Image preview - the first page of the document
>> Download Samsung SGH-R208 service manual documenatation <<
Text preview - extract from the document
DUAL BAND Mobile
ELECTRONICS
Cellular Phone
SGH-R208
SERVICE Manual
DUAL BAND MOBILE CELLULAR PHONE CONTENTS
1. Exploded Views and Parts List
2. PCB Diagrams
3. Electrical Parts List
4. Block Diagrams
5. Flow Chart of Troubleshooting and
Circuit Diagrams
ELECTRONICS
Samsung Electronics Co.,Ltd.
Printed in Korea
03/2001 Rev 1.0
GH68-02377A
1. Exploded Views and Parts List
1-1 Main
1-2 Main Parts List
1-3 Travel Adapter
1-4 Travel Adapter Parts List
1-5 Ciger Light Adapter
1-6 Ciger Light Adapter Parts List
1-7 Test Jig
1-8 EAR Microphone
1-9 Data Kit
1-10 Battery Charger
2. PCB Diagrams
2-1 Main Top
2-2 Main Bottom
3. Electrical Parts List
3-1 Main Parts List Top
3-2 Main Parts List Bottom
4. Block Diagrams
4-1 Main Baseband
4-2 Main RF
4-2-1 RF Transmit Part
4-2-2 RF Receive Part
5. Flow Chart of Troubleshooting and Circuit Diagrams
5-1 Power ON
5-2 Initial
5-3 Charging Part
5-4 Sim Part
5-5 Microphone Part
5-6 Speaker Part
5-7 Key Data Input
5-8 Alert Tone
5-9 Ring Indicator
5-10 Back Light
5-11 GSM Receiver
5-12 GSM Transmitter
5-13 DCS Receiver
5-14 DCS Transmitter
1. Exploded Views and Parts List
1-1 Main
1-5
1
1-2
1-8
1-1
1-7
1-6
1-3
1-4
2
4
3
5
7-2
6 7-3 8
7-1 7-4
7-5
7
9
10
11
12
Exploded Views and Parts List 1-1
1-2 Main Parts List
SEC CODE
Location No. Description Remark
Navy Blue Gold Dark Silver
1 MEC-FRONT COVER GH75-01439A GH75-01439B GH75-01439C SA
1-1 FRONT COVER GH72-02670A GH72-02670B GH72-02670C SNA
1-2 WINDOW LCD GH72-02672B GH72-02672B GH72-02672B SNA
1-3 FI KEY GH72-03043A GH72-02782A GH72-02782A SA
1-4 MEC-KEYPAD GH75-01164A GH75-01164A GH75-01164A SA
1-5 MEC-DUMMY COVER GH75-01163A GH75-01163A GH75-01163A SNA
1-6 MIC GH59-00240B GH59-00240B GH59-00240B SA
1-7 SPEAKER 3001-001233 3001-001233 3001-001233 SA
1-8 EARPHONE COVER GH73-00757A GH73-00757D GH73-00757E SNA
2 DOME SHEET GH72-02984A GH72-02984A GH72-02984A SA
3 MAIN PBA GH92-01222A GH92-01222A GH92-01222A SA
4 BUZZER 3002-001098 3002-001098 3002-001098 SA
5 DISPLAY LCD GH07-00075B GH07-00075B GH07-00075B SA
6 I/F COVER GH73-00758A GH73-00758E GH73-00758F SA
7 MEC-REAR COVER GH75-01165A GH75-01165D GH75-01165E SA
7-1 REAR COVER GH72-02674A GH72-02674D GH72-02674E SNA
7-2 VIBRATOR GH31-00019A GH31-00019A GH31-00019A SA
7-3 BRACKET-ANT GH71-00505A GH71-00505A GH71-00505A SNA
7-4 SPRING LOCKER GH70-10633A GH70-10633A GH70-10633A SNA
7-5 LOCKER MAIN GH72-02676A GH72-02676D GH72-02676E SNA
8 ANTENNA GH42-00141C GH42-00141E GH42-00141D SA
9 R/F COVER GH73-00759A GH73-00759D GH73-00759E SA
10 SCREW-MACHINE 6001-001542 6001-001542 6001-001542 SA
11 LABEL GH68-02245A GH68-02245A GH68-02245A SA
12 BATTERY GH43-00398A GH43-00398D GH43-00398E SA
1-2 Exploded Views and Parts List
1-3 Travel Adapter
A B
C D
1-4 Travel Adapter Parts List
TYPE SEC CODE REMARK
A GH44-00171A CHINA
B GH44-00184A EUROPE
C GH44-00171C UNITED KINGDOM
D Gh44-00171E TAIWAN
Exploded Views and Parts List 1-3
1-5 Ciger Light Adapter
1-6 Ciger Light Adapter Parts List
DESCRIPTION SEC CODE REMARK
Ciger Light Adapter Code GH44-00170A BLACK
1-4 Exploded Views and Parts List
1-7 Test Jig
TEST JIG GH80-10508A
TEST JIG CABLE GH39-00079A
RF CABLE GH39-00090A
Exploded Views and Parts List 1-5
1-7-1 Test Jig
DC
POWER
SUPPLY
8922 or 8960
WIRELESS COMMUNICATIONS
TEST SET
RF JIG CABLE
TEST JIG CABLE
232 CABLE
Note PC
1-6 Exploded Views and Parts List
1-8 EAR Microphone
EAR MICROPHONE GH59-00168A
1-9 Data Kit
DATA KIT GH39-00078A
1-10 Battery Charger
BATTERY CHAGER GH44-00221B
Exploded Views and Parts List 1-7
2. PCB Diagrams
2-1 Main Top
2-1 PCB Diagrams
2-2 Main Bottom
2-2 PCB Diagrams
3. Electrical Parts List
3-1 Main Parts List Top
NO SEC CODE Reference Part Description Vendor Part No.
