5. Exploded View & Part List
5. Exploded View & Part List
5-1. LE46C750R2* Exploded View
R001A
T0101
T0101
T0175
INVER
T0175
T0101
T0910 T0101
PANEL M0174
TCON
M0014
F001A
T0920
SB04A
5-1
5. Exploded View & Part List
5-2. LE46C750R2* Parts List
Location No. Code No. Description & Specification Q'ty S.A/S.N.A Remark
F001A BN96-12781B ASSY COVER P-FRONT;46,LC750,EO,PC+PC,V2, 1 SA
PANEL BN07-00805A LCD-PANEL;LTF460HQ01,SSEZQS,8bit,46,16.7 1 SA
TCON BN81-04160A A/S-T CON LTF460HQ01;LTF460HQ01 1 SA
INVER BN81-04176A A/S-BB-L LTF460HQ01;LTF460HQ01 1 SNA
M0174 BN44-00341A AC VSS(I)-TV;PSIV281510A,I46F1_ASM,14mA, 1 SA
M0014 BN94-03388B ASSY PCB MAIN;LE46C750R2WX* 1 SA
T0910 BN96-13342A ASSY BRACKET P-STAND LINK;LC530 37/40/46 1 SNA
T0101 BN61-05997A BRACKET-WALL;LC650 46,SECC,T1.6 4 SNA
T0175 BN96-12837B ASSY SPEAKER P;6ohm,4pin,10W,L:630 R:290 1 SA
R001A BN96-14017G ASSY COVER P-REAR;46,LC750,EO,PCM,T0.5,B 1 SA
T0920 BN61-06003A GUIDE-STAND;37,40,46,LC650,PC+G/F,20%,V2 1 SNA
SB04A BN96-13133E ASSY STAND P-BASE;46/55,FOUR-LEG,PC+ABS, 1 SA
5-2
5. Exploded View & Part List
5-2-1. LE46C750R2* Parts List
Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
LE46C750R2WXXC
0.1 BN90-02457A ASSY COVER FRONT;46,LC750,EO 1 SNA
..2 F001A BN96-12781B ASSY COVER P-FRONT;46,LC750,EO,PC+PC,V2, 1 SA
...3 M0081 6003-001003 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 1 SA
...3 AB326 BN61-04661A BRACKET-STOPPER;L650,SK-5,T0.4,Plating,H 4 SNA
...3 CCM1 BN63-05199B COVER-SHEET;AMBER,PE,T0.08,W65mm,200M,CL 1.15 SNA
...3 CCM1 BN63-05199C COVER-SHEET;AMBER,PE,T0.08,W55mm,200M,CL 2.55 SNA
...3 F001 BN63-06417B COVER-FRONT;46,LC750,EO,PC+PC,V2,TP0010+ 1 SNA
....4 0103-007268 RESIN-PC;TP0010,2.0V0,NH PC,NH PC 2.0 V2 900 SNA
....4 0103-007269 RESIN-PC;GY0132,2.0V0,NH PC,NH PC 2.0 V2 800 SNA
...3 BN96-12757B ASSY HOLDER P-BOSS BOTTOM;40,46,55,LC650 1 SNA
....4 BN61-04731A BOSS-TAPE;AMBER,ACRYL,T1.1,W8.0mm,WHITE 0.41 SNA
....4 BN61-05983B HOLDER-BOSS BOTTOM;40,46,55,LC650,ABS,HB 1 SNA
.....5 0103-004612 RESIN-ABS;BK0020,HB,ABS,High Flow ABS 115 SNA
...3 BN74-00052A TAPE-PAPER;LB530,Crepe Paper,0.17mm, 10m 0.05 SNA
...3 FB26A BN96-14262B ASSY BOARD P-TOUCH FUNCTION&POWER IR;LC7 1 SA
...3 BN60-00163D SPACER-FOAM;LC650-46",FOAM,590,0.5,25,Bo 2 SNA
...3 BN60-00163J SPACER-FOAM;LC650-46",FOAM,1024,T 0.5,20 1 SNA
...3 BN60-00162E SPACER-FOAM;FOAM,50000mm,Dark Gray,0.5T, 0.36 SNA
..2 T0175 BN96-12837B ASSY SPEAKER P;6ohm,4pin,10W,L:630 R:290 1 SA
0.1 S001A BN90-02492A ASSY STAND;46,LC750,EO,FOUR-LEG 1 SNA
..2 SG03A BN96-13961B ASSY STAND P-GUIDE;40,46,LC750,W/W,PC+G/ 1 SA
...3 T0524 6902-001048 BAG PE;LDPE,T0.05,W160,L300,TRP,4g 1 SNA
...3 T0920 BN61-06003A GUIDE-STAND;37,40,46,LC650,PC+G/F,20%,V2 1 SNA
....4 0103-007285 RESIN-PC;BK0007,2.0 V2,PC/GF20%,Glass fi 478 SNA
...3 BN68-02821B MANUAL FLYER-STAND GUIDE;L750,SAMSUNG,W/ 1 SNA
...3 BN96-12031K ASSY ACCESSORY-SCREW;LC750,6003-001003,4 1 SNA
....4 M0081 6003-000133 SCREW-TAPTYPE;BH,+,-,S,M4,L8,ZPC(BLK),SW 4 SA
....4 M0081 6003-001003 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 4 SA
....4 T0524 6902-000341 BAG PE;LDPE,T0.05,L90,W70,TRP,,,PE MARK 1 SNA
