Image preview - the first page of the document
Samsung SGH-D600E service manual


>> Download Samsung SGH-D600E service manual documenatation <<

Text preview - extract from the document
                GSM TELEPHONE
                SGH-D600E




GSM TELEPHONE                      CONTENTS


                  1.   Specification

                  2.   Circuit Description

                  3.   Exploded Views and Parts List

                  4.   Electrical Parts List

                  5.   Block Diagrams

                  6.   PCB Diagrams
                  7.   Flow Chart of Troubleshooting
This Service Manual is a property of Samsung Electronics Co.,Ltd.  Samsung Electronics Co.,Ltd. October. 2005
Any unauthorized use of Manual can be punished under applicable    Printed in Korea.
International and/or domestic law.

                                                                 Code No.: GH68-08640A
                                                                 BASIC.
1. Specification

1-1. GSM General Specification
                         GSM900               EG SM 900               DCS1800
                                                                                      PCS1900
                         Phas e 1              Ph ase 2               Phas e 1

 Fr eq. Band[MHz]        890~915                880~915              1710~1785        1850~1910
 Uplink/ Downli nk       935~960                925~960              1805~1880        1930~1990

                                               0~124 &
   ARFCN r ange            1~124                                      512~885          512~810
                                               975~1023

  Tx/ Rx s paci ng        45MHz                 45MHz                  95MHz            80MHz


   Mod. Bit r ate      270.833kbps           270.833kbps            270.833kbps      270.833kbps
    / Bit Pe r iod       3.692us               3.692us                3.692us          3.692us


 T ime Slot Period       576.9us                576.9us                576.9us         576.9us
  / F rame Peri od       4.615ms                4.615ms                4.615ms         4.615ms


    Modulati on          0.3GMSK               0.3GMSK                0.3GMSK         0.3GMSK


    MS Power          33dBm~5dBm            33dBm~5dBm             30dBm~0dBm        30dBm~0dBm

   Power Cl a ss       5pcl ~ 19pcl           5pcl ~ 19pcl           0pcl ~ 15pcl     0pcl ~ 15pcl

    Sensit ivit y        - 102dBm              -102dBm                - 100dBm         - 100dBm

    TDMA Mux                  8                     8                      8               8

    Cell Radius            35Km                  35Km                    2Km               -




                                                  1-1
                     SAMSUNG Proprietary-Contents may change without notice
                     This Document can not be used without Samsung's authorization
Specification




1-2. GSM TX power class
      TX Power                          TX Power                             TX Power
                     GSM900                                 DCS1800                         PCS1900
     control level                    control level                         control level

           5         33
