Image preview - the first page of the document



>> Download 17_SVC GUIDE documenatation <<

Text preview - extract from the document

                                  IMPORTANT SERVICE GUIDE
 MODE SWITCH (PROGRAM SWITCH) ASSEMBLY POINT

1) When installing the ass'y deck on the Main PCB, be sure to align the assembly point of mode switch.




                                                                                                               ASSEMBLY POINT




                                           VCR MAIN PCB

                                                                  Fig. 1

 HOW TO EJECT THE CASSETTE TAPE
 (If the tape is stuck in the unit)

1) Turn the Gear Worm OE clockwise in the direction of arrow with a screwdriver. (See Fig. 2)
   (Other method ; Remove the screw of Motor Load Ass'y, Separate the Motor Load Ass'y)
2) When Slider S, T approachs the unloading position, rotate holder Clutch counterclockwise after inserting screwdriver in the
   frame's bottom hole in order to wind the unwound tape. (Refer to Fig. 3)
   (If you rotate Gear Worm OE continuously when tape is unwinding, you may cause tape contamination by grease and
   tape damage. Be sure to wind the unwound tape with the unit in the horizontall position.)
3) Rotate Gear Worm OE clockwise using a screwdriver until the mecha is in the eject state. Remove the tape. (Refer to Fig. 2)




                                                                                      FRAME




                                     OE GEAR WORM




                         Fig. 2                                                                Fig. 3
