Image preview - the first page of the document
>> Download 11_Electrical Part List documenatation <<
Text preview - extract from the document
6 Electrical Parts List
6 Electrical Parts List
You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
0 LA40F71BX/XST LA40F71B,Q56B/40F70-GFM,40,LCD-TV,THAILA 0
0.1 M0001 BN90-00935K ASSY COVER FRONT;40F71,SO,ABS+PMMA,HB,BK 1 S.N.A
..2 T0175 BN96-03271A ASSY SPEAKER P;8ohm,Mosel 32,Left,10W,BA 1 S.A
..2 T0175 BN96-03272A ASSY SPEAKER P;8ohm,Mosel 32,Right,10W,B 1 S.A
..2 T0003 BN96-03412M ASSY COVER P-FRONT;40F71,SO,ABS+PMMA,HB, 1 S.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 4 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 S.N.A
...3 M2893 BN39-00609A LEAD CONNECTOR;VE20EO,UL1015#22 BLACK,1P 1 S.A
...3 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
...3 BN61-02667A HOLDER-BOSS;MOSEL 40,ABS,VO,TOP 2 S.N.A
...3 BN61-02670A HOLDER-BOSS;MOSEL 40,ABS,VO,BOTTOM,LEFT 1 S.N.A
...3 BN61-02671A HOLDER-BOSS;MOSEL 40,ABS,VO,BOTTOM,RIGHT 1 S.N.A
...3 BN61-02771A BOSS-BOND;MOSEL,ABS+PMMA,NATURAL,BOND 14 S.N.A
...3 CCM1 BN63-02183G COVER-SHEET;Rhcm,PE Vinyl,T0.05,1100mm,2 1.983 S.N.A
...3 M0112 BN63-02488M COVER-FRONT;40F71,SO,ABS+PMMA,-,-,-,HB,- 1 S.N.A
...3 T0056 BN63-02831A COVER-DECORATION;40" MOSEL,AL,Extruding 1 S.N.A
...3 T0023 BN64-00342A KNOB POWER;ROME,40,PC,VIOLET 1 S.N.A
...3 T0059 BN64-00366A INDICATOR LED;ROME-I,PC,CLEAR,ALL MODEL 1 S.N.A
...3 T0054 BN64-00443A KNOB-DECORATION;32R71,ABS,HB,GR503,VACUU 1 S.N.A
...3 T0061 BN64-00453A WINDOW-REMOCON;32R71,PC,V0,VIOLET,DIFFUS 1 S.N.A
...3 T0022 BN64-00467A KNOB CONTROL;SONOMA26,32,40,ABS,-,-,-,V0 1 S.A
...3 M0145 BN96-03466B ASSY BOARD P-FUNCTION;LE40M71BX,CT5000-4 1 S.A
...3 M0020 BN96-04015C ASSY BOARD P;LE40M91BX,CT5000-4330C,POWE 1 S.A
0.1 M0002 BN90-00938J ASSY COVER REAR;40F71,SO,HIPS,HB,BK500 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 2 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 14 S.A
..2 M0013 BN96-04227C ASSY COVER P-REAR;40F71,SO,-,HIPS,HB,BK5 1 S.A
...3 T0069 AA60-00091G SPACER-FELT;-,FELT,200X10,-,-,BLK,T0.5,- 2 S.N.A
...3 T0069 AA63-60122K SPACER-FELT;SPD-42P3S,FELT,L60,D20,T0.35 4 S.N.A
...3 BN61-02776A HOLDER-WALL;32R7,ABS,HB,BLK 1 S.N.A
...3 M0006 BN63-02690C COVER-REAR;40F71,SO,HIPS,-,-,-,HB,-,BK50 1 S.N.A
...3 T0071 BN64-00483A INLAY-TERMINAL;MOSEL 40",PS SHEET,T0.5,E 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,PP,V0,BLK 1 S.N.A
0.1 M0216 BN90-00941A ASSY STAND;40M70,ABS+PMMA,HB,BK23,H/GLAS 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
..2 M0013 BN96-03418A ASSY STAND P-BASE;40M70,ABS+PMMA,HB,BK23 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,B,M4,L10,ZPC(YEL),SWR 4 S.A
...3 BN61-02247A HOLDER-SWIVEL RING;40R71,ACETAL,BLK 1 S.N.A
...3 BN61-02248A HOLDER-SWIVEL RING;40R71,ACETAL NATUAL,T 1 S.N.A
...3 BN61-02249A HOLDER-SWIVEL RING;40R71,ACETAL NATUAL,B 1 S.N.A
...3 BN61-02259A BRACKET-STAND BOTTOM;BORDEAUX 40,SGHC,T3 1 S.N.A
...3 BN61-02260A BRACKET-HINGE SWIVEL;BORDEAUX 40,SGHC,T3 1 S.N.A
...3 CCM1 BN63-02183E COVER-SHEET;Rhcm,PE Vinyl,T0.05,750mm,20 0.5 S.N.A
...3 T0004 BN63-02364A COVER-STAND BASE;40R71,ABS+PMMA,HB,BK23, 1 S.N.A
...3 BN63-02495A COVER-STAND SUB;40M70,ABS+PMMA,HB,BK23,H 1 S.N.A
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1. 4 S.N.A
...3 T0920 BN61-02410A GUIDE-STAND;MOSEL,40,ABS,V0,-,-,-,BK07,- 1 S.N.A
....4 T0514 BN61-02368A BRACKET-SUPPORT;BORDEAUX 40,SECC,T1.2 2 S.N.A
0.1 T0852 BN91-01058Q ASSY LCD-SPZ;LNS4096DX/XAA 1 S.N.A
