Image preview - the first page of the document
>> Download 11_Electrical Part List documenatation <<
Text preview - extract from the document
6 Electrical Parts List
6 Electrical Parts List
You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LA27S71B1 Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
0 LA27S71B1X/XTT LA27S71B1,Q52G/27S70-GSM,27,LCD-TV,CHINA 0
0.1 M0001 BN90-00978B ASSY COVER FRONT;27T70,CO,ABS+PMMA,HB,BK 1 S.N.A
..2 M0081 6006-001096 SCREW-TAPTITE;BH,+,WP,B,M4.0,L12,ZPC(BLK 4 S.N.A
..2 T0175 BN96-03279A ASSY SPEAKER P;16ohm,Sonoma 26,Left,5W,N 1 S.A
..2 T0175 BN96-03280A ASSY SPEAKER P;16ohm,Sonoma 26,Right,5W, 1 S.A
..2 T0003 BN96-03836B ASSY COVER P-FRONT;27T70,CO,ABS+PMMA,HB, 1 S.A
...3 M0162 6502-001067 CABLE CLAMP;DAFC-1300,ID2.2,T5.2,NYLIN6/ 2 S.N.A
...3 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20 1.118 S.N.A
...3 M0112 BN63-02656B COVER-FRONT;27T70,CO,ABS+PMMA,HB,BK23,S/ 1 S.N.A
...3 T0059 BN64-00379A INDICATOR LED;ROME-II,23,PC,CLEAR 1 S.N.A
...3 T0061 BN64-00453A WINDOW-REMOCON;32R71,PC,V0,VIOLET,DIFFUS 1 S.N.A
...3 T0022 BN64-00467A KNOB CONTROL;SONOMA26,32,40,ABS,-,-,-,V0 1 S.A
...3 T0054 BN64-00477A KNOB-DECORATION;SONOMA26,32,40,ABS,HB,GR 1 S.N.A
...3 M0146 BN96-03437A ASSY BOARD P-POWER;BORDEAUX2,CT5000-4150 1 S.A
...3 M0145 BN96-03466A ASSY BOARD P-FUNCTION;SONOMA,SJ06-01-008 1 S.A
...3 T0067 BP60-00032K SPACER-SCREEN;56L5,EVA,V0,T1.0,295 6 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 1 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 T0056 BN63-02658B COVER-DECORATION;SONOMA27,HIPS,HB,GR503, 1 S.N.A
...3 T0023 BN64-00476D KNOB POWER;SONOMA,26,32,40,HIPS,-,-,-,HB 1 S.N.A
0.1 M0002 BN90-00979B ASSY COVER REAR;27T71,CO,HIPS,HB,BK500 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 2 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 9 S.A
..2 M0013 BN96-04031A ASSY COVER P-REAR;27S71,CO,HIPS,HB,BK500 1 S.A
...3 T0101 BN61-02058A BRACKET-WALL;23,27,MGM,SECC,T1.6 2 S.N.A
...3 M0006 BN63-02789A COVER-REAR;GSM27,HIPS HB,BK500,TTSEC 1 S.N.A
...3 T0071 BN64-00445C INLAY-TERMINAL;26R71,PS SHEET,T0.5,-,-,B 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,PP,V0,BLK 1 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 4 S.N.A
0.1 M0216 BN90-01005C ASSY STAND;27S70,EO,SO,-,ABS+PMMA,HB,BK2 1 S.N.A
..2 T0524 6902-000561 BAG PE;HDPE+NITRON(DOUBLE),T0.015+T0.5,W 1 S.N.A
..2 M0013 BN96-03945B ASSY STAND P-BASE;SONOMA,27,ABS+PMMA,HB, 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 3 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,-,B,M4,L10,ZPC(WHT),S 6 S.A
...3 BN61-01830A BRACKET-STAND BOTTOM;26 MILANO,SECC,T2.0 1 S.N.A
...3 T0920 BN61-02369B GUIDE-STAND;SONOMA,26,HIPS,V0,BK500,NON 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.4 S.N.A
...3 T0004 BN63-02696A COVER-STAND BASE;GML26,ABS+PMMA,HB,BK23, 1 S.N.A
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1. 6 S.N.A