1 0401-001033 D441 DIODE-SWITCHING,MCL4154,25V,200mA,M-MELF MCL4154
2 0406-001083 D406 DIODE-TVS,6.1/-/7.2V,150W,SOT-323-5L ESDA6V1W5
3 0406-001083 D407 DIODE-TVS,6.1/-/7.2V,150W,SOT-323-5L ESDA6V1W5
4 0406-001083 D408 DIODE-TVS,6.1/-/7.2V,150W,SOT-323-5L ESDA6V1W5
5 0407-001002 D401 DIODE-ARRAY,DAN222,80V,300mA,CA2-3,EM3 DAN222
6 0407-001007 D304 DIODE-ARRAY,UMN1,80V,25mA,CA4-2,UM5 UMN1
7 0501-000218 Q400 TR-SMALL SIGNAL,2SC4081,NPN,200mW,UMT 2SC4081
8 0501-000225 Q100 TR-SMALL SIGNAL,2SC4617,NPN,200mW,EM3 2SC4617
9 0501-002011 Q403 TR-SMALL SIGNAL,2SD2114K,NPN,200mW,SOT-23 2SD2114KT146V
10 0502-001201 Q405 TR-POWER,ZXT13P20DE6,PNP,1100MW,SOT-23-6 ZXT13P20DE6
11 0504-000167 U615 TR-DIGITAL,RN1102,NPN,100MW,10K/10K DTC114EE/TR
12 0504-001012 Q406 TR-DIGITAL,DTC114YE,NPN,150MW,10K/47K DTC114YE
13 0504-001012 Q407 TR-DIGITAL,DTC114YE,NPN,150MW,10K/47K DTC114YE
14 0504-001012 Q408 TR-DIGITAL,DTC114YE,NPN,150MW,10K/47K DTC114YE
15 0504-001021 U616 TR-DIGITAL,DTB113ZK,PNP,200MW,10K,SC-59 DTB113ZK
16 0504-001058 U465 TR-DIGITAL,RN4985,NPN/PNP,200mW,2.2Kohm RN4985
17 0505-001332 Q401 FET-SILICON,FDG6301,N,25V,0.22A,SC70-6 FDG6301N
18 0505-001376 U474 FET-SILICON,FDC6329L,N/P,8V,2.5A,0.7W,SC-74 SI3865DV
19 0505-001423 Q102 FET-SILICON,FDG6323L,N/P,-,-,-,0.3W,SC70-6 FDG6323L
20 0505-001423 Q402 FET-SILICON,FDG6323L,N/P,-,-,-,0.3W,SC70-6 FDG6323L
21 0506-001004 U309 TR-ARRAY,UMC5N,NPN/PNP,2,50V,-,-100mA,3 UMC5NTR
22 0601-001542 LED3 LED,CHIP,BLUE,1.2X0.8MM,480NM E1S03-AB1A7
23 0601-001542 LED4 LED,CHIP,BLUE,1.2X0.8MM,480NM E1S03-AB1A7
24 0601-001542 LED5 LED,CHIP,BLUE,1.2X0.8MM,480NM E1S03-AB1A7
25 0601-001542 LED6 LED,CHIP,BLUE,1.2X0.8MM,480NM E1S03-AB1A7
26 0801-002540 U452 IC-CMOS LOGIC;NC7SZ19P6X NC7SZ19P6X
27 1103-001185 U617 IC-EEPROM,24A2561,32Kx8Bit,TSSOP,8P S524AD0XF1
28 1106-001326 U464 IC-SRAM,616FU4110,256Kx16Bit,uBGA,48P KM616FU4110CFI-7
29 1107-001304 U466 IC-FLASH MEMORY,AM29DL162,2MX8BIT,48P AM29DL162DT-90WCI
30 1201-001785 U476 IC-POWER AMP,08122,-,8P,-,DUAL,34DB PF08122B-TB
31 1203-001204 U470 IC-VOLTAGE REGULATOR,2981,SOT-23,5P,59MIL LP2981AIM5X-3.3
32 1203-001454 U101 IC-VOLTAGE REGULATOR,2981,SOT-23,5P,59MIL LP2981AIM5X-3.0
33 1203-001454 U102 IC-VOLTAGE REGULATOR,2981,SOT-23,5P,59MIL LP2981AIM5X-3.0
34 1203-001701 U613 IC-VOLTAGE REGULATOR,2982,SOT-23,5P,3.0V LP2982AIM5X-3.0
35 1203-002127 U614 IC-BATTERY,1734,SOT-23,6P,150MIL LTC1734ES6-4.2#TR
36 1203-002128 U619 IC-VOLTAGE REGULATOR,2985,MICRO SMD,5P LP2985AIBPX-3.0
37 1203-002128 U620 IC-VOLTAGE REGULATOR,2985,MICRO SMD,5P LP2985AIBPX-3.0
38 1203-002160 U621 IC-VOLTAGE REGULATOR,2981,SMD,5P,63MIL LP2981AIBPX-3.3
3-1 Electrical Parts List
NO SEC CODE Reference Part Description Vendor Part No.
39 1203-002247 U475 IC-VOL. DETECTOR,S-809,SOT-23-5,5P S-80926ALMP-DAP-T2
40 1205-001881 U618 IC-COMM. CONTROLLER,VP40575,BGA,180P VP40575
41 1205-001935 U454 IC-TRANSCEIVER,HD155128TF,TP,56P,-,-,3V HD155128TF
42 1209-001337 U478 IC-PLL/SYNTHESISER,LCC,28P,3.6V,-40to+85C SI4133-MLP28
43 1404-001005 TH1 THERMISTOR-NTC,47Kohm,5%,4050K,2.0mW/C NTH5G20P40B473J07TE
44 1405-001018 D419 VARISTOR,14V,-,1.6x0.8mm,TP VC060314A300R
45 1405-001018 D420 VARISTOR,14V,-,1.6x0.8mm,TP VC060314A300R
46 1405-001018 D424 VARISTOR,14V,-,1.6x0.8mm,TP VC060314A300R
47 1405-001082 D435 VARISTOR,5.6V,20A,1x0.5x0.6mm VC04025X150R
48 1405-001082 D436 VARISTOR,5.6V,20A,1x0.5x0.6mm VC04025X150R
49 1405-001082 D437 VARISTOR,5.6V,20A,1x0.5x0.6mm VC04025X150R
50 1405-001082 D438 VARISTOR,5.6V,20A,1x0.5x0.6mm VC04025X150R
51 1405-001082 D439 VARISTOR,5.6V,20A,1x0.5x0.6mm VC04025X150R
52 1405-001082 D440 VARISTOR,5.6V,20A,1x0.5x0.6mm VC04025X150R
53 1405-001093 D421 VARISTOR,14V,20A,1x0.5x0.6mm VC040214X500R
54 1405-001093 D422 VARISTOR,14V,20A,1x0.5x0.6mm VC040214X500R
55 1405-001093 D425 VARISTOR,14V,20A,1x0.5x0.6mm VC040214X500R
56 2007-000138 R200 R-CHIP,100ohm,5%,1/16W,DA,TP,1005 RK73K1ETP101J
57 2007-000138 R321 R-CHIP,100ohm,5%,1/16W,DA,TP,1005 RK73K1ETP101J
58 2007-000139 R203 R-CHIP,220ohm,5%,1/16W,DA,TP,1005 RK73K1ETP221J
59 2007-000139 R204 R-CHIP,220ohm,5%,1/16W,DA,TP,1005 RK73K1ETP221J
60 2007-000139 R444 R-CHIP,220ohm,5%,1/16W,DA,TP,1005 RK73K1ETP221J
61 2007-000139 R447 R-CHIP,220ohm,5%,1/16W,DA,TP,1005 RK73K1ETP221J
62 2007-000140 R106 R-CHIP,1Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP102J
63 2007-000140 R107 R-CHIP,1Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP102J
64 2007-000140 R575 R-CHIP,1Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP102J
65 2007-000140 R584 R-CHIP,1Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP102J
66 2007-000140 R738 R-CHIP,1Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP102J
67 2007-000141 R103 R-CHIP,2.2Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP222J
68 2007-000141 R223 R-CHIP,2.2Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP222J
69 2007-000141 R433 R-CHIP,2.2Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP222J
70 2007-000141 R434 R-CHIP,2.2Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP222J
71 2007-000145 R117 R-CHIP,6.2Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP622J
72 2007-000148 R101 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
73 2007-000148 R112 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
74 2007-000148 R313 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
75 2007-000148 R315 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
76 2007-000148 R303 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
77 2007-000148 R348 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
78 2007-000148 R430 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
79 2007-000148 R435 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
80 2007-000148 R438 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
Electrical Parts List 3-2
NO SEC CODE Reference Part Description Vendor Part No.
