Image preview - the first page of the document
>> Download 03_Exploded View & Part List documenatation <<
Text preview - extract from the document
5 Exploded View & Parts List
5 Exploded View and Parts List
- You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
5-1 LA40F71B Exploded View
M0013
T0447 M0014
M0146
M0215
M0059
M0146
T0003
T0003
T0003
M0013
5-1
5 Exploded View & Parts List
5-2 LA40F71B Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-03412M ASSY COVER P-FRONT;40F71,SO,ABS+PMMA,HB, 1 S.A
T0175 BN96-03271A ASSY SPEAKER P;8ohm,Mosel 32,Left,10W,BA 1 S.A
T0175 BN96-03272A ASSY SPEAKER P;8ohm,Mosel 32,Right,10W,B 1 S.A
M0215 BN07-00288A LCD-PANEL;LTA400HS-LH1,8bit,952*551*51.0 1 S.A
T0447 BN96-03421A ASSY BRACKET P-PANEL;40M7,EO,MOSEL 1 S.N.A
M0014 BN94-01119A ASSY PCB MAIN;LA40F71BX/* 1 S.A
M0013 BN96-04227C ASSY COVER P-REAR;40F71,SO,-,HIPS,HB,BK5 1 S.A
M0013 BN96-03418A ASSY STAND P-BASE;40M70,ABS+PMMA,HB,BK23 1 S.A
5-2
5 Exploded View & Parts List
5-3 LA46F71B Exploded View
M0013
M0146 M0014
M0215 M0059
T0447
M0013
M0146
M0146
T0175
M0115
M0013
T0175
5-3
5 Exploded View & Parts List
5-4 LA46F71B Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-03411J ASSY COVER P-FRONT;46F71,SO,ABS+PMMA,HB, 1 S.A
T0175 BN96-03593C ASSY SPEAKER P;8ohm,Mosel 46inch,Right,1 1 S.A
T0175 BN96-03591C ASSY SPEAKER P;8ohm,Mosel 46inch,LEFT,10 1 S.A
M0215 BN07-00291A LCD-PANEL;LTA460HS-LH1,8bit,1083*627*56. 1 S.A
T0447 BN96-03420D ASSY BRACKET P-PANEL;46F71.SO,FHD MOSEL 1 S.N.A
M0014 BN94-01119B ASSY PCB MAIN;LA46F71BX/* 1 S.A
M0013 BN96-03417A ASSY STAND P-BASE;46M7,-,ABS+PMMA,HB,BK2 1 S.A
M0013 BN96-04226C ASSY COVER P-REAR;46N71,SO,HIPS,HB,BK500 1 S.A
5-4
