Image preview - the first page of the document
Product Specification


>> Download Product Specification documenatation <<

Text preview - extract from the document
                                                                                             2. Product specifications

2. Product specifications
2-1. Feature & Specifications
               Model                                                  LA32A550P1R

                                                        Feature

   HD_READY (FHD), RF, 3-HDMI, 2-Component, 2-A/V(REAR/ SIDE), 1-S-Video, USB2.0(WISELINK -JPEG/ MP3), D-SUB
   Brightness : 500cd/m2
   Contrast Ratio : 8000:1
   Response time : 6ms
   Dynamic contrast, Super-PVA
   PIP(in HDMI 1, 2, 3, Component 1, 2, PC Mode and Sub picture is available only in TV/ AV mode)

                                                     Specifications

               Item                                                    Description
LCD Panel                      TFT-LCD panel, RGB vertical stripe, SPVA mode, normaly black,
                               32-Inch viewable, 0.3635 (H) x 0.36375 (W) mm pixel pitch
Scanning Frequency             Horizontal : 67.5 kHz (Automatic)
                               Vertical : 48 Hz ~ 63 Hz (Automatic)
Display Colors                 16.7 million colors
Maximum resolution             Horizontal : 1920 Pixels
                               Vertical : 1080 Pixels
Input Signal                   Analog 0.7 Vp-p
