Image preview - the first page of the document
>> Download 11_Electrical Part List documenatation <<
Text preview - extract from the document
6 Electrical Parts List
6 Electrical Parts List
You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LNS4096D Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
0 LNS4096DX/XAA LN-S4096D,E53A/40M70-GMS,40,LCD-TV,UNITE 0
0.1 M0001 BN90-00935B ASSY COVER FRONT;40M71,UO,PC+ABS,V0,BK25 1 S.N.A
..2 T0175 BN96-03271A ASSY SPEAKER P;8ohm,Mosel 32,Left,10W,BA 1 S.A
..2 T0175 BN96-03272A ASSY SPEAKER P;8ohm,Mosel 32,Right,10W,B 1 S.A
..2 T0003 BN96-03412B ASSY COVER P-FRONT;40M71,UO,PC+ABS,V0,BK 1 S.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 4 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 S.N.A
...3 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
...3 CCM1 BN63-02183G COVER-SHEET;Rhcm,PE Vinyl,T0.05,1100mm,2 1.983 S.N.A
...3 M0112 BN63-02488B COVER-FRONT;40M71,UO,PC+ABS,V0,BK25,S/MO 1 S.N.A
...3 T0023 BN64-00342A KNOB POWER;ROME,40,PC,VIOLET 1 S.N.A
...3 T0054 BN64-00443A KNOB-DECORATION;32R71,ABS,HB,GR503,VACUU 1 S.N.A
...3 T0061 BN64-00453A WINDOW-REMOCON;32R71,PC,V0,VIOLET,DIFFUS 1 S.N.A
...3 T0022 BN64-00467A KNOB CONTROL;SONOMA26,32,40,ABS,-,-,-,V0 1 S.N.A
...3 M0145 BN96-03466B ASSY BOARD P-FUNCTION;LE40M71BX,CT5000-4 1 S.A
...3 BN61-02667A HOLDER-BOSS;MOSEL 40,ABS,VO,TOP 2 S.N.A
...3 BN61-02670A HOLDER-BOSS;MOSEL 40,ABS,VO,BOTTOM,LEFT 1 S.N.A
...3 BN61-02671A HOLDER-BOSS;MOSEL 40,ABS,VO,BOTTOM,RIGHT 1 S.N.A
...3 M0146 BN96-03634C ASSY BOARD P-POWER & IR;LNS4069D,CT5000- 1 S.A
...3 BN61-02771A BOSS-BOND;MOSEL,ABS+PMMA,NATURAL,BOND 14 S.N.A
...3 BN96-03665B ASSY COVER P-DECORATION;MOSEL,40,PC,CLEA 1 S.N.A
....4 T0069 AA60-00091B SPACER-FELT;-,FELT,100X10,-,-,BLK,T0.35, 2 S.N.A
....4 T0069 AA63-60001Q SPACER-FELT;-,FELT,-,-,-,BLK,T0.35,-,150 2 S.N.A
....4 CCM1 BN63-02183G COVER-SHEET;Rhcm,PE Vinyl,T0.05,1100mm,2 0.09 S.N.A
....4 T0056 BN63-02490A COVER-DECORATION;MOSEL 40,PC,CLEAR 1 S.N.A
....4 T0056 BN63-02528A COVER-DECORATION;MOSEL,40,ABS,HB,Cr-Plat 1 S.N.A
....4 T0056 BN63-02529A COVER-DECORATION;MOSEL,40,ABS,HB,Cr-Plat 1 S.N.A
0.1 M0002 BN90-00938B ASSY COVER REAR;40M71,UO,HIPS,V0,BK500 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 2 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 14 S.A
..2 M0013 BN96-03818A ASSY COVER P-REAR;40M71,UO,HIPS,V0,BK500 1 S.A
...3 M0006 BN63-02634A COVER-REAR;MOSEL,40UO,HIPS,-,-,-,V0,-,BK 1 S.N.A
...3 T0071 BN64-00482A INLAY-TERMINAL;MOSEL 40",PS SHEET,T0.5,U 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,PP,V0,BLK 1 S.N.A
...3 T0069 AA63-60122K SPACER-FELT;SPD-42P3S,FELT,L60,D20,T0.35 4 S.N.A
...3 BN61-02776B HOLDER-WALL;32R7,ABS,VO,BLK 1 S.N.A
...3 T0069 AA60-00091G SPACER-FELT;-,FELT,200X10,-,-,BLK,T0.5,- 2 S.N.A
0.1 M0216 BN90-00941A ASSY STAND;40M70,ABS+PMMA,HB,BK23,H/GLAS 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