81 2007-000148 R450 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
82 2007-000148 R461 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
83 2007-000148 R526 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
84 2007-000148 R527 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
85 2007-000148 R535 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
86 2007-000148 R542 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
87 2007-000148 R550 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
88 2007-000148 R554 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
89 2007-000148 R558 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
90 2007-000148 R573 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
91 2007-000148 R604 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
92 2007-000148 R661 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
93 2007-000148 R723 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
94 2007-000152 R429 R-CHIP,20Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP203J
95 2007-000153 R213 R-CHIP,22Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP223J
96 2007-000155 R104 R-CHIP,27Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP273J
97 2007-000157 R441 R-CHIP,47Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP473J
98 2007-000157 R442 R-CHIP,47Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP473J
99 2007-000157 R443 R-CHIP,47Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP473J
100 2007-000159 R656 R-CHIP,56Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP563J
101 2007-000162 R316 R-CHIP,100Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP104J
102 2007-000162 R402 R-CHIP,100Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP104J
103 2007-000162 R432 R-CHIP,100Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP104J
104 2007-000162 R437 R-CHIP,100Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP104J
105 2007-000162 R460 R-CHIP,100Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP104J
106 2007-000162 R555 R-CHIP,100Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP104J
107 2007-000162 R579 R-CHIP,100Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP104J
108 2007-000162 R583 R-CHIP,100Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP104J
109 2007-000162 R605 R-CHIP,100Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP104J
110 2007-000162 R606 R-CHIP,100Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP104J
111 2007-000168 R440 R-CHIP,470Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP474J
112 2007-000168 R735 R-CHIP,470Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP474J
113 2007-000172 R220 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 RK73K1ETP100J
114 2007-000172 R224 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 RK73K1ETP100J
115 2007-000172 R577 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 RK73K1ETP100J
116 2007-000172 R578 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 RK73K1ETP100J
117 2007-000172 R664 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 RK73K1ETP100J
118 2007-000172 R731 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 RK73K1ETP100J
119 2007-000172 R736 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 RK73K1ETP100J
120 2007-000172 R737 R-CHIP,10ohm,5%,1/16W,DA,TP,1005 RK73K1ETP100J
121 2007-000174 R123 R-CHIP,47ohm,5%,1/16W,DA,TP,1005 RK73K1ETP470J
122 2007-000174 R569 R-CHIP,47ohm,5%,1/16W,DA,TP,1005 RK73K1ETP470J
3-3 Electrical Parts List
NO SEC CODE Reference Part Description Vendor Part No.
123 2007-000242 R582 R-CHIP,1.5Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP152J
124 2007-001119 R726 R-CHIP,680ohm,5%,1/16W,DA,TP,1005 RK73K1ETP681J
125 2007-001244 R105 R-CHIP,91Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP913J
126 2007-001298 R221 R-CHIP,51ohm,5%,1/16W,DA,TP,1005 RK73K1ETP510J
127 2007-001298 R724 R-CHIP,51ohm,5%,1/16W,DA,TP,1005 RK73K1ETP510J
128 2007-001301 R202 R-CHIP,68ohm,5%,1/16W,DA,TP,1005 ERJ2GEJ680X
129 2007-001301 R210 R-CHIP,68ohm,5%,1/16W,DA,TP,1005 ERJ2GEJ680X
130 2007-001305 R211 R-CHIP,120ohm,5%,1/16W,DA,TP,1005 RC1005J121CS
131 2007-001306 R728 R-CHIP,150ohm,5%,1/16W,DA,TP,1005 RK73K1ETP151J
132 2007-001307 R727 R-CHIP,180ohm,5%,1/16W,DA,TP,1005 RK73K1ETP181J
133 2007-001311 R218 R-CHIP,270ohm,5%,1/16W,DA,TP,1005 RK73K1ETP271J
134 2007-002796 R445 R-CHIP,510ohm,5%,1/16W,DA,TP,1005 RK73K1ETP511J
135 2007-002796 R446 R-CHIP,510ohm,5%,1/16W,DA,TP,1005 RK73K1ETP511J
136 2007-002965 R217 R-CHIP,15OHM,5%,1/16W,DA,TP,1005 RK73K1ETP150J
137 2007-007107 R658 R-CHIP,100Kohm,1%,1/16W,DA,TP,1005 RK73H1ETP1003F
138 2007-007317 R452 R-CHIP,2.2Kohm,1%,1/16W,DA,TP,1005 RK73H1ETP2201F
139 2007-007317 R453 R-CHIP,2.2Kohm,1%,1/16W,DA,TP,1005 RK73H1ETP2201F
140 2007-007317 R454 R-CHIP,2.2Kohm,1%,1/16W,DA,TP,1005 RK73H1ETP2201F
141 2007-007317 R455 R-CHIP,2.2Kohm,1%,1/16W,DA,TP,1005 RK73H1ETP2201F
142 2007-007317 R594 R-CHIP,2.2Kohm,1%,1/16W,DA,TP,1005 RK73H1ETP2201F
