Image preview - the first page of the document
>> Download 11_Electrical Part List documenatation <<
Text preview - extract from the document
6 Electrical Parts List
6 Electrical Parts List
You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LA15S51BP Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
0 LA15S51BPX/SAP LA15S51BP,Q10D/15A90-GPL,15,LCD-TV,SINGA 0
1 M0001 BN90-00710B ASSY COVER FRONT;SP15EO 1 SNA
..2 T0003 BN96-01864B ASSY COVER P-FRONT;SP15EO,ABS,V0,GR70,SV 1 SA
...3 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 2 SNA
...3 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 1 SNA
...3 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 2 SNA
...3 M0081 6003-001467 SCREW-TAPTITE;PWH,+,B,M3,L10,ZPC(YEL) 4 SNA
...3 M2893 BN39-00613B LEAD CONNECTOR;SPARTA,UL1061#28,UL/CSA,1 1 SA
...3 T0750 BN63-01742B COVER-MASK;SP15EO,HIPS,V0,BK500,BKM1143 1 SNA
...3 M0112 BN63-01743A COVER-FRONT;SP15,ABS,V0,GR70,SV012P 1 SNA
...3 T0057 BN64-00031A BADGE-BRAND;RB15AS,AL,T1.4,6.3,40.1,SILI 1 SNA
...3 M0007 BN64-00330A KNOB-FUNCTION;SPARTA,ABS,HB,BK07,HI-GLOS 1 SNA
...3 T0175 BN96-01690A ASSY SPEAKER P;16OHM,LEFT,3W,250MM,SPART 1 SA
...3 M0145 BN96-01883A ASSY BOARD P-FUNCTION;SPARTA,CT5000-3240 1 SA
...3 T0714 BN96-01884A ASSY BOARD P-IR;SPARTA,CT5000-3250,IR BO 1 SA
...3 T0175 BN96-01891A ASSY SPEAKER P;16ohm,Right,3W,550mm,Spar 1 SA
...3 T0382 BP61-00509C HOLDER-CARE;PJT,ACRYL-FOAM,T0.25,W20.0mm 0.28 SNA
...3 T0299 BN64-00370A WINDOW-RMC LED;SP20UO,ACRYL,DIFFUSIVE 1 SNA
...3 T0069 AA60-00091D SPACER-FELT;-,FELT,200X10,-,-,BLK,T0.35, 2 SNA
...3 T0069 AA60-00091K SPACER-FELT;-,FELT,330X10,-,-,BLK,T0.35, 2 SNA
...3 T0069 AA60-00171F SPACER-FELT;50L2,FELT,350,T0.5,5 2 SNA
1 M0002 BN90-00712D ASSY COVER REAR;SP15SO 1 SNA
..2 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 2 SNA
..2 M0013 BN96-01865D ASSY COVER P-REAR;SP15SO,HIPS,V0,GR86 1 SA
...3 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 1 SNA
...3 M0114 BN61-01576A HOLDER-WIRE;SP20,HIPS,V0,GR86 1 SNA
...3 BN63-01178L COVER-INLAY;SPSO,PC SHEET,T0.5,SPARTA 1 SNA
...3 M0006 BN63-01744A COVER-REAR;SP15UO,HIPS,V0,GR86 1 SNA
...3 T0069 AA63-60001E SPACER-FELT;-,FELT,-,-,-,BLK,0.5,-,55X15 2 SNA
...3 T0069 AA63-60131J SPACER-FELT;54J9,62J9,FELT,-,-,-,-,T0.5, 1 SNA
...3 T0067 BP60-00061Q SPACER-SCREEN;SP20UO,SPONGE,35,T2.0,20,E 2 SNA
1 M0216 BN90-00713A ASSY STAND;SP15 1 SNA
..2 M0081 6003-001324 SCREW-TAPTITE;BH,+,B,M4,L16,NI PLT,SWRCH 4 SNA
..2 M0013 BN96-01867A ASSY STAND P-BASE;SPARTA 15,HIPS,HB,GR86 1 SA
...3 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 4 SNA
