Image preview - the first page of the document
>> Download samsung_bn44_00520f_power_supply_sm documenatation <<
Text preview - extract from the document
REQUEST FOR APPROVAL
ITEM DC Voltage Stabilized Supply
SPEC.
SPEC
Maker P/N PD46B1QE_CSM
CODE NO. BN44-00520F
APPLIED TO 40 & 46 inch
REFERENCE REV R.A
2012.07.03
DRAWING CHECK AGREEMENT APPROVAL
H.H.Lee N.J.Park S.H.Kim
2012.07.18 2012.07.18 2012.07.18
A TERM OF VALIDITY OVER AT LEAST 15-YEARS ISSUED DATE
Indemnification
SEMCO will indemnify, hold harmless, and at Samsung's request, defend Samsung and Samsung's directors,
officers, employees, agents and independent contractors from and against any loss, cost, liability or expense
(including court costs and reasonable fees of attorneys and other professionals) arising out of or resulting from
any third party claim that any Products and/or Components provided by SEMCO infringes patent, copyright, trade
secret right or other intellectual property right. If SEMCO receives notice of an alleged patent, copyright, trade
secret or other intellectual property right infringement or if Samsung's use of the Products and/or the
Components provided by SEMCO shall be prevented by permanent injunction for reasons of patent, copyright or
trade secret infringement, SEMCO may, at its sole option and expense, procure for Samsung the right to continued
use of the Products and/or the Components as provided hereunder, or modify the allegedly infringing item such
Samsung
MAKER TEL 82-31-210-3458
Electro-Mechanics.Co.,Ltd O
ADDRESS 314 Maetan3-Dong, Yeongton-Gu,
(HEADQUARTER) Suwon, Gyunggi-Do,Korea 443-743
Dong Guan 86-769-8330-5000
FACTORY 1 TEL
Samsung Electro-Mechanics (EXT) 6401
O
Hengkeng Management Area Liaobu Town,
ADDRESS
Dongguan City, Guangdong Province, China
Dongguan AP tech 86-769-8895-0018
FACTORY 2 TEL
Electronics Co.,Ltd 86-769-8281-5981
O
DongGuan APtech Electronics Co., Ltd. Tangchun East Jinfu, Huanan Park, Liaobu Town,
ADDRESS
Dongguan City, Guangdong Province 518407, China
Dongguan IM Digital 86-769-8303-8000
FACTORY 3 TEL
Electronics Co.,Ltd (EXT) 6630
O
Baiye lnd. zone Liaobu Town,
ADDRESS
Dongguan City, Guangdong Province, China
SEMTHAI Samsung
FACTORY 4 TEL 66-38-526-101
Electro-Mechanics Thailand O
WELLGROW INDUSTRIAL ESTATE, 93 Moo 5 T. Bangsamak,
ADDRESS
A.Bangpakong, Chachoengsao 24180 THAILAND
, .
We are not supposed to force the partners to provide the Technical Document without valid reason.
pp p p
The acquired Technical Document should not be used elsewhere.
SPECIFICATION STD RECORD NO. BN44-00520F
MARK PD46B1QE_CSM PAGE PUB.DATE 2012.07.18
(DOCUMENT INFORMATION) PAGE REV.DATE
CONTENTS
1. REVISION HISTORY
2. ELECTRICAL SPECIFICATION
3. COMPONENT LIST
(4 Points Conformity final result)
4. CIRCUIT DRAWING
5. BLOCK DIAGRAM
6. BOARD PHOTOGRAPHY
7. PCB DRAWING
8. TEST RESULT
9. STRESS DATA
10. EDGE DATA
11. PACKING DRAWING PART
12. LABEL DRAWING PART
13. RoHS 6 MATERIAL INGREDIENT DATA
14. MVT ACTUAL INSPECTION RESULT
SPECIFICATION STD RECORD NO. BN44-00520F
MARK PD46B1QE_CSM PAGE PUB.DATE 2012.07.18
(REVISION HISTORY) PAGE REV.DATE
1.
1 REVISION HISTORY
SPECIFICATION STD RECORD NO. BN44-00520F
0 PD46B1QE_CSM PAGE PUB.DATE 2012.07.18
(REVISION HISTORY) PAGE REV.DATE
:
Revision
No.