..2 SB04A BN96-13133E ASSY STAND P-BASE;46/55,FOUR-LEG,PC+ABS, 1 SA
...3 M0081 6003-001003 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 13 SA
...3 SCREW 6003-001785 SCREW-TAPTYPE;FH,+,B,M4,L8,ZPC(BLK),SWRC 4 SA
...3 BN61-05240A HOLDER-SWIVEL RING TOP;LB700 46,POM HB,A 1 SNA
...3 AB323 BN61-06196A BRACKET-STAND;46,55 FOUR-LEG,ALDC12,ALDC 1 SNA
...3 BN61-06200A BRACKET-STAND, FRONT;46,55 FOUR-LEG,HGI, 2 SNA
...3 BN61-06204A BRACKET-STAND, REAR;46,55 FOUR-LEG,HGI,T 2 SNA
...3 BN61-06268A BRACKET-SWIVEL TOP;SPC,T 3.0,Zn-Plating, 1 SNA
...3 BN61-06331A HOLDER-SWIVEL RING BOTTOM;UC7K 46/55,POM 1 SNA
...3 BN63-05135E COVER-SHEET;4-LEG,Rhcm PE Vinyl,T0.05,W6 2 SNA
...3 BN63-06582E COVER-STAND, BASE;46/55,FOUR-LEG,ABS+PC, 1 SNA
....4 0103-005041 RESIN-PC;V0,PC+ABS 180 SNA
...3 T0527 BN68-00513A LABEL-E,PASS;ALL MODEL,YUPO(110G),50X15, 1 SNA
...3 M0126 BN73-00052E RUBBER-FOOT;4-LEG,CR RUBBER,T1.5 DIA17,R 4 SNA
...3 BN74-00031A GREASE;kanto-kasei FL-955,grease,wht 0.6 SNA
...3 BN96-13563A ASSY BRACKET P-SWIVEL BOT;4-LEG(55),BRKT 1 SNA
....4 BN61-02428Q STUD-PEM;PNA,M4,D7,L9.3,ZPC(SIL),SUM24L 4 SNA
5-3
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 BN61-06269A BRACKET-SWIVEL BOT;SPC,T 3.0,Zn-Plating, 1 SNA
...3 BN63-06574A COVER-STAND,TOP;46/55,FOUR-LEG,ABS,HB,NC 1 SNA
...3 BN63-06575A COVER-STAND,TOP;46/55,FOUR-LEG,ABS,HB,NC 1 SNA
...3 BN63-06946A COVER-STAND FRONT;46/55,FOUR-LEG,ABS,HB, 1 SNA
0.1 BN91-04900A ASSY LCD-AMLCD;BN07-00805A 1 SNA
..2 PANEL BN07-00805A LCD-PANEL;LTF460HQ01,SSEZQS,8bit,46,16.7 1 SA
...3 TCON BN81-04160A A/S-T CON LTF460HQ01;LTF460HQ01 1 SA
...3 INVER BN81-04176A A/S-BB-L LTF460HQ01;LTF460HQ01 1 SNA
0.1 BN91-05087A ASSY SHIELD;LE46C750R2WX* 1 SNA
..2 T0081 6001-002284 SCREW-MACHINE;BH,+,M4,L8,ZPC(WHT),SWRCH1 11 SA
..2 T0081 6001-002604 SCREW-MACHINE;BH,+,M4,L10,ZPC(WHT),SWRCH 2 SA
..2 M0081 6003-000337 SCREW-TAPTYPE;BH,+,S,M4,L10,ZPC(BLK),SWR 6 SA
..2 M0081 6003-001003 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 6 SA
..2 M0174 BN44-00341A AC VSS(I)-TV;PSIV281510A,I46F1_ASM,14mA, 1 SA
..2 BN61-06441A HOLDER-INLET;LC530,ABS,V0 1 SNA
...3 0103-004627 RESIN-ABS;VE-0812/K2901,BK0020,V0,ABS,No 18 SNA
..2 FL06 BN96-12723G ASSY CABLE P-FPCB LVDS CABLE;240Hz-46inc 1 SA
..2 M0523 BN96-12974A ASSY BRACKET P-WALL;46,52,55,LC650,SECC, 4 SNA
...3 T0101 BN61-05997A BRACKET-WALL;LC650 46,SECC,T1.6 4 SNA
...3 BN60-00188A SPACER-FOAM;LCD,FELT,20,3.0,30,Center : 4 SNA
..2 T0910 BN96-13342A ASSY BRACKET P-STAND LINK;LC530 37/40/46 1 SNA
...3 BN61-02429K STUD-PEM;PNB,M3.8,D7,L14.9,ZPC(SIL),SUM2 2 SNA
...3 M0115 BN61-05998A BRACKET-STAND LINK;LC650 46,SECC,T1.6 1 SNA
...3 BN61-05281A HOLDER-CLAMP;LCD,NYLON 66,WHT 3 SNA
..2 BN61-05991A HOLDER-SIDE AV;40,LC650,EO,PC+ABS,V0,BK0 1 SNA
...3 0103-005041 RESIN-PC;V0,PC+ABS 21 SNA
..2 M2893 BN39-01024E LEAD CONNECTOR;LC5F,UL3239#24,2P,175mm,1 1 SA
..2 M2893 BN39-01267C LEAD CONNECTOR;LE37B530,UL 2651 AWG#26,1 1 SA
..2 M2893 BN39-01279F LEAD CONNECTOR;LN46C650L1FXZA,UL1061 #28 1 SA
..2 BN73-00273B SILICON/RUBBER-GAPPAD;UE32C6500,SILICON+ 1 SNA
0.1 M0017 BN91-05216B ASSY CHASSIS;LE46C750R2WX* 1 SNA
