Image preview - the first page of the document



>> Download Схема в разобранном виде и список деталей documenatation <<

Text preview - extract from the document

                                                                                                           5 Exploded View & Parts List


5 Exploded View and Parts List
- You can search for updated part codes through ITSELF web site.
  URL : http://itself.sec.samsung.co.kr/
5-1 LE40M71B Exploded View


                                                                                                   M0013




                                                                                   T0447
                                                                                           M0014




                                                                   M0215




                       T0003




                                           T0175




                                                                           T0175




                                                                                   M0013




                                                                                                                                   5-1
5 Exploded View & Parts List

5-2 LE40M71B Parts list

  Location   Code.No       Item & Specification                       Q'ty   SA/SNA   Remark

  T0003      BN96-03412A   ASSY COVER P-FRONT;40M70,EO,ABS+PMMA,HB,    1      S.A

  T0175      BN96-03271A   ASSY SPEAKER P;8ohm,Mosel 32,Left,10W,BA    1      S.A

  T0175      BN96-03272A   ASSY SPEAKER P;8ohm,Mosel 32,Right,10W,B    1      S.A

  M0215      BN07-00271A   LCD-PANEL;LTA400WH-LH1,10bit/120Hz,952*5    1      S.A

  T0447      BN96-03421A   ASSY BRACKET P-PANEL;40M7,EO,MOSEL          1     S.N.A

  M0014      BN94-00964B   ASSY PCB MAIN;LE40M71BX/*                   1      S.A

  M0013      BN96-03415A   ASSY COVER P-REAR;40M71,EO,HIPS,HB,BK500    1      S.A

  M0013      BN96-03418A   ASSY STAND P-BASE;40M70,ABS+PMMA,HB,BK23    1      S.A




5-2