Ass'y PCB Loc
SR (Assy Rev : Rev R.A, PCB Rev : Rev 1.0, Date : 2011.06.21)
SPECIFICATION STD RECORD NO. BN44-00520F
MARK PD46B1QE_CSM PAGE PUB.DATE 2012.07.18
(ELECTRICAL SPECIFICATION) PAGE REV.DATE
2.
2 ELECTRICAL SPECIFICATION
SPECIFICATION STD RECORD NO. BN44-00520F
PD46B1QE_CSM PAGE PUB.DATE 2012.07.18
(ELECTRICAL SPECIFICATION) PAGE REV. DATE
CONTENTS
1. General Description
2. Suitable Load
3. Electrical Specification(DC VSS)
3-1 INPUT REQUIREMENTS
3-2 OUTPUT REQUIREMENTS
4. Test Inspection
4-1 Load regulation
4-2 Line regulation
4-3 Input Current
4-4 Ripple & Noise
4-5 Minimum Load Power Consumtion
4-6 Efficiency
4-7 Inrush Current
4-8 Short Circuit Protection
5. Other Test
5-1 Hi-Pot
5-2 Insulation Resistance
5-3 GND Continuity Test
5-4 Burn-in
5-5 Earth Leakage Current
6. LED driver
7. Connector & Pin Assignment
7-1 AC Input Connector
7-2 DC Output Connector
7-3 LED Output Connector
7-4 MECHANICAL OUT DRAWING
SPECIFICATION STD RECORD NO. BN44-00520F
PD46B1QE_CSM PAGE PUB.DATE 2012.07.18
(ELECTRICAL SPECIFICATION) PAGE REV. DATE
1. General Description
This is a PD-Board (Monolithic Power and LED driver)
which is developed for driving LED Lamp panel backlight system.
2. Suitable Load
LED TV MODULE : 40" & 46" _LED panel
3. Electrical Specification
3-1 INPUT REQUIREMENTS
List Requirement Input Range
Regular Input Voltage AC100V ~120V , AC 200~240V
Variable Input Voltage AC90V ~264V
Regular Input Current Max 3.5Arms
Frequency Regular Frequency 50Hz~60Hz
Variable Frequency 47Hz~63Hz
3-2 OUTPUT REQUIREMENTS
NO List CH1 CH2 CH3 CH4
1 Channel A5V B5V B13V Vamp
2 Regular Output Voltage +5.3Vdc +5.3Vdc +12.8Vdc +12.8Vdc
3 Typical Output Current 70mA 3.4A 2.2A 0.3A
4 Max Output Current 80mA 3.7A 2.4A 2.3A
5 Min Output Current 0A 0A 0A 0A
6 Peak Output Current 100mA 4.1A 2.7A 3.3A
7 Load Regulation Voltage 5.04V~5.57V 5.04V~5.57V 11.88V~13.13V 11.88V~13.13V
8 Line Regulation Voltage 5.04V~5.57V 5.04V~5.57V 11.88V~13.13V 11.88V~13.13V
9 Ripple & Noise 200mV 200mV 500mV 500mV
Stress(Voltage,Current,Temperature) test : typ. Load condition
4. Test Inspection
4-1 Load regulation
1) Test Requirements : Input Votage : 100Vac / 240Vac
2) A method of measurements : Auto Power Tester
3) Voltage Criterion for Judging
Output Minimum Maximum Output Current Remark
Voltage Voltage Voltage Conditions
A5V : +5.3Vdc +5.04Vdc +5.57Vdc 0A~70mA
B5V : +5.3Vdc +5.04Vdc +5.57Vdc 0A~3.4A
B13V : +12.8Vdc +11.88Vdc +13.13Vdc 0A~2.2A
Vamp : +12.8Vdc +11.88Vdc +13.13Vdc 0A~0.3A
Output voltage value measures IP Board connector in (CNM803) only.
SPECIFICATION STD RECORD NO. BN44-00520F
PD46B1QE_CSM PAGE PUB.DATE 2012.07.18
(ELECTRICAL SPECIFICATION) PAGE REV. DATE
4-2 Line regulation
1) Test Requirements : Input Votage : 100Vac ~ 240Vac
2) A method of measurements : Auto Power Tester
3) Voltage Criterion for Judging
Output Minimum Maximum Output Current Remark
Voltage Voltage Voltage Conditions
A5V : +5.3Vdc +5.04Vdc +5.57Vdc 0A~70mA
B5V : +5.3Vdc +5.04Vdc +5.57Vdc 0A~3.4A
B13V : +12.8Vdc +11.88Vdc +13.13Vdc 0A~2.2A
Vamp : +12.8Vdc +11.88Vdc +13.13Vdc 0A~0.3A
Output voltage value measures IP Borad connector in (CNM803) only.
