Image preview - the first page of the document

>> Download Samsung SGH-E500 service manual documenatation <<

Text preview - extract from the document

GSM TELEPHONE
SGH-E500

GSM TELEPHONE CONTENTS

1. Safety Precautions
2. Specification

3. Product Function

4. Array course control

5. Exploded View/Disassembly
and Assembly Instructions

6. MAIN Electrical Parts List

7. Block Diagrams

8. PCB Diagrams

9. Flow Chart of Troubleshooting

10. Reference data
CONTENTS

1. Safety Precautions
1-1. Repair Precaution...........................................................................1-1
1-2. ESD(Electrostatically Sensitive Devices) Precaution ..........................1-2

2. Specification
2-1. GSM General Specification .............................................................2-1
2-2. GSM Tx Power Class .....................................................................2-2

3. Product Function

4. Array course control
4-1. Downloading Binary,Tfs Files .........................................................4-2
4-2. Pre-requsite for Downloading .........................................................4-2
4-3. S/W Downloader Program .............................................................4-3

5. Exploded View/Disassembly & Assembly Instructions
5-1. Cellular phone Exploded View.........................................................5-1
5-2. Cellular phone Parts list.................................................................5-2
5-3. Disassembly & Assembly Instructions..............................................5-4

6. MAIN Electrical Parts List

7. Block Diagrams
7-1. RF Solution Block Diagram.............................................................7-1
7-2. Base Band Solution Block Diagram..................................................7-2

8. PCB Diagrams
CONTENTS

9. Flow Chart of Troubleshooting
9-1. Power On......................................................................................9-1
9-2. Initial ..........................................................................................9-4
9-3. Charging Part................................................................................9-6
9-4. Sim Part.......................................................................................9-8
9-5. Microphone Part ..........................................................................9-10
9-6. Speaker Part...............................................................................9-12
9-7. Key Data Input............................................................................9-15
9-8. Receiver Part...............................................................................9-17
9-9. Back Light(for LCD)......................................................................9-19
9-10. Key Back Light...........................................................................9-21
9-11. Camera Part..............................................................................9-22
9-12. BLUETOOTh...............................................................................9-24
9-13. GSM Receiver............................................................................9-26
9-14. GSM Transmitter........................................................................9-29
9-15. DCS Receiver.............................................................................9-31
9-16. DCS Transmitter........................................................................9-33
9-17. PCS Receiver.............................................................................9-35
9-18. PCS Transmitterr........................................................................9-37

10. Reference data
1. Safety Precautions

1-1. Repair Precaution

Repair in Shield Box, during detailed tuning.
Take specially care of tuning or test,
because specificity of cellular phone is sensitive for surrounding interference(RF noise).

Be careful of using any kind of magnetic object or tool,
because performance of parts is damaged by the influence of magnetic force.

Surely use a standard screwdriver when you disassemble this product,
otherwise, screw will be worn away.

Use a thick twisted wire when you measure level.
A thick twisted wire has low resistance, therefore, a chance of measurement error is low.

Repair after separate Test Pack & Set because of short-danger (for example an
overcurrent and furious flames of parts, etc) when you repair board in condition of
connecting Test Pack and tuning on.

Take special care of soldering, because Land of PCB is small and weak in heat.

Surely turn on/off the phone while using AC power plug, because a repair of battery
charger is dangerous when you turn ON/OFF PBA and Connector after disassembling charger.

Don't use as you pleases after change other material than replacement registered on SEC System.
Otherwise engineer in charge isn't charged with problem that you don't keep this rules.

1-1
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Safety Precautions

1-2. ESD(Electrostatically Sensitive Devices) Precaution

Several semiconductor may be damaged easily by static electricity. Such parts are called by ESD
(Electrostatically Sensitive Devices), for example IC,BGA chip etc. Read Precaution below.
You can prevent from ESD damage by static electricity as following:

Remove remaining static electricity on your body before you touch semiconductor or parts with
semiconductor. Please touch an earthed place or wear static electricity
prevention string on wrist.

Use earthed soldering steel when you connect or disconnect ESD.

Use soldering-removing tool to break static electricity ,otherwise ESD will be damaged by
static electricity.

Don't unpack until you set up ESD on product. Because most of ESDs are packed in box and
aluminum plate to have conductive power to avoid static electricity.

You must maintain electric contact between ESD and plate until ESD is connected
completely to the proper place or a circuit board.

1-2
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
2. Specification

2-1. GSM General Specification
GSM 900 GSM 900 DCS 1800 DCS 1800 PCS 1900
Phas e 1 Phas e 2 Phas e 1 Phas e 2

Fr eq.
890~9 15 880~9 15 1710~ 1785 1710~ 1785 1850~ 1910
Band[ MHz]
935~9 60 925~9 60 1805~ 1880 1805~ 1880 1930~ 1990
Uplink/Downlin k

ARFCN r ange 1~12 4 0~124 & 512~ 885 512~ 885 512~ 810
975~1 023

Tx/Rx spa cing 45MHz 45MHz 95MHz 95MHz 80MHz

Mod. Da ta rate/ 270.8 33kbps 270.8 33kbps 270.8 33kbps 270.8 33kbps 270.8 33kbps
Bit Period 3.69 2us 3.69 2us 3.6 92us 3.6 92us 3.6 92us

T im e Sl ot
576. 9us 576. 9us 576. 9us 576. 9us 576. 9us
Period/F rame
4 .615ms 4 .615ms 4.615 ms 4.615 ms 4.615 ms
Pe rio d

Modulatio n 0.3G MSK 0.3G MSK 0.3 GMSK 0.3 GMSK 0.3 GMSK

MS Powe r 33dBm~ 5dBm 33dBm~ 5dBm 30dBm~ 0dBm 30dBm~ 0dBm 30dBm~ 0dBm

Power Co ntr ol 5pcl ~ 1 9pcl 5pcl ~ 19pcl 0pcl ~ 15pcl 0pcl ~ 1 5pcl 0pcl ~ 1 5pcl
level

Sensit ivit y - 102dBm - 102dBm - 100dBm - 100dBm - 100dBm

TDMA Mux 8 8 8 8 8

Cell Radius 35Km 35 km 2km 2km 2km

2-1
Speclflcation

2-2. GSM Tx Power Class

TX Power TX Power TX Power
GSM900 DCS1800 PCS1800
control level control level control level

5 33
