Image preview - the first page of the document
>> Download 11_Electrical Part List documenatation <<
Text preview - extract from the document
6 Electrical Parts List
6 Electrical Parts List
You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LA26R71B Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
0 LA26R71BX/SAP LA26R71B,Q52G/26R70-GBD,26,LCD-TV,SINGAP 0
1 M0001 BN90-00844D ASSY COVER FRONT;26R71,SO,BORDEAUX 1 SNA
..2 T0003 BN96-03012F ASSY COVER P-FRONT;26R71,SO,ABS+PMMA,HB, 1 SA
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 SNA
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 SNA
...3 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 SA
...3 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20 1.118 SNA
...3 M0112 BN63-02331D COVER-FRONT;26R71,SO,ABS+PMMA,HB,BK23,S/ 1 SNA
...3 T0056 BN63-02333A COVER-DECORATION;26R71,HIPS,HB,GR503,BLM 1 SNA
...3 T0023 BN64-00342A KNOB POWER;ROME,40,PC,VIOLET 1 SNA
...3 T0059 BN64-00366A INDICATOR LED;ROME-I,PC,CLEAR,ALL MODEL 1 SNA
...3 T0054 BN64-00443A KNOB-DECORATION;32R71,ABS,HB,GR503,VACUU 1 SNA
...3 T0061 BN64-00453A WINDOW-REMOCON;32R71,PC,V0,VIOLET,DIFFUS 1 SNA
...3 BN96-03404A ASSY BOARD P-FUNCTION&KNOB;Bordeaux,CT50 1 SNA
....4 T0022 BN64-00442A KNOB CONTROL;26,32,40R71,PC,BLK,ACRYL CL 1 SNA
....4 M0145 BN96-03045A ASSY BOARD P-FUNCTION;BORDEAUX,FUNCTION 1 SA
...3 M0146 BN96-03405A ASSY BOARD P-POWER;BORDEAUX1,CT5000-4140 1 SA
..2 T0175 BN96-03053A ASSY SPEAKER P;16ohm,Bordeuax 26,Left,5W 1 SA
..2 T0175 BN96-03054A ASSY SPEAKER P;16ohm,Bordeuax 26,Right,5 1 SA
1 M0002 BN90-00846D ASSY COVER REAR;26R71,SO,BORDEAUX 1 SNA
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 2 SA
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 13 SA
..2 M0013 BN96-03014E ASSY COVER P-REAR;26R71,SO,ABS+PMMA,BK23 1 SA
...3 T0101 BN61-02058A BRACKET-WALL;23,27,MGM,SECC,T1.6 2 SNA
...3 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20 0.6 SNA
...3 M0006 BN63-02332A COVER-REAR;26R71,EO,SO,CO,ABS+PMMA,HB,BK 1 SNA
...3 T0071 BN64-00445A INLAY-TERMINAL;26R71,(BLK),PS SHEET,T0.5 1 SNA
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,PP,V0,BLK 1 SNA
1 M0216 BN90-00848A ASSY STAND;26R71,BORDEAUX 1 SNA
..2 T0524 6902-000561 BAG PE;HDPE+NITRON(DOUBLE),T0.015+T0.5,W 1 SNA
..2 M0013 BN96-03017A ASSY STAND P-BASE;26R71,ABS+PMMA,HB,BK23 1 SA
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 SA
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,B,M4,L10,ZPC(YEL),SWR 4 SA
...3 BN61-02192A GUIDE-STAND;26,32R71,ABS,V0,BLK 1 SNA
...3 BN61-02202A BRACKET-STAND BOTTOM;BORDEAUX 26,SECC,T2 1 SNA
...3 BN61-02204A HOLDER-SWIVEL RING;26,32R71,ACETAL,BLK 1 SNA
...3 BN61-02232A HOLDER-SWIVEL RING;32R71,ACETAL NATUAL,T 1 SNA
...3 BN61-02233A HOLDER-SWIVEL RING;32R71,ACETAL NATUAL,B 1 SNA
...3 BN61-02236A BRACKET-HINGE SWIVEL;BORDEAUX 32,SECC,T1 1 SNA
...3 BN63-02322A COVER-STAND SUB;32R71,ABS+PMMA,HB,BK23,H 1 SNA
...3 T0004 BN63-02335A COVER-STAND BASE;26R71,ABS+PMMA,HB,BK23, 1 SNA
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1. 4 SNA
...3 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.4 SNA
...3 T0514 BN61-02367A BRACKET-SUPPORT;BORDEAUX 32,SECC,T2.0 1 SNA
1 M0017 BN91-01006P ASSY CHASSIS;LA26R71BX,BORDEAUX,ASIA 1 SNA
..2 M0014 BN94-00879A ASSY PCB MAIN;LA26R71B,BORDEAUX,ASIA 1 SA
...3 T0245 0202-001522 SOLDER-WIRE FLUX;LFA3-107,-,D1.2,96.5Sn/ 0.25 SNA
...3 JA709 3701-001294 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,AU 1 SA
...3 CN501 3711-004068 HEADER-BOARD TO CABLE;BOX,5P,1R,2MM,ANGL 1 SA
...3 CN500 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 SA
...3 TEST901 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 SA
...3 CN503 3711-005884 HEADER-BOARD TO BOARD;BOX,30P,2R,2mm,ANG 1 SA
...3 CN800 3711-005942 HEADER-BOARD TO CABLE;BOX,16P,1R,2mm,STR 1 SA
6-1
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
...3 JA708 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 SA
...3 JA716 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 SA
...3 JA717_OP 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 SA
...3 JA712_OP 3722-001734 JACK-VHS;4P,SN,BLK,STRAIGHT 1 SA
...3 JA707_NT 3722-002143 JACK-PIN;5P,NI,GRN/BLU/RED/WHT/RED,STRAI 1 SA
...3 JA715 3722-002360 JACK-PIN;3P,AU,GRN/BLU/RED,STRAIGHT 1 SA
...3 JA704 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 SA
...3 JA711 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 SA
...3 JA713 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 SA
...3 JA714_OP 3722-002363 JACK-PIN;3P,Sn,YEL/WHT/RED,STRAIGHT 1 SA
...3 T0562 6046-001013 STAND OFF;M3,L5,Ni PLT,SUM24L,#4-40 2 SNA
...3 CIS3 BN40-00083A TUNER;TCPS3001PD32S(H),TCPS3001PD32S(H), 1 SA
...3 M0107 BN63-01847A SHIELD-COVER;ROME,SECC,T0.3,49.5,79.5,HE 1 SNA
...3 CIS8 BN73-00024C SILICON/RUBBER-BERGQUIST;VENUS 32,40",SI 1 SNA
...3 T0510 BN97-00848A ASSY SMD-MAIN;LA26R71BX,BORDEAUX,ASIA 1 SNA
....4 CIS5 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45?,96.5Sn/3 3.033 SNA
....4 D100 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D200 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D201 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D202 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D226 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D227 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D228 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D307 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D320 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D321 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D322 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D323 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D324 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D325 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D326 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D327 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D451_NT 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D467 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D485 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D486 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D487 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D494 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D946_OP 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D961_OP 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D979_OP 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
....4 D800 0402-000553 DIODE-RECTIFIER;SS24,40V,2A,DO-214AA,TP 1 SA
....4 D801 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 SA
....4 D906 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 SA