143 2007-007318 R456 R-CHIP,1Kohm,1%,1/16W,DA,TP,1005 RK73H1ETP1001F
144 2007-007318 R457 R-CHIP,1Kohm,1%,1/16W,DA,TP,1005 RK73H1ETP1001F
145 2007-007318 R458 R-CHIP,1Kohm,1%,1/16W,DA,TP,1005 RK73H1ETP1001F
146 2007-007318 R459 R-CHIP,1Kohm,1%,1/16W,DA,TP,1005 RK73H1ETP1001F
147 2007-007590 R659 R-CHIP,82Kohm,1%,1/16W,DA,TP,1005 RK73H1ETP8202F
148 2007-007771 R319 R-CHIP,0OHM,5%,1/16W,DA,TP,1005 ERJ2GE0R00L
149 2007-007771 R401 R-CHIP,0OHM,5%,1/16W,DA,TP,1005 ERJ2GE0R00L
150 2007-007771 R670 R-CHIP,0OHM,5%,1/16W,DA,TP,1005 ERJ2GE0R00L
151 2007-007771 R671 R-CHIP,0OHM,5%,1/16W,DA,TP,1005 ERJ2GE0R00L
152 2007-007771 R733 R-CHIP,0OHM,5%,1/16W,DA,TP,1005 ERJ2GE0R00L
153 2007-007771 R734 R-CHIP,0OHM,5%,1/16W,DA,TP,1005 ERJ2GE0R00L
154 2007-007771 R739 R-CHIP,0OHM,5%,1/16W,DA,TP,1005 ERJ2GE0R00L
155 2011-001344 R320 R-NETWORK,100ohm,5%,1/16W,L,CHIP,8P,TP EXB28V101JX
156 2011-001344 R485 R-NETWORK,100ohm,5%,1/16W,L,CHIP,8P,TP EXB28V101JX
157 2011-001345 R449 R-NETWORK,10Kohm,5%,1/16W,L,CHIP,8P,TP EXB28V103JX
158 2203-000233 C144 C-CERAMIC,CHIP,0.1nF,5%,50V,NP0,TP,1005 CL05C101JBNC
159 2203-000233 C305 C-CERAMIC,CHIP,0.1nF,5%,50V,NP0,TP,1005 CL05C101JBNC
160 2203-000233 C452 C-CERAMIC,CHIP,0.1nF,5%,50V,NP0,TP,1005 CL05C101JBNC
161 2203-000233 C453 C-CERAMIC,CHIP,0.1nF,5%,50V,NP0,TP,1005 CL05C101JBNC
162 2203-000233 C454 C-CERAMIC,CHIP,0.1nF,5%,50V,NP0,TP,1005 CL05C101JBNC
163 2203-000233 C455 C-CERAMIC,CHIP,0.1nF,5%,50V,NP0,TP,1005 CL05C101JBNC
164 2203-000233 C658 C-CERAMIC,CHIP,0.1nF,5%,50V,NP0,TP,1005 CL05C101JBNC
Electrical Parts List 3-4
NO SEC CODE Reference Part Description Vendor Part No.
165 2203-000233 C718 C-CERAMIC,CHIP,0.1nF,5%,50V,NP0,TP,1005 CL05C101JBNC
166 2203-000233 C719 C-CERAMIC,CHIP,0.1nF,5%,50V,NP0,TP,1005 CL05C101JBNC
167 2203-000254 C101 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
168 2203-000254 C102 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
169 2203-000254 C123 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
170 2203-000254 C210 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
171 2203-000254 C238 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
172 2203-000254 C307 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
173 2203-000254 C309 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
174 2203-000254 C313 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
175 2203-000254 C319 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
176 2203-000254 C326 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
177 2203-000254 C331 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
178 2203-000254 C335 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
179 2203-000254 C354 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
180 2203-000254 C434 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
181 2203-000254 C440 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
182 2203-000254 C449 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
183 2203-000254 C536 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
184 2203-000254 C587 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
185 2203-000254 C712 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
186 2203-000254 C725 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
187 2203-000254 C726 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
188 2203-000254 C744 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
189 2203-000254 C745 C-CERAMIC,CHIP,10nF,10%,16V,X7R,TP,1005 CL05B103KONC
190 2203-000278 C206 C-CERAMIC,CHIP,0.01nF,0.5pF,50V,NP0,1005 CL05C100CBNC
191 2203-000278 C239 C-CERAMIC,CHIP,0.01nF,0.5pF,50V,NP0,1005 CL05C100CBNC
192 2203-000359 C212 C-CERAMIC,CHIP,0.15nF,5%,50V,NP0,TP,1005 CL05C151JBNC
193 2203-000386 C235 C-CERAMIC,CHIP,0.015nF,5%,50V,NP0,1005 CL05C150JBNC
194 2203-000438 C138 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005 CL05B102KBNC
195 2203-000438 C211 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005 CL05B102KBNC
196 2203-000438 C221 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005 CL05B102KBNC
197 2203-000438 C227 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005 CL05B102KBNC
198 2203-000438 C229 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005 CL05B102KBNC
199 2203-000438 C230 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005 CL05B102KBNC
200 2203-000438 C240 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005 CL05B102KBNC
201 2203-000438 C261 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005 CL05B102KBNC
202 2203-000438 C556 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005 CL05B102KBNC
203 2203-000438 C557 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005 CL05B102KBNC
204 2203-000438 C562 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005 CL05B102KBNC
205 2203-000438 C580 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005 CL05B102KBNC
206 2203-000466 C575 C-CERAMIC,CHIP,0.001nF,0.25pF,50V,NP0,1005 CL05C010CBNC
3-5 Electrical Parts List
NO SEC CODE Reference Part Description Vendor Part No.
