Image preview - the first page of the document
>> Download Panel+Options+LCD+Samsung (1) documenatation <<
Text preview - extract from the document
Product Support SEA
Engineering Department
Scott Whitman
1/30/2009
Check your OPTION BYTE:
Whenever you are called in to service a Tulip chassis (61/65/66 series) always
check the Option Byte settings in the service menu. It's a good idea to get into the
habit of verifying that the Option Bytes are correct even before you remove the back
cover (it might be possible to view the service menu even if there is no video or
customer on-screen menu). There are various symptoms that could occur; from a
digitized picture to no video at all could be the effect if the Option Byte information
is set incorrectly.
Attached is the complete list of current models and their respective Factory
Option or "Option Byte" settings based on panel type.
Example using chart below:
1. Locate Model
2. Order parts based on the Side Label version sticker
3. If an alternate panel or main board is supplied, use the installed
Panel Name/Panel code
4. To set the "Factory Options"
Product Support SEA
Engineering Department
Scott Whitman
1/30/2009
Incorrect
Model: LNT4665
Option Byte setting incorrect: Lvds Tx Bit 8 bit
Symptom: Dim picture, lacks contrast. Notice background color of menu
Correct
Model: LNT4665
Option Byte setting correct: Lvds Tx Bit 10 bit
Notice background color of menu is now vivid blue.
Product Support SEA
Engineering Department
Scott Whitman
1/30/2009
Incorrect
Model: LNT4665: Light effect control
Option Byte setting incorrect: Model set to "Tulip"
Symptom: Loss of "Light Effect" in customer menu. Results in no control of the
Blue Light at the bottom center of the LCD TV.
Correct
Model: LNT4665: Light effect control
Option Byte setting correct: Model set to "Tulip Side"
"Light Effect" now listed in customers menu
Product Support SEA
Engineering Department
Scott Whitman
1/30/2009
All LCD Models: Setting the communication bit size via "Lvds Tx bit"
Setting the "Lvds Tx bit" to one level higher than required. In this case, a 10 bit
panel was set to 12 bit. The effect would be the same setting an 8 bit panel to 10 bit.
All LCD Models: Setting the communication type via "Lvds Tx Fmt"
Case: Setting the "Lvds Tx Fmt" incorrectly to JEIDA
10 bit panel where the "Lvds Tx Fmt" setting should have been VESA
Understand the results of this setting will differ with Model and panel type.
Product Support SEA
