Image preview - the first page of the document
>> Download 10_Exploded View & Part List documenatation <<
Text preview - extract from the document
5 Exploded View & Parts List
5 Exploded View and Parts List
- You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
5-1 LN26R71B Exploded View
M0014
M0013
T0175
T0159
T0447
M0215
T0175
M0013
T0003
5-1
5 Exploded View & Parts List
5-2 LN26R71B Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-03012F ASSY COVER P-FRONT;26R71,SO,ABS+PMMA,HB, 1 S.A
T0175 BN96-03053A ASSY SPEAKER P;16ohm,Bordeuax 26,Left,5W 1 S.A
T0175 BN96-03054A ASSY SPEAKER P;16ohm,Bordeuax 26,Right,5 1 S.A
M0215 BN07-00254A LCD-PANEL;T260XW02,8bit,626.0*373.0*50.0 1 S.A
T0447 BN96-03008C ASSY BRACKET P-PANEL;BORDEAUX,26,AUO,SMP 1 S.N.A
M0014 BN94-01012B ASSY PCB MAIN;LN26R71BX/XAZ,A51O,BORDEAU 1 S.A
T0159 BN96-03058A ASSY PCB P-SMPS;Bordeaux 26 PFC,LE26R71B 1 S.A
M0013 BN96-03014E ASSY COVER P-REAR;26R71,SO,-,ABS+PMMA,BK 1 S.A
M0013 BN96-03017A ASSY STAND P-BASE;26R71,ABS+PMMA,HB,BK23 1 S.A
5-2
5 Exploded View & Parts List
5-3 LN32R71B Exploded View
M0014
M0013
T0175
T0447
M0215
T0175
T0003
M0013
5-3
5 Exploded View & Parts List
5-4 LN32R71B Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-02996P ASSY COVER P-FRONT;32R71,SO(AUO),ABS+PMM 1 S.A
T0175 BN96-04207A ASSY SPEAKER P;8ohm,VE Type,Left,10W,Hor 1 S.A
T0175 BN96-04208A ASSY SPEAKER P;8ohm,VE Type,Right,10W,Ho 1 S.A
M0215 BN07-00289A LCD-PANEL;T315XW02,8bit,760.0*450.0*47.2 1 S.A
T0447 BN96-02999E ASSY BRACKET P-PANEL;BORDEAUX,32,AUO,SMP 1 S.N.A
M0014 BN94-01012A ASSY PCB MAIN;LN32R71BX/XAZ 1 S.A
M0013 BN96-02997D ASSY COVER P-REAR;32R71,SO,-,ABS+PMMA,HB 1 S.A
M0013 BN96-02998A ASSY STAND P-BASE;32R71,-,ABS+PMMA,HB,BK 1 S.A
5-4
5 Exploded View & Parts List
5-5 LN40R71B Exploded View
M0014
M0013
T0101
T0175
T0447
M0215
T0175
T0003
M0013
5-5
5 Exploded View & Parts List
5-6 LN40R71B Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-03011D ASSY COVER P-FRONT;40R71,SO,ABS+PMMA,HB, 1 S.A
T0175 BN96-03002A ASSY SPEAKER P;8ohm,Bordeuax 32"/37"/40" 1 S.A
T0175 BN96-03003A ASSY SPEAKER P;8ohm,Bordeuax 32"/37"/40" 1 S.A
M0215 BN07-00264A LCD-PANEL;LTA400WT-L01,8bit,952*551*51.0 1 S.A
T0447 BN96-03009C ASSY BRACKET P-PANEL;BORDEAUX,40,AMLCD,I 1 S.N.A
M0014 BN94-01012C ASSY PCB MAIN;LN40R71BX/XAZ,A51O,BORDEAU 1 S.A
T0101 BN61-02427A BRACKET-WALL;BORDEAUX 40,SECC,T1.2 1 S.N.A
M0013 BN96-03013D ASSY COVER P-REAR;40R71,SO,-,ABS+PMMA,HB 1 S.A
M0013 BN96-03016A ASSY STAND P-BASE;40R71,-,ABS+PMMA,HB,BK 1 S.A
5-6