..2 M0014 BN94-03388B ASSY PCB MAIN;LE46C750R2WX* 1 SA
...3 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0.25 SNA
...3 BN97-04253B ASSY SMD;LE46C750R2WX*,BN94-03388B 1 SNA
....4 0202-001767 SOLDER-CREAM;LST-5710,D20~38,42Sn/57Bi/1 5.235 SNA
....4 DS01A 0401-000116 DIODE-SWITCHING;MMSD914T1,100V,200mA,SOD 7 SA
....4 DS01A 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 14 SA
....4 D1 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 SA
....4 DR01A 0402-001098 DIODE-RECTIFIER;SK34,40V,3A,SMC,TP 1 SA
....4 0403-001164 DIODE-ZENER;MMSZ5232B,5.32-5.88V,500MW,S 1 SA
....4 0403-001783 DIODE-ZENER;BZB84-C6V2,5.8/6.6V,300mW,SO 23 SNA
....4 D0254 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 5 SA
....4 T0139 0406-001200 DIODE-TVS;RCLAMP0504F,6/-/-V,150W,SC-70 2 SA
....4 T0139 0406-001271 DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251 9 SNA
....4 AD12 0407-000123 DIODE-SWITCHING;DAN202K,80V,100mA,SOT-23 1 SA
....4 Q101 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 12 SA
....4 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 1 SA
....4 0501-002654 TR-SMALL SIGNAL;2PD601ASL,NPN,250mW,SOT- 2 SA
....4 CEQ2 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 5 SA
....4 Q409 0505-002386 FET-SILICON;AO3415AL,P,-20V,-4A,0.045ohm 3 SA
....4 IC104 0801-002630 IC-CMOS LOGIC;74AHCT1G08,2-INPUT AND GAT 1 SA
5-4
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 ND51C2 0801-002780 IC-CMOS LOGIC;74LVC1G17,SCHMITT-TRIGGER 1 SA
....4 IC104 0801-003330 IC-CMOS LOGIC;Octal buffer,DQFN,20P,4.5x 2 SA
....4 IC104 0802-001012 IC-CMOS LOGIC;74LCX245,TRANSCEIVER,DQFN, 1 SNA
....4 0904-002119 IC-I/O SUPPORT CHIP;PCF8574TS,8Bit,SSOP, 1 SA
....4 1001-000164 IC-ANALOG MULTIPLEX;74HC4052,CMOS,SOP,16 1 SA
....4 IC106 1001-001177 IC-VIDEO SWITCH;TEA6425D,VIDEO SWITCH,SO 1 SA
....4 IC106 1001-001627 IC-VIDEO SWITCH;SiI9389CTU,TQFP,100P,14x 1 SA
....4 IC107 1002-001482 IC-D/A CONVERTER;WM8521H9GED/R,16bit,SOI 1 SA
....4 IC112 1103-001310 IC-EEPROM;24LC02B,256X8BIT,SOIC,8P,3.91X 1 SNA
....4 IC112 1103-001475 IC-EEPROM;M24256-BR,256Kbit,32Kx8,SOP,8P 1 SNA
....4 1105-002049 IC-DDR2 SDRAM;EM68B16CWPA-25H,DDR2 SDRAM 1 SA
....4 1105-002058 IC-DDR2 SDRAM;K4T1G164QE-HCF8,DDR2,1Gbit 2 SA
....4 1105-002075 IC-DDR2 SDRAM;K4T1G084QE-HCF8,DDR2,1Gbit 4 SA
....4 1105-002086 IC-DDR SDRAM;EM6A9320BIA,128MB,LFBGA,144 1 SA
....4 T0085 1201-002487 IC-AUDIO AMP;MAX9728A,QFN,12P,3x3mm,DUAL 1 SA
....4 T0124 1201-002992 IC-POWER AMP;STA369BWS,PSSO,36P,10.3x7.5 1 SA
....4 T0087 1203-002519 IC-POSI.FIXED REG.;KIA7809AF,DPAK,3P,240 1 SA
....4 IC012 1203-003544 IC-POSI.ADJUST REG.;RT9173BPS,SOP-8,8P,5 2 SA
....4 1203-004363 IC-VOL. DETECTOR;RT9818C-29PV,SOT-23,3P, 1 SA
....4 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 SA
....4 IC012 1203-004937 IC-POSI.ADJUST REG.;MP2000DJ-ADJ-LF-Z,TS 1 SA
....4 1203-005538 IC-DC/DC CONVERTER;AOZ1021HAIL,SOP,8P,4. 2 SA
....4 1203-005559 IC-BACKLIGHT DRIVER;MP3302DJ,TSOT23,5P,2 1 SA
....4 IC012 1203-005756 IC-POSI.ADJUST REG.;AP7173-SP,SOP-8L-EP, 1 SA
....4 1203-006012 IC-DC/DC CONVERTER;MP8725EL,QFN14,14P,3x 1 SA