Engineering Department
Scott Whitman
1/30/2009
Jasmine Chassis
Factory Option Main Board
Side Label Panel
TV Model Panel Name Panel code Panel Dimming LVDS LVDS S/W Ver.
version Maker Model Gamma HSCB Parts Code Scaler
Option Selection Tx Fmt Tx Bit
LNT2342HX/XAA AT01 AUO T230XW01 BN07-00365A 23AUT - INT OFF - - - BN94-01188E X242
T-JM26AUS0-2022
LNT2642HX/XAA CM01, CM02 CMO V260B1-L04 BN07-00364A 26CMT - INT OFF - - - BN94-01188B X242
PP01, PP02 CPT CLAA320WB02 BN07-00315A 32CP JASMINE INT 0.95 STD [2] 8bit BN94-01188A SVP-PX
CM03, CM04 CMO V315B1-L01 BN07-00348A 32CM JASMINE INT 0.95 STD [2] 8bit T-JASMAUS0-1023 BN94-01188C SVP-PX
SP07, SP08 SAMSUNG LTA320WT-L07 BN07-00385A 32AM JASMINE INT 0.95 STD [2] 8bit BN94-01188G SVP-PX
PP09 CPT CLAA320WB02 BN07-00315A 32CP - INT 0.98 - - - T-SC37AUSC-1031 BN94-01400A X242
LNT3242HX/XAA SH10, SH11 SAMSUNG LTA320WT-L06 BN07-00453A 32AMV JASMINE INT 0.9 STD [2] 8bit T-JASMAUS0-1023 BN94-01188G SVP-PX
SH12 SAMSUNG LTA320WT-L06 BN07-00453A 32AMV - INT 0.9 - - - BN94-01400C X242
CM13 CMO V315B1-L01 BN07-00348A 32CM - INT 0.95 - - - BN94-01293E X242
T-SC37AUSC-1031
SQ14, SQ15,
SAMSUNG LTA320WT-L08 BN07-00482A 32AMV - INT 0.9 - - - BN94-01400K X242
SQ16
SP01, SP02 SAMSUNG LTA400WT-L06 BN07-00387A 40AM JASMINE INT 0.95 STD [2] 8bit T-JASMAUS0-1023 BN94-01188D SVP-PX
SP05 SAMSUNG LTA400WT-L06 BN07-00387A 40AM - INT 0.95 - - - T-SC40AUSC-1030 BN94-01400B X242
LNT4042HX/XAA SH06 SAMSUNG LTA400WT-L07 BN07-00451A 40AMV JASMINE INT 0.9 STD [2] 8bit T-JASMAUS0-1023 BN94-01188D SVP-PX
SH07 SAMSUNG LTA400WT-L07 BN07-00451A 40AMV - INT 0.9 - - - BN94-01400G X242
AA08, AA09 AUO T400XW01 BN07-00448A 40AUV - INT 0.9 - - - T-SC40AUSC-1030 BN94-01400H X242
SQ10, SQ11 SAMSUNG LTA400WT-L09 BN07-00489A 40AMV - INT 0.9 - - - BN94-01400L X242
SP01 SAMSUNG LTA460WT-L11 BN07-00389A 46AM JASMINE INT 0.95 STD [2] 8bit T-JASMAUS0-1023 BN94-01188F SVP-PX
SP03 SAMSUNG LTA460WT-L11 BN07-00389A 46AM - INT 0.95 - - - T-SC40AUSC-1030 BN94-01400D X242
LNT4642HX/XAA
SN04 SAMSUNG LTA460WT-L12 BN07-00452A 46AMV JASMINE INT 0.9 STD [2] 8bit T-JASMAUS0-1023 BN94-01188J SVP-PX
SN05 SAMSUNG LTA460WT-L12 BN07-00452A 46AMV - INT 0.95 - - - T-SC40AUSC-1030 BN94-01400F X242
Product Support SEA
Engineering Department
Scott Whitman
1/30/2009
Bordeaux Plus Chassis
Factory Option Main Board
Side Label Panel
TV Model Panel Name Panel code Panel Dimming LVDS LVDS S/W Ver.
version Maker Model Gamma HSCB Parts Code Scaler
Option Selection Tx Fmt Tx Bit
