Disassembly_n_Reassembly


>> Download Disassembly_n_Reassembly documenatation <<

Text preview - extract from the document
                                                                                          3. Disassembly and Reassembly

3. Disassembly and Reassembly
3-1. Tools for Removal and Reassembly




  Tool image




      No.                    Tool                 Type                                 Remarks
                     Adjustable Wrench
                     Open-end Wrench             1-7/16"     Leg
                                 Vice pliers
                                   Others                    Common tools for servicing
                   (screwdriver, nipper, long nose pliers)   Screwdriver - Philips, flat, Torx T20
                          Nut Driver              10mm       Heater bracket Nut


* Preparation for parts replacement
1. Take out the residual water inside the product.
   (Drain the water by operating the drain pump)
2. Close the water supply valve.
3. Turn off the power & disconnect power cable.
   You must turn off the circuit breaker connected to the product.
4. Pull out the unit from the sink and lay it on the floor.
   Be careful of the drain hose when pulling out the unit.


       Caution
When pulling out or laying the dishwasher down for service, it may be necessary to lower the height of the adjustable
legs to provide the clearance for the removal of the unit, prevent breaking the legs, or damaging the base of the unit.




                                                                                                                          3-1
3. Disassembly and Reassembly

3-2. Standard Disassembly Drawings
Throughout this manual, features and appearance may vary from your model.
   Warning
Always disconnect the electric power supply & water supply before servicing any electrical component, making
ohmmeter checks, or replacing any parts.
    Caution
Before moving the unit, laying it down for service, or removing any parts for service be sure to drain as much of the water
from the unit as possible. Use a protective mat or towel to prevent damage to the floor or having any of the remaining
water spill on the floor.

      All voltage checks should be made with a voltmeter having a full scale range of 250 volts or higher. After service is
      completed, be sure all safety grounding circuits are complete, all electrical connections are secure, and all access
      panels are in place.

Before servicing, make sure to remove all items include baskets inside dishwasher.



         Part                            Photo                                          Description
                        This dishwasher use 2 kinds terminal type.

 Terminal
 - Fasten type
                           Fasten type                     P-Lock type         P-Lock type                    Fasten type
 - P-Lock type




                             Buckle
 Remove the                                                       1. Terminal with buckle.
 Terminal                                                         2. Press the buckle, and pull out the terminal.
 - P-Lock type                                                    * P-lock type for drain pump.




                                                                  1. Use the proper tool to firmly insert or remove
 Remove the                                                          the "fasten" type terminals on the Main PCB, the
 Terminal                                                            dispenser "rinse aid" level sensor, and the heater.
 - Fasten type                                                       Hold both sides of the connection to prevent bending
                                                                     the terminals or breaking the PCB.




3-2
                                                                               3. Disassembly and Reassembly

        Part                        Photo                                  Description
                                                      Preparation:
                                                      * Make sure to disconnect the power.

                                                      1. You can see the Main-PBA case under the door.



                                                      2. Remove the two (2) screws of PBA case and pull
                                                         out the PBA cover carefully.



                                                      3. Remove the all connectors in the PBA include
                                                         two(2) fasten type ones at right side.



                                                      4. Remove the three (3) screws on the PBA board.



                                                      5. Pull out the PBA board carefully..




                                                         When removing the Main PBA, lift up the PBA board
     Main PBA                                            carefully because it is hanging to the PBA case with
                                                         two(2) hooks.




                                                         If you feel hard to disconnect the wire connectors.
                                                         Follow the below.
                                                       a. Release two(2) fasten type connector located right
                                                         side.
                                                       b. Unscrew the three(3) screws in PBA board & pull
                                                         out the PBA board.
                                                       c. Disconnect the wire connectors.




 Reassembly is in the reverse order of the removal.




                                                                                                           3-3
3. Disassembly and Reassembly

         Part                       Photo                                  Description
                                                      Preparation:
                                                      * Make sure to disconnect the power.
                                                      * Remove the lower basket in the dishwasher.
                                                      * Cover the Assy sump with towel for prevent losing
                                                        screws.


                                                      1. Open the door completely.
                                                       Remove the 12 screws holding the tub front,
                                                       frame front, and control panel in place.


                                                         Before removing it, place a cushioned mat on the
                                                         floor to prevent being scratched.
                                                         After removing screws, make sure to hold the tub
                                                         front using your hand. It can prevent closing door
                                                         suddenly and harming you.

      Frame front
                                                         Caution
                                                         Do not place the removed screws on the tub front.
                                                         They may fall into the sump assy.


                                                      2. Pull out the Frame front & the Assy control panel
                                                          carefully.


                                                      3. Remove the Assy control panel from Frame front. (
                                                          Pull out just a little and push down it.)




                                                      Preparation:
                                                      * Disassemble the frame front.

                                                      1. When removing the door latch, lift up the door latch
 Door Lock Switch
                                                         which is fixed by two hooks.
   (Door latch)
                                                         Use a flat screwdriver to remove it.

                                                      2. Release the micro switch.

 Reassembly is in the reverse order of the removal.




3-4
                                                                              3. Disassembly and Reassembly

        Part                        Photo                                 Description
                                                      Preparation:
                                                      * Disassemble the frame front , Assy control panel
                                                          and Door lock switch.
                                                       - Refer the "Frame front" disassembly section to
                                                          separate the Frame front.

                                                      1. Remove the two(2) screws on the control panel
                                                          and release the window panel using flat screw
                                                          driver.
                                                       - Insert the flat screw driver into the gap of screw
                                                          boss and turn it over.

   Control Panel                                      2. Rotate the window panel to upside and
         +                                               disconnect the wire connector.
   Window Panel
    (DMT800)                                          3. Release the two(2) screws on the window panel
                                                         to release the guide LED.




                                                      Preparation:
                                                      * Disassemble the frame front , Assy control panel
                                                          and Door lock switch.
                                                       - Refer the "Frame front" disassembly section to
                                                          separate the Frame front.

                                                      1. Remove two(2) connectors in the display
