Image preview - the first page of the document
BN44-00517C


>> Download BN44-00517C documenatation <<

Text preview - extract from the document
                                                                                                           AOD4184A
                                                                                                 40V N-Channel MOSFET



  General Description                                                    Product Summary

  The AOD4184A combines advanced trench MOSFET                           VDS                                   40V
  technology with a low resistance package to provide                    ID (at VGS=10V)                       50A
  extremely low RDS(ON). This device is well suited for high             RDS(ON) (at VGS=10V)                  < 7m
  current load applications.                                             RDS(ON) (at VGS = 4.5V)               < 9.5m




                                                                         100% UIS Tested
                                                                         100% Rg Tested




                                      TO252
                                      DPAK                                                                 D
                    Top View                   Bottom View

                                           D
             D


                                                                                                 G
                                          S                          G
                                                                                                           S
                                    G                          S

Absolute Maximum Ratings TA=25