AT01 AUO M190PW01 V0 BN07-00350A 26CMT - INT OFF - - - T-BRDP19AUS-1006BN94-01208A X242
ST02 SAMSUNG LTM190M2-L31 BN07-00351A - - - - - - - T-BRDP19AUS-2002BN94-01208C X242
LNT1953HX/XAA NT03 NEC SVA190WX02TB BN07-00459A 19NE - INT OFF - - - T-BRDP19AUS-3002BN94-01208E X242
AV04 AUO M190PW01 V1 BN07-00440A - - - - - - - T-BRDP19AUS-1006BN94-01208A X242
NU06 NEC SVA190WX02TB BN07-00459B 19NE - INT OFF - - - T-BRDP19AUS-3002BN94-01208E X242
AT01 AUO M190PW01 V0 BN07-00350A 26CMT - INT OFF - - - T-BRDP19AUS-1006BN94-01208A X242
ST02 SAMSUNG LTM190M2-L31 BN07-00351A - - - - - - - T-BRDP19AUS-2001BN94-01208C X242
LNT1954HX/XAA NT03 NEC SVA190WX02TB BN07-00459A 19NE - INT OFF - - - T-BRDP19AUS-3002BN94-01208E X242
AV04 AUO M190PW01 V1 BN07-00440A - - - - - - - T-BRDP19AUS-1006BN94-01208A X242
NU05 NEC SVA190WX02TB BN07-00459B 19NE - INT OFF - - - T-BRDP19AUS-3002BN94-01208E X242
LNT2353HX/XAA AT01 AUO T230XW01 BN07-00365A 23AUT - INT OFF - - - BN94-01183D X242
LNT2354HX/XAA AT01 AUO T230XW01 BN07-00365A 23AUT - INT OFF - - - BN94-01183D X242
AM01, AM02 AUO T260XW02 BN07-00254A 26AU - EXT_POS OFF - - - T-BP26AUS0-2023 BN94-01183B X242
LNT2653HX/XAA
AR03, AR04 AUO T260XW02 VA BN07-00494A 26AU2 - INT OFF - - - BN94-01183L X242
LNT2654HX/XAA AM01, AM02 AUO T260XW02 BN07-00254A 26AU - EXT_POS 0 - - - BN94-01183B X242
SP01, SP02 SAMSUNG LTA320WT-L07 BN07-00385A 32AM bordplus INT 0.95 STD [2] 8bit BN94-01183A SVP-PX
LNT3253HX/XAA SN03, SN04 SAMSUNG LTA320WT-L06 BN07-00453A 32AMV bordplus INT 0.9 STD [2] 8bit BN94-01183H SVP-PX
SQ05, SQ06 SAMSUNG LTA320WT-L08 BN07-00482A 32AMV bordplus INT 0.9 STD [2] 8bit BN94-01183J SVP-PX
T-BRDPAUS0-1022
SQ01, SQ02 SAMSUNG LTA400WT-L06 BN07-00387A 40AM bordplus INT 0.95 STD [2] 8bit BN94-01183C SVP-PX
LNT4053HX/XAA SN03, SN04 SAMSUNG LTA400WT-L07 BN07-00451A 40AMV bordplus INT 0.9 STD [2] 8bit BN94-01183G SVP-PX
SS05, SS06 SAMSUNG LTA400WT-L09 BN07-00489A 40AMV bordplus INT 0.9 STD [2] 8bit BN94-01183K SVP-PX
SQ01, SQ02 SAMSUNG LTA400HT-LH1 BN07-00383A 40AMW BORD FHD INT 0.9 WCG1 JEIDA 10bit BN94-01199G SVP-LX
LNT4066FX/XAA SS03, SS04 SAMSUNG LTA400HT-L07 BN07-00455A 40AMV BORD FHD INT OFF STD JEIDA 8bit T-TULPAUS0-1037 BN94-01199N SVP-LX
SX05, SX06 SAMSUNG LTA400HT-L06 BN07-00483A 40AMV BORD FHD INT OFF STD JEIDA 8bit BN94-01199P SVP-LX
Product Support SEA
Engineering Department
Scott Whitman
1/30/2009
Tulip Chassis
Side Factory Option Main Board
Panel
TV Model Label Panel Name Panel code Panel Dimming LVDS LVDS S/W Ver.
