Image preview - the first page of the document



>> Download 02_Product Specification documenatation <<

Text preview - extract from the document

                                                                                   2 Product Specifications



2 Product specifications

2-1 Fashion Feature

Supreme Digital Interface & Networking
- With a built-in HD digital tuner, it supports HD broadcasting with no particular set-top box and provides
  simple access with a single remote control.

Excellent Picture Quality
- DNle technology provides life-like clear images.

SRS TruSurround XT
- SRS TruSurround XT provides a virtual Dolby surround system.

Convenience
- The TV utilizes the HDMI system to implement perfect digital sound and picture quality.
- Supports DVB-CI (Common Interface)
- Supports Modem (Only for Italy)
- Supports SMART CARD (NON CAS / Only for Italy)
        Inch                32"                            40"                             46"
  PJT           Chassis           Panel          Chassis         Panel         Chassis            Panel
 LE32N73BD      MOSEL           AUO             MOSEL         AMLCD            MOSEL              AMLCD
 LE40N73BD      (50Hz)        1366X768          (50Hz)       1366X768          (50Hz)            1366X768
 LE46N73BD     MMS,USB          100%           MMS,USB         100%           MMS,USB              100%


Wise link
- Accept 10 types of Memory Cards including USB (10 in 3 ) Excellent Compatibility.
  SD/MMC/CF/MD/MS/MSPRO/XD/SM

LCD 100Hz
- You can experience more natural picture and clearer texts without motion blur even in fast
  moving scenes.

Wide Color Gamut
- More natural and vivid picture quality by WCG (127%)

High Dynamic Contrast
- 7000:1 Highest dynamic Contrast Ratio

Best Off-Angle Viewing
- Widened Viewing Angle , 178      / 178   (Left/Right)

Real 10 Bit
- Panel 10 Bit + Signal Processing 10 Bit

Game Mode
- Present the most suitable picture for gaming

Swivel Stand
- 20 / 20 (left/right)




                                                                                                            2-1
2 Product Specifications


2-2 Technical and Environmental Specifications


Model Name                                  LE32N73BD                             LE40N73BD                               LE46N73BD
Screen Size (Diagonal)                        32 inch                                  40 inch                                  46 inch
PC Resolution                          1360 x 768 @ 60 Hz                       1360 x 768 @ 60 Hz                       1360 x 768 @ 60 Hz
Input Signal
Sync.                               H/V Separate, TTL, P. or N.              H/V Separate, TTL, P. or N.              H/V Separate, TTL, P. or N.
Video Signal                            0.7 Vp-p @ 75 ohm                        0.7 Vp-p @ 75 ohm                        0.7 Vp-p @ 75 ohm
TV
Colour System                        PAL, SECAM-B/G, D/K,                     PAL, SECAM-B/G, D/K,                     PAL, SECAM-B/G, D/K,
                                 I, I/I, L/L
