Image preview - the first page of the document
>> Download exploded_view_and_part_list_358 documenatation <<
Text preview - extract from the document
5 Exploded View & Parts List
5 Exploded View and Parts List
- You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
5-1 LE26S81BX Exploded View
M0013
M0014
T0447
M0146
M0215
T0175
T0003 M0115
M0027
5-1
5 Exploded View & Parts List
5-2 LE26S81BX Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-04750B ASSY COVER P-FRONT;26S81,EO,ABS+PMMA,HB, 1 S.A
T0175 BN96-04769A ASSY SPEAKER P;16ohm,4pin,5W,Jasmine 23" 1 S.A
M0215 BN07-00364A LCD-PANEL;V260B1-L04,6bit+FRC,26inch,16. 1 S.A
T0447 BN96-04682B ASSY BRACKET P-PANEL;26R81,AUO 1 S.N.A
M0146 BN61-02207A BRACKET-PANEL SIDE;Bordeaux 26,SECC,T1.2 4 S.N.A
M0115 BN61-02931A BRACKET-STAND LINK;JASMINE 26,SECC,T1.6 1 S.N.A
M0014 BN94-01194A ASSY PCB MAIN;LE26S81BX/* 1 S.A
M0027 BN96-04745A ASSY STAND P-BASE;23,26S81,ABS+PMMA,HB,B 1 S.A
M0013 BN96-04820A ASSY COVER P-REAR;26S81,EO,HIPS,HB,BK500 1 S.A
5-2
5 Exploded View & Parts List
5-3 LE32S81BX Exploded View
M0013
M0014
T0447
M0146
M0215 T0764
T0003
T0531
M0115
T0175 M0027
5-3
5 Exploded View & Parts List
5-4 LE32S81BX Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-04694B ASSY COVER P-FRONT;32S81,EO,ABS+PMMA,HB, 1 S.A
T0175 BN96-04770A ASSY SPEAKER P;8ohm,4pin,10W,Jasmine 32" 1 S.A
M0215 BN07-00315A LCD-PANEL;CLAA320WB02,8bit/60Hz,743*447* 1 S.A
T0447 BN96-04681C ASSY BRACKET P-PANEL;32R81,AUO,SMPS 1 S.N.A
M0146 BN61-02207A BRACKET-PANEL SIDE;Bordeaux 26,SECC,T1.2 4 S.N.A
T0764 BN44-00156A SMPS-LCDTV;MK32P,SEM,AC/DC,180W,AC100 ~ 1 S.A
T0531 BN63-03093B COVER-BOTTOM;32S81,HIPS,-,-,-,HB,-,BK500 1 S.A
M0115 BN61-02947A BRACKET-STAND LINK;JASMINE 32",SECC,T1.6 1 S.N.A
M0014 BN94-01352L ASSY PCB MAIN-CPT;LE32S81BX/*0876B.No tu 1 S.N.A
M0013 BN96-04697A ASSY STAND P-BASE;32S81,-,ABS+PMMA,HB,BK 1 S.A
M0013 BN96-04698A ASSY COVER P-REAR;32S81,EO,HIPS,HB,BK500 1 S.A
5-4
5 Exploded View & Parts List
5-5 LE37S81BX Exploded View
M0013
M0014
T0447
M0146
M0107
T0764
M0215
T0003
M0146
T0531
M0115
T0175 M0027
5-5
5 Exploded View & Parts List
5-6 LE37S81BX Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-04752C ASSY COVER P-FRONT;37S86,EO,ABS+PMMA,HB, 1 S.A
T0175 BN96-04770A ASSY SPEAKER P;8ohm,4pin,10W,Jasmine 32" 1 S.A