Maker Model Gamma HSCB Parts Code Scaler
version Option Selection Tx Fmt Tx Bit
SAMSUNG LTA400HT-L01 BN07-00409A 40AM Tulip INT 0.95 STD JEIDA 8bit T-TULPAUS0-1037 BN94-01199D SVP-LX
SS03, SS04
SAMSUNG LTA400HT-L01 BN07-00409A 40AM Tulip INT 0.95 STD 1 8bit BN94-01518A CORTEZ
LNT4061FX/XAA
CN05, CN06 CMO V400H1-L01 BN07-00472A 40CM Tulip INT 0.95 STD 1 8bit T-TULPAUSC-1014 BN94-01518F CORTEZ
SX07, SX08 SAMSUNG LTA400HT-L05 BN07-00485A 40AM Tulip INT 0.95 STD 1 8bit BN94-01518K CORTEZ
SAMSUNG LTA460HT-L01 BN07-00410A 46AM Tulip INT 0.95 STD JEIDA 8bit T-TULPAUS0-1037 BN94-01199E SVP-LX
SS03, SS04
SAMSUNG LTA460HT-L01 BN07-00410A 46AM Tulip INT 0.95 STD 1 8bit BN94-01518C CORTEZ
LNT4661FX/XAA CN05, CN06 CMO V460H1-L01 BN07-00395A 46CMO Tulip INT 0.95 STD 1 8bit BN94-01518B CORTEZ
T-TULPAUSC-1014
SX07, SX08 SAMSUNG LTA460HB05 BN07-00506A 46AM Tulip INT 0.95 STD 1 8bit BN94-01518L CORTEZ
AA09, AA10 AUO T460HW02 V1 BN07-00415A 46AU Tulip INT 0.95 STD 1 8bit BN94-01518M CORTEZ
SQ01, SQ02 SAMSUNG LTA400HT-LH1 BN07-00383A 40AMW Tulip Side INT 0.9 WCG1 JEIDA 10bit BN94-01199D SVP-LX
SS03, SS04 SAMSUNG LTA400HT-L07 BN07-00455A 40AMV Tulip Side INT OFF STD JEIDA 8bit T-TULPAUS0-1037 BN94-01199D SVP-LX
LNT4065FX/XAA
SX05, SX06 SAMSUNG LTA400HT-L06 BN07-00483A 40AMV Tulip Side INT OFF STD JEIDA 8bit BN94-01199P SVP-LX
SX07, SX08 SAMSUNG LTA400HT-L06 BN07-00483A T-TULPAUSC-1010 BN94-01518N CORTEZ
SQ01, SQ02 SAMSUNG LTA460HT-LH2 BN07-00391A 46AMW Tulip Side INT 0.9 WCG1 JEIDA 10bit BN94-01199E SVP-LX
LNT4665FX/XAA SS03, SS04 SAMSUNG LTA460HT-L11 BN07-00457A 46AMV Tulip Side INT OFF STD JEIDA 10bit T-TULPAUS0-1037 BN94-01199E SVP-LX
SX05, SX06 SAMSUNG LTA460HT-L04 BN07-00481A 46AMV Tulip Side INT OFF STD JEIDA 10bit BN94-01199Q SVP-LX
SQ02 SAMSUNG LTA520HA03 BN07-00394A 52AMW Tulip Side INT 0.9 WCG1 JEIDA 10bit BN94-01199F SVP-LX
SS03 SAMSUNG LTA520HB04 BN07-00466A 52AMV Tulip Side INT 0.95 STD JEIDA 8bit T-TULPAUS0-1037 BN94-01199L SVP-LX
LNT5265FX/XAA
CN04 CMO V520H1-L08 BN07-00445A 52CM Tulip Side INT OFF STD JEIDA 8bit BN94-01199M SVP-LX
SS05 SAMSUNG LTA520HB04 BN07-00466A T-TULPAUSC-1010 BN94-01518Q CORTEZ
CM01 CMO V460H1-L01 BN07-00395A 46CMO MOSEL3 INT 0.95 STD 1 8bit BN94-01518D CORTEZ
LNT466FX/XAA T-TULPAUSC-1014
AA03 AUO T460HW02 V1 BN07-00415A 46AU MOSEL3 INT 0.95 STD 1 8bit BN94-01518M CORTEZ
Product Support SEA
Engineering Department
Scott Whitman
1/30/2009
Sonoma 2 Chassis
Factory Option Main Board
Side Label Panel
TV Model Panel Name Panel code Panel Dimming LVDS LVDS S/W Ver.
