Image preview - the first page of the document



>> Download Disassembly & Reassembly documenatation <<

Text preview - extract from the document

                                                                                       3. Disassembly and Reassembly

3. Disassembly and Reassembly
This section of the service manual describes the disassembly and reassembly procedures for the LE46A956D LCD TV.
    WARNING: This LCD TV contains electrostatically sensitive devices. Use caution when handling these components.

3-1. Disassembly and Reassembly
   Cautions: 1. Disconnect the LCD TV from the power source before disassembly.
             2. Follow these directions carefully; never use metal instruments to pry apart the cabinet.


                 Description                                    Picture Description                        Screws
 1. Place the TV face down on cushioned table.                                                              46"
    Remove screws from the rear cover.
    Remove stand.
    Lift up the rear cover.




                                                                                                            55"




                                                                                                           46"/55"




                                                                                                           46"/55"




                                                                                                                     3-1
3. Disassembly and Reassembly


                Description           Picture Description   Screws
2. Detach all cables.                                        46"
   Remove screws of boards.
   (SMPS, Local Dimming, Mainboard)
   Remove the boards.




                                                             55"




                                                             46"




                                                             55"




3-2
                                                      3. Disassembly and Reassembly


               Description           Picture Description               Screws
3. Remove screws of stand-bracket.                                      46"/55"
   Remove screws of woofers.
   Remove screws of inlet socket.




                                                                        46"/55"




                                                                        46"/55"




                                                                                  3-3
3. Disassembly and Reassembly


                Description               Picture Description   Screws
4. Remove screws of side-AV. (only 46")                         46"/55"




5. Remove screws of panel-bracket.                               46"
   Lift up the panel bracket.




                                                                 55"




                                                                46"/55"




3-4
                                                                             3. Disassembly and Reassembly


                Description                                 Picture Description               Screws
6. Remove LED's screws. Lift up the panel.                                                     46"/55"




                                                                                               46"/55"




                                                                                                 46"




                                                                                                 55"




 Reassembly procedures are in the reverse order of disassembly procedures.




                                                                                                         3-5
3. Disassembly and Reassembly

Memo




3-6
