Image preview - the first page of the document
>> Download 03_Exploded View & Part List documenatation <<
Text preview - extract from the document
5 Exploded View & Parts List
5 Exploded View and Parts List
- You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
5-1 LA27S71B1 Exploded View
M0013
T0447 T0159
M0215
T0003
T0175
M0014
T0175
M0013
5-1
5 Exploded View & Parts List
5-2 LA27S71B Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-03836B ASSY COVER P-FRONT;27T70,CO,ABS+PMMA,HB, 1 S.A
T0175 BN96-03279A ASSY SPEAKER P;16ohm,Sonoma 26,Left,5W,N 1 S.A
T0175 BN96-03280A ASSY SPEAKER P;16ohm,Sonoma 26,Right,5W, 1 S.A
M0215 BN07-00369A LCD-PANEL;V270B1-L04,8bit,27inch,16.7M,1 1 S.A
T0447 BN96-03944A ASSY BRACKET P-PANEL;SONOMA27, EO,READY, 1 S.N.A
M0014 BN94-01046E ASSY PCB MAIN;LA27S71BX/* 1 S.A
T0447 BN96-03944A ASSY BRACKET P-PANEL;SONOMA27, EO,READY, 1 S.N.A
M0013 BN96-03945B ASSY STAND P-BASE;SONOMA,27,ABS+PMMA,HB, 1 S.A
M0013 BN96-04031A ASSY COVER P-REAR;27S71,CO,HIPS,HB,BK500 1 S.A
5-2
5 Exploded View & Parts List
5-3 LA32S71B3 / LA32S72B Exploded View
M0014
T0159
T0447
M0215
M0013
T0076
T0003
T0175
M0013
T0175
5-3
5 Exploded View & Parts List
5-4 LA32S71B3 Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-03628E ASSY COVER P-FRONT;32T70,CO,ABS+PMMA,HB, 1 S.A
T0175 BN96-03247B ASSY SPEAKER P;8ohm,Yellow/Black,470mm,1 1 S.A
T0175 BN96-03248B ASSY SPEAKER P;8ohm,Red/Black,950mm,10W, 1 S.A
M0215 BN07-00348A LCD-PANEL;V315B1-L01,8bit,31.5inch,16.7M 1 S.A
T0447 BN96-02999A ASSY BRACKET P-PANEL;BORDEAUX,32,AMLCD,S 1 S.N.A
T0076 BN39-00615D CBF HARNESS;BORDEAUX,1617#22,3P,1P,RING, 1 S.A
M0014 BN94-01046K ASSY PCB MAIN;LA32S71BX/* 1 S.A
T0159 BN96-03775A ASSY PCB P-SMPS;FreeVoltage SMPS,LA32R71 1 S.A
M0013 BN96-03188D ASSY COVER P-REAR;32T71,CO,HIPS,HB,BK500 1 S.A
M0013 BN96-03698B ASSY STAND P-BASE;SONOMA,32,ABS+PMMA,HB, 1 S.A
5-5 LA32S72B Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-03628M ASSY COVER P-FRONT;32S72,SO,ABS+PMMA,HB, 1 S.A
T0175 BN96-03247B ASSY SPEAKER P;8ohm,Yellow/Black,470mm,1 1 S.A
T0175 BN96-03248B ASSY SPEAKER P;8ohm,Red/Black,950mm,10W, 1 S.A
M0215 BN07-00348A LCD-PANEL;V315B1-L01,8bit,31.5inch,16.7M 1 S.A
T0447 BN96-02999A ASSY BRACKET P-PANEL;BORDEAUX,32,AMLCD,S 1 S.N.A
T0076 BN39-00615D CBF HARNESS;BORDEAUX,1617#22,3P,1P,RING, 1 S.A
M0014 BN94-01046K ASSY PCB MAIN;LA32S71BX/* 1 S.A
T0159 BN96-03775A ASSY PCB P-SMPS;FreeVoltage SMPS,LA32R71 1 S.A
M0013 BN96-03188E ASSY COVER P-REAR;32T71,SO,HIPS,HB,BK500 1 S.A
M0013 BN96-03698B ASSY STAND P-BASE;SONOMA,32,ABS+PMMA,HB, 1 S.A
5-4
5 Exploded View & Parts List
5-6 LA37S71B1 Exploded View
M0014
T0159
T0447
M0215
M0013
T0003
T0076
T0175
M0013
T0175
5-5
5 Exploded View & Parts List
5-7 LA37S71B Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-04044B ASSY COVER P-FRONT;37S71,SO,ABS+PMMA,HB, 1 S.A
T0175 BN96-03247A ASSY SPEAKER P;8ohm,Sonoma 32,Left,10W,N 1 S.A
T0175 BN96-03248A ASSY SPEAKER P;8ohm,Sonoma 32,Right,10W, 1 S.A
M0215 BN07-00255A LCD-PANEL;T370XW01,8bit,877.0*514.6*54.7 1 S.A
T0447 BN96-03253A ASSY BRACKET P-PANEL;BORDEAUX-2,37,AUO,S 1 S.N.A
T0076 BN39-00615D CBF HARNESS;BORDEAUX,1617#22,3P,1P,RING, 1 S.A
M0014 BN94-01046G ASSY PCB MAIN;LA37S71BX/* 1 S.A
T0159 BN96-03050A ASSY PCB P-SMPS;Bordeaux 37 PFC,LE37R71B 1 S.A
M0013 BN96-04119A ASSY COVER P-REAR;37S71,SO,HIPS,HB,BK500 1 S.A
M0013 BN96-03697B ASSY STAND P-BASE;SONOMA,40,ABS+PMMA,HB, 1 S.N.A
5-6
5 Exploded View & Parts List
5-8 LA40S71B Exploded View
M0014
M0174
T0447
M0215
M0013
T0003
T0076
T0175
M0013
T0175
5-7
5 Exploded View & Parts List
5-9 LA40S71B Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-03394G ASSY COVER P-FRONT;40T70,SO,ABS+PMMA,HB, 1 S.A
T0175 BN96-03247A ASSY SPEAKER P;8ohm,Sonoma 32,Left,10W,N 1 S.A
T0175 BN96-03248A ASSY SPEAKER P;8ohm,Sonoma 32,Right,10W, 1 S.A
M0215 BN07-00264A LCD-PANEL;LTA400WT-L01,8bit,952*551*51.0 1 S.A
T0447 BN96-03528B ASSY BRACKET P-PANEL;SONOMA,40EO,READY,S 1 S.N.A
T0076 BN39-00615D CBF HARNESS;BORDEAUX,1617#22,3P,1P,RING, 1 S.A
M0014 BN94-01046H ASSY PCB MAIN;LA40S71BX/* 1 S.A
M0174 BN44-00134C IP BOARD;PSIV230601A,40"BORDEAUX,2.0~3.0 1 S.A
M0013 BN96-03187E ASSY COVER P-REAR;40S71,SO,-,HIPS,HB,BK5 1 S.A
M0013 BN96-03697B ASSY STAND P-BASE;SONOMA,40,ABS+PMMA,HB, 1 S.A
5-8
