Image preview - the first page of the document
exploded_DMT800RHS_XAA


>> Download exploded_DMT800RHS_XAA documenatation <<

Text preview - extract from the document
                                                                                  Exploded Views and Parts List



1. Title
Exploded View




Parts List
 No.   Parent              Lvl.   Loc.     Material Code   Description & Specification             SNA   Qty.
 1     DMT800RHS/XAA 1            F176     DD94-01040A     ASSY-DOOR; DMT800,R3-PJT                SNA      1
 2     DMT800RHS/XAA 1                     DD94-01063A     ASSY-WASH; DMT800/700,R3-PJT            SNA      1
 3     DMT800RHS/XAA 1            Z019     DD94-01034A     ASSY-TUB; DMT800,R3-PJT                 SNA      1
 4     DMT800RHS/XAA 1            F167     DD94-01033A     ASSY-BASE; DMT800,R3-PJT                SNA      1
 5     DMT800RHS/XAA 1            F176     DD94-01040A     ASSY-DOOR; DMT800,R3-PJT                SNA      1
 6     DD94-01040A         2      F385     DD64-00060A     HANDLE-DOOR;                            SA       1
                                                           DMR78,STS430,1.0mm,-,-,-,-,-
 7     DD94-01040A         2      F344     DD61-00260A     FRAME-FRONT-HIDDEN;                     SA       1
                                                           DMT800,STAINLESS-STS4
 8     DD94-01040A         2      F197     DD61-00243A     HOLDER-BOLT;                            SA       2
                                                           DM1477,MSWR,OD20,ID5.5,T2.0,
 9     DD94-01064A         3      F366     DD64-00066A     WINDOW-PANEL HIDDEN;                    SA       1
                                                           DMT800,ABS,T1.0,W52,
 10    DD94-01064A         3      F192     DD63-00116A     GUIDE-LED; DMT800,ABS,R3-PJT            SA       4
 11    DD94-01064A         3      F347     DD63-00107A     GUIDE-LED COVER;                        SA       1
                                                           DMT800,ABS,W65,L202,NTR,
 12    DD94-01040A         2      F331     DD94-01064A     ASSY-WINDOW PANEL H; DMT800,R3          SA       1
 13    DD94-01040A         2      F354     DD64-00065A     PANEL-CONTROL-HIDDEN;                   SA       1
                                                           DMT800,ABS,T2.5,W46
 14    DD94-01040A         2      F363     DD62-00082A     SEAL-PANEL-CONTROL;                     SA       1
                                                           DMT800,EPDM,BLK,W40,L
 15    DD94-01040A         2      A008     DD34-00002A     SWITCH-DOOR LOCK;                       SA       1
                                                           38.0245,NORMAL CLOSE,T6