....4 D300 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D304 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D305 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D490 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D491 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D492 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D493 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D499 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D500 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D501 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D502 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D503 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D504 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D505 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D506 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D507 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D508 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D509 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D510 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
6-2
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 D511 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D512 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D513 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D909 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D911 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 SA
....4 D301 0403-001016 DIODE-ZENER;RLZ6.2B,5.96-6.27V,500mW,LL- 1 SA
....4 D418 0403-001169 DIODE-ZENER;RLZ16C,15.96-16.51V,500MW,LL 1 SA
....4 D421 0403-001169 DIODE-ZENER;RLZ16C,15.96-16.51V,500MW,LL 1 SA
....4 D101 0403-001425 DIODE-ZENER;BZX84C33,31-35V,350mW,SOT-23 1 SA
....4 D308 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D309 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D401 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D403 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D404 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D405 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D406 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D407 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D408 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D409 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D410_NT 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D411_NT 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D412_NT 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D428 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D461 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D462 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D470 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D471 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D472 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D483 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D484 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D949_OP 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D950_OP 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D962_OP 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D963_OP 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D964_OP 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D975_OP 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D976_OP 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 SA
....4 D600 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 SA
....4 D601 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 SA
....4 D900 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 SA
....4 D901 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 SA
....4 Q603 0501-000280 TR-SMALL SIGNAL;KSA1182,PNP,150MW,SOT-23 1 SA
....4 Q100 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 SA
....4 Q301 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 SA
....4 Q501 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 SA
....4 Q600 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 SA
....4 Q601 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 SA
....4 Q602 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 SA
....4 Q605 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 SA
....4 Q606 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 SA
....4 Q609 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 SA
....4 Q802 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 SA
....4 Q900 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 SA
....4 Q904 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 SA
....4 Q905 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 SA
....4 Q906 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 SA
....4 Q972 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 SA
....4 Q973 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 SA
....4 Q222 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 SA
....4 Q800 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 SA
....4 Q801 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 SA
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 SA
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 SA
6-3
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 SA
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 SA
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 SA
....4 Q409 0505-001170 FET-SILICON;SI9933ADY-T1,P,-20V,3.4A,0.0 1 SA
....4 IC104 0801-002095 IC-CMOS LOGIC;74LCX245,TRANSCEIVER,TSSOP 1 SA
....4 IC900 0903-001432 IC-MICROCOMPUTER;M30840SGP,16Bit,LQFP,10 1 SA
....4 IC605 1001-000164 IC-ANALOG MULTIPLEX;74HC4052,CMOS,SOP,16 1 SA
....4 IC905 1001-001109 IC-ANALOG SWITCH;FST3125M,BUS SWITCH & C 1 SA
....4 IC107 1002-001399 IC-D/A CONVERTER;PCM1754,24BIT,SSOP,16P, 1 SA
....4 IC110 1006-001076 IC-DRIVER/RECEIVER;MAX232ECWE+T,SOP,16P, 1 SA
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 SA
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 SA
....4 IC112 1103-001279 IC-EEPROM;24C32,32Kbit,4Kx8Bit,SOP,8P,5x 1 SA
....4 IC222 1105-001538 IC-VIDEO RAM;K4D263238,-,128M,4x1Mx32Bit 1 SNA
....4 DU410 1201-000166 IC-OP AMP;LM358,SOP,ST,8P,150MIL,DUAL,10 1 SA
....4 T0085 1201-002136 IC-AUDIO AMP;LM4810,MSOP,8P,3x3mm,DUAL,- 1 SA
....4 T0085 1201-002246 IC-AUDIO AMP;STA323W,SO,36P,15.9x11mm,-, 1 SNA
....4 IC503_OP 1203-001559 IC-RESET;DS1834A,SOIC,8P,150MIL,PLASTIC, 1 SA
....4 IC910 1203-001559 IC-RESET;DS1834A,SOIC,8P,150MIL,PLASTIC, 1 SA
....4 T0087 1203-001815 IC-POSI.FIXED REG.;78M09,TO-252,3P,-,PLA 1 SA
....4 T0087 1203-001816 IC-POSI.FIXED REG.;78M08,TO-252,3P,-,PLA 1 SA
....4 T0087 1203-002842 IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P 1 SA
....4 T0087 1203-002842 IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P 1 SA
....4 T0087 1203-002855 IC-POSI.FIXED REG.;MC33269DTRK-5.0,DPRK, 1 SA
....4 T0087 1203-002974 IC-POSI.FIXED REG.;AP1117D-25A,TO-252,3P 1 SA
....4 T0170 1203-003059 IC-SWITCH VOL. REG.;MP1583,SOIC,8P,4.9x3 1 SA
....4 IC601 1204-002464 IC-AUDIO PROCESSOR;STV8257DSX,TQFP,80P,1 1 SNA
....4 IC118 1204-002503 IC-VIDEO PROCESS;SVP-PX56-7256,PQFP,256P 1 SNA
....4 R221 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 SA
