Image preview - the first page of the document
>> Download Samsung SGH-D500 service manual documenatation <<Text preview - extract from the document GPRS TELEPHONE
SGH-D500
GPRS TELEPHONE CONTENTS
1. Specification
2. Circuit Description
3. Exploded Views and Parts List
4. Electrical Parts List
5. Block Diagrams
6. PCB Diagrams
7. Flow Chart of Troubleshooting
Samsung Electronics Co.,Ltd. Nov. 2004
This Service Manual is a property of Samsung Electronics Co.,Ltd. Printed in South Korea.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law. Code No.: GH68-05955A
BASIC.
1 . SGH - D 5 0 0 S p e c if ic a t io n
1. GSM General Specification
GS M9 0 0 E GS M 9 0 0 DC S 1 8 0 0
PC S1 9 0 0
Ph a se 1 Ph a se 2 P h as e 1
F r eq . B a n d [M Hz ] 8 9 0 ~9 1 5 8 8 0 ~9 1 5 1 7 1 0 ~1 7 8 5 1 8 5 0 ~1 9 1 0
Up l in k / Do w n li n k 9 3 5 ~9 6 0 9 2 5 ~9 6 0 1 8 0 5 ~1 8 8 0 1 9 3 0 ~1 9 9 0
0~124 &
A RF C N r a n g e 1 ~1 2 4 5 1 2 ~8 8 5 5 1 2 ~8 1 0
9 7 5 ~1 0 2 3
T x /R x s p ac in g 4 5 MHz 4 5 MHz 9 5 M Hz 8 0 MH z
Mod. Bit rate 270.833kbps 2 7 0 .8 3 3 k b p s 270.833kbps 2 7 0 .8 3 3 k b p s
/ Bi t Pe r i o d 3.692us 3 .6 9 2 u s 3.692us 3 .6 9 2 u s
Ti me Sl o t Pe r i o d 576.9us 5 7 6 .9 u s 576.9us 5 7 6 .9 u s
/ F r am e P er io d 4 .6 1 5 m s 4 .6 1 5 m s 4 .6 1 5 m s 4 .6 1 5 ms
Mo d u l a ti o n 0 .3 G MS K 0 .3 G MS K 0 .3 GM SK 0 .3 GM SK
M S P o we r 3 3 d Bm ~5 d B m 3 3 d Bm ~5 d B m 3 0 d B m ~0 d B m 3 0 d B m~0 d B m
Po w er C l as s 5 p cl ~ 1 9 p c l 5pcl ~ 19pcl 0pcl ~ 15pcl 0pcl ~ 15pcl
Se n si t iv i t y -102dBm - 1 0 2 d Bm -100dBm -100dBm
TDM A M u x 8 8 8 8
C el l Ra d iu s 3 5 Km 3 5 Km 2 Km -
1- 1
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Specification
2. GSM TX power class
TX Power TX Power TX Power
GSM900 DCS1800 PCS1900
control level control level control level
5 33
