Image preview - the first page of the document
>> Download 04_Disassembly & Reassembly documenatation <<
Text preview - extract from the document
3 Disassembly and Reassembly
This section of the service manual describes the disassembly and reassembly procedures for the
ES15A*/ES17A* monitor.
WARNING: This monitor contains electrostatically sensitive devices. Use caution when handling
these components.
3-1 Disassembly
Cautions:1. Disconnect the monitor from the power source before disassembly.
2. Follow these directions carefully; never use metal instruments to pry apart the cabinet.
3-1 General Alignment Instuction 5. Connect the TV only to an DC power source
with voltage and frequency as specified on
1. Usually, a color TV-VCR needs only slight the backcover nameplate.
touch-up adjustment upon installation.
6. Do not attempt to connect or disconnect any
Check the basic characteristics such as height,
wire while the TV is turned on. Make sure
horizontal and vertical sync.
that the power cord is disconnected before
2. Use the specified test equipment or its replacing any parts.
equivalent.
7. To protect aganist shock hazard,use an
3. Correct impedance matching is essential. isolation transform.
4. Avoid overload. Excessive signal from a
sweep generator might overload the front-end
of the TV. When inserting signal markers,
do not allow the marker generator to distort
test result.
3-2 Replacement Order of Lamp Assemblies
1. After confirm there is nothing
on the desk
Turn the LCD module over
and put it on a flat desk set to
the ground.
ES15A*/ES17A* 3-1
3 Disassembly and Reassembly
2. Push down the stopper and
slide the lamp unit.
3. Please take out the lamp
units from the LCD module.
4. Please fix the new lamp
units on the LCD module :
opposite process 2 and 3
* Replacement of lamp unit should be done at the power off state and recommended clean bench
condition.
3-3 Reassembly
Reassembly procedures are in the reverse order of Disassembly procedures.
3-2 ES15A*/ES17A*
