Image preview - the first page of the document
>> Download 11_Electrical Part List documenatation <<
Text preview - extract from the document
6 Electrical Parts List
6 Electrical Parts List
You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
LE46M53BDX/XEU LE46M53BD,R62J/46M50-GMT,46,LCD-TV,UNITE
0.1 M0001 BN90-00769M ASSY COVER FRONT;46M53,EO,ABS,HB,BK23,S/ 1 S.N.A
..2 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 1 S.N.A
..2 M0081 6006-001096 SCREW-TAPTITE;BH,+,WP,B,M4.0,L12,ZPC(BLK 8 S.N.A
..2 T0003 BN96-02052J ASSY COVER P-FRONT;46M53,EO,ABS,HB,BK23, 1 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 4 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 S.N.A
...3 T0069 AA60-00091K SPACER-FELT;-,FELT,330X10,-,-,BLK,T0.35, 5 S.N.A
...3 M0112 BN63-01829H COVER-FRONT;46M53,EO,ABS,HB,BK23,S/MOLD 1 S.A
...3 T0069 BN63-01830B COVER-MIDDLE;FIRENZE,MILANO,46,ABS,T3.0, 1 S.N.A
...3 T0056 BN63-01932B COVER-DECORATION;MILANO,46EO,ABS,VO,GR70 1 S.N.A
...3 CCM1 BN63-02183H COVER-SHEET;Rhcm,PE Vinyl,T0.05,1300mm,2 2.21 S.N.A
...3 T0061 BN64-00343A WINDOW-REMOCON;ROME,40,PC,CLEAR 1 S.N.A
...3 T0022 BN64-00375A KNOB CONTROL;MILANO,26,ABS+PC,GR70,SVM-3 1 S.N.A
...3 M0145 BN96-02400A ASSY BOARD P-FUNCTION;LNR269DX/XAA,CT500 1 S.A
...3 T0382 BP61-00509C HOLDER-CARE;PJT,ACRYL-FOAM,T0.25,W20.0mm 0.28 S.N.A
..2 T0175 BN96-02077D ASSY SPEAKER P;8ohm,Left,15W,400mm,Milan 1 S.A
..2 T0175 BN96-02078D ASSY SPEAKER P;8ohm,Right,15W,400mm,Mila 1 S.A
..2 T0023 BN96-02244A ASSY COVER P-KNOB POWER;MILANO,26,ABS,V0 1 S.N.A
...3 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
...3 T0081 BN61-01821A GUIDE-POWER;MILANO,26,ACRYL,SMOG 1 S.N.A
...3 T0023 BN64-00376A KNOB POWER;MILANO,26,ABS,V0,GR70,AL,H/ST 1 S.N.A
...3 T0054 BN64-00406A KNOB-DECORATION;MILANO,ABS,HB,GR70,SV012 1 S.N.A
..2 T0382 BP61-00495C HOLDER-CARE;PJT,ACRYL-FOAM,T0.25,W30.0mm 0.2 S.N.A
0.1 M0002 BN90-00770M ASSY COVER REAR;46M53,EO,HIPS,HB,GR503 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 13 S.A
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 3 S.N.A
..2 REAR 6006-001112 BOLT-ETC;M8,L16,ZPC(BLK),SWRCH18A,WP 4 S.A
..2 T0279 BN63-02895A COVER-JACK;MILANO 46",HIPS,T3.0,HB,GR503 1 S.A
..2 M0013 BN96-04288B ASSY COVER P-REAR;46M53,EO,HIPS,HB,GR503 1 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 S.N.A
...3 M0114 BN61-01605A HOLDER-WIRE;FIRENZE 46,HIPS HB,GR503 1 S.N.A
...3 M0006 BN63-02893B COVER-REAR;46M53,EO,HIPS,HB,GR503 1 S.A
0.1 M0216 BN90-00771A ASSY STAND;46M50 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
..2 M0013 BN96-02053B ASSY STAND P-BASE;46 MILANO,ABS HB,BK07, 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 10 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,B,M4,L10,ZPC(YEL),SWR 10 S.A
...3 T0920 BN61-01624A GUIDE-STAND;FIRENZE 46,ABS HB,BK07 1 S.N.A
...3 BN61-01628A BRACKET-STAND BOTTOM;FIRENZE 46,SECC,T3. 1 S.N.A
...3 M0111 BN63-01811B COVER-STAND;MILANO46,ABS,T3.0,HB,BK07,BK 1 S.N.A
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1. 10 S.N.A
