Image preview - the first page of the document



>> Download Disassembly & Reassembly documenatation <<

Text preview - extract from the document

                                                                                       3. Disassembly and Reassemble

3. Disassembly and Reassemble
This section of the service manual describes the disassembly and reassembly procedures for the (LA32A550P1R) LCD TV.
    WARNING: This LCD TV contains electrostatically sensitive devices. Use caution when handling these components.

3-1. Disassembly (LA32A550P1R)
   Cautions: 1. Disconnect the TV from the power source before disassembly.
             2. Follow these directions carefully; never use metal instruments to pry apart the cabinet.


                 Description                                    Picture Description                        Screws
 1. Place TV face down on cushioned table.
    Remove screws from the Stand.
    Remove stand.




 2. Remove the screws of rear-cover.




                                                                                                                3-1
3. Disassembly and Reassemble


                 Description    Picture Description   Screws
3. Lift up the rear-cover.




3-2
                                                          3. Disassembly and Reassemble


                Description              Picture Description               Screws
4. Remove the screws of Main boards.




5. Remove the screws of Left/Right,
   Bottom Left/Bottom Right and center
   woofer speaker.




                                                                                   3-3
3. Disassembly and Reassemble


                 Description                    Picture Description   Screws
6. Remove the screws of Stand BKLT.
   Lift up the Stand BKLT.




7. Remove the Side AV Ass'y (only 46")




8. Remove the Bracket of Boards




* Caution: Don't force yourself on wall mount
  bracket during disassembly.
  It may be deformationed.




3-4
                                                                             3. Disassembly and Reassemble


                Description                                 Picture Description               Screws
9. Remove the screws on Panel.




 Reassembly procedures are in the reverse order of disassembly procedures.




                                                                                                      3-5
3. Disassembly and Reassemble




3-2. Disassembly (LA40A650A1R)
      Cautions: 1. Disconnect the TV from the power source before disassembly.
                2. Follow these directions carefully; never use metal instruments to pry apart the cabinet.


                    Description                                    Picture Description                        Screws
 1. Place TV face down on cushioned table.
    Remove screws from the Stand.
    Remove stand.




 2. Remove the screws of rear-cover.




3-6
                                                3. Disassembly and Reassemble


                 Description   Picture Description               Screws
3. Lift up the rear-cover.




                                                                         3-7
3. Disassembly and Reassemble


                Description             Picture Description   Screws
4. Remove the screws of Main boards.




5. Remove the screws of INLET Socket.




3-8
                                                                 3. Disassembly and Reassemble


                 Description                    Picture Description               Screws
6. Remove the screws of Stand BKLT.
   Lift up the Stand BKLT.




7. Remove the Side AV Ass'y (only 46")




8. Remove the Bracket of Boards




* Caution: Don't force yourself on wall mount
  bracket during disassembly.
  It may be deformationed.




                                                                                          3-9
3. Disassembly and Reassemble


                Description                                 Picture Description   Screws
9. Remove the screws on Panel.




 Reassembly procedures are in the reverse order of disassembly procedures.




3-10