..2 M0013 BN96-03418A ASSY STAND P-BASE;40M70,ABS+PMMA,HB,BK23 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,B,M4,L10,ZPC(YEL),SWR 4 S.A
...3 BN61-02247A HOLDER-SWIVEL RING;40R71,ACETAL,BLK 1 S.N.A
...3 BN61-02248A HOLDER-SWIVEL RING;40R71,ACETAL NATUAL,T 1 S.N.A
...3 BN61-02249A HOLDER-SWIVEL RING;40R71,ACETAL NATUAL,B 1 S.N.A
...3 BN61-02259A BRACKET-STAND BOTTOM;BORDEAUX 40,SGHC,T3 1 S.N.A
...3 BN61-02260A BRACKET-HINGE SWIVEL;BORDEAUX 40,SGHC,T3 1 S.N.A
...3 CCM1 BN63-02183E COVER-SHEET;Rhcm,PE Vinyl,T0.05,750mm,20 0.5 S.N.A
...3 T0004 BN63-02364A COVER-STAND BASE;40R71,ABS+PMMA,HB,BK23, 1 S.N.A
...3 BN63-02495A COVER-STAND SUB;40M70,ABS+PMMA,HB,BK23,H 1 S.N.A
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1. 4 S.N.A
...3 T0920 BN61-02410A GUIDE-STAND;MOSEL,40,ABS,V0,-,-,-,BK07,- 1 S.N.A
....4 T0514 BN61-02368A BRACKET-SUPPORT;BORDEAUX 40,SECC,T1.2 2 S.N.A
0.1 T0852 BN91-01058Q ASSY LCD-SPZ;LNS4096DX/XAA 1 S.N.A
..2 M0215 BN07-00288A LCD-PANEL;LTA400HS-LH1,8bit,952*551*51.0 1 S.A
0.1 M0017 BN91-01084B ASSY CHASSIS;LNS4096DX/XAA 1 S.N.A
..2 M0014 BN94-01008F ASSY PCB MAIN;LNS4096DX/XAA 1 S.A
...3 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.25 S.N.A
...3 CN093 3701-001294 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,AU 1 S.A
...3 CN121 3709-001346 CONNECTOR-CARD SLOT;68P,0.27mm,ANGLE,AU1 1 S.A
...3 CN330 3711-003272 HEADER-BOARD TO CABLE;BOX,10P,2R,2.54mm, 1 S.A
...3 CN330 3711-004236 HEADER-BOARD TO CABLE;BOX,6P,1R,2MM,STRA 1 S.A
...3 CN330 3711-004349 HEADER-BOARD TO CABLE;BOX,3P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004909 HEADER-BOARD TO CABLE;BOX,14P,2R,2MM,ANG 1 S.A
...3 CN330 3711-005607 HEADER-BOARD TO CABLE;BOX,32P,2R,2mm,STR 1 S.A
...3 CN081 3711-005884 HEADER-BOARD TO BOARD;BOX,30P,2R,2mm,ANG 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
6-1
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA332 3722-001734 JACK-VHS;4P,SN,BLK,STRAIGHT 1 S.A
...3 JA333 3722-001903 JACK-PIN;2P,-,AU,WHT/RED,- 1 S.A
...3 JA333 3722-001903 JACK-PIN;2P,-,AU,WHT/RED,- 1 S.A
...3 JA333 3722-001903 JACK-PIN;2P,-,AU,WHT/RED,- 1 S.A
...3 JA333 3722-001938 JACK-PIN;3P,-,AU,GRN/BLU/RED,- 1 S.A
...3 JA333 3722-001938 JACK-PIN;3P,-,AU,GRN/BLU/RED,- 1 S.A
...3 JA333 3722-002063 JACK-PIN;3P,AU,YEL/WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002063 JACK-PIN;3P,AU,YEL/WHT/RED,STRAIGHT 1 S.A
...3 CN141 3722-002429 JACK-IEEE1394;4P,AU30U,BLK,STRAIGHT,IEEE 1 S.A
...3 CN142 3722-002429 JACK-IEEE1394;4P,AU30U,BLK,STRAIGHT,IEEE 1 S.A
...3 CIS3 BN40-00090A TUNER;DNVS356GH401A,DNVS356GH401A,POD Sy 1 S.A
...3 T0099 BN62-00003A HEAT SINK-IC;NK,SUN,A6063S,T2.5,W28,L28, 2 S.N.A
...3 T0852 BN96-01470A ASSY BOARD P-OPTICAL;HP-P5581,OPTICAL 1 S.A
....4 CN906 3707-001067 CONNECTOR-OPTICAL;PLUG,SM,-,4.4/2.0mm 1 S.A
...3 T0174 BN97-01047F ASSY SMD;LNS4096DX/XAA 1 S.N.A
....4 CIS05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