M0215 BN07-00366A LCD-PANEL;CLAA370WA03,8bit,37inch,16.7M, 1 S.A
T0447 BN96-04680A ASSY BRACKET P-PANEL;BORDEAUX PLUS37 1 S.N.A
M0146 BN61-02241A BRACKET-PANEL SIDE;Bordeaux 37,SECC,T1.2 1 S.N.A
M0146 BN61-02242A BRACKET-PANEL SIDE;Bordeaux 37,SECC,T1.2 1 S.N.A
T0764 BN44-00157A SMPS-LCDTV;MK37,SEM,AC/DC,280W,AC100 ~ 2 1 S.A
T0531 BN63-03127B COVER-BOTTOM;37,40S81,HIPS,-,-,-,HB,-,BK 1 S.A
M0107 BN63-03039A SHIELD-COVER;MURANO40,PCM,T0.5,IDTV 1 S.N.A
M0115 BN61-02882A BRACKET-STAND LINK;TULIP,40,SECC,T1.6,-, 1 S.N.A
M0014 BN94-01193C ASSY PCB MAIN;LE37S86BDX/* 1 S.A
M0013 BN96-04754A ASSY STAND P-BASE;37,40S81,ABS+PMMA,HB,B 1 S.A
M0013 BN96-04826B ASSY COVER P-REAR;37S86,EO,HIPS,HB,BK500 1 S.A
5-6
5 Exploded View & Parts List
5-7 LE40S81BX Exploded View
M0013
M0014
T0447
M0146
M0215
T0003
M0146
T0531
M0115
T0175 M0027
5-7
5 Exploded View & Parts List
5-8 LE40S81BX Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-04753H ASSY COVER P-FRONT;40S81,EO,ABS+PMMA,HB, 1 S.A
T0175 BN96-04770B ASSY SPEAKER P;8ohm,4pin,10W,600/1250mm, 1 S.A
M0215 BN07-00387A LCD-PANEL; LTA400WT-L06,8bit,40inch,16.7 1 S.A
T0447 BN96-04679A ASSY BRACKET P-PANEL;BORDEAUX PLUS40 1 S.N.A
M0146 BN61-02256B BRACKET-PANEL SIDE;Bordeaux 40,SECC,T1.2 1 S.N.A
M0146 BN61-02257B BRACKET-PANEL SIDE;Bordeaux 40,SECC,T1.2 1 S.N.A
T0531 BN63-03127B COVER-BOTTOM;37,40S81,HIPS,-,-,-,HB,-,BK 1 S.A
M0115 BN61-02882A BRACKET-STAND LINK;TULIP,40,SECC,T1.6,-, 1 S.N.A
M0014 BN94-01352P ASSY PCB MAIN-AMLCD;LE40S81BX/AST 1 S.A
M0027 BN96-04754A ASSY STAND P-BASE;37,40S81,ABS+PMMA,HB,B 1 S.A
M0013 BN96-04822A ASSY COVER P-REAR;40S81,EO,HIPS,HB,BK500 1 S.A
5-8
5 Exploded View & Parts List
5-9 LE46S81BX Exploded View
M0013
M0014
M0215
T0003
T0531
M0115
T0175
M0027
5-9
5 Exploded View & Parts List
5-10 LE46S81BX Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-04738B ASSY COVER P-FRONT;46S81,EO,ABS+PMMA,HB, 1 S.A
T0175 BN96-04770C ASSY SPEAKER P;8ohm,4pin,10W,750/1250mm, 1 S.A
M0215 BN07-00389A LCD-PANEL; LTA460WT-L11,8bit,46inch,16.7 1 S.A
T0447 BN96-05214D ASSY BRACKET P-PANEL;46S81,KO 1 S.N.A
T0531 BN63-03185B COVER-BOTTOM;46S81,HIPS,-,-,-,HB,-,BK500 1 S.A
M0014 BN94-01194R ASSY PCB MAIN-AMLCD;LE46S81BX/* 1 S.A
M0027 BN96-04743A ASSY STAND P-BASE;46S81,ABS+PMMA,HB,BK23 1 S.A
M0013 BN96-04825A ASSY COVER P-REAR;46S81,EO,HIPS,HB,BK500 1 S.A
5-10