...3 M0081 6003-001001 SCREW-TAPTITE;FH,+,B,M3,L8,ZPC(BLK),SWRC 5 SNA
...3 BN61-01595A BRACKET-STAND BOTTOM;SP15UO,SECC,T1.0 1 SNA
...3 M0111 BN63-01794A COVER-STAND;SP15,HIPS,T2.5,HB,GR86,SV012 1 SNA
...3 BN63-01795A COVER-STAND SUB;SP15,ABS,T2.5,HB,GR86,SV 1 SNA
...3 BN64-00333A KNOB-LOCKING;SPARTA,ABS,HB,GR86,SVM3012 1 SNA
...3 T0132 BN73-60002C RUBBER FOOT;VENICE 15",RUBBER,DIA 14,1.0 4 SNA
...3 T0022 BN96-01866A ASSY HINGE P-SIMPLE;SP15UO 1 SNA
1 BN91-00567K ASSY LCD-S3;ES15/MB15,S3 1 SNA
..2 M0019 BN07-00111A LCD;LTM150XH-L06,CZB,6BIT FRC,331.6*254. 1 SA
1 M0112 BN91-00844R ASSY SHIELD;LA15S51BPX/SHI,PL15KE(S) 1 SNA
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 4 SNA
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 4 SNA
..2 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 2 SNA
..2 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 6 SNA
..2 M0162 6502-000121 CABLE CLAMP;DAMC-101,D7~8,L19,SCP-1,NTR 1 SNA
..2 M2893 BN39-00687A LEAD CONNECTOR;Venice PLUS,UL1061#28,20P 1 SA
..2 M0174 BN44-00112B IP BOARD;SSIP-15-SP,Venice,3.0mA,6.7mA,5 1 SA
..2 T0081 BN61-01234A HOLDER-INVERTER;MATISSE,ABS V0,BK07 2 SNA
..2 BN96-01875A ASSY SHIELD P-PANEL;SP15S5,SECC,T1.0 1 SNA
...3 T0514 BN61-01597A BRACKET-SUPPORT;SP15UO,SECC,T1.0 1 SNA
...3 M0125 BN63-01740A SHIELD-PANEL;LN15S51B,SECC,T1.0,CMO 1 SNA
1 M0017 BN91-00940R ASSY CHASSIS-STZ;LA15S51BPX/SHI,PL15KE(S 1 SA
..2 M0014 BN94-00747R ASSY PCB MAIN-ATZ;LA15S51BPX/SHI,PL215KE 1 SNA
...3 T0245 0202-001522 SOLDER-WIRE FLUX;LFA3-107,-,D1.2,96.5Sn/ 0.03 SNA
6-1
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
...3 Q802 0501-000321 TR-SMALL SIGNAL;KSB1116-Y,PNP,750mW,TO-9 1 SA
...3 Q804 0501-000321 TR-SMALL SIGNAL;KSB1116-Y,PNP,750mW,TO-9 1 SA
...3 FT206 2904-001143 FILTER-SAW AV;38.9MHz,SIP5K,ST,18dB,B/G, 1 SA
...3 FT205 2904-001195 FILTER-SAW AV;38.9MHz,SIP5K,ST,17.9dB,B/ 1 SA
...3 CN908 3701-001294 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,AU 1 SA
...3 CN100 3711-004712 HEADER-BOARD TO CABLE;BOX,9P,1R,2mm,STRA 1 SA
...3 CN401 3711-005884 HEADER-BOARD TO BOARD;BOX,30P,2R,2mm,ANG 1 SA
...3 CN900 3722-000158 JACK-PIN;1P,SN,YEL,ANGLE 1 SA
...3 CN909 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 SA
...3 CN903 3722-001734 JACK-VHS;4P,SN,BLK,STRAIGHT 1 SA
...3 CN913 3722-001846 JACK-PIN;2P,8.3MM,AU,WHT/RED,- 1 SA
...3 CN901 3722-002143 JACK-PIN;5P,NI,GRN/BLU/RED/WHT/RED,STRAI 1 SA
...3 CIS3 BN40-00077A TUNER;TECH0849PG31B(S),TECH0849PG31B(S), 1 SA
...3 BN97-00647Q ASSY SMD-S3;LA15S51BPX/SHI,PL15KE(S) 1 SNA
....4 CIS5 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
