;C101J,100PF,50V" GRP1555C1H101JD01E
60 C624 2203-000233 "C-CERAMIC,CHIP;C101J,100PF,50V" GRP1555C1H101JD01E
61 C625 2203-005053 "C-CERAMIC,CHIP;C3R9C,3.9PF,50V" CL05C3R9CBNC
62 C627 2203-000438 "C-CERAMIC,CHIP;C102K,1NF,50V" GRP155R71H102KA01E
63 C630 2203-000359 "C-CERAMIC,CHIP;C151J,150PF,50V" GRP1555C1H151JD01E
64 C631 2203-000654 "C-CERAMIC,CHIP;C271K,270PF,50V" GRP155R71H271KD01E
65 C632 2203-000438 "C-CERAMIC,CHIP;C102K,1NF,50V" GRP155R71H102KA01E
66 C635 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
67 C636 2203-000438 "C-CERAMIC,CHIP;C102K,1NF,50V" GRP155R71H102KA01E
68 C636 2203-000812 "C-CERAMIC,CHIP;C330J,33PF,50V" GRP1555C1H330JZ01E
69 C637 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
70 C638 2203-000438 "C-CERAMIC,CHIP;C102K,1NF,50V" GRP155R71H102KA01E
71 C639 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
72 C640 2203-000812 "C-CERAMIC,CHIP;C330J,33PF,50V" GRP1555C1H330JZ01E
73 C641 2404-001105 "C-TA,CHIP;10UF/6.3V" TCSCS0J106MPAR
74 C643 2203-000233 "C-CERAMIC,CHIP;C101J,100PF,50V" GRP1555C1H101JD01E
75 C644 2404-001280 "C-TA,CHIP;220UF/6.3V" F750J227MUCGZT
76 C645 2203-000438 "C-CERAMIC,CHIP;C102K,1NF,50V" GRP155R71H102KA01E
77 C646 2203-005050 "C-CERAMIC,CHIP;C1R8C,1.8PF,50V" GRP1555C1H1R8CZ01E
78 C648 2203-000438 "C-CERAMIC,CHIP;C102K,1NF,50V" GRP155R71H102KA01E
79 C649 2404-001101 "C-TA,CHIP;1UF/16V" TAJR105M016R
80 C650 2203-000438 "C-CERAMIC,CHIP;C102K,1NF,50V" GRP155R71H102KA01E
81 C651 2203-000812 "C-CERAMIC,CHIP;C330J,33PF,50V" GRP1555C1H330JZ01E
82 C652 2203-002443 "C-CERAMIC,CHIP;C331K,330PF,50V" CL05B331KBNC
83 C653 2301-001197 "C-FILM,CHIP;0.39nF,5%,50V,TP,2x1." ECHU1H391JX5
84 C654 2301-001213 "C-FILM,CHIP;6.8nF,5%,16V,TP,2012," ECHU1C682JX5
Electrical Parts List 3-8
NO Reference SEC Code Part Description Vendor Part No
85 C655 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
86 C658 2203-000812 "C-CERAMIC,CHIP;C330J,33PF,50V" GRP1555C1H330JZ01E
87 C662 2203-002525 "C-CERAMIC,CHIP;C561K,560PF,50V" GRP155R71H561KD01E
88 C664 2203-000233 "C-CERAMIC,CHIP;C101J,100PF,50V" GRP1555C1H101JD01E
89 C665 2203-000233 "C-CERAMIC,CHIP;C101J,100PF,50V" GRP1555C1H101JD01E
90 C669 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
91 C670 2203-002525 "C-CERAMIC,CHIP;C561K,560PF,50V" GRP155R71H561KD01E
92 C671 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
93 C673 2203-002525 "C-CERAMIC,CHIP;C561K,560PF,50V" GRP155R71H561KD01E
94 C674 2203-000254 "C-CERAMIC,CHIP;C103K,10NF,16V" GRP155R71C103KA01E
95 C675 2203-000233 "C-CERAMIC,CHIP;C101J,100PF,50V" GRP1555C1H101JD01E
96 C676 2203-000233 "C-CERAMIC,CHIP;C101J,100PF,50V" GRP1555C1H101JD01E
97 C677 2203-000233 "C-CERAMIC,CHIP;C101J,100PF,50V" GRP1555C1H101JD01E
98 C678 2203-000233 "C-CERAMIC,CHIP;C101J,100PF,50V" GRP1555C1H101JD01E
99 C679 2203-000679 "C-CERAMIC,CHIP;C270J,27PF,50V" GRP1555C1H270JZ01E