207 2203-000468 C747 C-CERAMIC,CHIP,0.001nF,0.25pF,50V,NP0,1608 CL10C010CBNC
208 2203-000585 C112 C-CERAMIC,CHIP,220pF,10%,50V,X7R,TP,1005 C1005X7R1H221KT
209 2203-000628 C237 C-CERAMIC,CHIP,0.022nF,5%,50V,NP0,TP,1005 CL05C220JBNC
210 2203-000628 C400 C-CERAMIC,CHIP,0.022nF,5%,50V,NP0,TP,1005 CL05C220JBNC
211 2203-000628 C401 C-CERAMIC,CHIP,0.022nF,5%,50V,NP0,TP,1005 CL05C220JBNC
212 2203-000679 C200 C-CERAMIC,CHIP,0.027nF,5%,50V,NP0,TP,1005 CL05C270JBNC
213 2203-000679 C232 C-CERAMIC,CHIP,0.027nF,5%,50V,NP0,TP,1005 CL05C270JBNC
214 2203-000679 C262 C-CERAMIC,CHIP,0.027nF,5%,50V,NP0,TP,1005 CL05C270JBNC
215 2203-000679 C540 C-CERAMIC,CHIP,0.027nF,5%,50V,NP0,TP,1005 CL05C270JBNC
216 2203-000679 C555 C-CERAMIC,CHIP,0.027nF,5%,50V,NP0,TP,1005 CL05C270JBNC
217 2203-000679 C569 C-CERAMIC,CHIP,0.027nF,5%,50V,NP0,TP,1005 CL05C270JBNC
218 2203-000679 C586 C-CERAMIC,CHIP,0.027nF,5%,50V,NP0,TP,1005 CL05C270JBNC
219 2203-000679 C727 C-CERAMIC,CHIP,0.027nF,5%,50V,NP0,TP,1005 CL05C270JBNC
220 2203-000679 C728 C-CERAMIC,CHIP,0.027nF,5%,50V,NP0,TP,1005 CL05C270JBNC
221 2203-000679 C740 C-CERAMIC,CHIP,0.027nF,5%,50V,NP0,TP,1005 CL05C270JBNC
222 2203-000679 C741 C-CERAMIC,CHIP,0.027nF,5%,50V,NP0,TP,1005 CL05C270JBNC
223 2203-000696 C582 C-CERAMIC,CHIP,0.002nF,0.25pF,50V,NP0,1005 CL05C020CBNC
224 2203-000812 C143 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
225 2203-000812 C204 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
226 2203-000812 C217 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
227 2203-000812 C234 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
228 2203-000812 C263 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
229 2203-000812 C264 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
230 2203-000812 C310 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
231 2203-000812 C311 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
232 2203-000812 C312 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
233 2203-000812 C327 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
234 2203-000812 C330 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
235 2203-000812 C437 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
236 2203-000812 C438 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
237 2203-000812 C439 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
238 2203-000812 C441 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
239 2203-000812 C442 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
240 2203-000812 C443 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
241 2203-000812 C448 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
242 2203-000812 C460 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
243 2203-000812 C758 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
244 2203-000854 C244 C-CERAMIC,CHIP,0.039nF,5%,50V,NP0,TP,1005 CL05C390JBNC
245 2203-000854 C698 C-CERAMIC,CHIP,0.039nF,5%,50V,NP0,TP,1005 CL05C390JBNC
246 2203-000854 C699 C-CERAMIC,CHIP,0.039nF,5%,50V,NP0,TP,1005 CL05C390JBNC
247 2203-000870 C213 C-CERAMIC,CHIP,0.003nF,0.25pF,50V,NP0,1005 CL05C030CBNC
248 2203-001020 C538 C-CERAMIC,CHIP,0.004nF,0.25pF,50V,NP0,1608 CM105CG4R0C50AT
Electrical Parts List 3-6
NO SEC CODE Reference Part Description Vendor Part No.
249 2203-001153 C215 C-CERAMIC,CHIP,0.068nF,5%,50V,NP0,TP,1005 CL05C680JBNC
250 2203-001153 C494 C-CERAMIC,CHIP,0.068nF,5%,50V,NP0,TP,1005 CL05C680JBNC
251 2203-002525 C126 C-CERAMIC,CHIP,0.56nF,10%,50V,X7R,TP,1005 C1005X7R1H561KT
252 2203-002525 C137 C-CERAMIC,CHIP,0.56nF,10%,50V,X7R,TP,1005 C1005X7R1H561KT
253 2203-002525 C481 C-CERAMIC,CHIP,0.56nF,10%,50V,X7R,TP,1005 C1005X7R1H561KT
254 2203-002668 C214 C-CERAMIC,CHIP,0.0005nF,0.1pF,50V,1005 CL05C0R5BBNC
255 2203-003054 C329 C-CERAMIC,CHIP,0.009nF,0.25pF,50V,1005 C1005C0G1H090CT
256 2203-003054 C444 C-CERAMIC,CHIP,0.009nF,0.25pF,50V,1005 C1005C0G1H090CT
257 2203-003054 C445 C-CERAMIC,CHIP,0.009nF,0.25pF,50V,1005 C1005C0G1H090CT
258 2203-003054 C539 C-CERAMIC,CHIP,0.009nF,0.25pF,50V,1005 C1005C0G1H090CT
259 2203-003054 C757 C-CERAMIC,CHIP,0.009nF,0.25pF,50V,1005 C1005C0G1H090CT
260 2203-005050 C600 C-CERAMIC,CHIP,0.0018nF,0.25pF,50V,1005 CL05C1R8CBNC
261 2203-005061 C106 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
262 2203-005061 C107 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
263 2203-005061 C110 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
264 2203-005061 C111 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
265 2203-005061 C114 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
266 2203-005061 C301 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
267 2203-005061 C332 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
268 2203-005061 C409 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
269 2203-005061 C427 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
270 2203-005061 C534 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
271 2203-005061 C588 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
272 2203-005061 C597 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
273 2203-005061 C701 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
274 2203-005061 C706 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
275 2203-005061 C711 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
276 2203-005065 C108 C-CERAMIC,CHIP,1000nF,+80-20%,10V,1608 GRM39Y5V105Z10PT
277 2203-005065 C125 C-CERAMIC,CHIP,1000nF,+80-20%,10V,1608 GRM39Y5V105Z10PT
278 2203-005065 C318 C-CERAMIC,CHIP,1000nF,+80-20%,10V,1608 GRM39Y5V105Z10PT
279 2203-005065 C403 C-CERAMIC,CHIP,1000nF,+80-20%,10V,1608 GRM39Y5V105Z10PT
280 2203-005065 C431 C-CERAMIC,CHIP,1000nF,+80-20%,10V,1608 GRM39Y5V105Z10PT
281 2203-005065 C545 C-CERAMIC,CHIP,1000nF,+80-20%,10V,1608 GRM39Y5V105Z10PT
282 2203-005065 C705 C-CERAMIC,CHIP,1000nF,+80-20%,10V,1608 GRM39Y5V105Z10PT
283 2203-005065 C748 C-CERAMIC,CHIP,1000nF,+80-20%,10V,1608 GRM39Y5V105Z10PT
284 2203-005065 C749 C-CERAMIC,CHIP,1000nF,+80-20%,10V,1608 GRM39Y5V105Z10PT
285 2203-005234 C596 C-CERAMIC,CHIP,0.0012nF,0.25pF,50V,1005 CL05C1R2CBNC
286 2203-005382 C248 C-CERAMIC,CHIP,0.006nF,0.1pF,50V,1005 C1005C0G1H060BT
287 2203-005383 C752 C-CERAMIC,CHIP,7pF,0.1pF,50V,NPO,TP,1005 C1005C0G1H070BT
288 2203-005383 C753 C-CERAMIC,CHIP,7pF,0.1pF,50V,NPO,TP,1005 C1005C0G1H070BT
289 2203-005383 C754 C-CERAMIC,CHIP,7pF,0.1pF,50V,NPO,TP,1005 C1005C0G1H070BT
290 2203-005383 C755 C-CERAMIC,CHIP,7pF,0.1pF,50V,NPO,TP,1005 C1005C0G1H070BT
3-7 Electrical Parts List
NO SEC CODE Reference Part Description Vendor Part No.