....4 R222 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 SA
....4 R9004 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 SA
....4 R9005 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 SA
....4 R9006 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 SA
....4 R9007 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 SA
....4 R9008 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 SA
....4 R9009 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 SA
....4 R9010 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 SA
....4 R9015 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 SA
....4 R9028 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 SA
....4 R9032 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 SA
....4 R976 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 SA
....4 R109 2007-000060 R-CHIP;100Kohm,1%,1/10W,TP,1608 1 SA
....4 R807 2007-000067 R-CHIP;15Kohm,1%,1/10W,TP,1608 1 SA
....4 26_ 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R321 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R440_NT 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R441_NT 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R442_NT 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R443_NT 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R444 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R446 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R456_NT 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R480 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R491_OP 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R492_OP 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R493_OP 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R500 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R501 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R502 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R511 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R512 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R514_OP 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R516 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
6-4
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R523 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R539 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R540 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R542 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R563_OP 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R564_OP 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R565_OP 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R566_OP 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R567_OP 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R568_OP 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R569_OP 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R570_OP 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R571_OP 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R572_OP 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R574 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R575 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R577 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R592 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R656 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R691 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R692 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R693 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R9000 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R9013 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R9014 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R9030 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R909 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R913 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R928 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R931 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R932 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R933 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R934 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R936 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R939 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R940 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R941 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R949 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R950 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R951 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R952 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R953 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R998 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4 R224 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 SA
....4 R225 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 SA
....4 R226 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 SA
....4 R227 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 SA
....4 R458 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 SA
....4 R499 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 SA
....4 R503 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 SA
....4 R504 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 SA
....4 R505 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 SA
....4 R506 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 SA
....4 R507 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 SA
....4 R508 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 SA
....4 R509 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 SA
....4 R510 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 SA
....4 R518 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 SA
....4 R585 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 SA
....4 R586 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 SA
....4 R104 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 SA
....4 R105 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 SA
....4 R306 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 SA
6-5
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R308 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 SA
....4 R475 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 SA
....4 R495 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 SA
....4 R611 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 SA
....4 R612 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 SA
....4 R658 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 SA
....4 R659 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 SA
....4 R676 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 SA
....4 R682 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 SA