100 C700 2203-000330 "C-CERAMIC,CHIP;C120J,12PF,50V" GRP1555C1H120JZ01E
101 C702 2203-000278 "C-CERAMIC,CHIP;C100D,10PF,50V" GRP1555C1H100JZ01E
102 CN2 3710-001105 CONNECTOR;24-8005-002-000-867 24-8005-002-000-867
103 CN211 3711-004937 CONNECTOR;AXK6F14335J AXK6F14335J
104 CN220 3710-001595 CONNECTOR;1004-0018-304 1004-0018-304
105 CN3 3710-001105 CONNECTOR;24-8005-002-000-867 24-8005-002-000-867
106 CN310 3709-001177 CONNECTOR;ID1AS1-6S-2.54SFD ID1AS1-6S-2.54SFD
107 CN501 3722-001715 "JACK-PHONE;6P,2.3PI,AU,BLK,-" 02-828P0-53BKA
108 D300 0407-001007 "DIODE-ARRAY;UMN1,80V,25mA,CA4-2,U" UMN1
109 L600 2703-001669 INDUCTOR-SMD;0603CS-72NXJBC 0603CS-72NXJBC
110 L601 2703-001669 INDUCTOR-SMD;0603CS-72NXJBC 0603CS-72NXJBC
111 L602 2703-002201 INDUCTOR-SMD;CIH05T33NJNC CIH05T33NJNC
112 L603 2703-001514 INDUCTOR-SMD;0603CS-68NXJBC 0603CS-68NXJBC
113 L605 2703-002268 INDUCTOR-SMD;CIH05T8N2JNC CIH05T8N2JNC
114 L606 2703-002204 INDUCTOR-SMD;CIH05T22NJNC CIH05T22NJNC
115 L607 2703-002281 INDUCTOR-SMD;CIH05T5N6SNC CIH05T5N6SNC
116 L608 2703-002170 INDUCTOR-SMD;CIH05T6N8JNC CIH05T6N8JNC
117 L609 2703-002201 INDUCTOR-SMD;CIH05T33NJNC CIH05T33NJNC
118 L612 2703-001685 INDUCTOR-SMD;0603CS-82NXJBC 0603CS-82NXJBC
119 L615 2703-002170 INDUCTOR-SMD;CIH05T6N8JNC CIH05T6N8JNC
120 L616 2703-002170 INDUCTOR-SMD;CIH05T6N8JNC CIH05T6N8JNC
121 L618 2703-002207 INDUCTOR-SMD;CIH05T3N3SNC CIH05T3N3SNC
122 L622 2703-002198 INDUCTOR-SMD;CIH05T10NJNC CIH05T10NJNC
123 L623 2703-002208 INDUCTOR-SMD;CIH05T2N2SNC CIH05T2N2SNC
124 M100 4302-001119 "BATTERY-LI(2ND);3V,0.1MAH,-,-,3.1" ML414R-TT30
125 Q300 0506-001004 "TR-ARRAY;UMC5N,NPN/PNP,2,50V,-,-1" UMC5NTR
126 Q303 0501-002346 TR-SMALL SIGNAL;2SB1427-E-T100 2SB1427-E-T100
3-9 Electrical Parts List
NO Reference SEC Code Part Description Vendor Part No
127 Q604 0501-000225 TR-SMALL SIGNAL;2SC4617 2SC4617R
128 R102 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
129 R103 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
130 R104 2007-000140 "R-CHIP;1K,5%" RC1005J102CS
131 R105 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
132 R107 2007-000140 "R-CHIP;1K,5%" RC1005J102CS
133 R108 2007-000140 "R-CHIP;1K,5%" RC1005J102CS
134 R300 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
135 R301 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
136 R302 2007-000148 "R-CHIP;10K,5%" RC1005J103CS
137 R303 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
138 R304 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
139 R305 2007-000162 "R-CHIP;100K,5%" RC1005J104CS
140 R306 2007-000148 "R-CHIP;10K,5%" RC1005J103CS
141 R307 2007-000159 "R-CHIP;56K,5%" RC1005J563CS
142 R320 2007-007590 "R-CHIP;82K,1%" MCR01MZSF8202
143 R323 2007-007107 "R-CHIP;100K,1%" RK73H1ETP1003F
144 R328 2007-008117 "R-CHIP;2.7K,1%" RK73H1ETP2701F
145 R492 2007-000143 "R-CHIP;4.7K,5%" RC1005J472CS
