Image preview - the first page of the document
>> Download 03_Exploded View & Part List documenatation <<
Text preview - extract from the document
5 Exploded View & Parts List
5 Exploded View and Parts List
- You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
5-1 LE27S73BD Exploded View
M0013
T0447 T0159
M0215
T0003
T0175
M0014
T0175
M0013
5-1
5 Exploded View & Parts List
5-2 LE27S73BD Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-03836D ASSY COVER P-FRONT;27S73,EO,ABS+PMMA,HB, 1 S.A
T0175 BN96-03279A ASSY SPEAKER P;16ohm,Sonoma 26,Left,5W,N 1 S.A
T0175 BN96-03280A ASSY SPEAKER P;16ohm,Sonoma 26,Right,5W, 1 S.A
M0215 BN07-00136A LCD-PANEL;V270B1-L01,Torino,8BIT,638.5*3 1 S.A
T0447 BN96-04168A ASSY BRACKET P-PANEL;SONOMA,27EO,IDTV,SE 1 S.N.A
M0014 BN94-01063B ASSY PCB MAIN;LE27S73BDX/FID 1 S.A
T0159 BN96-03058A ASSY PCB P-SMPS;Bordeaux 26 PFC,LE26R71B 1 S.A
M0013 BN96-03837B ASSY COVER P-REAR;27S73,EO,-,HIPS,HB,BK5 1 S.A
M0013 BN96-03945A ASSY STAND P-BASE;SONOMA 27,ABS+PMMA,HB, 1 S.A
5-2
5 Exploded View & Parts List
5-3 LE32S73BD Exploded View
M0014
T0159
T0447
M0215
M0013
T0076
T0003
T0175
M0013
T0175
5-3
5 Exploded View & Parts List
5-4 LE32S73BD Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-03628H ASSY COVER P-FRONT;32S73,EO,-,ABS+PMMA,H 1 S.A
T0175 BN96-03247B ASSY SPEAKER P;8ohm,Yellow/Black,470mm,1 1 S.A
T0175 BN96-03248B ASSY SPEAKER P;8ohm,Red/Black,950mm,10W, 1 S.A
M0215 BN07-00247A LCD-PANEL;LTA320WT-L14,-,8BIT,760*450*50 1 S.A
T0447 BN96-03440A ASSY BRACKET P-PANEL;CAMBRIDG32,-,SECC,- 1 S.N.A
T0076 BN39-00615D CBF HARNESS;BORDEAUX,1617#22,3P,1P,RING, 1 S.A
M0014 BN94-01064B ASSY PCB MAIN;LE32S73BDX/FID 1 S.A
T0159 BN96-03775A ASSY PCB P-SMPS;FreeVoltage SMPS,LA32R71 1 S.A
M0013 BN96-03838B ASSY COVER P-REAR;32S73,EO,-,HIPS,HB,BK5 1 S.A
M0013 BN96-03698A ASSY STAND P-BASE;SONOMA32,ABS+PMMA,HB,B 1 S.A
5-4
5 Exploded View & Parts List
5-5 LE37S73BD Exploded View
M0014
T0159
T0447
M0215
M0013
T0003
T0076
T0175
M0013
T0175
5-5
5 Exploded View & Parts List
5-6 LE37S73BD Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-04044D ASSY COVER P-FRONT;37S73,EO(XET),ABS+PMM 1 S.A
T0175 BN96-03247A ASSY SPEAKER P;8ohm,Sonoma 32,Left,10W,N 1 S.A
T0175 BN96-03248A ASSY SPEAKER P;8ohm,Sonoma 32,Right,10W, 1 S.A
M0215 BN07-00255A LCD-PANEL;T370XW01,8bit,877.0*514.6*54.7 1 S.A
T0447 BN96-03441A ASSY BRACKET P-PANEL;37,SECC,BUILT-IN 1 S.N.A
T0076 BN39-00615D CBF HARNESS;BORDEAUX,1617#22,3P,1P,RING, 1 S.A
M0014 BN94-01064N ASSY PCB MAIN;LE32S73BDX/XET 1 S.A
T0159 BN96-03050A ASSY PCB P-SMPS;Bordeaux 37 PFC,LE37R71B 1 S.A
M0013 BN96-03697B ASSY STAND P-BASE;SONOMA,40,ABS+PMMA,HB, 1 S.A
M0013 BN96-04045C ASSY COVER P-REAR;37S73,EO(XET),HIPS,HB, 1 S.A
5-6
5 Exploded View & Parts List
5-7 LE40S73BD Exploded View
M0014
M0174
T0447
M0215
M0013
T0003
T0076
T0175
M0013
T0175
5-7
5 Exploded View & Parts List
5-8 LE40S73BD Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-03394H ASSY COVER P-FRONT;40S73,EO,ABS+PMMA,HB, 1 S.A
T0175 BN96-03247A ASSY SPEAKER P;8ohm,Sonoma 32,Left,10W,N 1 S.A
T0175 BN96-03248A ASSY SPEAKER P;8ohm,Sonoma 32,Right,10W, 1 S.A
M0215 BN07-00264A LCD-PANEL;LTA400WT-L01,8bit,952*551*51.0 1 S.A
T0447 BN96-04182A ASSY BRACKET P-PANEL;SONOMA,40EO,IDTV,SE 1 S.N.A
T0076 BN39-00615D CBF HARNESS;BORDEAUX,1617#22,3P,1P,RING, 1 S.A
M0014 BN94-01064A ASSY PCB MAIN;LE32S73BDX/XEU 1 S.A
M0174 BN44-00134A IP BOARD;SIP40,LE40R71B,2.0~3.0mA,6.0~7. 1 S.A
M0013 BN96-03839B ASSY COVER P-REAR;40S73,EO,-,HIPS,HB,BK5 1 S.A
M0013 BN96-03697A ASSY STAND P-BASE;SONOMA40,ABS+PMMA,HB,B 1 S.A
5-8