version Maker Model Gamma HSCB Parts Code Scaler
Option Selection Tx Fmt Tx Bit
LNT2332HX/XAA AT01 AUO T230XW01 BN07-00365A 23AUT - INT OFF - - - BN94-01294A X242
LNT2632HX/XAA CT01, CT02 CMO V260B1-L04 BN07-00364A 26CMT - INT OFF - - - BN94-01294B X242
PP01, PP02 CPT CLAA320WB02 BN07-00315A 32CP - INT 0.98 - - - BN94-01294C X242
CM03, CM04 CMO V315B1-L01 BN07-00348A 32CM - INT 0.95 - - - BN94-01294G X242
LNT3232HX/XAA T-SC37AUSC-1031
SH05, SH06 SAMSUNG LTA320WT-L06 BN07-00453A 32AMV - INT 0.9 - - - BN94-01294H X242
SQ07, SQ08 SAMSUNG LTA320WT-L08 BN07-00482A 32AMV - INT 0.9 - - - BN94-01294H X242
PM01 CPT CLAA370WA03 BN07-00366A 37CP - INT 0.98 - - - BN94-01294D X242
LNT3732HX/XAA
PR02 CPT CLAA370WA03SC BN07-00446A 37CP2 - INT 0.9 - - - BN94-01294K X242
AM01, AM02 AUO T400XW02 BN07-00370A 40AUO - INT 0.98 - - - BN94-01294F X242
LNT4032HX/XAA T-SC40AUSC-1030
AA05, AA06 AUO T400XW01 V1 BN07-00448A 40AUV - INT 0.9 - - - BN94-01294M X242
Product Support SEA
Engineering Department
Scott Whitman
1/30/2009
Bordeaux 2 Chassis
Factory Option Main Board
Side Label Panel
TV Model Panel Name Panel code Panel Dimming LVDS LVDS S/W Ver.
version Maker Model Gamma HSCB Parts Code Scaler
Option Selection Tx Fmt Tx Bit
CM03 CMO V315B1-L01 BN07-00348A 32CM - INT 0.95 - - - BN94-01293E X242
PP02 CPT CLAA320WB02 BN07-00315A 32CP - INT 0.98 - - - BN94-01293A X242
LNT325HAX/XAA SH04 SAMSUNG LTA320WT-L06 BN07-00453A 32AMV - INT 0.9 - - - BN94-01293F X242
SQ05 SAMSUNG LTA320WT-L08 BN07-00482A T-SC37AUSC-1031 BN94-01293K X242
CM06 CMO V315B1-L01 BN07-00348A 32CM - INT 0.95 - - - BN94-01293E X242
PM01 CPT CLAA370WA03 BN07-00366A 37CP - INT 0.98 - - - BN94-01293D X242
LNT375HAX/XAA
PR02 CPT CLAA370WA03SC BN07-00446A 37CP2 - INT 0.9 - - - BN94-01293H X242
AM01, AM02 AUO T400XW02 BN07-00370A 40AUO - INT 0.98 - - - BN94-01293C X242
SN03, SN04 SAMSUNG LTA400WT-L07 BN07-00451A 40AMV - INT 0.9 - - - BN94-01293G X242
LNT405HAX/XAA T-SC40AUSC-1030
AA05, AA06 AUO T400XW01 V1 BN07-00448A 40AUV - INT 0.9 - - - BN94-01293J X242
SQ07, SQ08 SAMSUNG LTA400WT-L09 BN07-00489A 40AMV - INT 0.9 - - - BN94-01293G X242
Product Support SEA
Engineering Department
Scott Whitman
1/30/2009
Peony & Peony 2 Chassis
Side Factory Option Main Board
Panel
TV Model Label Panel Name Panel code Panel Dimming LVDS LVDS S/W Ver.
