Image preview - the first page of the document
>> Download 20040213164951421_l63a_evapl documenatation <<Text preview - extract from the document Exploded View & Parts List
2. Exploded View & Parts List
2-1 SP43L2HX1X/RAD
No Code No Description;Specification Q'ty Remark S.N.A
You can search for the updated part code through ITSELF web site.
URL : http://itself.sec.samsung.co.kr
1-1 AA64-01788P CABINET FRONT;43L2,HIPS,HB,GRY,SV012P+DG 1 CIS3 S.N.A
1-2 AA64-01791B CABINET-MIDDLE;43L2,HIPS,HB,G4309,SV-012 1 CIS6 S.N.A
1-3 BP63-00031A COVER-DECO,TOP;43L2,ABS,HB,BLK,SVM-4704P 1 T0501 S.N.A
1-4 BP63-00037A COVER-DECO,PAL;43L2,PAL,ABS,HB,BLK,SVM-4 1 T0503 S.N.A
1-5 BP63-00033A COVER-DECO,L;43L2,ABS,HB,BLK,SVM-4704P, 1 T0502 S.N.A
1-6 BP64-00177A BADGE-BRAND;ALL,AL,T1.5,70,11.3,BLK,SILI 1 T0057 S.N.A
1-7 AA64-01793B KNOB-FAMILY;43L2,ABS,HB,G3676,SVM-3012 1 T0024 S.N.A
1-8 AA64-01794B KNOB-HOLDER;43L2,ABS,HB,G3676,VACCUM PLA 1 T0138 S.N.A
1-9 AA60-00050A SPACER-FRONT;43J6,NEOPRENE HB,-,-,-,GRAY 4 S.N.A
1-10 BP67-00079A SCREEN LENTI;SAM 43WL,MS,973*558,2.1
