Image preview - the first page of the document
>> Download Список электрических деталей documenatation <<
Text preview - extract from the document
6 Electrical Parts List
6 Electrical Parts List
You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LE40M71B Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
0 LE40M71BX/NWT LE40M71B,Q56A/40M70-GMS,40,LCD-TV,UKRAIN 0
0.1 M0001 BN90-00935A ASSY COVER FRONT;40M70,EO,ABS+PMMA,HB,BK 1 S.N.A
..2 T0175 BN96-03271A ASSY SPEAKER P;8ohm,Mosel 32,Left,10W,BA 1 S.A
..2 T0175 BN96-03272A ASSY SPEAKER P;8ohm,Mosel 32,Right,10W,B 1 S.A
..2 T0003 BN96-03412A ASSY COVER P-FRONT;40M70,EO,ABS+PMMA,HB, 1 S.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 4 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 S.N.A
...3 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
...3 CCM1 BN63-02183G COVER-SHEET;Rhcm,PE Vinyl,T0.05,1100mm,2 1.983 S.N.A
...3 M0112 BN63-02488A COVER-FRONT;40M70,EO,ABS+PMMA,-,-,-,HB,- 1 S.N.A
...3 T0023 BN64-00342A KNOB POWER;ROME,40,PC,VIOLET 1 S.N.A
...3 T0054 BN64-00443A KNOB-DECORATION;32R71,ABS,HB,GR503,VACUU 1 S.N.A
...3 T0061 BN64-00453A WINDOW-REMOCON;32R71,PC,V0,VIOLET,DIFFUS 1 S.N.A
...3 T0022 BN64-00467A KNOB CONTROL;SONOMA26,32,40,ABS,-,-,-,V0 1 S.N.A
...3 M0145 BN96-03466B ASSY BOARD P-FUNCTION;LE40M71BX,CT5000-4 1 S.A
...3 M0146 BN96-03634B ASSY BOARD P-POWER & IR;LE40M71BX,CT5000 1 S.A
...3 BN61-02667A HOLDER-BOSS;MOSEL 40,ABS,VO,TOP 2 S.N.A
...3 BN61-02670A HOLDER-BOSS;MOSEL 40,ABS,VO,BOTTOM,LEFT 1 S.N.A
...3 BN61-02671A HOLDER-BOSS;MOSEL 40,ABS,VO,BOTTOM,RIGHT 1 S.N.A
...3 BN61-02771A BOSS-BOND;MOSEL,ABS+PMMA,NATURAL,BOND 14 S.N.A
...3 BN96-03665B ASSY COVER P-DECORATION;MOSEL,40,PC,CLEA 1 S.N.A
....4 T0069 AA60-00091B SPACER-FELT;-,FELT,100X10,-,-,BLK,T0.35, 2 S.N.A
....4 T0069 AA63-60001Q SPACER-FELT;-,FELT,-,-,-,BLK,T0.35,-,150 2 S.N.A
....4 CCM1 BN63-02183G COVER-SHEET;Rhcm,PE Vinyl,T0.05,1100mm,2 0.09 S.N.A
....4 T0056 BN63-02490A COVER-DECORATION;MOSEL 40,PC,CLEAR 1 S.N.A
....4 T0056 BN63-02528A COVER-DECORATION;MOSEL,40,ABS,HB,Cr-Plat 1 S.N.A
....4 T0056 BN63-02529A COVER-DECORATION;MOSEL,40,ABS,HB,Cr-Plat 1 S.N.A
0.1 M0002 BN90-00938A ASSY COVER REAR;40M70,EO,HIPS,HB,BK500 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 2 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 14 S.A
..2 M0013 BN96-03415A ASSY COVER P-REAR;40M71,EO,HIPS,HB,BK500 1 S.A
...3 M0006 BN63-02489A COVER-REAR;40M71,EO,HIPS,-,-,-,HB,-,BK50 1 S.N.A
...3 T0071 BN64-00481A INLAY-TERMINAL;MOSEL,40,EO,PS SHEET,T0.5 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,PP,V0,BLK 1 S.N.A
...3 T0069 AA63-60122K SPACER-FELT;SPD-42P3S,FELT,L60,D20,T0.35 4 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 S.N.A
...3 BN61-02776A HOLDER-WALL;32R7,ABS,HB,BLK 1 S.N.A
0.1 M0216 BN90-00941A ASSY STAND;40M70,ABS+PMMA,HB,BK23,H/GLAS 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
..2 M0013 BN96-03418A ASSY STAND P-BASE;40M70,ABS+PMMA,HB,BK23 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,B,M4,L10,ZPC(YEL),SWR 4 S.A
...3 BN61-02247A HOLDER-SWIVEL RING;40R71,ACETAL,BLK 1 S.N.A
...3 BN61-02248A HOLDER-SWIVEL RING;40R71,ACETAL NATUAL,T 1 S.N.A
...3 BN61-02249A HOLDER-SWIVEL RING;40R71,ACETAL NATUAL,B 1 S.N.A
...3 BN61-02259A BRACKET-STAND BOTTOM;BORDEAUX 40,SGHC,T3 1 S.N.A
...3 BN61-02260A BRACKET-HINGE SWIVEL;BORDEAUX 40,SGHC,T3 1 S.N.A
...3 CCM1 BN63-02183E COVER-SHEET;Rhcm,PE Vinyl,T0.05,750mm,20 0.5 S.N.A
...3 T0004 BN63-02364A COVER-STAND BASE;40R71,ABS+PMMA,HB,BK23, 1 S.N.A
...3 BN63-02495A COVER-STAND SUB;40M70,ABS+PMMA,HB,BK23,H 1 S.N.A
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1. 4 S.N.A
...3 T0920 BN61-02410A GUIDE-STAND;MOSEL,40,ABS,V0,-,-,-,BK07,- 1 S.N.A
....4 T0514 BN61-02368A BRACKET-SUPPORT;BORDEAUX 40,SECC,T1.2 2 S.N.A
6-1
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
0.1 M0017 BN91-01055A ASSY CHASSIS-SPZ;LE40M71BX/XEC,Q56A ,AM 1 S.N.A
..2 T0862 BN94-00868D ASSY PCB MISC-MMS;LE40M71BX/XEC 1 S.A
...3 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.003 S.N.A
...3 CN330 3711-003340 HEADER-BOARD TO CABLE;BOX,16P,2R,2mm,STR 1 S.A
...3 T0174 BN97-00842E ASSY SMD;LE40M71BX/XEC 1 S.N.A
....4 CIS05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