..2 M0215 BN07-00288A LCD-PANEL;LTA400HS-LH1,8bit,952*551*51.0 1 S.A
0.1 M0112 BN91-01235A ASSY SHIELD;LA40F71BX/* 1 S.N.A
6-1
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 1 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 6 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 5 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 4 S.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 5 S.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,B,M4,L10,YEL,SWRCH18A 2 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,B,M4,L10,YEL,SWRCH18A 9 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,B,M4,L10,YEL,SWRCH18A 2 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,B,M4,L10,YEL,SWRCH18A 2 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,B,M4,L10,YEL,SWRCH18A 1 S.N.A
..2 M0081 6003-001439 SCREW-TAPTITE;BH,+,S,M4,L8,ZPC(YEL) 1 S.N.A
..2 T0076 BN39-00615D CBF HARNESS;BORDEAUX,1617#22,3P,1P,RING, 1 S.A
..2 M2893 BN39-00716B LEAD CONNECTOR;LE40R71BX/XEC,UL3239#24,2 1 S.A
..2 M2893 BN39-00717A LEAD CONNECTOR;LE32R71BX/XEC,UL3443#28,5 1 S.A
..2 M2893 BN39-00725E LEAD CONNECTOR;LE40F71BX,UL2835#28,UL/CS 1 S.A
..2 M2893 BN39-00727D LEAD CONNECTOR;LE40F71BX,UL1571#30,UL/CS 1 S.A
..2 M2893 BN39-00741A LEAD CONNECTOR;LE40M71BX,UL1007#26,UL/CS 1 S.A
..2 M0174 BN44-00140A IP BOARD;PSIV280601A,40" MOSEL,44mA,86m 1 S.A
..2 M0146 BN61-02256A BRACKET-PANEL SIDE;BORDEAUX 40,SECC,T1.2 1 S.N.A
..2 M0146 BN61-02257A BRACKET-PANEL SIDE;BORDEAUX 40,SECC,T1.2 1 S.N.A
..2 M0115 BN61-02414A BRACKET-STAND LINK;MOSEL 40",SECC,T1.6 1 S.N.A
..2 M0114 BN61-02500A HOLDER-WIRE;NYLON6.6,NATURAL 2 S.N.A
..2 T0447 BN96-03421A ASSY BRACKET P-PANEL;40M7,EO,MOSEL 1 S.N.A
...3 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 1 S.A
...3 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 2 S.A
...3 M0146 BN61-02251A BRACKET-PANEL TOP;Bordeaux 40,SECC,T1.2 1 S.N.A
...3 BN61-02252A BRACKET-PANEL BOTTOM;Bordeaux 40,SECC,T1 1 S.N.A
...3 BN61-02253A BRACKET-GUIDE MAIN;Bordeaux 40,SECC,T1.2 1 S.N.A
...3 BN61-02254A BRACKET-GUIDE POWER;Bordeaux 40,SECC,T1. 1 S.N.A
...3 BN61-02255A BRACKET-GUIDE POWER;Bordeaux 40,SECC,T1. 1 S.N.A
...3 T0101 BN61-02438A BRACKET-WALL;MOSEL 40,SECC T1.6 1 S.N.A
...3 M0131 BN63-02549A GASKET;LE37R72B,Conductive Fabric,26mm,1 3 S.N.A
...3 M0131 BN63-02712A GASKET;LE40M71BX,Conductive Fabric,8mm,1 1 S.N.A
...3 T0069 AA60-00091J SPACER-FELT;-,FELT,330X10,-,-,BLK,T0.5,- 1 S.N.A
...3 M0131 BN63-02628A GASKET;Oxford,Conductive Fabric,8,12,300 1 S.N.A
...3 T0514 BN61-02778A BRACKET-SUPPORT;40M7,SECC T1.2 1 S.N.A
..2 M0059 BN96-03431G ASSY BOARD P-HOLDER AV;40F71,MOSEL,CT500 1 S.N.A
...3 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 2 S.A
...3 BN61-02411A HOLDER-SIDE AV;MOSEL,40,HIPS,V0,-,-,-,BK 1 S.N.A
...3 T0578 BN64-00454B INLAY AV;BORDEAUX,PS SHEET,T0.3,-,-,BLAC 1 S.N.A
...3 T0186 BN64-00484A INLAY-MMS;MOSEL,40,PS SHEET,T0.3,-,-,-,- 1 S.N.A
...3 M0020 BN96-02439B ASSY BOARD P-SIDE AV;LE40M71BX,CT5000-36 1 S.N.A
..2 M2893 BP39-00177B LEAD CONNECTOR;RE40**,UL1007#26,5P,150mm 1 S.A
0.1 M0017 BN91-01237A ASSY CHASSIS;LA40F71BX/* 1 S.N.A
..2 T0862 BN94-00868G ASSY PCB MISC-MMS;MOSEL,NEO MOSEL ALL 1 S.N.A
...3 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.003 S.N.A
...3 CN330 3711-003340 HEADER-BOARD TO CABLE;BOX,16P,2R,2mm,STR 1 S.A
...3 CN5 3722-001051 JACK-USB;4P/1C,AU,BLK,ANGLE,A TYPE 1 S.A
...3 SUB06 BN63-02530A SHIELD-MMS;MOSEL,SPTE T0.2,-,-,-,-,- 1 S.N.A
...3 T0174 BN97-00842J ASSY SMD;LE26R73BDX/XET 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
