Image preview - the first page of the document



>> Download Specifications documenatation <<

Text preview - extract from the document

                                                                                          2. Features and Specifications

2. Features and Specifications
2-1. Features

          Features                                     Description                                    Remarks

                               The upper rack is slanted for larger dishes. The space
Extra large capacity           has been maximized to accommodate a variety of dish
                               sizes.

Elegant design with digital    Digital touch sensors are used in the control panel for more
touch sensors                  simple operation, with a touch of elegance.

                               The smart auto cycle determines the level of soil on the
Increased convenience          dishes and initiates the optimal cycle using this feature
                               saving water, energy and time.

                               Efficient noise control technology is used for the quietest
Extremely quiet operation      possible operation. Your new Samsung dishwasher will be
                               quieter than ever.

                               Cleaning the filter yourself is a thing of the past! This product
Self-cleaning filter           keeps food waste internally while operating, then drains it
                               automatically with the water.

                               With a jet stream like a geyser, Storm Wash effectively
Storm wash
                               cleans big, heavily soiled pots with ease. Look for the built-in
(For DMT800 & DMT700
                               extra nozzle and spray in the specialized Storm Washing
series)                        Zone.

                               Two fans connected to one motor make for better drying
                               performance. Still better, your dishwasher emits no hot
Twin fan condensing drying     steam. Instead, it mixes external fresh air with the internal
                               hot steam during drying to eliminate the steam, making your
                               dishwasher safer and easier to use.




                                                                                                                    2-1
2. Features and Specifications

2-2. Specifications

 Wash capacity                                   14 place settings

 Type                                            Dishwasher

 Model                                           DMT800 Series, DMT700 Series, DMT400 Series

 Power                                           Single-phased alternating current of 60Hz, 15A at 120V

 Used water pressure                             20 ~ 120 psi (140 ~ 830 kPa)

 Wash type                                       Rotating nozzle spray

 Dry type                                        Air diffusion condensing dry system

 Power usage                                     Main Motor : (2-step) 185W/150W, Heater : 1100W

 Standard amount of used water                   5.3~7.9 gallon (20~30L), Normal Cycle

 Size (W