....4 R108 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R113 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R116 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R243 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R244 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R406 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R409 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R457_NT 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R498 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R525 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R533 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R538 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R559 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R582 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R584 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R587 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R614 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R615 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R616 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R617 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R618 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R619 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R620 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R621 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R636 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R637 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R639 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R640 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R644 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R645 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R648 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R650 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R651 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R653 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R654 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R678 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R679 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R680 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R802 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R9002 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R901 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R9016 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R9023 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R9025 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R911 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R916 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R917 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R919 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R937 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R947 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R966 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R967 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R971 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R972 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
6-6
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R973 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R977 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R978 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R999 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 SA
....4 R562 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 1 SA
....4 R100 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 1 SA
....4 R405 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 1 SA
....4 R410 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 1 SA
....4 R114 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 SA
....4 R307 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 SA
....4 R311 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 SA
....4 R403 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 SA
....4 R407 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 SA
....4 R408 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 SA
....4 R411 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 SA
....4 R429 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 SA
....4 R474 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 SA
....4 R476 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 SA
....4 R487 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 SA
....4 R528 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 SA
....4 R590 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 SA
....4 R591 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 SA
....4 R810 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 SA
....4 R9026 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 SA
....4 R946 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 SA
....4 R103 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 SA
....4 R106 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 SA
....4 R119_OP 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 SA
....4 R120_OP 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 SA
....4 R312 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 SA
....4 R322 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 SA
....4 R522 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 SA
....4 R535 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 SA
....4 R537 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 SA
....4 R554 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 SA
....4 R576 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 SA
....4 R9019 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 SA
....4 R9044 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 SA
....4 R9045 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 SA
....4 R905 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 SA
....4 R935 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 SA
....4 R530 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 SA
....4 R532 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 SA
....4 R925 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 SA
....4 R926 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 SA
....4 R963 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 SA
....4 R964 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 SA
....4 R242 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R526 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R541 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R578 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R593 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R643 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R655 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R670 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R808 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R809 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R9011_OP 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R9027 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R9033 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R9034 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R9035 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R9036 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
