10 Operating Instructions and Installation

10 Operating Instructions and Installation
10-1 Front

- The product color and shape may vary depending on the model.

1. SOURCE 6. POWER INDICATOR
Displays a menu of all of the available input sources Blinks and turns off when the power is on and lights
(TV, Ext.1, Ext.2, AV, S-Video, Component, PC, DVI). up in stand-by mode.
In the on-screen menu, use this button as you use the
ENTER button on the remote control. 7. REMOTE CONTROL SENSOR
Aim the remote control towards this spot on the TV.
2. MENU
Press to see an on-screen menu of your TV's features. 8. (POWER)
Press to turn the TV on and off.
3.
Press to decrease or increase the volume.
In the on-screen menu, use the buttons as
you use the and buttons on the remote control.

4. C/P.
Press to change channels.
In the on-screen menu, use the C/P. buttons
as you use the and buttons on the remote control.

5. SPEAKERS

10-1
10 Operating Instructions and Installation

10-2 Connection Panel

10-2
10 Operating Instructions and Installation

1. Connecting an Aerial or Cable Television Network
To view television channels correctly, a signal must be received by the set from one of the following sources:
- An outdoor aerial / A cable television network / A satellite network
2. Connecting HDMI/DVI
- Supports connections between HDMI-connection-enabled AV devices (Set-Top Boxes, DVD players, AV receivers
and digital TVs).
- No sound connection is needed for an HDMI to HDMI connection.
What is HDMI?
- HDMI, or high-definition multimedia interface, is a next-generation interface that enables the transmission of digital
audio and video signals using a single cable without compression.
- "Multimedia interface" is a more accurate name for it especially because it allows multiple channels of digital
audio(5.1 channels).The difference between HDMI and DVI is that the HDMI device is smaller in size, has the
HDCP(High Bandwidth Digital Copy Protection) coding feature installed, and supports multi - channel digital audio.
- Use the HDMI/DVI terminal for DVI connection to an extended device.
You should use the DVI-to-HDMI cable or DVI-HDMI Adapter for the connection, and the "R - AUDIO - L" terminal
on DVI for sound output.
3. Connecting Set-Top Box, VCR or DVD
- Connect the VCR or DVD SCART cable to the SCART connector of the VCR or DVD.
- If you wish to connect both the Set-Top Box and VCR (or DVD), you should connect the Set-Top Box to the VCR
(or DVD) and connect the VCR (or DVD) to your set.
5. Connecting External A/V Devices
- Connect RCA or S-VIDEO cable to an appropriate external A/V device such as VCR, DVD or Camcorder.
- Connect RCA audio cables to "R - AUDIO - L" on the rear of your set and the other ends to corresponding audio
out connectors on the A/V device.
- Headphone may be connected to the headphone output ( 4 ) on the rear of your set. While the headphone is
connected, the sound from the built-in speakers will be disabled.
6. SERVICE
- Connector for engineer.
7. Connecting AUDIO
- Connect RCA audio cables to "R - AUDIO - L" on the rear of your set and the other ends to corresponding audio
in connectors on the Amplifier or DVD Home Theater.
8. Connecting Computer
- Connect the D- Sub cable (optional) to "PC (PC IN)" on the rear of your set and the other end to the Video Card
of your computer.
- Connect the stereo audio cable (optional) to "AUDIO (PC IN)" on the rear of your set and the other end to "Audio
Out" of the sound card on your computer.
9. Connecting Component Devices (DTV/DVD)
- Connect component video cables (optional) to component connector ("PR", "PB", "Y") on the rear of your set and
the other ends to corresponding component video out connectors on the DTV or DVD.
- If you wish to connect both the Set-Top Box and DTV (or DVD), you should connect the Set-Top Box to the DTV (or
DVD) and connect the DTV (or DVD) to component connector ("PR", "PB", "Y") on your set.
- The PR, PB and Y connectors on your component devices (DTV or DVD) are sometimes labeled Y, B-Y and
R-Y or Y, Cb and Cr.
- Connect RCA audio cables (optional) to "R - AUDIO - L" on the rear of your set and the other ends to
corresponding audio out connectors on the DTV or DVD.
- This LCD TV displays the optimum picture in 720p mode.
10. Kensington Lock
- The Kensington lock (optional) is a device used to physically fix the system when used in a public place.
- If you want to use a locking device, contact the dealer where you purchased the TV.
- The place of the Kensington Lock may be different depending on its model.

10-3
10 Operating Instructions and Installation

10-3 Remote Control
1 Television Standby button
2 Number buttons for direct channel access
3 One/Two-digit channel selection
4 Selects the TV mode directly
5 It display "Channel Manager" on the screen.
6 Volume decrease
Volume increase
7 Temporary sound switch-off
8 Menu display and change confirmation
9 Sound mode selection
10 Picture-In-Picture On / Off
11 Picture effect selection
12 PIP FUNCTIONS
SOURCE: Input source selection
SWAP: Interchange the main and sub picture
SIZE: PIP size selection
POSITION: PIP position selection
P : Next channel
P : Previous channel
13 Sound effect selection
14 SRS TSXT selection
15 Available source selection
16 Previous channel
17 Selects the PC mode directly
18 Automatic Power-off
19 P : Next channel
P : Previous channel
20 Exit the OSD
21 Control the cursor in the menu
22 Use to see information on the current
broadcast
23 Picture freeze
25 Picture size selection
Teletext Functions
4 Exit from the teletext display
8 Teletext index
10 Teletext hold
12 SOURCE: Teletext size selection
SWAP: Teletext store
15 Teletext mode selection (LIST/FLOF)
16 Teletext sub page
19 P : Teletext next page
P : Teletext previous page
20 Teletext cancel
22 Teletext reveal
24 Teletext display/mix both teletext information
and the normal broadcast
9, 11, 23, 25
Fastext topic selection

10-4
10 Operating Instructions and Installation

10-4 Installing the Stand

1. Place the TV faced down on a soft cloth or cushion on a table.
2. Put the stand into the hole at the bottom of the TV.
3. Insert screw into the hole indicated and tighten.

10-5
10 Operating Instructions and Installation

Memo

10-6