0.1 BN91-01058G ASSY LCD-SPB;LN46M51BD 1 S.N.A
..2 M0215 BN07-00311A LCD-PANEL;LTA460WS-L01,8bit,1083*627*56. 1 S.A
0.1 M0112 BN91-01191A ASSY SHIELD;LE46M53BDX/XEU 1 S.N.A
..2 T0081 6001-001920 SCREW-MACHINE;PH,+,WWP,M5,L12,NI PLT,SWR 8 S.A
..2 M0081 6003-000133 SCREW-TAPTITE;BH,+,-,S,M4,L8,ZPC(BLK),SW 14 S.A
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 S.N.A
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 7 S.N.A
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 6 S.N.A
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 S.N.A
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 S.N.A
6-1
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 8 S.N.A
..2 M0081 6003-001001 SCREW-TAPTITE;FH,+,B,M3,L8,ZPC(BLK),SWRC 2 S.N.A
..2 T0081 6006-000245 SCREW-MACHINE;WSP,PH,+,M4,L8,ZPC(YEL),SW 1 S.N.A
..2 M0162 6502-001027 CABLE CLAMP;DAWH-5NA,ID11.5,T3,NYLON66,N 2 S.N.A
..2 M0162 6502-001067 CABLE CLAMP;DAFC-1300,ID2.2,T5.2,NYLIN6/ 1 S.N.A
..2 M2893 BH39-00362C LEAD CONNECTOR;Beethoven,UL1007#26,5P,30 1 S.A
..2 M2893 BN39-00604B LEAD CONNECTOR;LNR409DX/XAA,UL1007#26,14 1 S.A
..2 M2893 BN39-00605A LEAD CONNECTOR;RE40**,UL2835#28,12/15P,4 1 S.A
..2 M2893 BN39-00672B LEAD CONNECTOR;LNR469DX/XAA,UL2835#28,14 1 S.A
..2 M2893 BN39-00712C LEAD CONNECTOR-LVDS;Bordeaux,UL1571#30,U 1 S.A
..2 M2893 BN39-00765A LEAD CONNECTOR;MILANO,UL1007#26,UL/CSA,1 1 S.A
..2 M0114 BN61-01709A HOLDER-WIRE;NYLON 6/6,NATURAL,DAWS-1ND 2 S.N.A
..2 BN61-01823A BRACKET-STAND LINK;46 MILANO,SECC,T2.0,L 1 S.N.A
..2 M0146 BN61-01889A BRACKET-PANEL TOP;46 MILANO,SECC,T1.6 1 S.N.A
..2 BN61-01890A BRACKET-PANEL BOTTOM;46 MILANO,SECC,T1.6 1 S.N.A
..2 BN61-01891A BRACKET-PANEL SIDE;46 MILANO,SECC,T1.6,L 1 S.N.A
..2 BN61-01892A BRACKET-GUIDE STAND;46 MILANO,SECC,T1.0 1 S.N.A
..2 BN61-01893A BRACKET-PANEL SIDE;46 MILANO,SECC,T1.6,R 1 S.N.A
..2 BN61-01894A BRACKET GUIDE-SOCKET;46 MILANO,SECC,T1.0 1 S.N.A
..2 M0114 BN61-02618A HOLDER-WIRE;FLAT CLAMP,NYLON 66,NATURAL 2 S.N.A
..2 M0146 BN63-01949A SHIELD CASE;26 MILANO,SPTE,T0.5,POWER 1 S.N.A
..2 M0521 BN96-02401B ASSY BOARD P-POWER LED/IR;Milano3,CT5000 1 S.A
..2 M0412 BN96-02412D ASSY BRACKET P-PCB;46M53,EO(IDTV),SECC,T 1 S.N.A
...3 M0081 6003-001321 SCREW-TAPTITE;BH,+,B,M4,L8,ZPC(BLK),SWRC 6 S.A
...3 M0081 6003-001321 SCREW-TAPTITE;BH,+,B,M4,L8,ZPC(BLK),SWRC 16 S.A
...3 M0131 AA63-01129A GASKET;JD26KO,Conductive Fabric,7mm,15mm 4 S.N.A
...3 M0131 AA63-01179A GASKET;JD32KO,Conductive Fabric,15mm,17m 1 S.N.A
...3 T0069 AA63-60122K SPACER-FELT;SPD-42P3S,FELT,L60,D20,T0.35 1 S.N.A
...3 BN61-01606A HOLDER-BOSS;FIRENZE 46,AL DIECASTING 4 S.N.A
...3 BN61-01808A BRACKET-WALL R/L;46 MILANO,SECC,T2.0 2 S.N.A
...3 M0107 BN61-01809E BRACKET-PCB;MILANO 46,SECC,T0.5,iDTV,EO 1 S.N.A
..2 M0452 BN96-02447C ASSY COVER P-HOLDER AV;MILANO,40,46EO,AB 1 S.N.A
...3 BN61-01975A HOLDER-SIDE AV;40MILANO,HIPS V0,T3.0,GR5 1 S.N.A
...3 T0578 BN64-00403C INLAY AV;MILANO,32,40,46,57,PS,T0.5,BLK, 1 S.N.A
...3 M0020 BN96-02439A ASSY BOARD P-SUB AV SIDE;MILANO,CT5000-3 1 S.N.A
...3 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 2 S.A