146 R546 2007-007317 "R-CHIP;2.2K,1%" MCR01MZSF2201
147 R602 2007-001298 "R-CHIP;51,5%" RC1005J510CS
148 R604 2007-000172 "R-CHIP;10,5%" RC1005J100CS
149 R605 2007-001298 "R-CHIP;51,5%" RC1005J510CS
150 R606 2007-001335 "R-CHIP;36K,5%" RC1005J363CS
151 R607 2007-000139 "R-CHIP;220,5%" RC1005J221CS
152 R608 2007-000139 "R-CHIP;220,5%" RC1005J221CS
153 R609 2007-001290 "R-CHIP;24,5%" RC1005J240CS
154 R610 2007-000138 "R-CHIP;100,5%" RC1005J101CS
155 R611 2007-001290 "R-CHIP;24,5%" RC1005J240CS
156 R612 2007-001301 "R-CHIP;68,5%" RC1005J680CS
157 R613 2007-000139 "R-CHIP;220,5%" RC1005J221CS
158 R614 2007-000139 "R-CHIP;220,5%" RC1005J221CS
159 R615 2007-000138 "R-CHIP;100,5%" RC1005J101CS
160 R616 2007-000138 "R-CHIP;100,5%" RC1005J101CS
161 R621 2007-000174 "R-CHIP;47,5%" RC1005J470CS
162 R624 2007-000148 "R-CHIP;10K,5%" RC1005J103CS
163 R632 2007-000140 "R-CHIP;1K,5%" RC1005J102CS
164 R633 2007-000148 "R-CHIP;10K,5%" RC1005J103CS
165 R635 2007-000140 "R-CHIP;1K,5%" RC1005J102CS
166 R636 2007-007529 "R-CHIP;91K,1%" MCR01MZSF9102
167 R637 2007-000172 "R-CHIP;10,5%" RC1005J100CS
168 R638 2007-001333 "R-CHIP;18K,5%" RC1005J183CS
Electrical Parts List 3-10
NO Reference SEC Code Part Description Vendor Part No
169 R642 2011-001264 "R-NETWORK;10ohm,5%,1/16W,L,CHIP,8" EXB28V100J
170 R643 2007-001319 "R-CHIP;1.2K,5%" MCR01MZSJ122
171 R644 2007-000172 "R-CHIP;10,5%" RC1005J100CS
172 SW1 3404-001152 "SWITCH-TACT;12V DC,20mA,160gf,4.5" LS10N2-T
173 SW2 3404-001152 "SWITCH-TACT;12V DC,20mA,160gf,4.5" LS10N2-T
174 TH300 1404-001005 "THERMISTOR-NTC;47Kohm,5%,4050K,2." NCP21WB473J03RA
175 U102 1203-002076 IC;LP2985AIM5-3.0 LP2985AIM5-3.0
176 U103 1203-001701 IC;LP2982AIM5X-3.0 LP2982AIM5X-3.0
177 U104 0505-001423 TR-SMALL SIGNAL;FDG6323L FDG6323L
178 U105 1203-002076 IC;LP2985AIM5-3.0 LP2985AIM5-3.0
179 U106 0505-001376 TR-SMALL SIGNAL;FDC6329L FDC6329L
180 U110 1203-002076 IC;LP2985AIM5-3.0 LP2985AIM5-3.0
181 U111 0505-001423 TR-SMALL SIGNAL;FDG6323L FDG6323L
182 U300 0505-001423 TR-SMALL SIGNAL;FDG6323L FDG6323L
183 U303 1203-002127 IC;LTC1734ES6-4.2#TR LTC1734ES6-4.2#TR
184 U420 1003-001440 IC;MDC3105LT1 MDC3105LT1
185 U580 1203-001511 IC;MAX809REUR-T MAX809REUR-T
186 U600 3705-001242 CONNECTOR;CRS5001-1702 CRS5001-1702
187 U601 2903-001266 "FILTER-DIELECTRIC;BP,225MHz,-,9dB" SAFCJ225MRA0X01R11
188 U602 2909-001164 "FILTER-DUPLEXER;1.99GHZ,1.85GHZ,1" LMG002S-5029A
189 U604 2904-001389 "FILTER-SAW;1.96GHZ,75MHZ,925-960M" WG60AR0
190 U605 1205-001935 IC;HD155128TF HD155128TFSEB
191 U607 4709-001214 "COUPLER-DIRECTION;880-915MHz,19.5" DCS214E-0897
192 U608 1201-001864 IC;PF08123B-TB PF08123B-TB
193 U609 4709-001243 "COUPLER-DIRECTION;1850-1910MHZ,14" DCS214A-1880
194 U610 NEW-IC001 OSCILLATOR-VCO;VOD1880C29KRB VOD1880C29KRB
195 U612 1209-001337 "IC-PLL/SYNTHESISER;SI4133G-XM2R,L" SI4133G-XM2R