291 2203-005446 C721 C-CERAMIC,CHIP,0.0027nF,0.1pF,50V,1005 C1005C0G1H2R7BT
292 2203-005480 C450 C-CERAMIC,CHIP,33nF,10%,10V,X7R,TP,1005 C1005X7R1C333KT
293 2203-005480 C451 C-CERAMIC,CHIP,33nF,10%,10V,X7R,TP,1005 C1005X7R1C333KT
294 2203-005481 C459 C-CERAMIC,CHIP,47nF,10%,10V,X7R,TP,1005 C1005X7R1A473KT
295 2203-005482 C746 C-CERAMIC,CHIP,100nF,10%,10V,X5R,TP,1005 GRM36X5R104K10PT
296 2203-005482 C751 C-CERAMIC,CHIP,100nF,10%,10V,X5R,TP,1005 GRM36X5R104K10PT
297 2203-005503 C456 C-CERAMIC,CHIP,0.18nF,5%,25V,NP0,TP,1005 C1005CH1E181J
298 2203-005503 C457 C-CERAMIC,CHIP,0.18nF,5%,25V,NP0,TP,1005 C1005CH1E181J
299 2203-005552 C727 C-CERAMIC,CHIP,0.0022nF,0.1pF,50V,NP0,1005 C1005C0G1H2R2BT
300 2301-001197 C202 C-FILM,CHIP,0.39nF,5%,50V,TP,2x1.25x0.8mm ECHU1H391JX5
301 2301-001213 C203 C-FILM,CHIP,6.8nF,5%,16V,TP,2012 ECHU1C682JX5
302 2404-001020 C710 C-TA,CHIP,10uF,20%,10V,GP,TP,3216 TAJA106M010R
303 2404-001083 C249 C-TA,CHIP,220uF,20%,6.3V,LZ,TP,7132 F750J227MCCGZT
304 2404-001101 C220 C-TA,CHIP,1uF,20%,16V,GP,TP,2012 TAJR105M016R
305 2404-001105 C105 C-TA,CHIP,10UF,20%,6.3V,GP,TP,2012 ECST0JZ106R
306 2404-001105 C117 C-TA,CHIP,10UF,20%,6.3V,GP,TP,2012 ECST0JZ106R
307 2404-001105 C124 C-TA,CHIP,10UF,20%,6.3V,GP,TP,2012 ECST0JZ106R
308 2404-001105 C145 C-TA,CHIP,10UF,20%,6.3V,GP,TP,2012 ECST0JZ106R
309 2404-001105 C306 C-TA,CHIP,10UF,20%,6.3V,GP,TP,2012 ECST0JZ106R
310 2404-001105 C328 C-TA,CHIP,10UF,20%,6.3V,GP,TP,2012 ECST0JZ106R
311 2404-001105 C535 C-TA,CHIP,10UF,20%,6.3V,GP,TP,2012 ECST0JZ106R
312 2404-001105 C708 C-TA,CHIP,10UF,20%,6.3V,GP,TP,2012 ECST0JZ106R
313 2404-001105 C750 C-TA,CHIP,10UF,20%,6.3V,GP,TP,2012 ECST0JZ106R
314 2404-001134 C436 C-TA,CHIP,100UF,20%,6.3V,LZ,TP,4028 595D107X06R3B2T
315 2404-001134 C579 C-TA,CHIP,100UF,20%,6.3V,LZ,TP,4028 595D107X06R3B2T
316 2404-001162 C446 C-TA,CHIP,47uF,20%,4V,LZ,TP,3216 F950G476MAAJZTQ2
317 2703-001178 L594 INDUCTOR-SMD,3.3nH,0.3nH,1x0.5x0.5mm HK1005-3N3S-T
318 2703-001180 L211 INDUCTOR-SMD,15nH,5%,1x0.5x0.5mm LL1005-FH15NJ
319 2703-001257 L599 INDUCTOR-SMD,3.9nH,0.3nH,1.6x0.8X0.8mm HK1608-3N9S-T
320 2703-001293 L200 INDUCTOR-SMD,82nH,5%,1.6x0.8x0.8mm HK1608-82NJ-T
321 2703-001514 L201 INDUCTOR-SMD,68nH,5%,1.8x1.12x1.02mm 0603CS-68NXJBC
322 2703-001545 L212 INDUCTOR-SMD,47nH,5%,1.8x1.12x1.02mm 0603CS-47NXJBC
323 2703-001545 L213 INDUCTOR-SMD,47nH,5%,1.8x1.12x1.02mm 0603CS-47NXJBC
324 2703-001708 L406 INDUCTOR-SMD,5.6nH,10%,1.0x0.5x0.5mm HK1005-5N6K-T
325 2703-001735 L596 INDUCTOR-SMD,3.9nH,10%,1x0.5x0.5mm HK1005-3N9K-T
326 2703-001750 L402 INDUCTOR-SMD,2.2NH,0.3NH,1X0.5X0.5MM LL1005-FH2N2S
327 2703-001752 L601 INDUCTOR-SMD,39nH,5%,1.0x0.5x0.5mm LL1005-FH39NJ
328 2703-001786 L404 INDUCTOR-SMD,10NH,5%,1.0X0.5X0.5MM LL1005-FH10NJ
329 2703-001943 L600 INDUCTOR-SMD,10nH,5%,1.0x0.5x0.5mm HK1005-10NJ-T
330 2703-001949 L595 INDUCTOR-SMD,4.7nH,10%,1.0x0.5x0.5mm HK1005-4N7K-T
331 2703-001950 L204 INDUCTOR-SMD,12nH,10%,1.0x0.5x0.5mm HK1005-12NK-T
332 2703-001952 L209 INDUCTOR-SMD,8.2nH,5%,1.0x0.5x0.5mm HK1005-8N2J-T
Electrical Parts List 3-8
NO SEC CODE Reference Part Description Vendor Part No.