6-7
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R9037 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R9038 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R9051 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R9052 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R9053 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R9054 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R9055 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R9056 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R9057 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R908 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R918 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R923 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R924 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R927 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R929 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R930 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R938 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R943 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R962 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R996 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....4 R426 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608 1 SA
....4 R427 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608 1 SA
....4 R302 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R303 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R316 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R445 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R447 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R459 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R473 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R515 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R519 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R555 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R556 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R610 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R661 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R665 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R673 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R801 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R803 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R804 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R9029 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R9043 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R906 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R907 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R912 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R915 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R920 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R921 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R922 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R954 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R956 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R970 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R994 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R995 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 SA
....4 R664 2007-000093 R-CHIP;20Kohm,5%,1/10W,TP,1608 1 SA
....4 R666 2007-000093 R-CHIP;20Kohm,5%,1/10W,TP,1608 1 SA
....4 R101 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 SA
....4 R914 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 SA
....4 R313 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 1 SA
....4 R527_OP 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 1 SA
....4 R601 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 1 SA
....4 R646 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 1 SA
....4 R652 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 1 SA
6-8
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R657 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 1 SA
....4 R993 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 1 SA
....4 R602 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 SA
....4 R603 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 SA
....4 R604 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 SA
....4 R605 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 SA
....4 R606 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 SA
....4 R607 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 SA
....4 R608 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 SA
....4 R609 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 SA
....4 R626 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 SA
....4 R627 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 SA
....4 R628 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 SA
....4 R629 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 SA
....4 R630 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 SA
....4 R631 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 SA
....4 R632 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 SA
....4 R633 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 SA
....4 R102 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 SA
....4 R660 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 SA
....4 R663 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 SA
....4 R667 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 SA
....4 R800 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 SA
....4 R806 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 SA
....4 R107 2007-000106 R-CHIP;220Kohm,5%,1/10W,TP,1608 1 SA
....4 R111 2007-000106 R-CHIP;220Kohm,5%,1/10W,TP,1608 1 SA
....4 R112 2007-000106 R-CHIP;220Kohm,5%,1/10W,TP,1608 1 SA
....4 R668 2007-000107 R-CHIP;470Kohm,5%,1/10W,TP,1608 1 SA
....4 R5004 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 SA
....4 R550 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 SA
....4 R551 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 SA
....4 R553 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 SA
....4 R638 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608 1 SA
....4 R236 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608 1 SA
....4 R237 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608 1 SA
....4 R238 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608 1 SA
....4 R683 2007-000125 R-CHIP;3.9Kohm,5%,1/10W,TP,1608 1 SA
....4 R413 2007-000293 R-CHIP;100ohm,5%,1/4W,TP,3216 1 SA
....4 R417 2007-000293 R-CHIP;100ohm,5%,1/4W,TP,3216 1 SA
....4 R434 2007-000293 R-CHIP;100ohm,5%,1/4W,TP,3216 1 SA
....4 R481 2007-000293 R-CHIP;100ohm,5%,1/4W,TP,3216 1 SA
....4 R9012_OP 2007-000293 R-CHIP;100ohm,5%,1/4W,TP,3216 1 SA
