Image preview - the first page of the document
>> Download Samsung SGH-C160M service manual documenatation <<
Text preview - extract from the document
GSM TELEPHONE
SGH-C160M
GSM TELEPHONE CONTENTS
1. Safety Precautions
2. Specification
3. Operation Instruction and
Installation
4. Array course control
5. Exploded View/Disassembly
and Assembly Instructions
6. MAIN Electrical Parts List
7. Block Diagrams
8. PCB Diagrams
9. Flow Chart of Troubleshooting
10. Reference data
1. Safety Precautions
1-1. Repair Precaution
Repair in Shield Box, during detailed tuning.
Take specially care of tuning or test, because the specification of cellular phone is sensitive for
surrounding interference(RF noise).
Be careful to use a kind of magnetic object or tool, because performance of parts is damaged by the
influence of magnetic force.
Surely use a standard screwdriver when you disassemble this product, otherwise screw will be worn
away.
Use a thicken twisted wire when you measure level.
A thicken twisted wire has low resistance, therefore error of measurement is few.
Repair after separate Test Pack and Set because for short danger (for example an
overcurrent and furious flames of parts etc) when you repair board in condition of
connecting Test Pack and tuning on.
Take specially care of soldering, because Land of PCB is small and weak in heat.
Surely tune on/off while using AC power plug, because a repair of battery charger is
dangerous when tuning ON/OFF PBA and Connector after disassembling charger.
Don't use as you pleases after change other material than replacement registered on SEC System.
Otherwise engineer in charge isn't charged with problem that you don't keep this rules.
1-1
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Safety Precautions
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Several semiconductor may be damaged easily by static electricity. Such parts are called by ESD
(Electrostatically Sensitive Devices), for example IC,BGA chip etc. Read Precaution below.
You can prevent from ESD damage by static electricity.
Remove static electricity remained your body before you touch semiconductor or parts with
semiconductor. There are ways that you touch an earthed place or wear static electricity
prevention string on wrist.
Use earthed soldering steel when you connect or disconnect ESD.
Use soldering removing tool to break static electricity. , otherwise ESD will be damaged by
static electricity.
Don't unpack until you set up ESD on product. Because most of ESD are packed by box and
aluminum
plate to have conductive power,they are prevented from static electricity.
You must maintain electric contact between ESD and place due to be set up until ESD is connected
completely to the proper place or a circuit board.
1-2
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
2. Specification
2-1. GSM General Specification
EG SM 900 DCS1800
Fr eq. Band[ MHz] 880 ~915 1710 ~1785
Uplink/Downlink 925 ~960 1805 ~1880
ARFCN rang e 0~124 & 975 ~1023 512 ~885
Tx/ Rx spacing 45 MHz 95 MHz
Mod. Bit rat e/ 270. 833kbps 270. 833kbps
Bi t Pe rio d 3. 692us 3. 692us
T ime Slot Per iod/ Fra me 576 .9us 576 .9us
Period 4.61 5ms 4.61 5ms
Modu lation 0. 3GMSK 0. 3GMSK
MS Power 33dBm~5dBm 30dBm~0dBm
4 1
Power Cl ass
(max +33dBm) (max +30dBm)
Sensitivity - 102d Bm - 100d Bm
T DM A M u x 8 8
Cell Ra dius 35 Km 2 Km
2-1
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Specification
2-2. GSM TX power class
TX Power TX Power
GSM900 DCS1800
control level control level
