Image preview - the first page of the document
>> Download Samsung SGH-F210 service manual documenatation <<
Text preview - extract from the document
GSM TELEPHONE
SGH-F210
GSM TELEPHONE CONTENTS
1. Safety Precautions
2. Specification
3. Product Function
4. Array course control
5. Exploded View and Parts list
6. MAIN Electrical Parts List
7. Block Diagrams
8. PCB Diagrams
9. Chart of Troubleshooting
10. Reference data
11. Disassembly and Assembly
Instructions
GSPN (Global Service Partner Network)
Country Web Site
North America service.samsungportal.com
Latin America latin.samsungportal.com
CIS cis.samsungportal.com
Europe europe.samsungportal.com
China china.samsungportal.com
Asia asia.samsungportal.com
Mideast & Africa mea.samsungportal.com
This Service Manual is a property of Samsung Electronics Co.,Ltd. Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law. 2007. 09. Rev.1.0
1. Safety Precautions
1-1. Repair Precaution
Repair in Shield Box, during detailed tuning.
Take specially care of tuning or test,
because specipicty of cellular phone is sensitive for surrounding interference(RF noise).
Be careful to use a kind of magnetic object or tool,
because performance of parts is damaged by the influence of manetic force.
Surely use a standard screwdriver when you disassemble this product,
otherwise screw will be worn away.
Use a thicken twisted wire when you measure level.
A thicken twisted wire has low resistance, therefore error of measurement is few.
Repair after separate Test Pack and Set because for short danger (for example an
overcurrent and furious flames of parts etc) when you repair board in condition of
connecting Test Pack and tuning on.
Take specially care of soldering, because Land of PCB is small and weak in heat.
Surely tune on/off while using AC power plug, because a repair of battery charger is
dangerous when tuning ON/OFF PBA and Connector after disassembing charger.
Don't use as you pleases after change other material than replacement registered on SEC
System.
Otherwise engineer in charge isn't charged with problem that you don't keep this rules.
1-1
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Safety Precautions
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Several semiconductor may be damaged easilly by static electricity. Such parts are called by
ESD(Electrostatically Sensitive Devices), for example IC,BGA chip etc. Read Precaution below.
You can prevent from ESD damage by static electricity.
Remove static electricity remained your body before you touch semiconductor or parts with
semiconductor. There are ways that you touch an earthed place or wear static electricity
prevention string on wrist.
Use earthed soldering steel when you connect or disconnect ESD.
Use soldering removing tool to break static electricity. , otherwise ESD will be damaged by
static electricity.
Don't unpack until you set up ESD on product. Because most of ESD are packed by box
and aluminum plate to have conductive power,they are prevented from static electricity.
You must maintain electric contact between ESD and place due to be set up until ESD is
connected completely to the proper place or a circuit board.
1-2
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
2. Specification
2-1. GSM General Specification
E- GSM DCS1800 P C S 19 00
Freq. Ban d [M Hz ] 88 0~9 15 1 71 0~ 1 78 5 1 85 0~ 1 91 0
Upl in k/Downl in k 92 5~9 60 1 80 5~ 1 88 0 1 93 0~ 1 99 0
97 5~ 10 23
A RF C N ra n g e 51 2~8 85 51 2~8 10
0~12 4
Tx/R x sp aci ng 45 MHz 95 MHz 80 MHz
27 0. 83 3K b ps 27 0. 83 3K b ps 27 0. 83 3K b ps
M od . B i t GPRS
3.692us 3.692us 3.692us
rate/
8 12 . 5 K b p s 8 12 . 5 K b p s 8 12 . 5 K b p s
Bi t P eri od EDGE
3.692us 3.692us 3.692us
Ti me S lot P eri od /F ra me 576.9us 576.9us 576.9us
Peri od 4. 61 5ms 4. 61 5ms 4. 61 5ms
GP RS 0. 3GM SK 0. 3GM SK 0. 3GM SK
M od ul a ti on
EDGE 8PSK 8PSK 8PSK
G P RS 3 3d B m ~ 5 d Bm 3 0d B m ~ 0 d Bm 3 0d B m ~ 0 d Bm
MS P ow er
EDGE 26dbm~0dBm 2 6d Bm~0dBm 2 6d Bm~0dBm
G P RS 5~1 9( cl as s4 ) 0~15(class1) 0~15(class1)
Power Level
EDGE 8~ 19 (cl a ss E2) 2~15(class E2) 2~15(class E2)
Sensitivity -102dBm -100 dBm -102dBm
TDM A Mu x 8 8 8
Cell Radius 35Km 2Km 2 Km
Operating Temperature -20 ~ 45 -20 ~ 45 -20 ~ 45
Supply Voltage 3.7V 3.7V 3.7V