333 2703-001952 L597 INDUCTOR-SMD,8.2nH,5%,1.0x0.5x0.5mm HK1005-8N2J-T
334 2703-001953 L218 INDUCTOR-SMD,6.8nH,5%,1.0x0.5x0.5mm HK1005-6N8J-T
335 2801-003856 X1 CRYSTAL-SMD,0.032786MHz,20ppm MC-146(32.768KHZ,20P
336 2806-001239 U200 OSCILLATOR-VCO,1748MHz,-,50ohm,TP,2.8V VOF1748C28KRF
337 2809-001237 U100 OSCILLATOR-VCTCXO,13MHz,5ppm,10Kohm KT16-KEU30L-13.000M-T
338 2901-001116 E200 FILTER-EMI SMD,50V,0.3A,-,470pF NFM2012R13C471R
339 2904-001235 F203 FILTER-SAW,1.8425GHz,75MHz,+-37.5MHz FAR-G6CH-1G8425-L218
340 2904-001300 F204 FILTER-SAW,1.8425GHZ,75MHZ,1805-1880MHZ FAR-G6CH-1G8425-L227B
341 2904-001302 F200 FILTER-SAW,225MHZ,0.16MHZ,0.7MS,TP B4846
342 2909-001146 U203 FILTER-DUPLEXER,942.5MHZ,897.5MHZ LMG002S-5008C
343 3705-001226 CN1 CONNECTOR-COAXIAL,JACK,75mohm,50ohm MHC-188
344 3709-001088 J402 CONNECTOR-CARD EDGE,6P,2.54mm 2-338063-2
345 3710-001105 M1 CONNECTOR-SOCKET 24-8005-002-100-867
346 3710-001595 J403 IF CONNECTOR;18P,1R.0.5mm 1004-0018-304
347 3722-001587 U400 JACK-PHONE,6P,2.6PI,AG,BLK 02-828DO-53BKA
348 4302-001119 BAT1 BATTERY-LI(2ND),3V,0.1MAH RB414II06N
349 4709-001144 U318 COUPLER-DIRECTION,897.5/1747.5MHZ LDC21897M19D-078
349 N.C POINT C201 N.C POINT
350 N.C POINT C242 N.C POINT
351 N.C POINT C304 N.C POINT
352 N.C POINT C413 N.C POINT
353 N.C POINT C704 N.C POINT
354 N.C POINT C714 N.C POINT
355 N.C POINT C717 N.C POINT
356 N.C POINT C728 N.C POINT
357 N.C POINT C743 N.C POINT
358 N.C POINT R436 N.C POINT
359 N.C POINT R448 N.C POINT
3-9 Electrical Parts List
3-2 Main Parts List Bottom
NO SEC CODE Reference Part Description Vendor Part No.
1 0407-001002 D302 DIODE-ARRAY,DAN222,80V,300mA,CA2-3,EM3 DAN222
2 0501-002011 Q300 TR-SMALL SIGNAL,2SD2114K,NPN,200mW,SOT-23 2SD2114KT146V
3 0504-001012 U209 TR-DIGITAL,DTC114YE,NPN,150MW,10K/47K DTC114YE
4 0504-001058 U204 TR-DIGITAL,RN4985,NPN/PNP,200mW,2.2Kohm RN4985
5 0504-001058 U492 TR-DIGITAL,RN4985,NPN/PNP,200mW,2.2Kohm RN4985
6 0504-001058 U493 TR-DIGITAL,RN4985,NPN/PNP,200mW,2.2Kohm RN4985
7 0601-001402 LED1 LED,CHIP,RED/Y-GRN,1.2x1.5mm,660/570nm CL165HR/YG-D-T
8 0601-001547 LED2 LED,CHIP,BLUE,1.1X0.8MM,485NM SLSNNBL102TS
9 0601-001584 D433 LED,CHIP,BLUE,1.2X0.8MM,480NM SLSNNBF102TS
10 0601-001584 D434 LED,CHIP,BLUE,1.2X0.8MM,480NM SLSNNBF102TS
11 0601-001584 D427 LED,CHIP,BLUE,1.2X0.8MM,480NM SLSNNBF102TS
12 0601-001584 D428 LED,CHIP,BLUE,1.2X0.8MM,480NM SLSNNBF102TS
13 0601-001584 D429 LED,CHIP,BLUE,1.2X0.8MM,480NM SLSNNBF102TS
14 0601-001584 D430 LED,CHIP,BLUE,1.2X0.8MM,480NM SLSNNBF102TS
15 0601-001584 D431 LED,CHIP,BLUE,1.2X0.8MM,480NM SLSNNBF102TS
16 0601-001584 D432 LED,CHIP,BLUE,1.2X0.8MM,480NM SLSNNBF102TS
17 1209-001379 U611 IC-ETC, LINEAR,16P,3.4V,240MW HD155173ANPEL
18 1405-001093 D411 VARISTOR,14V,20A,1x0.5x0.6mm VC040214X500R
19 1405-001093 D415 VARISTOR,14V,20A,1x0.5x0.6mm VC040214X500R
20 2007-000139 R725 R-CHIP,220ohm,5%,1/16W,DA,TP,1005 RK73K1ETP221J
21 2007-000139 R573 R-CHIP,220ohm,5%,1/16W,DA,TP,1005 RK73K1ETP221J
22 2007-000139 R572 R-CHIP,220ohm,5%,1/16W,DA,TP,1005 RK73K1ETP221J
23 2007-000139 R574 R-CHIP,220ohm,5%,1/16W,DA,TP,1005 RK73K1ETP221J
24 2007-000143 R305 R-CHIP,4.7Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP472J
25 2007-000148 R238 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
26 2007-000148 R240 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
27 2007-000148 R241 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
28 2007-000148 R424 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
29 2007-000148 R427 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
30 2007-000148 R651 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP103J
31 2007-000162 R304 R-CHIP,100Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP104J
32 2007-000162 R422 R-CHIP,100Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP104J
33 2007-000162 R423 R-CHIP,100Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP104J
34 2007-000982 R624 R-CHIP,5.6Kohm,5%,1/16W,DA,TP,1005 RK73K1ETP562J
35 2007-001301 R665 R-CHIP,68ohm,5%,1/16W,DA,TP,1005 ERJ2GEJ680X
36 2007-001301 R666 R-CHIP,68ohm,5%,1/16W,DA,TP,1005 ERJ2GEJ680X
37 2007-001306 R667 R-CHIP,150ohm,5%,1/16W,DA,TP,1005 RK73K1ETP151J
38 2007-007142 R617 R-CHIP,10Kohm,1%,1/16W,DA,TP,1005 RK73H1ETP1002F
39 2007-007142 R618 R-CHIP,10Kohm,1%,1/16W,DA,TP,1005 RK73H1ETP1002F
40 2007-007311 R626 R-CHIP,22Kohm,1%,1/16W,DA,TP,1005 RK73H1ETP2202F
41 2007-007771 R729 R-CHIP,0OHM,5%,1/16W,DA,TP,1005 ERJ2GE0R00L
42 2203-000654 C655 C-CERAMIC,CHIP,270pF,10%,50V,X7R,TP,1005 C1005X7R1H271KT
Electrical Parts List 3-10
NO SEC CODE Reference Part Description Vendor Part No.