....4 1203-006013 IC-DC/DC CONVERTER;AOZ1031AI,SO-8,8P,4.9 2 SA
....4 T0087 1203-006109 IC-POSI.FIXED REG.;S-1206B33-M3T1G,SOT-2 1 SA
....4 T0087 1203-006130 IC-POSI.FIXED REG.;S-1172B25-U5T1G,SOT-8 1 SA
....4 T0087 1203-006136 IC-POSI.FIXED REG.;AP1117D-18-GZ-13-89,T 1 SA
....4 IC012 1203-006138 IC-POSI.ADJUST REG.;AP1117DGZ-13-89,TO-2 1 SA
....4 T0087 1203-006141 IC-POSI.FIXED REG.;S-1172B33-U5T1G,SOT-8 3 SA
....4 1203-006167 IC-POSI.FIXED REG.;S-1172B12-U5T1G,SOT-8 1 SA
....4 1204-003100 IC-DECODER;SDP92,FCPBGAH,937P,35x35mm,PL 1 SA
....4 IC118 1204-003101 IC-VIDEO PROCESS;SDP94,PBGA,345P,19x19mm 1 SNA
....4 IC118 1204-003128 IC-VIDEO PROCESS;FRC9459S,FBGA,372P,23x2 1 SNA
....4 1205-003479 IC-SWITCH;TPS2051BDBVR,SOT-23,5P,2.9x1.6 1 SA
....4 1205-003733 IC-SWITCH;AP2191MPG-13,MSOP-8L-EP,8P,2.9 2 SA
....4 1205-003735 IC-SWITCH;AP2151WG-7,SOT25,5P,2.9x1.6mm, 1 SA
....4 1205-003834 IC-ETHERNET CONTROLLER;RTL8201E-VC-GR,QF 1 SA
....4 1205-003840 IC-CODEC;WM8595GEFL/RS,QFN,48P,7x7x0.9mm 1 SA
....4 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 SA
....4 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 40 SA
....4 PR6 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 4 SNA
....4 MR604 2007-000137 R-CHIP;2Kohm,5%,1/16W,TP,1005 12 SNA
....4 R105 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 41 SA
....4 HDR7 2007-000139 R-CHIP;220ohm,5%,1/16W,TP,1005 1 SNA
....4 AR49 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 60 SNA
....4 R319 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 66 SNA
....4 2007-000146 R-CHIP;6.8Kohm,5%,1/16W,TP,1005 2 SNA
....4 R104 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 35 SA
....4 MR36 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 3 SNA
5-5
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R509 2007-000170 R-CHIP;1Mohm,5%,1/16W,TP,1005 3 SNA
....4 R111 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 19 SNA
....4 HDR17 2007-000172 R-CHIP;10ohm,5%,1/16W,TP,1005 45 SNA
....4 R338 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 39 SNA
....4 UR23 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 60 SNA
....4 2007-000231 R-CHIP;1.3Kohm,1%,1/10W,TP,1608 2 SA
....4 MR39 2007-000242 R-CHIP;1.5Kohm,5%,1/16W,TP,1005 1 SNA
....4 UR53 2007-000305 R-CHIP;10Mohm,5%,1/10W,TP,1608 1 SA
....4 RT01 2007-000483 R-CHIP;1ohm,5%,1/8W,TP,2012 2 SNA
....4 HR12 2007-000591 R-CHIP;22ohm,1%,1/10W,TP,1608 1 SNA
....4 2007-000606 R-CHIP;240ohm,1%,1/10W,TP,1608 2 SA
....4 JR11 2007-000614 R-CHIP;24Kohm,1%,1/10W,TP,1608 2 SNA
....4 KAR28 2007-000637 R-CHIP;270Kohm,5%,1/10W,TP,1608 1 SNA
....4 2007-000755 R-CHIP;330Kohm,1%,1/10W,TP,1608 1 SA
....4 R19 2007-000763 R-CHIP;330ohm,1%,1/10W,TP,1608 1 SNA
....4 R124 2007-000775 R-CHIP;33Kohm,5%,1/16W,TP,1005 3 SNA
....4 DR37 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 9 SNA
....4 2007-001285 R-CHIP;5.6ohm,5%,1/16W,TP,1005 32 SA
....4 OTR1 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 10 SNA
....4 CER07 2007-001308 R-CHIP;200ohm,5%,1/16W,TP,1005 3 SNA
....4 HR10 2007-001320 R-CHIP;1.8Kohm,5%,1/16W,TP,1005 1 SA
....4 R326 2007-001325 R-CHIP;3.3Kohm,5%,1/16W,TP,1005 3 SNA
