Image preview - the first page of the document
>> Download Samsung SGH-ZV30 service manual documenatation <<Text preview - extract from the document UMTS TELEPHONE
SGH-ZV30
UMTS TELEPHONE CONTENTS
1. Specification
2. Circuit Description
3. Exploded Views and Parts List
4. Electrical Parts List
5. Block Diagrams
6. PCB Diagrams
7. Flow Chart of Troubleshooting
This Service Manual is a property of Samsung Electronics Co.,Ltd. Samsung Electronics Co.,Ltd. September. 2005
Any unauthorized use of Manual can be punished under applicable Printed in Korea.
International and/or domestic law.
Code No.: GH68-08450A
BASIC.
1. Specification
1-1. GSM General Specification
EG SM 900 DCS1800 PCS1 900 W- CDMA
Fr eq.
880~9 15 1710 ~1785 1850~1 910 1 920~19 80
Band [MHz]
925~9 60 1805 ~1880 1930~1 990 2 110~21 70
Uplink/Downlink
0~1 24 & UL:9 612~98 88
ARFCN rang e 512 ~885 512~8 10
975~1 023 DL:10 562~10 838
Tx/ Rx spacing 45MHz 95 MHz 80MHz 190MHz
Mod. Bit rat e/ 270.8 33kbps 270. 833kbps 270.8 33kbps 3. 84Mcps
Bi t Pe rio d 3.69 2us 3. 692us 3.69 2us
Tim e Slot
576. 9us 576 .9us 576. 9us F rame l ength : 10ms
Per iod/ Fra me
4 .615ms 4.61 5ms 4 .615ms Slot lengt h : 0. 667ms
Period
QPSK
Modu lation 0.3G MSK 0. 3GMSK 0.3G MSK
HQPSK
MS Power 33dBm~ 5dBm 30dBm~0dBm 30dBm~ 0dBm 2 4dBm ~ - 50dBm
4 1 1 3
Power Cl ass
(max +33dBm) (max +30dBm) (max +30dBm) (max +24dBm)
Sensitivity - 102dBm - 100d Bm - 100dBm - 106.7 dBm
T DM A M u x 8 8 8
Cell Ra dius 35Km 2 Km 2Km 2Km
1-1
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used with out Samsung's authorization
Specification
1-2. GSM TX power class
TX Power TX Power TX Power
GSM900 DCS1800 PCS1900
control level control level control level
5 33