0.1 BN91-01114F ASSY SHIELD-CRE;LA27S71BX/* 1 S.N.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 3 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 4 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 4 S.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 6 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 1 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 4 S.N.A
..2 M0081 6003-001439 SCREW-TAPTITE;BH,+,-,S,M4,L8,ZPC(WHT),SW 1 S.N.A
..2 M2893 BH39-00362B LEAD CONNECTOR;RE32**,UL1007#26,5P,150mm 1 S.A
..2 T0076 BN39-00615D CBF HARNESS;BORDEAUX,1617#22,3P,1P,RING, 1 S.A
..2 M2893 BN39-00659A LEAD CONNECTOR;RE32*CMO,UL1007#26,14/12P 1 S.A
6-1
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
..2 M2893 BN39-00691B LEAD CONNECTOR;LE32R71BX,UL1007#26,16P,1 1 S.A
..2 M2893 BN39-00721A LEAD CONNECTOR-LVDS;Sonoma,UL1571#30,30P 1 S.A
..2 M0146 BN61-02207A BRACKET-PANEL SIDE;Bordeaux 26,SECC,T1.2 2 S.N.A
..2 M0115 BN61-02364A BRACKET-STAND LINK;SONOMA 32,SECC,T1.6 1 S.N.A
..2 M0114 BN61-02500A HOLDER-WIRE;NYLON6.6,NATURAL 2 S.N.A
..2 M0146 BN61-02936A BRACKET-PANEL SIDE;27T7,SECC T1.2,CMO 27 2 S.N.A
..2 T0159 BN96-03058A ASSY PCB P-SMPS;Bordeaux 26 PFC,LE26R71B 1 S.A
..2 T0447 BN96-03944A ASSY BRACKET P-PANEL;SONOMA27, EO,READY, 1 S.N.A
...3 M0131 AA63-01401A GASKET;LE40R71BX,Conductive Fabric,22mm, 1 S.N.A
...3 BN61-02208A BRACKET GUIDE-MAIN;Bordeaux 26,SECC,T1.2 1 S.N.A
...3 BN61-02209A BRACKET-GUIDE POWER;Bordeaux 26,SECC,T1. 1 S.N.A
...3 BN61-02210A BRACKET-GUIDE POWER;Bordeaux 26,SECC,T1. 1 S.N.A
...3 M0146 BN61-02362A BRACKET-PANEL TOP;SONOMA 27,SECC,T1.2 1 S.N.A
...3 BN61-02363A BRACKET-PANEL BOTTOM;SONOMA 27,SECC,T1.6 1 S.N.A
0.1 M0017 BN91-01147A ASSY CHASSIS;LA27S71BX/* 1 S.N.A
..2 M0014 BN94-01046E ASSY PCB MAIN;LA27S71BX/* 1 S.A
...3 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.25 S.N.A
...3 JA709 3701-001294 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,AU 1 S.A
...3 CN330 3711-004068 HEADER-BOARD TO CABLE;BOX,5P,1R,2MM,ANGL 1 S.A
...3 CN503 3711-005884 HEADER-BOARD TO BOARD;BOX,30P,2R,2mm,ANG 1 S.A
...3 CN330 3711-005942 HEADER-BOARD TO CABLE;BOX,16P,1R,2mm,STR 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA332 3722-001734 JACK-VHS;4P,SN,BLK,STRAIGHT 1 S.A
...3 JA333 3722-002143 JACK-PIN;5P,NI,GRN/BLU/RED/WHT/RED,STRAI 1 S.A
...3 JA333 3722-002360 JACK-PIN;3P,AU,GRN/BLU/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002363 JACK-PIN;3P,Sn,YEL/WHT/RED,STRAIGHT 1 S.A
...3 T0562 6046-001013 STAND OFF;M3,L5,Ni PLT,SUM24L,#4-40 2 S.N.A
...3 CIS3 BN40-00083A TUNER;TCPS3001PD32S(H),TCPS3001PD32S(H), 1 S.A
...3 M0107 BN63-01847A SHIELD-COVER;ROME,SECC,T0.3,49.5,79.5,HE 1 S.N.A
...3 SUB07 BN73-00024C SILICON/RUBBER-BERGQUIST;VENUS 32,40",SI 1 S.N.A
...3 T0174 BN97-01116E ASSY SMD;LA27S71BX/* 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