....4 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 2 SNA
....4 2007-001335 R-CHIP;36Kohm,5%,1/16W,TP,1005 2 SA
....4 PR24 2007-002970 R-CHIP;56ohm,5%,1/16W,TP,1005 1 SA
....4 2007-003022 R-CHIP;62ohm,5%,1/16W,TP,1005 17 SNA
....4 R133 2007-007004 R-CHIP;12Kohm,1%,1/10W,TP,1608 3 SA
....4 2007-007008 R-CHIP;300ohm,5%,1/16W,TP,1005 1 SNA
....4 TR30 2007-007009 R-CHIP;75ohm,5%,1/16W,TP,1005 8 SA
....4 PR8 2007-007015 R-CHIP;13Kohm,5%,1/16W,TP,1005 1 SNA
....4 R365 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 19 SNA
....4 2007-007132 R-CHIP;15Kohm,1%,1/16W,TP,1005 1 SA
....4 2007-007134 R-CHIP;39Kohm,1%,1/16W,TP,1005 2 SA
....4 2007-007136 R-CHIP;4.7Kohm,1%,1/16W,TP,1005 6 SNA
....4 2007-007137 R-CHIP;1.2Kohm,1%,1/16W,TP,1005 1 SA
....4 2007-007138 R-CHIP;27Kohm,1%,1/16W,TP,1005 5 SNA
....4 2007-007139 R-CHIP;47Kohm,1%,1/16W,TP,1005 15 SA
....4 DR4 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 10 SNA
....4 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 2 SNA
....4 2007-007197 R-CHIP;3.3ohm,5%,1/16W,TP,1005 1 SNA
....4 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 17 SNA
....4 2007-007317 R-CHIP;2.2Kohm,1%,1/16W,TP,1005 4 SA
....4 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 30 SNA
....4 2007-007352 R-CHIP;130Kohm,1%,1/10W,TP,1608 1 SA
....4 2007-007469 R-CHIP;110ohm,1%,1/16W,TP,1005 1 SNA
....4 HDR44 2007-007470 R-CHIP;7.5Kohm,1%,1/16W,TP,1005 2 SNA
....4 2007-007538 R-CHIP;56Kohm,1%,1/16W,TP,1005 1 SA
....4 2007-007617 R-CHIP;2.49Kohm,1%,1/10W,TP,1608 1 SA
....4 2007-007697 R-CHIP;2.4Kohm,1%,1/16W,TP,1005 1 SNA
....4 2007-007698 R-CHIP;5.1Kohm,1%,1/16W,TP,1005 2 SNA
....4 2007-007724 R-CHIP;40.2ohm,1%,1/10W,TP,1608 2 SA
5-6
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 2007-007730 R-CHIP;6.8Mohm,1%,1/10W,TP,1608 1 SA
....4 2007-007766 R-CHIP;2Kohm,1%,1/16W,TP,1005 1 SNA
....4 2007-007947 R-CHIP;36ohm,1%,1/10W,TP,1608 1 SA
....4 MR11 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 18 SNA
....4 2007-008263 R-CHIP;3Kohm,1%,1/16W,TP,1005 1 SA
....4 2007-008275 R-CHIP;30Kohm,1%,1/16W,TP,1005 2 SNA
....4 2007-008294 R-CHIP;33ohm,1%,1/16W,TP,1005 21 SA
....4 2007-008391 R-CHIP;6.34Kohm,1%,1/16W,TP,1005 1 SA
....4 2007-008811 R-CHIP;1.5ohm,5%,1/16W,TP,1005 1 SA
....4 2007-009853 R-CHIP;1.6Kohm,1%,1/16W,TP,1005 1 SNA
....4 MR38 2011-001093 R-NETWORK;100ohm,5%,1/16W,L,CHIP,8P,TP,3 1 SA
....4 ZRN10 2011-001261 R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,2. 3 SA
....4 DAR09 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 26 SA
....4 2011-001264 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,2. 6 SNA
....4 2011-001345 R-NETWORK;10Kohm,5%,1/16W,L,CHIP,8P,TP,2 3 SA
....4 DRP29 2011-001396 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP, 2 SA
....4 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010 7 SA
....4 2011-001585 R-NETWORK;47ohm,5%,1/16W,L,CHIP-V,4P,TP, 1 SNA
....4 2011-001589 R-NETWORK;0ohm,5%,1/16W,L,CHIP-V,4P,TP,1 1 SNA
....4 AC1 2203-000125 C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,- 4 SA
....4 PC43 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,TP,1005 14 SA