..2 M0112 BN96-04289A ASSY SHIELD P-PCB;MILANO,46EO,SECC,T0.5 1 S.N.A
...3 T0178 BN63-02030A SHIELD-PCB;46 MILANO,SECC,T0.5,SMPS 1 S.N.A
...3 M0146 BN63-02062A SHIELD-PCB SMPS;46 MILANO,SECC,T0.5,SOCK 1 S.N.A
...3 T0178 BN63-02896A SHIELD-PCB;MILANO 46,SECC,T0.5,SMPS_SUPP 1 S.N.A
..2 T0067 BP60-00061R SPACER-SCREEN;BE46PS,SPONGE,45,T4.0,12,E 1 S.N.A
..2 M0081 6003-001268 SCREW-TAPTITE;TH,+,B,M4,L12,ZPC(YEL),SWR 9 S.N.A
..2 M0081 6003-001268 SCREW-TAPTITE;TH,+,B,M4,L12,ZPC(YEL),SWR 16 S.N.A
..2 M0081 6003-001268 SCREW-TAPTITE;TH,+,B,M4,L12,ZPC(YEL),SWR 2 S.N.A
..2 M0081 6003-001268 SCREW-TAPTITE;TH,+,B,M4,L12,ZPC(YEL),SWR 4 S.N.A
..2 M0081 6003-001268 SCREW-TAPTITE;TH,+,B,M4,L12,ZPC(YEL),SWR 2 S.N.A
..2 M0006 BN96-04309A ASSY SHIELD P-COVER;46M53,SECC T0.5,iDTV 1 S.N.A
...3 M0131 BN63-02627A GASKET;Oxford,Conductive Fabric,8,13,30, 1 S.N.A
...3 T0603 BN63-02897A SHIELD-PCB MAIN;MILANO 46,SECC,T0.5,EO,I 1 S.N.A
..2 FT532 2901-001346 FILTER-EMI AC LINE;250V,6A,-,-,50x22.5x3 1 S.A
..2 M2893 BN39-00603A LEAD CONNECTOR;RE40**,UL1007#26,UL,14P,2 1 S.A
0.1 M0017 BN91-01192A ASSY CHASSIS;LE46M53BDX/XEU 1 S.A
..2 T0374 BN94-00700A ASSY PCB P-POWER;MILANO, 46",Free Volt,O 1 S.A
...3 D811S 0402-000102 DIODE-BRIDGE;D2SB60,600V,1.5A,SIP-4,ST 1 S.A
...3 DP803 0402-000562 DIODE-RECTIFIER;UF5406,600V,3A,DO-201AD, 1 S.A
...3 PC801S 0604-001032 PHOTO-COUPLER;TR,170-260%,300mW,DIP-4,ST 1 S.A
...3 PC802S 0604-001032 PHOTO-COUPLER;TR,170-260%,300mW,DIP-4,ST 1 S.A
...3 PC803S 0604-001032 PHOTO-COUPLER;TR,170-260%,300mW,DIP-4,ST 1 S.A
...3 PC804AS 0604-001032 PHOTO-COUPLER;TR,170-260%,300mW,DIP-4,ST 1 S.A
...3 PC811S 0604-001032 PHOTO-COUPLER;TR,170-260%,300mW,DIP-4,ST 1 S.A
...3 T0086 1203-002177 IC-PWM CONTROLLER;VIPER12ADIP,DIP,8P,300 1 S.A
...3 T0086 1203-002828 IC-PWM CONTROLLER;4981,DIP,20P,25.4X7.1M 1 S.A
6-2
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
...3 T0900 1404-001195 THERMISTOR-NTC;5.1ohm,15%,2900,27mW/C,BK 1 S.A
...3 T0900 1404-001195 THERMISTOR-NTC;5.1ohm,15%,2900,27mW/C,BK 1 S.A
...3 T0900 1404-001195 THERMISTOR-NTC;5.1ohm,15%,2900,27mW/C,BK 1 S.A
...3 RI834 2009-000026 R-METAL PLATE;0.15OHM,10%,5W,CL,TP,5X14X 1 S.A
...3 RM825 2009-000026 R-METAL PLATE;0.15OHM,10%,5W,CL,TP,5X14X 1 S.A
...3 RP803 2009-001146 R-METAL PLATE;0.05ohm,10%,5W,CL,TP,15x18 1 S.A
...3 RP805 2009-001146 R-METAL PLATE;0.05ohm,10%,5W,CL,TP,15x18 1 S.A
...3 CY802S 2201-000963 C-CERAMIC,DISC;1NF,20%,400V,Y5U,TP,9.5X6 1 S.A
...3 CY814S 2201-000987 C-CERAMIC,DISC;2.2NF,20%,400V,Y5U,BK,12. 1 S.A
...3 CX811S 2306-000318 C-FILM,LEAD-PPF;220nF,20%,275V,BK,26x7x1 1 S.A
...3 CX812S 2306-000318 C-FILM,LEAD-PPF;220nF,20%,275V,BK,26x7x1 1 S.A
...3 CP825 2306-000321 C-FILM,LEAD-PPF;470NF,20%,275V,BK,31X11X 1 S.A
...3 CX813S 2306-000321 C-FILM,LEAD-PPF;470NF,20%,275V,BK,31X11X 1 S.A
...3 CI816 2401-003024 C-AL;220uF,20%,200V,WT,BK,22x35,10 1 S.A
...3 CI817 2401-003024 C-AL;220uF,20%,200V,WT,BK,22x35,10 1 S.A
...3 CP823 2401-003092 C-AL;330◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