4-3 Input Current
1) Test Requirements :
AC Input A5V B5V B13V Vamp
90Vac 70mA 3.4A 2.2A 0.3A
2) A method of measurements : Auto Power Tester
3) Criterion for Judging : < 3.5Arms
4-4 Ripple & Noise
The power supply shall not exceed the following limits on the indicated
voltage for 60Hz or 50Hz ripple, switching frequency ripple and noise
dynamic load variation measured with a 20MHz bandwidth.
1) Test Requirements :
AC Input A5V B5V B13V Vamp
100Vac 70mA 3.4A 2.2A 0.3A
240Vac 70mA 3.4A 2.2A 0.3A
2) A method of measurements : Auto Power Tester
3) Criterion for Judging
A5V B5V B13V Vamp
200mVp-p 200mVp-p 500mVp-p 500mVp-p
Colume A : Out Voltage
Colume B : 60Hz Ripple + Switching Ripple & Switching Ripple & Noise
(Ripple and Noise are measured at the end of output cables witch are added
a 0.1F ceramic cap. and a 47F electrolytic cap. )
SPECIFICATION STD RECORD NO. BN44-00520F
PD46B1QE_CSM PAGE PUB.DATE 2012.07.18
(ELECTRICAL SPECIFICATION) PAGE REV. DATE
4-5 Minimum Load Power Consumtion
1) Test Requirements : Remote Off
AC Input Stand-by
230Vac 2mA
2) A method of measurements : Auto Power Tester
3) Criterion for Judging : Input power 27mW under
4-6 Efficiency
1) Test Requirements :
AC Input A5V B5V B13V Vamp
110Vac 70mA 3.4A 2.2A 0.3A
2) A method of measurements : Auto Power Tester
3) Criterion for Judging : Min 80%
4) Test condition : Efficiency should be tested Typ-load condition(Stand by+Multy+LED)
AC-110V, AC-220V, LED Dimming Duty 100% ~ 20% PF 0.9
4-6 Inrush Current
1) Test Requirements :
AC Input A5V B5V B13V Vamp
90Vac 70mA 3.4A 2.2A 0.3A
2) Criterion for Judging : No Damage
2) A method of measurements : SPECIFICATION STD RECORD NO. BN44-00520F
3) Criterion for Judging : No dam PD46B1QE_CSM PAGE PUB.DATE 2012.07.18
(ELECTRICAL SPECIFICATION) PAGE REV. DATE
4-7 Short Circuit Protection
1) Test Requirements :
AC Input A5V B5V B13V Vamp
100Vac 70mA 3.4A 2.2A 0.3A
240Vac 70mA 3.4A 2.2A 0.3A
2) A method of measurements : Auto Power Tester
3) Criterion for Judging : No Damage
OCP, Criterion for Judging : No Damage
OVP, only Internal test. Criterion for judging : No damage
5. Other Test
5-1 Hi-Pot
SPECIFICATION STD RECORD NO. BN44-00520F
PD46B1QE_CSM PAGE PUB.DATE 2012.07.18
(ELECTRICAL SPECIFICATION) PAGE REV. DATE
5-2 Insulation Resistance
1) Test Requirements - Input Voltage : 500Vdc
- Temparature : 25+/-5'C
2) Criterion for Judging : Insulation resistance > 100Mohm
5-3 GND Continuity Test
1) Test Requirements - Input current : 25A
- Measurement Time : 3sec
- Temparature : 25+/-5'C
2) A method of measurements : Primary inlet F.G to secondary GND
3) Criterion for Judging : < Resistor 100mohm
5-4 Burn-in
1) AC Input Voltage : 110V or 220V (Factory's AC Power Source if not specified)
2) AC Input Frequency : 50Hz or 60Hz (Factory's AC Power Source if not specified)
3) AC Input ON/OFF : ON(19Minutes) -> OFF/ON(1Minute) -> ON(19Minutes)
OFF/ON : "OFF" for 2 Seconds, "ON" for 4 Seconds. 10 Cycles.
4) Duration : 2 Hours
5) Output Load : 80% Typical Load for All Outputs
6) Ambinent Temperature : 45◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