....4 DC54 2203-000278 C-CER,CHIP;.01nF,0.5pF,50V,C0G,TP,1005 7 SA
....4 C3 2203-000384 C-CER,CHIP;0.015nF,5%,50V,C0G,1608 2 SNA
....4 MC302 2203-000425 C-CER,CHIP;.018nF,5%,50V,C0G,TP,1005 6 SA
....4 C254 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 22 SA
....4 C507 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1005 5 SA
....4 ZC14 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 2 SNA
....4 AD480 2203-000679 C-CER,CHIP;0.027nF,5%,50V,C0G,1005 1 SA
....4 DC25 2203-000812 C-CER,CHIP;.033nF,5%,50V,C0G,1005 11 SA
....4 CK40B 2203-000838 C-CER,CHIP;0.39NF,5%,50V,C0G,TP,1608 4 SNA
....4 C132 2203-000854 C-CER,CHIP;0.039nF,5%,50V,C0G,1005 4 SA
....4 KAC5 2203-001126 C-CER,CHIP;0.68nF,10%,50V,X7R,1608 1 SNA
....4 AD480 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 46 SNA
....4 AD480 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 3 SNA
....4 C711 2203-002982 C-CER,CHIP;6.8nF,10%,50V,X7R,1005 2 SA
....4 DC18 2203-005138 C-CER,CHIP;1.8nF,10%,50V,X7R,1005 6 SA
....4 AAC1 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 45 SNA
....4 AD480 2203-005344 C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,- 15 SNA
....4 PC8 2203-005642 C-CER,CHIP;0.22nF,5%,50V,NP0,1005 2 SNA
....4 AD480 2203-005968 C-CER,CHIP;4.7NF,10%,50V,X7R,TP,1005 3 SNA
....4 AD480 2203-006104 C-CER,CHIP;1000nF,10%,50V,X7R,3225 2 SA
....4 AD480 2203-006126 C-CER,CHIP;47nF,10%,16V,X7R,1005 8 SNA
....4 PC11 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 5 SNA
....4 C102 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 291 SNA
....4 AD480 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 2 SNA
....4 HE4 2203-006474 C-CER,CHIP;22000nF,20%,6.3V,X5R,2012 7 SA
....4 HDC11 2203-006562 C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 48 SNA
....4 AD480 2203-006636 C-CER,CHIP;220nF,10%,25V,X7R,1608 13 SA
....4 AD480 2203-006824 C-CER,CHIP;4700nF,10%,10V,X5R,1608 6 SNA
....4 AD480 2203-006842 C-CER,CHIP;0.47nF,5%,50V,C0G,1005 4 SNA
....4 AD480 2203-006992 C-CER,CHIP;0.33nF,5%,50V,C0G,TP,1005 5 SNA
5-7
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 AD480 2203-007132 C-CER,CHIP;10000nF,10%,25V,X7R,TP,3216 16 SA
....4 AD480 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 38 SNA
....4 AD480 2203-007233 C-CER,CHIP;22000nF,10%,16V,X5R,TP,3216 6 SA
....4 AD480 2203-007270 C-CER,CHIP;10000nF,10%,10V,X5R,TP,1608 91 SNA
....4 2503-001051 C-NETWORK;100nFx4,20%,16V,2012 5 SA
....4 T0052 2703-000125 INDUCTOR-SMD;10uH,10%,2012 8 SA
....4 T0052 2703-000158 INDUCTOR-SMD;1uH,10%,2012 6 SA
....4 T0052 2703-000222 INDUCTOR-SMD;560nH,10%,2012 3 SA
....4 T0052 2703-000296 INDUCTOR-SMD;680nH,10%,1608 1 SA
....4 T0052 2703-000392 INDUCTOR-SMD;10uH,5%,4532 2 SA
....4 VL6 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 SA
....4 T0052 2703-001239 INDUCTOR-SMD;3.3uH,10%,1608 2 SA
....4 T0052 2703-002332 INDUCTOR-SMD;330nH,5%,1608 1 SA
....4 T0052 2703-002557 INDUCTOR-SMD;270NH,5%,1608 3 SNA
....4 T0052 2703-003150 INDUCTOR-SMD;4.7uH,20%,5050 4 SNA
....4 T0052 2703-003713 INDUCTOR-SMD;1.5uH,20%,7366 3 SA