Maker Model Gamma HSCB Parts Code Scaler
version Option Selection Tx Fmt Tx Bit
SQ01 SAMSUNG LTA400HH-LH1 BN07-00286A 40AMWM PEONY EXT_PWM OFF WCG2 VESA 10bit BN94-01432A SVP-LX
T-PEONAUSC-1013
LNT4071FX/XAA SS02 SAMSUNG LTA400HH-L01 BN07-00475A 40AMM PEONY EXT_PWM OFF STD VESA 10bit BN94-01432D SVP-LX
SS03 SAMSUNG LTA400HH-L01 BN07-00475A 40AMM PEONY_M EXT_PWM OFF STD JEIDA 10bit T-PEONAUSC-2004 BN94-01432K SVP-LX
SQ01 SAMSUNG LTA460HH-LH1 BN07-00441A 46AMWM PEONY EXT_PWM OFF WCG2 VESA 10bit BN94-01432B SVP-LX
T-PEONAUSC-1013
LNT4671FX/XAA SS02 SAMSUNG LTA460HH-L01 BN07-00476A 46AMM PEONY EXT_PWM OFF STD VESA 10bit BN94-01432E SVP-LX
SS03 SAMSUNG LTA460HH-L01 BN07-00476A 46AMM PEONY_M EXT_PWM OFF STD JEIDA 10bit T-PEONAUSC-2004 BN94-01432H SVP-LX
SQ01 SAMSUNG LTA520HC03 BN07-00447A 52AMWM PEONY EXT_PWM OFF WCG2 VESA 10bit BN94-01432C SVP-LX
T-PEONAUSC-1013
LNT5271FX/XAA SS02 SAMSUNG LTA520HC05 BN07-00484A 52AMM PEONY EXT_PWM OFF STD VESA 10bit BN94-01432F SVP-LX
SS03 SAMSUNG LTA520HC05 BN07-00484A 50AMM PEONY_M EXT_PWM OFF STD JEIDA 10bit T-PEONAUSC-2004 BN94-01432J SVP-LX
SQ01 SAMSUNG LTA400HH-L02 BN07-00477A 40AM2 PEONY EXT_PWM OFF STD VESA 10bit T-PEONAUSC-1013 BN94-01545A SVP-LX
LNT4069FX/XAA
SQ02 SAMSUNG LTA400HH-L02 BN07-00477A 40AM2 PEONY_M EXT_PWM OFF STD JEIDA 10bit T-PEONAUSC-2004 BN94-01545C SVP-LX
SQ01 SAMSUNG LTA460HH-L02 BN07-00478A 46AM2 PEONY EXT_PWM OFF STD VESA 10bit T-PEONAUSC-1013 BN94-01545B SVP-LX
LNT4669FX/XAA
SQ02 SAMSUNG LTA460HH-L02 BN07-00478A 46AM2 PEONY_M EXT_PWM OFF STD JEIDA 10bit T-PEONAUSC-2004 BN94-01545D SVP-LX
Product Support SEA
Engineering Department
Scott Whitman
1/30/2009
ROSE Chassis
Factory Option Main Board
Side
Panel
TV Model Label Panel Name Panel code Panel Dimming LVDS LVDS S/W Ver.
Maker Model Gamma HSCB Parts Code Scaler
version Option Selection Tx Fmt Tx Bit
LNT4081FX/XAA SN01 SAMSUNG LTA400HA04 BN07-00442A 40AML ROSE DIGITAL OFF WCG3 JEIDA 10bit BN94-01433B SVP-LX
LNT4681FX/XAA SN01 SAMSUNG LTA460HA05 BN07-00443A 46AML ROSE DIGITAL OFF WCG3 JEIDA 10bit BN94-01433A SVP-LX
T-ROSEAUSC-1008
LNT5281FX/XAA SN01 SAMSUNG LTA520HA05 BN07-00444A 52AML ROSE DIGITAL OFF WCG3 JEIDA 10bit BN94-01433C SVP-LX
LNT5781FX/XAA SQ01 SAMSUNG LTA570HS01 BN07-00450A 57AML ROSE DIGITAL OFF WCG3 JEIDA 10bit BN94-01433D SVP-LX
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
