Image preview - the first page of the document



>> Download samsung_lnr469dx_sm documenatation <<

Text preview - extract from the document

                   8 Wiring Diagrams



8 Wiring Diagram




                                8-1
8 Wiring Diagrams

Memo




8-2
                                                                        3 Alignments and Adjustments


3 Alignments and Adjustments

3-1 Service Instruction
1. Usually, a color TV-VCR needs only slight touch-up adjustment upon installation.
   Check the basic characteristics such as height, horizontal and vertical sync.
2. Use the specified test equipment or its equivalent.
3. Correct impedance matching is essential.
4. Avoid overload. Excessive signal from a sweep generator might overload the front-end
   of the TV. When inserting signal markers, do not allow the marker generator to distort
   test result.
5. Connect the TV only to an AC power source with voltage and frequency as specified on
   the backcover nameplate.
6. Do not attempt to connect or disconnect any wire while the TV is turned on. Make sure
   that the power cord is disconnected before replacing any parts.
7. To protect aganist shock hazard, use an isolation transform.




                                                                                                 3-1
3 Alignments and Adjustments

3-2 How to Access Service Mode
3-2-1 Entering Factory Mode
 Using the Customer Remote
 1. Turn the power off and set to stand-by mode
 2. Press the remote buttons in this order : POWER OFF         MUTE     1   8   2   POWER ON to turn the set
      on.
 3. The set turns on and enters service mode.
 4. Press the Power button to exit and store data in memory.
      *If you fail to enter service mode, repeat steps 1 and 2 above.
 5. Initial SERVICE MODE DISPLAY State




* "T-SAN2NUS02-1005 May 21 2005" and "T-SAN2NUS5-0118" are firmware version.
  The firmware version is subject to change without notice.


6.Buttons operations within Service Mode




3-3 Factory Data




3-2
3 Alignments and Adjustments




                         3-3
3 Alignments and Adjustments




3-4
3 Alignments and Adjustments




                         3-5
3 Alignments and Adjustments




3-6
3 Alignments and Adjustments




                         3-7
3 Alignments and Adjustments

3-4 Service Adjustment

3-4-1 White Ratio (Balance) Adjustment
1. You can adjust the white ratio in factory mode (1:Calibration, 3:White-Balance).

2. Since the adjustment value and the data value vary depending on the input source, you have to

  adjust these in CVBS, Component 1 and HDMI modes.

3. The optimal values for each mode are configured by default. (Refer to Table 1, 2.)



- Equipment : CS-1000

- Pattern: Master MSPG925 #16 "ABL Pattern" as standard

      - Use other equipment only after comparing the result                                   20mm

          with that of the Master equipment.
                                                                                              20mm
- Set Aging time : 60min

- Calibration and Manual setting for WB adjustment.

      HDMI: No Calibration     Manual adjustment at #16 pattern (1080i)

      COMP: Calibration at #24 Chessboard Pattern           Manual adjustment at #16 pattern (720p)

      CVBS: Calibration at #24 Chessboard Pattern           Manual adjustment at #16 pattern (NTSC)

      PC : Calibration at #24 Chessboard Pattern          No Manual adjustment (1024x768@60Hz)


-White Balance Manual Adjustment (ABL Pattern)


                                                        Adjustment Coordinate

                                    x               y              Y (cd/m2)             T(K) + MPCD


                     L/L          263               263                -                    15000K/0
      CVBS
                     L/L          263                 263         3.8(1.1Ft)                15000K/0


                     H/L          263                 263              -                    15000K/0
  Component
    (720p)
                     L/L          263                 263         4.2(1.2Ft)                15000K/0


                     H/L          263                 263              -                    15000K/0
       HDMI
      (1080i)
                     L/L          263                 263         4.2(1.2Ft)                15000K/0




3-8
                                                                          3 Alignments and Adjustments

3-4-2 Servicing Information

A. Source Program Download & Generals
-Sofrware Version Check Method
Check the S/W version to see if the source code is updated.
Press the Menu key and select the Preference. where you can find the Help menu in it.
When you press the Help. on/off menu shows up. Highlight ON and press the INFO key.
Then the S/W version will be displayed on the Help screen.

B. Serial Download Method
1. Downloading boot code
(1) Trun off LCD-TV.
(2) Connect the RS-232 serial cable to the service jack of LCD-TV.
(3) Enter the DOS Mode and move to the directory including
