Image preview - the first page of the document
>> Download 07_Alignment & Adjustment documenatation <<
Text preview - extract from the document
3 Alignments and Adjustments
3 Alignments and Adjustments
3-1 Service Instruction
1. Usually, a color TV-VCR needs only slight touch-up adjustment upon installation.
Check the basic characteristics such as height, horizontal and vertical sync.
2. Use the specified test equipment or its equivalent.
3. Correct impedance matching is essential.
4. Avoid overload. Excessive signal from a sweep generator might overload the front-end
of the TV. When inserting signal markers, do not allow the marker generator to distort
test result.
5. Connect the TV only to an AC power source with voltage and frequency as specified on
the backcover nameplate.
6. Do not attempt to connect or disconnect any wire while the TV is turned on. Make sure
that the power cord is disconnected before replacing any parts.
7. To protect aganist shock hazard, use an isolation transform.
3-1
3 Alignments and Adjustments
3-2 How to Access Service Mode
3-2-1 Entering Factory Mode
" "
Power OFF INFO MENU MUTE Power ON
- If you have Factory remote - control
PICTURE ON DISPLAY FACTORY
- The buttons are active in the service mode.
1. Remote - Control Key : Power, Arrow Up, Arrow Down, Arrow Left
Arrow Right, Menu, Enter, Number Key(0~9)
2. Function - Control Key : Power, CH +, CH -, VOL +, VOL -,
Menu, TV/VIDEO(Enter)
3-2
3 Alignments and Adjustments
3-3 Factory Data
1. Calibration
2. Option Table XXXX XXXX
3. White Balance
4. SVP-PX
5. Option Block
6. STV8257/STA323W
7. YC Delay
8. Adjust
9. I2C Check
10. W/B MOVIE
11. Checksum
12. Reset
13. Spread Spectrum
T-FHDMPEU-0000
T-BRDMPEUS-0000
T-MSLMPEUW-0000
1. Calibration
1) AV Calibration
2) Comp Calibration
3) PC Calibration
4) HDMI Calibration
2. Option Table XXXX XXXX
Inch Option 40" Carrier Mute OFF TTX Group Auto
Gamma AMLCD Language English Auto Power ON
Panel Option AMLCD_INT Auto FM ON Magazine LNA OFF
2HDMI ON High Deviation OFF VOL MODE SMALL
Brt.Sensor OFF TTX ON ---- OFF
EnergySave OFF TTX List Flof Debug OFF
LBE/FBE ON ACR OFF Ch.Table SUWON
FRC(Micronas) OFF Dynamic CE ON iDTV_Cntry UK
FRC 2X OFF Dynamic Dimming ON Dynamic Contrast OFF
LNA ON Tuner TOP 8
3-3
3 Alignments and Adjustments
3. White Balance
No. Item TV/AV Component DVI (HDMI)
1 Sub-Briteness 130
2 R-offset 128
3 G-offset 128
4 B-offset 128
5 Sub-Contrast 145
6 R-Gain 128
7 G-Gain 128
8 B-Gain 128
4. SVP-PX
1) ComB Filter
No Item Range EEPROM NTSC PAL SECAM Control IC Remark
1 Y-Filter 0 ~ 255 80h X
2) Sharpness
H2 Gain 05H Sl2 gain 02H
H4 Gain 02H Sl4 gain 08H
V2 Gain 0CH Peakth 1 04H
V4 Gain 04H Peakth 2 2FH
Sr2 Gain 02H Peakth 3 3FH
Sr4 Gain 00H
3) NR
Y_NR_OFF 80H
C_NR_OFF
Y_NR_ON
C_NR_ON
4) RGB Calibration
R-offset 48H
G-offset 48H
B-offset 48H
R-Gain 39H
G-Gain 39H
B-Gain 39H
5) ADC Calibration
TCD3 Contrast 78H Analog PB offset 80H
TCD3 CR 20H PR offset 80H
TCD3 CB 80H Y-Gain B7H
TCD3 Delay 00H PB-Gain 9AH
Analog Y offset 3DH PR-Gain 9AH
Black level 00H
SVP Brightness 00H
3-4
3 Alignments and Adjustments
6) Calibration Target
low high delta
AV ADC 17 D5H 02H
COMP ADC 0FH EBH 02H
PC ADC 17H D5H 04H
ALL RGB 00H DDH 08H
7) Color Management
Skin Direction Reddish
Skin Enhance 40H
Green Stretch 00H
Blue Stretch 00H
5. Option Block
FRC (Micronas)
FRC 2X
LBE / FBE
6. STV 8257 / STA 323W
Ch1 Volume 4BH AV delay 41H
Ch2 Volume 4BH Comp delay 41H
AGC Gain 07H HDMI delay 41H
AV-Prescale 00H PC delay 41H
L1 Att / Rel Thres 7FH
7. YC Delay(TV)
RF PAL - B/G AAH RF NTSC 3.58 66H
RF PAL - D/K 99H RF NTSC 4.43 CCH
RF PAL - I 99H AV PAL AAH
RF SECAM B/G RF SECAM -B/G AV SECAM 88H
RF SECAM D/K 44H AV NTSC 3.58 BBH
RF SECAM L/L' 88H AV NTSC 4.43 AAH
AV PAL 60 77H
8. Adjust
Video mute time 10
Melody volume 9
Ana_Dimm_Max FEH
LNA PLUS
Hotel Option
9. I2C Check
3-5
3 Alignments and Adjustments
10. W/B movie
WB movie Off W2 R Gain 142 Movie sharpness 35
color mode Movie W2 B Gain 48 Movie colortone warm 2
W2 R Offset 129
W1 R Gain 157 W2 B Offset 143
W1 B Gain 157 Movie contrast 80
W1 R Offset 157 Movie Brightness 65
W1 B Offset 157 Movie color 35
11. Checksum
12. Reset
13. Spread Spectrum
Spectrum on
Delta 0
Positive 8
Negative 2
3-6
3 Alignments and Adjustments
3-4 Service Adjustment
3-4-1 White Balance - Calibration
If picture color is wrong, do calibration first.
