Image preview - the first page of the document
>> Download DVDHR773_ET-SB-EX-SI_1242635479 documenatation <<
Text preview - extract from the document
DVD-HDD RECORDER
Chassis : Hiddink (5th Generation)
BASIC : DVD-HR773
Application Models
: DVD-HR769 /DVD-HR770 /
DVD-HR773 / DVD-HR775 /
DVD-HR776 / DVD-HR777
Application Area
SERVICE MANUAL
: XEF, XEC, XEE, XEG, XEU, EUR, EDC,
XET, XEN, XEB, AUS, XER, NWT, XSA,
XSH, XSS, SMR, XST, XSG, XFA
SERVICE Manual
DVD-HR769 /DVD-HR770 /DVD-HR773 /DVD-HR775 /DVD-HR776 /DVD-HR777
DVD-HDD RECORDER Contents
1. Precautions
If you want to know additional information which is not included on this Service 2. Product Specification
Manual, Please refer to the SKP(Samsung Knowledge Portal) web site.
3. Disassembly and Reassembly
Area Web Site
4. Trouble Shooting
North America URL ; http://service.samsungportal.com
Latin America URL ; http://latin.samsungportal.com
DVD-HR773 / DVD-HR775 /
DVD-HR776 / DVD-HR777 5. Exploded View and Parts List
CIS URL ; http://cis.samsungportal.com
Europe URL ; http://europe.samsungportal.com 6. PCB Diagrams
China URL ; http://china.samsungportal.com
Asia URL ; http://asia.samsungportal.com 7. Schematic Diagrams
Mideast & Africa URL ; http://mea.samsungportal.com
DVD-HR769 / DVD-HR770
