Image preview - the first page of the document



>> Download Samsung-DVD-VCR documenatation <<

Text preview - extract from the document

Introducing Samsung DVD Recorder & VCR
             ( DVD-VR375 )




                    2008.2.
          Samsung Electronics Co. LTD
              Digital AV Division
              Samsung DVD Recorder & VCR
 General Introduction

 Model No : DVD-VR375
 Market Introduction Date
   : APR 2008 (EU)



 Characteristics

   1. Super picture & sound quality recording with MPEG-2(VBR) on DVD-RW, DVD-R

     compatible with A/V & PC ( Playback only for DVD-RAM )
   2. Convenient control through random accessibility of optical discs
        - One touch recording : Automatic empty area recording
        - Program Navigation
        - High Speed Search and Play
   3. Advanced playback functions for multiple purposes

   (Compatible with DVD, Audio-CD, CD-R/RW(MP-3), DVD-R, DVD-RW Disc)
                                                                              2
      DVD-VR375 Playback & other Features


 Progressive Scan
  By scanning all 576 lines in one pass,
  progressive scanning provides high vertical
  resolution and flicker-free, high-density image
  output that does not suffer from the loss of
  quality during subject movement -- which is
  characteristic of the conventional interlaced
  scanning method.                                  30 Frame/Sec             60 Frame/Sec

 Program Navigator

  Recorded programs are shown as thumbnail pictures, and information such as title, recording
  dates and times are displayed on menu screen. User can choose a desired program.

 Editing
  Simple non-linear editing is possible on menu screen without additional editing
  system. User can delete part of a program or entire program, and edit program title.
                                                                                            3
             DVD-VR375 Key Features
 Recording Features
  MPEG-2 VBR(Variable Bit Rate) Recording
  Creating a DVD video title using DVD-RW/DVD-R
  Automated Quality Adjustment for Timer Recording
  Copying data from a digital camcorder using a DV input jack
  Selectable Recording Mode

 Playing Features
  Progressive Scan both DVD and VCR modes
  Program Navigation

 Other Features
  Easy Editing
  Quick Recording
  Auto Chaptering
  HDMI out /w up-scale
   - Anynet+ (HDMI CEC), up to 1080P                            4
            '08 DVD Recorder New Features

 Samsung's Unique Features          Differential Features
EZ REC mode                    -R Dual Layer Recording
1 sec Quick Recording        DivX Playback
on All Format                  EVQ (Enhanced Video Quality)

             L1200                          L1200




    Convenience                   DSlim & Deluxe
                                   esign
       EZ REC Mode
       (DVDR Like VCR)                Design Identity
     Dual Layer Recording ( only for -R disc)

1 dual layer disc is enough for 3hrs movie (SP mode)

     Single Layer Disc
