Image preview - the first page of the document
20080328124348671_02_specifications


>> Download 20080328124348671_02_specifications documenatation <<

Text preview - extract from the document
                                                                                             2. Product specifications

2. Product specifications
2-1. Feature & Specifications
               Model                                                  LE32A55*P

                                                        Feature

   Digital-TV,RF,3-HDMI, 2Ext, 1Component,1-A/V,1-S-video,USB2.0(Wiselink), D-sub
   Brightness : 500cd/m2
   Dynamic Contrast Ratio : 15,000:1
   Response time : 8ms
   Dynamic contrast, Super-PVA
   PIP(in HDMI1,2,3,Component1,PC mode and Sub picture is available TV, Ext1/2, AV)

                                                     Specifications

               Item                                                   Description
LCD Panel                      TFT-LCD panel, RGB vertical stripe, SPVA mode, normaly black,
                               32-Inch viewable, 0.3635(H) x 0.36375(V) x 3 mm pixel pitch
Scanning Frequency             Horizontal : 30 kHz ~ 80 kHz (Automatic)
                               Vertical : 56 Hz ~ 75 Hz (Automatic)
Display Colors                 16.7 million colors
Maximum resolution             Horizontal : 1920 Pixels
                               Vertical : 1080 Pixels
Input Signal                   Analog 0.7 Vp-p