....4 X202 2801-003326 CRYSTAL-SMD;24MHz,30ppm,28-ABX,20pF,50oh 2 SA
....4 X202 2801-003773 CRYSTAL-SMD;12MHz,30ppm,28-AAN,20pF,50oh 1 SA
....4 X202 2801-003954 CRYSTAL-SMD;27MHz,30ppm,28-AAN,16pF,50oh 1 SA
....4 X202 2801-004629 CRYSTAL-SMD;27MHz,20ppm,12pF,50ohm,TP 1 SNA
....4 X202 2801-004734 CRYSTAL-SMD;25.000000MHz,20ppm,28-AAN,12 1 SA
....4 2804-001878 OSCILLATOR-CLOCK;49.152MHz,50ppm,10TTL/1 1 SA
....4 F103 2901-001506 FILTER-EMI SMD;5V,0.13A,0pF,2x1x0.5mm,TP 2 SA
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 38 SA
....4 T0568 3301-002039 BEAD-SMD;26ohm,1608,TP 45 SA
....4 3701-001591 CONNECTOR-HDMI;19P,2ROW,FEMALE,SMD-S,AU 3 SNA
....4 3701-001693 CONNECTOR-HDMI;19P,2ROW,FEMALE,SMD-A 1 SA
....4 AC510 3708-002777 CONNECTOR-FPC/FFC/PIC;82P,0.5mm/0.75mm,S 1 SA
....4 CN906 3711-007317 CONNECTOR-HEADER;BOX,13P,1R,2.0mm,SMD-A, 1 SA
....4 HB01A 3711-007336 HEADER-BOARD TO CABLE;B0X,4P,1R,2.5mm,SM 1 SA
....4 IC125 BN13-00031A IC ASIC;LUNA,SDP95,400,3.6,-40to+125C,CA 1 SA
....4 BN97-03979A ASSY MICOM;KFG8GH6U4M-DIB6,N79A,2009.10. 1 SNA
.....5 1107-001868 IC-NAND FLASH;KFG8GH6U4M-AIB6,1GByte,512 1 SNA
....4 BN97-04238A ASSY MICOM;AT24C512BN-SH25-T,N79A,2010.1 1 SNA
.....5 IC112 1103-001406 IC-EEPROM;AT24C512BN-SH25-T,512Kbit,64Kx 1 SNA
....4 BN97-04240A ASSY MICOM;T-VALCPLD-0010,2010.04.28 1 SNA
.....5 1301-001969 IC-CPLD;EPM240T100C4N,TQFP,100P,16x16mm, 1 SNA
....4 T0010 BP27-00002A COIL CHOKE;SLF6028T-220MR77,22uF,20%,0.1 1 SA
....4 DC1 2203-000386 C-CER,CHIP;.015nF,5%,50V,C0G,TP,1005 2 SA
....4 T0052 2703-003790 INDUCTOR-SMD;4.7uH,20%,8080 2 SA
....4 1006-001480 IC-LINE TRANSCEIVER;MAX3222ECAP+T,SSOP,2 1 SA
....4 FR18 2007-000982 R-CHIP;5.6Kohm,5%,1/16W,TP,1005 1 SA
....4 T0568 3301-001236 BEAD-SMD;60ohm,1608 3 SNA
....4 BN97-04473A ASSY MICOM;T-VAL8DEUS-1005,2010.04.23 1 SNA
.....5 IC520 0903-001651 IC-MICROCONTROLLER;61P802-RG480WT,LQFP,4 1 SNA
....4 3701-001480 CONNECTOR-DSUB;15P,3R,FEMAIL,STAMPED PIN 1 SA
....4 CN906 3707-001096 CONNECTOR-OPTICAL;STRAIGHT W/L,SPDIF 1 SA
....4 3709-001601 CONNECTOR-CARD SLOT;68P W/L,1.27mm,PCMCI 1 SA
....4 3711-007302 HEADER-BOARD TO BOARD;BOX,18P,2R,2mm,ANG 1 SA
....4 3722-003037 JACK-USB;4P/1C W/L,AU/NI,BLK,ANGLE,A 2 SA
....4 JA330 3722-003038 JACK-PHONE;7P/1C W/L,SN,BLK 2 SA
5-8
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 JA333 3722-003040 JACK-PIN;3P W/L,SN,BLK/YEL/WHT/RED,ANGLE 1 SA
....4 JA333 3722-003052 JACK-PIN;5P+Shield W/L,NI/SN,GN/BL/RD/WH 1 SA
....4 3722-003058 JACK-MODULAR;8P/8C W/L,Y,STRAIGHT,N,AU,1 1 SA
....4 3722-003063 JACK-SCART;42P W/L,SN,BLK 1 SA
....4 CIS3 BN40-00173A TUNER;DTOS40CVL081A,DVB-T/C,164CH,38.9MH 1 SA
....4 BN41-01423B PCB MAIN;LC7J,FR-4,4,B,1.2,220*240,N86A 1 SNA
...3 BN62-00084A HEAT SINK-ES;LE32C650L1WXXC,A6063,2.5,28 3 SNA
...3 BN62-00090A HEAT SINK-ES;LE46C750R2W,A6063,4t,WHITE, 1 SNA
...3 T0066 BP62-00064B HEAT SINK-ES;ROBOCOP,A6063,T4.0,40,40,BL 1 SNA
0.1 ACCE1 BN92-05805B ASSY ACCESSORY;LE46C750R2WXXC 1 SNA
..2 BN96-13293A ASSY ACCESSORY-MANUAL;LE40C750R2WXXC,46 1 SNA
...3 T0524 6902-000110 BAG PE;LDPE,T0.05,W250,L400,TRP,28,2,9.2 1 SNA
...3 T0527 BN68-00513A LABEL-E,PASS;ALL MODEL,YUPO(110G),50X15, 1 SNA