....4 R323 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R324 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R325 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R326 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R327 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R328 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R329 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R330 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R942 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R955_OP 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R957_OP 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R969 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R974 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R975 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R979 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R980 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R982 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R983 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R984 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R985 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R986 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
6-9
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R987 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R988 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R989 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R990 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R991 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R992 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R997 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
....4 R412 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608 1 SA
....4 R416 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608 1 SA
....4 R9041 2007-000704 R-CHIP;3.6Kohm,5%,1/10W,TP,1608 1 SA
....4 R9042 2007-000704 R-CHIP;3.6Kohm,5%,1/10W,TP,1608 1 SA
....4 R557 2007-000903 R-CHIP;430ohm,1%,1/10W,TP,1608 1 SA
....4 R117 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 SA
....4 R118 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 SA
....4 R414 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 SA
....4 R415 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 SA
....4 R418 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 SA
....4 R477 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 SA
....4 R478 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 SA
....4 R482 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 SA
....4 R902 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 SA
....4 R903 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 SA
....4 R948 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 SA
....4 R223 2007-001014 R-CHIP;51OHM,5%,1/10W,TP,1608 1 SA
....4 R228 2007-001014 R-CHIP;51OHM,5%,1/10W,TP,1608 1 SA
....4 R805 2007-001068 R-CHIP;6.8Kohm,1%,1/10W,TP,1608 1 SA
....4 R110 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 SA
....4 R115_OP 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 SA
....4 R318 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 SA
....4 R320 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 SA
....4 R423 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 SA
....4 R424 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 SA
....4 R425 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 SA
....4 R435 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 SA
....4 R484 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 SA
....4 R485 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 SA
....4 R486 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 SA
....4 R904_OP 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 SA
....4 R910_OP 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 SA
....4 R468 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 SA
....4 R469 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 SA
....4 R470 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 SA
....4 R471 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 SA
....4 R472 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 SA
....4 R483 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 SA
....4 R496 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 SA
....4 R497 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 SA
....4 R675 2007-008720 R-CHIP;4.7ohm,1%,1/4W,TP,3216 1 SA
....4 R677 2007-008720 R-CHIP;4.7ohm,1%,1/4W,TP,3216 1 SA
....4 R681 2007-008720 R-CHIP;4.7ohm,1%,1/4W,TP,3216 1 SA
....4 R684 2007-008720 R-CHIP;4.7ohm,1%,1/4W,TP,3216 1 SA
....4 IC223 2011-000585 R-NET;47ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 SA
....4 RA221 2011-000585 R-NET;47ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 SA
....4 RA222 2011-000585 R-NET;47ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 SA
....4 RA223 2011-000585 R-NET;47ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 SA
....4 RA224 2011-000585 R-NET;47ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 SA
....4 RA225 2011-000585 R-NET;47ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 SA
....4 RA226 2011-000585 R-NET;47ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 SA
....4 RA227 2011-000585 R-NET;47ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 SA
....4 RA903 2011-000651 R-NET;10ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
....4 RA904 2011-000651 R-NET;10ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
....4 RA906 2011-000651 R-NET;10ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
....4 RA907 2011-000651 R-NET;10ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
6-10
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 RA908 2011-000651 R-NET;10ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
....4 RA910 2011-000651 R-NET;10ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
....4 RA500 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
....4 RA501 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
....4 RA900 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
....4 RA901 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
....4 RA902 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
....4 RA905 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
....4 RA909 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
....4 RA911 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
....4 RA913 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
....4 RA916 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
....4 RA917 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
....4 RA918 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
....4 RA919 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
....4 RA920 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 SA
....4 RA921 2011-001◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
