Image preview - the first page of the document
>> Download electrical_part_list_169 documenatation <<
Text preview - extract from the document
6 Electrical Parts List
6 Electrical Parts List
-You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LE26S81BX Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
LE26S81BX/XEC LE26S81B,N33A/26S80-GJA,26,LCD-TV,SPAIN
0.1 M0001 BN90-01201B ASSY COVER FRONT;26S81,EO,ABS+PMMA,HB,BK 1 S.N.A
..2 T0003 BN96-04750B ASSY COVER P-FRONT;26S81,EO,ABS+PMMA,HB, 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 M0081 6006-001096 SCREW-TAPTITE;BH,+,WP,B,M4.0,L12,ZPC(BLK 4 S.N.A
...3 M0162 6502-001067 CABLE CLAMP;DAFC-1300,ID2.2,T5.2,NYLIN6/ 2 S.N.A
...3 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20 1.118 S.N.A
...3 M0112 BN63-03172B COVER-FRONT;26S81,EO,ABS+PMMA,-,-,-,HB,- 1 S.N.A
...3 T0059 BN64-00366A INDICATOR LED;ROME-I,PC,CLEAR,ALL MODEL 1 S.N.A
...3 T0022 BN64-00467D KNOB CONTROL;MOSEL32,ABS,-,-,-,V0,BK07,- 1 S.A
...3 T0023 BN64-00589A KNOB POWER;32S81,PC,-,-,-,-,VIOLET,-,- 1 S.N.A
...3 T0054 BN64-00590A KNOB-DECORATION;JASMINE 32,ABS,-,-,-,HB, 1 S.N.A
...3 T0175 BN96-04769A ASSY SPEAKER P;16ohm,4pin,5W,Jasmine 23" 1 S.A
...3 T0066 BN96-04748B ASSY COVER P-DECORATION;26S81,ABS,HB,IV1 1 S.N.A
....4 T0056 BN63-03174B COVER-DECORATION;26S81,ABS,HB,IV16,BKM-2 1 S.N.A
....4 BN61-03261C BOSS-TAPE;Tulip,ACRYL,T1.1,W24mm,GRAY,TA 0.6 S.N.A
...3 M0145 BN96-03466A ASSY BOARD P-FUNCTION;SONOMA,SJ06-01-008 1 S.A
...3 M0146 BN96-04884B ASSY BOARD P-POWER & IR;LNT3242HX/XAA,CT 1 S.A
...3 T0069 AA60-00091J SPACER-FELT;-,FELT,330X10,-,-,BLK,T0.5,- 2 S.N.A
...3 T0069 AA60-00171N SPACER-FELT;61L3,FELT,620,T0.5,10 2 S.N.A
0.1 M0002 BN90-01207B ASSY COVER REAR;26S81,EO,HIPS,HB,BK500,R 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 11 S.A
..2 M0013 BN96-04820A ASSY COVER P-REAR;26S81,EO,HIPS,HB,BK500 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 4 S.N.A
...3 M0006 BN63-03194A COVER-REAR;26S81,EO,HIPS,-,-,-,HB,-,BK50 1 S.N.A
...3 T0071 BN64-00555A INLAY-TERMINAL;07,COMMON,EO,PS SHEET,T0. 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,PP,V0,BLK 1 S.N.A
...3 T0101 BN61-03346A BRACKET-WALL;LCD TV,SECC,T1.2 4 S.N.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 1 S.A
0.1 M0216 BN90-01212A ASSY STAND;26S81 1 S.N.A
..2 M0027 BN96-04745A ASSY STAND P-BASE;23,26S81,ABS+PMMA,HB,B 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,-,B,M4,L10,ZPC(WHT),S 4 S.A
...3 T0920 BN61-03024A GUIDE-STAND;JASMINE 26,ABS,BK500,V0 1 S.N.A
...3 BN61-03028A BRACKET-STAND BOTTOM;JASMINE 26",SECC,T1 1 S.N.A
...3 T0004 BN63-03178A COVER-STAND BASE;JASMINE 26",ABS+PMMA,HB 1 S.N.A
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1. 4 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.4 S.N.A
..2 T0524 6902-000520 BAG PE;HDPE/NITRON(DOUBLE),T0.015/T0.5(D 1 S.N.A
0.1 T0852 BN91-01180K ASSY LCD-CMO;LE26R32BX/* 1 S.N.A
..2 M0215 BN07-00364A LCD-PANEL;V260B1-L04,6bit+FRC,26inch,16. 1 S.A
0.1 M0017 BN91-01387A ASSY CHASSIS;LE26S81BX/* 1 S.N.A
..2 M0014 BN94-01194P ASSY PCB MAIN;LE26S81BX/* 1 S.A
...3 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.25 S.N.A
...3 JA306 3701-001400 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,Ni 1 S.A
...3 CN330 3711-000058 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5MM,AN 1 S.A
...3 CN330 3711-004379 HEADER-BOARD TO CABLE;BOX,4P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004531 HEADER-BOARD TO CABLE;BOX,10P,1R,2mm,ANG 1 S.A
...3 CN330 3711-005606 HEADER-BOARD TO CABLE;BOX,30P,2R,2mm,STR 1 S.A
...3 CN330 3711-005842 HEADER-BOARD TO CABLE;BOX,24P,2R,2MM,STR 1 S.A
6-1
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty S.A/S.N.A
...3 JA330 3722-000143 JACK-PHONE;1P(VER),AG,BLK,ANGLE 1 S.A
...3 JA202_EU 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 S.A
...3 JA207_EU 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA332 3722-001163 JACK-VHS;4P,AU,BLK,ANGLE 1 S.A
...3 JA333 3722-002360 JACK-PIN;3P,AU,GRN/BLU/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002543 JACK-PIN;3P,Sn,RED/WHT/YEL,ANGLE 1 S.A
...3 CIS3 BN40-00099A TUNER;HTM-6C/235S,HTM-6C/235S,PAL BG,DK, 1 S.A
...3 M0107 BN63-01847A SHIELD-COVER;ROME,SECC,T0.3,49.5,79.5,HE 1 S.N.A
...3 HDCP BN97-00688A ASSY HDCP;BN46-00018A,PS-42V6S,D73A,GENE 1 S.N.A
....4 BN46-00018A KEY CODE-CERTIFICATE;(HDCP KEY)PPM42M5S, 1 S.N.A
...3 T0174 BN97-01407P ASSY SMD;LE37S81BX 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
