Image preview - the first page of the document
>> Download 11_Electrical Part List documenatation <<
Text preview - extract from the document
6 Electrical Parts List
6 Electrical Parts List
-You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LE26R71BX/BWT Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
0 LE26R71BX/XEC LE26R71B,Q52A/26R70-GBD,26,LCD-TV,SPAIN 0
1 M0001 BN90-00844A ASSY COVER FRONT;LE26R71BX/XEC,BORDEAUX 1 SNA
..2 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 SNA
..2 T0003 BN96-03012A ASSY COVER P-FRONT;26R71,EO,ABS+PMMA,HB, 1 SA
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 SNA
...3 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 SA
...3 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20 1.118 SNA
...3 M0112 BN63-02331A COVER-FRONT;26R71,EO,ABS+PMMA,HB,BK23,S/ 1 SNA
...3 BN63-02333A COVER-DECORATION;26R71,HIPS,HB,GR503,BLM 1 SNA
...3 T0023 BN64-00342A KNOB POWER;ROME,40,PC,VIOLET 1 SNA
...3 T0071 BN64-00366A INDICATOR-LED;ROME-I,PC,CLEAR,ALL MODEL 1 SNA
...3 T0022 BN64-00442A KNOB CONTROL;26,32,40R71,PC,BLK,ACRYL CL 1 SNA
...3 T0054 BN64-00443A KNOB-DECORATION;32R71,ABS,HB,GR503,VACUU 1 SNA
...3 T0603 BN64-00453A WINDOW-RMC;32R71,PC,V0,VIOLET 1 SNA
...3 M0146 BN96-03046A ASSY BOARD P-POWER & IR &FUNCT;BORDEAUX, 1 SA
..2 T0175 BN96-03053A ASSY SPEAKER P;16ohm,Bordeuax 26,Left,5W 1 SA
..2 T0175 BN96-03054A ASSY SPEAKER P;16ohm,Bordeuax 26,Right,5 1 SA
1 M0002 BN90-00846A ASSY COVER REAR;26R71,EO,BORDEAUX 1 SNA
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 2 SA
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 13 SA
..2 M0013 BN96-03014A ASSY COVER P-REAR;26R71,EO,ABS+PMMA,HB,B 1 SA
...3 T0064 AA65-00003A CLAMPER CORE;SIR-T100,PE BLACK 1 SNA
...3 T0101 BN61-02058A BRACKET-WALL;23,27,MGM,SECC,T1.6 2 SNA
...3 M0006 BN63-02332A COVER-REAR;26R71,EO,SO,ABS+PMMA,HB,BK23, 1 SNA
...3 T0071 BN64-00444A INLAY-TERMINAL;26R71,(BLK),PS SHEET,T0.5 1 SNA
1 M0216 BN90-00848A ASSY STAND;26R71,BORDEAUX 1 SNA
..2 T0524 6902-000561 BAG PE;HDPE+NITRON(DOUBLE),T0.015+T0.5,W 1 SNA
..2 M0013 BN96-03017A ASSY STAND P-BASE;26R71,ABS+PMMA,HB,BK23 1 SA
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 SA
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,B,M4,L10,ZPC(YEL),SWR 4 SA
...3 BN61-02192A GUIDE-STAND;26,32R71,ABS,V0,BLK 1 SNA
...3 BN61-02202A BRACKET-STAND BOTTOM;BORDEAUX 26,SECC,T2 1 SNA
...3 BN61-02204A HOLDER-SWIVEL RING;26,32R71,ACETAL,BLK 1 SNA
...3 BN61-02232A HOLDER-SWIVEL RING;32R71,ACETAL NATUAL,T 1 SNA
...3 BN61-02233A HOLDER-SWIVEL RING;32R71,ACETAL NATUAL,B 1 SNA
...3 BN61-02236A BRACKET-HINGE SWIVEL;BORDEAUX 32,SECC,T1 1 SNA
...3 BN63-02322A COVER-STAND SUB;32R71,ABS+PMMA,HB,BK23,H 1 SNA
...3 T0004 BN63-02335A COVER-STAND BASE;26R71,ABS+PMMA,HB,BK23, 1 SNA
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1. 4 SNA
1 M0017 BN91-01005C ASSY CHASSIS;LE26R71BX/XEC,BORDEAUX 1 SNA
..2 M0014 BN94-00847A ASSY PCB MAIN;LE26R71BX,Q52A 1 SA
...3 T0245 0202-001522 SOLDER-WIRE FLUX;LFA3-107,-,D1.2,96.5Sn/ 0.25 SNA
...3 JA709 3701-001294 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,AU 1 SA
...3 CN501 3711-004068 HEADER-BOARD TO CABLE;BOX,5P,1R,2MM,ANGL 1 SA
...3 CN500 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 SA
...3 TEST901 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 SA
...3 CN503 3711-005884 HEADER-BOARD TO BOARD;BOX,30P,2R,2mm,ANG 1 SA
...3 CN800 3711-005942 HEADER-BOARD TO CABLE;BOX,16P,1R,2mm,STR 1 SA
...3 JA701_EU 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 SA
...3 JA702_EU 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 SA
...3 JA708 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 SA
...3 JA716 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 SA
...3 JA717_OP 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 SA
...3 JA712_OP 3722-001734 JACK-VHS;4P,SN,BLK,STRAIGHT 1 SA
...3 JA715 3722-002360 JACK-PIN;3P,AU,GRN/BLU/RED,STRAIGHT 1 SA
6-1
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
...3 JA704 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 SA
...3 JA711 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 SA
...3 JA713 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 SA
...3 JA714_OP 3722-002363 JACK-PIN;3P,Sn,YEL/WHT/RED,STRAIGHT 1 SA
...3 T0562 6046-001013 STAND OFF;M3,L5,Ni PLT,SUM24L,#4-40 2 SNA
...3 CIS3 BN40-00079A TUNER;TCPW3001PD32S(H),TCPW3001PD32S(H), 1 SA
...3 M0107 BN63-01847A SHIELD-COVER;ROME,SECC,T0.3,49.5,79.5,HE 1 SNA
...3 CIS8 BN73-00024C SILICON/RUBBER-BERGQUIST;VENUS 32,40",SI 1 SNA
...3 T0510 BN97-00807A ASSY SMD-MAIN;LE26R71B,Q52A,Bordeaux 1 SNA
....4 CIS5 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
