Image preview - the first page of the document
>> Download Samsung SGH-R220 service manual documenatation <<
Text preview - extract from the document
DUAL BAND Mobile
ELECTRONICS
Cellular Phone
SGH-R220
SERVICE Manual
DUAL BAND MOBILE CELLULAR PHONE CONTENTS
1. Exploded Views and Parts List
2. PCB Diagrams
3. Electrical Parts List
4. Block Diagrams
5. Flow Chart of Troubleshooting and
Circuit Diagrams
ELECTRONICS
Samsung Electronics Co.,Ltd.
Printed in Korea
03/2001 Rev 1.0
GH68-02128B
1. Exploded Views and Parts List
1-1 Main
1-2 Main Parts List
1-3 Travel Adapter
1-4 Travel Adapter Parts List
1-5 Ciger Light Adapter
1-6 Ciger Light Adapter Parts List
1-7 Test Jig
1-8 EAR Microphone
1-9 Data Kit
1-10 Battery Charger
2. PCB Diagrams
2-1 Main Top
2-2 Main Bottom
3. Electrical Parts List
3-1 Main Parts List Top
3-2 Main Parts List Bottom
4. Block Diagrams
4-1 Main Baseband
4-2 Main RF
4-2-1 RF Transmit Part
4-2-2 RF Receive Part
5. Flow Chart of Troubleshooting and Circuit Diagrams
5-1 Power ON
5-2 Initial
5-3 Charging Part
5-4 Sim Part
5-5 Microphone Part
5-6 Speaker Part
5-7 Key Data Input
5-8 Alert Tone
5-9 Ring Indicator
5-10 Back Light
5-11 GSM Receiver
5-12 GSM Transmitter
5-13 DCS Receiver
5-14 DCS Transmitter
1. Exploded Views and Parts List
1-1 Main
Exploded Views and Parts List 1-1
1-2 Main Parts List
SEC CODE
Location No. Description Remark
Navy Blue Green Dark Gray
1 MEC-FRONT COVER GH75-01162A GH75-01162B GH75-01162C SA
1-1 FRONT COVER GH72-02670A GH72-02670B GH72-02670C SNA
1-2 WINDOW LCD GH72-02672A GH72-02672A GH72-02672A SNA
1-3 FI KEY GH72-02782A GH72-02782A GH72-02782A SA
1-4 MEC-KEYPAD GH75-01164A GH75-01164A GH75-01164A SA
1-5 MEC-DUMMY COVER GH75-01163A GH75-01163A GH75-01163A SNA
1-6 MIC GH59-00240B GH59-00240B GH59-00240B SA
1-7 SPEAKER 3001-001233 3001-001233 3001-001233 SA
1-8 EARPHONE COVER GH73-00757A GH73-00757B GH73-00757C SNA
2 DOME SHEET GH72-02984A GH72-02984A GH72-02984A SA
3 MAIN PBA GH92-01202A GH92-01202A GH92-01202A SA
4 BUZZER 3002-001098 3002-001098 3002-001098 SA
5 DISPLAY LCD GH07-00075B GH07-00075B GH07-00075B SA
6 I/F COVER GH73-00758A GH73-00758B GH73-00758C SA
7 MEC-REAR COVER GH75-01165A GH75-01165B GH75-01165C SA
7-1 REAR COVER GH72-02674A GH72-02674B GH72-02674C SNA
7-2 VIBRATOR GH31-00019A GH31-00019A GH31-00019A SA
7-3 BRACKET-ANT GH71-00505A GH71-00505A GH71-00505A SNA
7-4 SPRING LOCKER GH70-10633A GH70-10633A GH70-10633A SNA
7-5 LOCKER MAIN GH72-02676A GH72-02676B GH72-02676C SNA
8 ANTENNA GH42-00120C GH42-00120B GH42-00120A SA
9 R/F COVER GH73-00759A GH73-00759A GH73-00759A SA
10 SCREW-MACHINE 6001-001346 6001-001346 6001-001346 SA
11 LABEL GH68-02110A GH68-02110A GH68-02110A SA
12 BATTERY GH43-00369A GH43-00369B GH43-00369C SA
1-2 Exploded Views and Parts List
1-3 Travel Adapter
A B
C D
1-4 Travel Adapter Parts List
TYPE SEC CODE REMARK
A GH44-00171A CHINA
B GH44-00184A EUROPE
C GH44-00171C UNITED KINGDOM
D Gh44-00171E TAIWAN
Exploded Views and Parts List 1-3
1-5 Ciger Light Adapter
1-6 Ciger Light Adapter Parts List
DESCRIPTION SEC CODE REMARK
Ciger Light Adapter Code GH44-00170A BLACK
1-4 Exploded Views and Parts List
1-7 Test Jig
TEST JIG GH80-10508A
TEST JIG CABLE GH39-00079A
RF CABLE GH39-00090A
Exploded Views and Parts List 1-5
1-7-1 Test Jig
DC
POWER
SUPPLY
8922 or 8960
WIRELESS COMMUNICATIONS
TEST SET
RF JIG CABLE
TEST JIG CABLE
232 CABLE
Note PC
1-6 Exploded Views and Parts List
1-8 EAR Microphone
EAR MICROPHONE GH59-00225B
1-9 Data Kit
DATA KIT GH39-00078A
1-10 Battery Charger
BATTERY CHAGER GH44-00221A
Exploded Views and Parts List 1-7
2. PCB Diagrams
2-1 Main Top
2-1 PCB Diagrams
2-2 Main Bottom
2-2 PCB Diagrams
3. Electrical Parts List
3-1 Main Parts List Top
SEC CODE Reference the name of an article Part Description