Equipment : CA210, Patten : chess pattern
Execute calibration in Factory Mode
Source AV: PAL composite, Component : 1280 x 720/60Hz
Component: 720P
PC: 1024*768/60Hz
HDMI: 720P
( chess patten )
3-4-2 White Balance - Adjustment
If picture color is wrong, check White Balance condition.
Equipment : CA210, Patten : New W/B Pattern
Adjust W/B in Factory Mode
Sub brightness and R/G/B Offset controls low light region
Sub contrast and R/G/B Gain controls high light region
Source AV : PAL composite, Component : 1280 x 720/60Hz
HDMI[DVI] : 1280 x 720/60Hz
[ Test Pattern : MSPG-945 Series Pattern #92 ]
*Color temperature
1500K +/-500, -6 ~-20 MPCD
*Color coordinate
H/L : 272/278 +/- 5
L/L : 272/278 +/-5 3.8ft +/- 0.2ft
New W/B Pattern
3-7
3 Alignments and Adjustments
3-4-3 Conditions for Measurement
1. On the basis of toshiba ABL pattern : High Light level (57 IRE)
- INPUT SIGNAL GENERATOR
* Mode NO 2 : 744X484 @ 60 Hz
NO 6 : 1280X720 @ 60 Hz
NO 21 : 1024X768 @ 60 Hz
* Pattern NO 17 : 16 Gray Pattern
NO 92 : Combination Pattern
2. Optical measuring device : CA210 (FL)
Please use the generator for model LA40F71B.
3-8
3 Alignments and Adjustments
3-5 White Ratio (Balance) Adjustment
1. You can adjust the white ratio in factory mode (1:Calibration, 3:White-Balance).
2. Since the adjustment value and the data value vary depending on the input source, you have to
adjust these in AV, Component 1 and HDMI 1 modes.
3. The optimal values for each mode are configured by default. (Refer to Table 1, 2.)
It varies with Panel's size and Specification.
- Equipment : CS-210
- Pattern: MIK K-7256 #92 "Flat W/B Pattern" as standard
- Use other equipment only after comparing the result
with that of the Master equipment.
- Set Aging time : 60min
- Calibration and Manual setting for WB adjustment.
HDMI : Calibration at #24 Chessboard Pattern Manual adjustment #92 pattern (720p)
COMP: Calibration at #24 Chessboard Pattern Manual adjustment at #92 pattern (720p)
AV Calibration at #24 Chessboard Pattern Manual adjustment at #92 pattern
- If finishing in HDMI mode, adjustment coordinate is almost same in AV/COMP mode.
- White Balance Manual Adjustment
Adjustment Coordinate (LE40F71B)
x y Y (cd/m2) T(K) + MPCD
H/L 272 278 - 12,000
AV
L/L 272 278 - 12,000
H/L 272 278 - 12,000
Component
(720P)
L/L 272 278 - 12,000
H/L 272 278 - 12,000
HDMI
(720P)
L/L 272 278 13.2cd/m2 12,000
- Adjustment Specification
White Balance : High light ( 2), Low light ( 3)
Luminance : High light (Don't care), Low light ( 0.2 Ft/L)
3-9
3 Alignments and Adjustments
Adjustment Coordinate (LE46F71B)
x y Y (cd/m2) T(K) + MPCD
H/L 268 283 - 12,000
AV
L/L 268 283 - 12,000
H/L 268 283 - 12,000
Component
(720P)
L/L 268 283 - 12,000
H/L 268 283 - 12,000
HDMI
(720P)
L/L 268 283 13.2cd/m2 12,000
- Adjustment Specification
White Balance : High light ( 2), Low light ( 3)
Luminance : High light (Don't care), Low light ( 0.2 Ft/L)
3-6 Servicing Information
3-6-1 USB Download Method
(1) Copy the Software file into the USB flash driver.
(2) Turn on your LCD TV and check the source is 'Analog TV Mode'.
(3) Insert the USB flash driver into the USB Jack of LCD TV.
(4) Press 'Mute'+'7'+'8'+'9'+'Exit' keys of your remote control.
(5) The banner osd "Updating SW..." is displayed.
(6) The banner osd "Completed..." is displayed when the updating is
completed.
(7) Remove the USB flash driver from LCD TV.
(8) Check the program version.
* How to check Program Version
1. Press " MENU "
2. Select " SET UP "
3. Select " INFORMATION HELP "
4. Highlight " ON " option
5. Press " INFO " button on the remote control
3-10