43 2203-000654 C585 C-CERAMIC,CHIP,270pF,10%,50V,X7R,TP,1005 C1005X7R1H271KT
44 2203-000438 C720 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005 CL05B102KBNC
45 2203-000995 C713 C-CERAMIC,CHIP,0.047nF,5%,50V,NP0,TP,1005 CL05C470JBNC
46 2203-000812 C664 C-CERAMIC,CHIP,0.033nF,5%,50V,NP0,TP,1005 CL05C330JBNC
47 2203-000311 C657 C-CERAMIC,CHIP,0.12nF,5%,50V,NP0,TP,1005 CL05C121JANC
48 2203-000233 C658 C-CERAMIC,CHIP,0.1nF,5%,50V,NP0,TP,1005 CL05C101JBNC
49 2203-000679 C665 C-CERAMIC,CHIP,0.027nF,5%,50V,NP0,TP,1005 CL05C270JBNC
50 2203-000438 C270 C-CERAMIC,CHIP,1nF,10%,50V,X7R,TP,1005 CL05B102KBNC
51 2203-000679 C267 C-CERAMIC,CHIP,0.027nF,5%,50V,NP0,TP,1005 CL05C270JBNC
52 2203-000679 C269 C-CERAMIC,CHIP,0.027nF,5%,50V,NP0,TP,1005 CL05C270JBNC
53 2203-005061 C308 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
54 2203-005061 C418 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
55 2203-005061 C419 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
56 2203-005061 C420 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
57 2203-005061 C421 C-CERAMIC,CHIP,100nF,+80-20%,16V,1005 C1005Y5V1C104ZT
58 2203-005065 C411 C-CERAMIC,CHIP,1000nF,+80-20%,10V,1608 GRM39Y5V105Z10PT
59 2203-005065 C412 C-CERAMIC,CHIP,1000nF,+80-20%,10V,1608 GRM39Y5V105Z10PT
60 2203-005065 C415 C-CERAMIC,CHIP,1000nF,+80-20%,10V,1608 GRM39Y5V105Z10PT
61 2203-005065 C417 C-CERAMIC,CHIP,1000nF,+80-20%,10V,1608 GRM39Y5V105Z10PT
62 2203-005065 C422 C-CERAMIC,CHIP,1000nF,+80-20%,10V,1608 GRM39Y5V105Z10PT
63 2203-005065 C490 C-CERAMIC,CHIP,1000nF,+80-20%,10V,1608 GRM39Y5V105Z10PT
64 2203-005444 C404 C-CERAMIC,CHIP,0.003nF,0.1pF,50V,NP0,1005 C1005C0G1H030BT
65 2703-001723 L408 INDUCTOR-SMD,33nH,5%,1.0x0.5x0.5mm HK1005-33NJ-T
66 2703-001723 L409 INDUCTOR-SMD,33nH,5%,1.0x0.5x0.5mm HK1005-33NJ-T
67 3002-001098 BUZ300 BUZZER-MAGNETIC,94dB,3V,150mA,2700Hz BRT-03S
68 N.C R730 N.C POINT
69 N.C C715 N.C POINT
3-11 Electrical Parts List
SIM CARD
BB INTERFACE
Block Diagrams
Serial Data
Interface
Battery
Type
VIBRATOR I/O
Interface
4-1 Main Baseband
MIC Battery
Voltage
4. Block Diagrams
A/D Battery
SPEAKER
Interface Temperature
ONE C
RF INTERFACE
SYSTEM CLOCK 3VTX
(13MHz)
AGC,AFC
XVCC
SRAM
PLL 3VRF
FLASH1
Li-Ion Battery
FLASH2 (Standard)
VCC
LOAD
AVCC
EEPROM SWITCH
Charging
RTC_CLOCK ALERT_VCC
Circuit
(32.768KHz)
KEYPAD
LCD RTC_3V3
4-1
4-2
C212
4-2 Main RF
EGSM L200
F204
925~960 MHz LC
(CH62 : 947.4 MHz) Filter
LNA F200
2nd Mixer 2 IRXP
Dual IF IRXN
DCS I&Q
SAW Mixer 1 SAW PGA
Demod. QRXP
1805~1880 MHz 45 MHz
Filter Filter
(CH698 : 1842.4 MHz) QRXN
LNA 225 MHz
SYNTHDATA
Serial data SYNTHCLOCK
Interface AGCLE
Bias
Circuit 45 MHz
F203
1st 270 MHz
Dual SAW 90 deg RXEN1
Filter EGSM : 1150 ~ 1185 MHz Shift RXEN2
SI4133-XM2 DCS : 1580 ~ 1655 MHz(Rx)
HD155128TF 1/2
(U478) RF VCO 1575 ~ 1650 MHz(Tx)
(U454)
1/2
PLL1 VP40575
1/6 (U618)
RF Antenna PLL2 1/2
Conector S/W DCS : 270 MHz
IF VCO 90 deg
(CN1) (U203) 1080 MHz TXEN
Shift
EGSM : 540 MHz 1/2
VCTCXO
(13MHz)
(U100)
DGSM : 270 MHz
EGSM : 270 MHz DCS : 135 MHz
DCS Dual PAM DCS : 135 MHz
TX VCO
1710 ~ 1785 MHz (U476)
(CH698 : 1747.4 MHz) (U200)
ITXP
Dual Loop Phase I&Q ITXN
Coupler Filter Detector Mod. QTXP
(U318) QTXN
EGSM
880 ~ 915 MHz
(CH62 : 902.4 MHz)
APCIC (U611)
Block Diagrams
Block Diagrams
SI4133-XM2
(U478) RF VCO
10 47 GSM : 1150 ~ 1185 MHz
PLL1
DCS : 1580 ~ 1655 MHz(Rx)
1575 ~ 1650 MHz(Tx)
2
PLL1 RF VCO
SI4133-MLP28 10 47 GSM : 1150 ~ 1185 MHz
RF
U302 PLL2 PCN : 1575 ~ 1650 MHz (Tx)
Conector 23 VP405575
30
(CN1) IF VCO 1080 MHz
1080 MHz U108
3 PLL2
Antenna 23 30 U618
8 VCTCXO VP40575
S/W 540 MHz
4-2-1 RF Transmit Part
(13MHz)
U203
Antenna (U100)
2 15 IF VCO
S/W 1080MHz HD155128TF
5 2 11 38 1
U304 3 VCTCXO TXEN1
13MHz AFCDAC U454 RAMPDAC
2
U305 35
13 4 14 11 7 U303 38 BAND Selection
1
DCS 11 TXEN - GSM : Low
EGSM 1710 ~ 1785 MHz - DCS 2
RAMPDAC : High
880 ~ 915 MHz 35
(CH698 : 1747.4 MHz) Dual PAM BAND Selection
11 HD155128TF
(CH62 : 902.4 MHz) - GSM : Low
U476 - DCS : High
1710 ~ 1785MHz(DCS) 880 ~ 915MHz(EGSM) Dual PAM
890 ~ 915MHz(PGSM) U312 TX VCO
7 1 5 8
U200
10 TX VCO 4 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
