Image preview - the first page of the document
>> Download SP43J6HDX_BWT.0000027750.E.10 documenatation <<
Text preview - extract from the document
Exploded View & Parts List
7. Exploded View & Parts List
7-1 SP43J6HDX
No Code No Description;Specification Q'ty Remark
1-1 AA91-00292A ASSY-COVER,GRILLE;-,-,700G GRAY,43J6 1
1-2 AA64-00548B CABINET-MAIN;-,43J6,LG-807P,HIPS,VO,GRAY 1
1-3 AA61-00181B HOLDER-MAIN;-,43J6,HIPS,HB,BLK,- 1
1-4 AA61-00181C HOLDER-MAIN,S;-,43J6,HIPS,HB,BLK,- 1
1-5 AA61-00165B BRACKET-GRILLE;-,43J6,SECC-1,T1.0,BLK,-, 4
1-6 AA60-00033A SPACER-LENS;P/U-FOAM V0 16,-,BLK,-,50J6, 1
1-7 3001-001144 SPEAKER;25W,7ohm,88dB,1.6KHz 2
1-8 3103-001017 FAN-DC;12VDC,120mA,2200rpm,1m^3,2.3P 1
1-9 AA61-00178B HOLDER-FAN;-,43J6,ABS,VO,BLK,- 1
1-10 3001-001142 SPEAKER;25W,8ohm,89dB,60Hz 2
1-11 3001-001143 SPEAKER;15W,8ohm,90dB,150Hz 1
2-1 AA63-00155B COVER-TOP;-,43J6,LG-807P,HIPS,HB,GRAY,-, 2
2-2 AA61-00375B HOLDER-SIDE,L;-,43J6,AL6063,-,-,GD-906P 1
2-3 AA63-00156B COVER-BOT;-,43J6,LG-807P,HIPS,HB,GRAY,-, 2
2-4 AA64-00545B CABINET-FRONT;-,43J6,LG-807P NO-SILK,HIP 1
2-5 AA60-00050A SPACER-FRONT;NEOPRENE HB,-,GRAY,-,43J6,- 4
2-6 AA95-00521A ASSY-PCB,LED KEY;-,SP43J6HD,M51A,-,-,- 1
2-7 AA64-00554B KNOB-FAMILY;-,43J6,GD-906P,ABS,HB,GRAY 1
2-8 AA64-00585B KNOB-MASTER;-,43J6,GD-906P,ABS,HB,GRAY 1
2-9 AA64-00809B INDICATOR LED;-,ST-43J6,-,ACRYL,-,CLR,- 1
2-10 AA61-00176B HOLDER-SIDE,R;-,43J6,AL6063,-,-,GD-906P 1
2-11 AA61-00405B BRACKET-SCREEN,SIDE;-,43J6,AL6063,-,BLK, 2
2-12 AA61-00406B BRACKET-SCREEN,TOP;-,43J6,AL6063,-,BLK,E 2
2-13 AA67-00051A SCREEN-LENTICULAR;-,43W,-,PMMA,-,T2.1,9 1
2-14 AA67-00050A SCREEN-FRESNEL;-,43W,-,PMMA,-,T2.0,973* 1
3-1 AA61-00183B BRACKET-MIRROR,LCD;-,43J6,SECC-1,T1.6,BL 1
3-2 AA61-00360B BRACKET-SIDE,LCD;-,43J6,SECC-1,T1.0,BLK, 2
3-3 AA67-00057A MIRROR-FRONT;-,43W,GLASS,T3.0,FSM,- 1
3-4 AA61-00184B BRACKET-MIRROR,TOP;-,43J6,SECC-1,T1.6,BL 1
3-5 AA63-00021A SPACER-MIRROR;PVC,-,BLK,-,SVP403J,- 1
3-6 AA63-00021G SPACER-MIRROR;PVC,-,BLK,L420,524J,434J,- 3
3-7 AA95-00520A ASSY-PCB,RCA JACK;-,SP43J6HD,M51A,-,-,- 1
3-8 AA64-00546B CABINET-BACK,TOP;-,43J6,-,HIPS,VO,BLK,-, 1
3-9 AA61-00180B HOLDER-CHASSIS;-,43J6,ABS,VO,GRAY,- 1
3-10 AA95-00532A ASSY-PCB,PFC;-,SP43J6HDX/XEF,M51A,-,-,FR 1
3-11 AA95-00570A ASSY PCB POWER;SP43J6HD,M51A,43,-,-,- 1
3-12 AA63-00157B COVER-DUST;-,43J6,-,HIPS,VO,BLK,-,- 1
3-13 AA63-00228B COVER-TERMINAL;-,43J6,-,ABS,VO,BLK,-,- 1
3-14 AA63-00152B COVER-BACK;-,43J6,-,HIPS,VO,BLK,-,- 1
3-15 AA63-00172B COVER-CAS;-,43J6,-,HIPS,VO,BLK,-,- 1
4-1 AA94-01910K ASSY PCB MAIN(OPT);SP43J6HDX/XEN,M51A,NE 1
4-2 AA91-00319A ASSY TERMINAL BOARD;-,HIPS,VO,BLK,M51A P 1
4-3 AA91-00290A ASSY-CABINET BACK,BOT;-,VO,PS BLK,43J6 1
5-1 AA91-00294A ASSY-FILTER;-,VO,PU-FORM BLK,43J6 1
5-2 AA63-00200B COVER-DUCT,TOP;-,43J6,-,HIPS,VO,BLK,-,- 1
5-3 LAMP
5-4 AA95-00506A ASSY-PCB,LCD CONTROL;-,SP403JHA,PLT51A,- 1
5-5 AA63-00199B COVER-LCD;-,40J3P,-,ABS,V0,BLK,-,- 1
5-6 LCD-PANEL
5-7 AA67-10047B LENS-ASSY;40J5,GLASS,-,F1.5/19.4,-,T533, 1
5-8 BALLAST
5-9 4712-001013 THERMOSTAT;125/250V,15A/7.5A,105+-5C,95+ 1
Samsung Electronics 7-1
