Image preview - the first page of the document
11_Electrical Part List


>> Download 11_Electrical Part List documenatation <<

Text preview - extract from the document
                                                                                       6 Electrical Parts List



6 Electrical Parts List
You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/

6-1 LE32N73BD Parts List

Level    Loc. No.     Code No.                           Description & Specification         Q'ty      SA/SNA

0                   LE32N73BDX/XEC   LE32N73BD,R54B/32M70-GNT,32,LCD-TV,SPAIN                  0

0.1     M0001       BN90-00936F      ASSY COVER FRONT;32N73,EO,ABS+PMMA,HB,BK                  1         S.N.A
..2     T0175       BN96-03271A      ASSY SPEAKER P;8ohm,Mosel 32,Left,10W,BA                  1          S.A
..2     T0175       BN96-03272A      ASSY SPEAKER P;8ohm,Mosel 32,Right,10W,B                  1          S.A
..2     T0003       BN96-03413D      ASSY COVER P-FRONT;32N73,EO,ABS+PMMA,HB,                  1          S.A
...3    M0081       6003-001003      SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR                  2         S.N.A
...3    M0081       6003-001003      SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR                  2         S.N.A
...3    M0081       6003-001003      SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR                  2         S.N.A
...3    M0162       6502-001067      CABLE CLAMP;DAFC-1300,ID2.2,T5.2,NYLIN6/                  1         S.N.A
...3    T0060       BN61-01655A      SPRING ETC;STS-304 SUS,D8,L12,T0.5                        1         S.N.A
...3                BN61-02665A      HOLDER-BOSS;MOSEL 32,ABS,VO,TOP                           1         S.N.A
...3                BN61-02668A      HOLDER-BOSS;MOSEL 32,ABS,VO,BOTTOM,LEFT                   1         S.N.A
...3                BN61-02669A      HOLDER-BOSS;MOSEL 32,ABS,VO,BOTTOM,RIGHT                  1         S.N.A
...3                BN61-02771A      BOSS-BOND;MOSEL,ABS+PMMA,NATURAL,BOND                     12        S.N.A
...3    CCM1        BN63-02183F      COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20                  1.48      S.N.A
...3    M0112       BN63-02533D      COVER-FRONT;32N73,EO,ABS+PMMA,HB,BK23,S/                  1         S.N.A
...3    T0023       BN64-00342A      KNOB POWER;ROME,40,PC,VIOLET                              1         S.N.A
...3    T0054       BN64-00443A      KNOB-DECORATION;32R71,ABS,HB,GR503,VACUU                  1         S.N.A
...3    T0061       BN64-00453A      WINDOW-REMOCON;32R71,PC,V0,VIOLET,DIFFUS                  1         S.N.A
...3    T0022       BN64-00467A      KNOB CONTROL;SONOMA26,32,40,ABS,-,-,-,V0                  1         S.N.A
...3    M0145       BN96-03466B      ASSY BOARD P-FUNCTION;LE40M71BX,CT5000-4                  1          S.A
...3    M0146       BN96-03634B      ASSY BOARD P-POWER & IR;LE40M71BX,CT5000                  1          S.A
...3                BN96-03664A      ASSY COVER P-DECORATION;MOSEL,32,PC,CLEA                  1         S.N.A
....4   CCM1        BN63-02183F      COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20                  0.07      S.N.A
....4   T0056       BN63-02528A      COVER-DECORATION;MOSEL,40,ABS,HB,Cr-Plat                  1         S.N.A
....4   T0056       BN63-02529A      COVER-DECORATION;MOSEL,40,ABS,HB,Cr-Plat                  1         S.N.A
....4   T0056       BN63-02536A      COVER-DECORATION;MOSEL 32,PC,Clear                        1         S.N.A
....4   T0069       AA60-00091F      SPACER-FELT;-,FELT,150X10,-,-,BLK,T0.5,-                  2         S.N.A
....4   T0069       AA63-60001E      SPACER-FELT;-,FELT,-,-,-,BLK,0.5,-,55X15                  4         S.N.A
...3    T0069       AA60-00171Q      SPACER-FELT;56L3,FELT,690,T0.35,8                         2         S.N.A
...3    T0069       AA63-60001Q      SPACER-FELT;-,FELT,-,-,-,BLK,T0.35,-,150                  1         S.N.A

0.1     M0216       BN90-00942B      ASSY STAND;32N71,-,-,-,SQUARE STAND                       1         S.N.A
..2     T0524       6902-000241      BAG PE;NITRON/HDPE,T0.5/T0.012,W600,L600                  1         S.N.A
..2     M0013       BN96-04114A      ASSY STAND P-BASE;32N71,EO(NEO),-,ABS+PM                  1          S.A
...3    T0081       6002-001294      SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK)                       4          S.A
...3    M0081       6003-001239      SCREW-TAPTITE;FH,+,B,M4,L10,ZPC(YEL),SWR                  6          S.A
...3                BN61-02204A      HOLDER-SWIVEL RING;26,32R71,ACETAL,BLK                    1         S.N.A
...3                BN61-02232A      HOLDER-SWIVEL RING;32R71,ACETAL NATUAL,T                  1         S.N.A
...3                BN61-02233A      HOLDER-SWIVEL RING;32R71,ACETAL NATUAL,B                  1         S.N.A
...3                BN61-02236A      BRACKET-HINGE SWIVEL;BORDEAUX 32,SECC,T1                  1         S.N.A
...3    T0920       BN61-02439A      GUIDE-STAND;MOSEL 32,ABS VO                               1         S.N.A
....4   T0514       BN61-02367A      BRACKET-SUPPORT;BORDEAUX 32,SECC,T2.0                     1         S.N.A
...3                BN61-02772A      BRACKET-STAND BOTTOM;NEO MOSEL 32,SECC,T                  1         S.N.A
...3                BN63-02537A      COVER-STAND SUB;32M71,ABS+PMMA,-,-,-,HB,                  1         S.N.A
...3    T0004       BN63-02851A      COVER-STAND BASE;32N71,EO(NEO),ABS+PMMA,                  1         S.N.A
...3    T0132       BN73-00052A      RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1.                  6         S.N.A

0.1     MP1.0       BN91-01058T      ASSY LCD-AMZ;LE32M61BX/XEC                                1         S.N.A
..2     M0215       BN07-00324A      LCD-PANEL;T315XW02(V3),8bit,760.0*450.0*                  1          S.A

0.1     M0017       BN91-01214A      ASSY CHASSIS;LE32N73BDX/XEC                               1         S.N.A
..2     T0862       BN94-00868G      ASSY PCB MISC-MMS;MOSEL,NEO MOSEL ALL                     1         S.N.A
...3    T0245       0202-001492      SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-,                  0.003     S.N.A
...3    CN330       3711-003340      HEADER-BOARD TO CABLE;BOX,16P,2R,2mm,STR                  1          S.A
...3    CN5         3722-001051      JACK-USB;4P/1C,AU,BLK,ANGLE,A TYPE                        1          S.A
...3    SUB06       BN63-02530A      SHIELD-MMS;MOSEL,SPTE T0.2,-,-,-,-,-                      1         S.N.A
...3    T0174       BN97-00842J      ASSY SMD;LE26R73BDX/XET                                   1         S.N.A
....4   SUB05       0202-001477      SOLDER-CREAM;LST309-M,-,D20~45