196 U613 2809-001255 OSCILLATOR;TCO-9133S(13MHZ) TCO-9133S(13MHZ)
197 U634 2904-001389 "FILTER-SAW;1.96GHZ,75MHZ,925-960M" WG60AR0
198 V200 1405-001110 "VARISTOR;18V,20A,1X0.5X0.6MM,TP" AVLC 14S 02 050
199 V201 1405-001110 "VARISTOR;18V,20A,1X0.5X0.6MM,TP" AVLC 14S 02 050
200 V2010 1405-001093 "VARISTOR;14V,20A,1x0.5x0.6mm,TP" VC040214X300
201 V202 1405-001110 "VARISTOR;18V,20A,1X0.5X0.6MM,TP" AVLC 14S 02 050
202 V203 1405-001110 "VARISTOR;18V,20A,1X0.5X0.6MM,TP" AVLC 14S 02 050
203 V204 1405-001110 "VARISTOR;18V,20A,1X0.5X0.6MM,TP" AVLC 14S 02 050
204 V205 1405-001082 "VARISTOR;5.6V,20A,1x0.5x0.6mm,TP" VC040205X150R
205 V206 1405-001110 "VARISTOR;18V,20A,1X0.5X0.6MM,TP" AVLC 14S 02 050
206 V207 1405-001110 "VARISTOR;18V,20A,1X0.5X0.6MM,TP" AVLC 14S 02 050
207 V208 1405-001110 "VARISTOR;18V,20A,1X0.5X0.6MM,TP" AVLC 14S 02 050
208 V209 1405-001093 "VARISTOR;14V,20A,1x0.5x0.6mm,TP" VC040214X300
209 V211 1405-001110 "VARISTOR;18V,20A,1X0.5X0.6MM,TP" AVLC 14S 02 050
210 V212 1405-001093 "VARISTOR;14V,20A,1x0.5x0.6mm,TP" VC040214X300
3-11 Electrical Parts List
NO Reference SEC Code Part Description Vendor Part No
211 V213 1405-001093 "VARISTOR;14V,20A,1x0.5x0.6mm,TP" VC040214X300
212 V400 1405-001082 "VARISTOR;5.6V,20A,1x0.5x0.6mm,TP" VC040205X150R
213 V401 1405-001082 "VARISTOR;5.6V,20A,1x0.5x0.6mm,TP" VC040205X150R
214 V402 1405-001082 "VARISTOR;5.6V,20A,1x0.5x0.6mm,TP" VC040205X150R
215 V501 1405-001082 "VARISTOR;5.6V,20A,1x0.5x0.6mm,TP" VC040205X150R
216 V502 1405-001082 "VARISTOR;5.6V,20A,1x0.5x0.6mm,TP" VC040205X150R
217 V503 1405-001082 "VARISTOR;5.6V,20A,1x0.5x0.6mm,TP" VC040205X150R
218 V504 1405-001082 "VARISTOR;5.6V,20A,1x0.5x0.6mm,TP" VC040205X150R
219 V505 1405-001082 "VARISTOR;5.6V,20A,1x0.5x0.6mm,TP" VC040205X150R
220 V506 1405-001082 "VARISTOR;5.6V,20A,1x0.5x0.6mm,TP" VC040205X150R
221 ZD202 0406-001121 "DIODE-TVS;SMF05C,6/-/-V,100W,SC-7" SMF05C
222 ZD203 0406-001121 "DIODE-TVS;SMF05C,6/-/-V,100W,SC-7" SMF05C
Electrical Parts List 3-12
4-1
SIM CARD
BB INTERFACE
Serial Data
Interface
Battery
Type
I/O
Interface
4-1 Main Base Band
MIC Battery
Voltage
4. Block Diagrams
SPEAKER A/D Temperature
ONE C Interface
Charging
Current
RF INTERFACE
SYSTEM CLOCK
(13MHz)
AGC,AFC 3VTXRX
YMU
XVCC
PLL
VIBRATOR
LED 3V3
Li-Ion Battery
(Standard)
SRAM
RTC VCC
EEPROM AVcc LDO
Load S/W
Charging
RTC_CLOCK Circuit
(32.768KHz) Vcc LDO
KEY_BOARD
LCD
Block Diagrams
SGH-N620 RF Block Diagram
Block Diagrams
4-2 Main RF
CH 62 : 1172.4MHz
Mixer 1 CH 698 : 1617.4MHz
1805~1880MHz U634
(CH 698 : 1842.4MHz) U601 C630, L612
LNA Mixer 2
IRXP
Dual IF SAW LC IRXN
925~960MHz SAW Filter Filter PGA I&Q Demo.
filter (225MHz) (45MHz) QRXP
(CH 62 : 947.4MHz) QRXN
LNA
45MHz
SCLK
Serial data
Dual SDATA
bias circuit interface
SAW AGC_EN
Filter
(U604)
SI4133-MLP28
(U612) GSM : 1150~1185MHz
DCS : 1580~1655MHz
270MHz
90 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