...3 BN68-00514E MANUAL FLYER-05,WARRANTY CARD;comm,Samsu 1 SNA
...3 BN68-02186A MANUAL FLYER-TOC GUIDE;COMM,SAMSUNG,11 L 1 SNA
...3 BN68-02808A MANUAL USERS;C750,SAMSUNG,6LANGS,XC,W/P 1 SNA
...3 BN68-02839D MANUAL FLYER-WARRANTY CARD;comm,Samsung, 1 SNA
...3 AA68-03242V MANUAL FLYER-SAFETY GUIDE;comm,Samsung,1 1 SNA
..2 ACCE2 BN96-13293D ASSY ACCESSORY-CABLE;LE46C750R2WX* 1 SNA
...3 T0268 3903-000456 CBF-POWER CORD;DT,EU/KR,CP3,IEC320 C13-R 1 SA
...3 T0120 4301-000121 BATTERY-MN;1.5V,R03,10.5x44.5m,HOLDER,7. 2 SNA
...3 REMO2 BN59-01040A REMOCON;TM1060,SAMSUNG,20PIN SINGLE,49KE 1 SA
...3 BN61-05596A HOLDER-WIRE CABLE;LED TV,LDPE,T0.8,L150, 1 SNA
...3 M9889 BN63-01798B CLOTH-CLEAN;cloth,180,200,sea blue,ToC 1 SA
...3 T0527 BN68-00513A LABEL-E,PASS;ALL MODEL,YUPO(110G),50X15, 1 SNA
...3 T0010 BN96-08624A ASSY HOLDER P;08 PDP MODEL,ABS HB,GRAY 1 SNA
....4 6902-000683 BAG ZIPPER;LDPE,T0.05,W60,L60,TRP,4-PE M 1 SNA
....4 T0010 BN61-04529A HOLDER-RING;ABS, HB,GRAY 4 SNA
...3 T0524 6902-000110 BAG PE;LDPE,T0.05,W250,L400,TRP,28,2,9.2 1 SNA
...3 RB01 BN63-06339C COVER-BOTTOM;37,40,46,LC650,ABS+PC,V0,BK 1 SA
....4 0103-005041 RESIN-PC;V0,PC+ABS 70 SNA
0.1 BN92-06091B ASSY BOX;46,LC750,EO 1 SNA
..2 BN69-04658C BOX-SET;46LC750-S,CB,A-01,DW2,ECT50,YEL, 1 SNA
..2 BH68-00662A LABEL BOX-00;ALL MODEL,MOJO 90G,60,110,W 1 SNA
0.1 BN92-06095A ASSY P/MATERIAL;46,LC750 1 SNA
..2 T0214 0203-001595 TAPE-OPP MASKING;OPP-2,0.075,75,800M,CLR 3.03 SNA
..2 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 4.07 SNA
..2 M040 6922-000003 BAND PP;PP,T0.8,W18,L1650M,TRP,DA69-9014 1.67 SNA
..2 BN68-02422B LABEL-WARNING SHIPPING;ALL MODEL,A/P 100 1 SNA
..2 BN69-00257E PACKING-BAG SHEET;-,CB,-,1400,500,-,-,WH 1 SNA
..2 BN69-03982C PAD PACKING-EDGE;LB6T,PAPER,8,120,1690,Y 1 SNA
..2 BN69-04326A CUSHION-01,SET;46LC750-FS,EPS,16.7g/l 1 SNA
..2 6902-001183 BAG PE;HDPE/NITRON,T0.015/T0.5,W1300,L90 1 SNA
..2 BN69-00257C PACKING-PAD;PAPER,CB-SW4,1350,830,YEL,36 1 SNA
..2 BN69-04451A PALLET;-,WOOD,1040,1360,135,14000,-,SESK 1 SNA
..2 6902-000379 BAG AIR;LDPE,T0.2,W1000,L1800,TRP,1260.0 1 SNA
0.1 BN92-06096A ASSY LABEL;LE40C750R2WXXC 1 SNA
..2 AA68-03752D LABEL-STICKER;WW,ALL,Art Paper(90g),44.5 1 SNA
..2 T0527 BP68-00052B LABEL-00,RATING;CCTV,TETRON PAPER,T0.05, 1 SNA
0.1 R001A BN90-02760F ASSY COVER REAR;46,LC750,EO 1 SNA
..2 M0081 6003-001003 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 14 SA
5-9
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
..2 R001A BN96-14017G ASSY COVER P-REAR;46,LC750,EO,PCM,T0.5,B 1 SA
...3 AH358 BN61-06545A HOLDER-REAR;LC650 37/40/46,PP,BLK 1 SNA
...3 R001 BN63-06337B COVER-REAR;46,LC650/630,EO,PCM,T0.5,BLK, 1 SNA
...3 BN63-06630A SHEET-INSULATOR SMPS;UC6100 40inch,PC,T0 1 SNA
...3 T0071 BN64-01227C INLAY-TERMINAL;LC750 40,PS SHEET,T0.5,EO 1 SNA
...3 BN64-01269A INLAY-AV;LC650,PS SHEET,T0.5,EO 1 SNA
...3 T0139 BN65-00003A CLAMPER BAG;42C7,LDPE,HB,BLK 1 SNA
...3 BN60-00162C SPACER-FOAM;FOAM,50000mm,Dark Gray,0.5T, 1.35 SNA
..2 T0382 BP61-00495C HOLDER-CARE;PJT,ACRYL-FOAM,T0.25,W30.0mm 0.1 SNA
5-10
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
