5. Exploded View & Part List
5. Exploded View & Part List
5-1. LS19CFEKF/EN - Exploded View
M0027
M0013
M0028
T0279
M0006
BN63-04960A
M0107
M0215
M0174
T0003
5-1
5. Exploded View & Part List
5-1-1. LS19CFEKF/EN - Parts List
Location No. Code No. Description & Specification Q'ty SA/SNA Remark
T0003 BN96-08516A ASSY COVER P-FRONT;CREAM 18.5"(933HD),AB 1 S.A
M0215 BN07-00583A LCD-PANEL;M185B1-L01 1 S.A
M0107 BN91-02618A ASSY LCD-CTZ;LS18CF,CHIMEI,M185B1-L01,Cr 1 S.N.A
M0174 BN44-00177D IP BOARD;PWI2204ST(A),T 20" MFM,1.4 ~2.8 1 S.A
M0006 BN96-08519A ASSY SHIELD P-COVER;CREAM 18.5"(933HD),S 1 S.N.A
BN63-04960A SHIELD-LAMP;933HD,SPTE,T0.3 1 S.N.A
T0279 BN63-04961A COVER-JACK;933HD,PC+ABS,5V,BK23,H/GLOSSY 1 S.N.A
M0013 BN96-08517A ASSY COVER P-REAR;CREAM 18.5"(933HD),ABS 1 S.A
M0028 BN96-08101A ASSY STAND P-BAR;2233BW,,ABS HB,BK23,GLO 1 S.A
M0027 BN96-08556A ASSY STAND P-BASE;Cream-MFM 18.5,ABS HB, 1 S.A
5-2
5. Exploded View & Part List
5-2. LS19CFEKF/EN - Parts List
Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
LS19CFEKF/EN 933HD,WVF1/S19S0-LCF,19,LCD-MO,NETHERLAN
0.1 M0001 BN90-01793A ASSY COVER FRONT;CREAM-MFM 19" 1 S.N.A
..2 T0003 BN96-08516A ASSY COVER P-FRONT;CREAM 18.5"(933HD),AB 1 S.A
...3 BN61-04252A HOLDER-LED PCB;2233BW,ABS HB,BK23 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.4 S.N.A
...3 M0112 BN63-04957A COVER-FRONT;933HD,PMMA ABS,HB,BK23,H/GLO 1 S.N.A
...3 T0056 BN63-04963A COVER-DECORATION;933HD,PC,TP25 1 S.N.A
...3 T0022 BN64-00953A KNOB-CONTROL;933HD,PMMA ABS,HB,BK23,H/GL 1 S.N.A
...3 T0238 BN64-00954A WINDOW REMOCON;933HD,PC,V0,VIOLET 1 S.N.A
...3 M0105 BN67-00229A LENS-LED;2233BW,PC,TP26 1 S.N.A
...3 M0145 BN96-08737B ASSY BOARD P-FUNCTION;SM933HD,CT5000-630 1 S.A
...3 T0069 AA60-00171T SPACER-FELT;56L7,FELT,50,T0.5,8 1 S.N.A
...3 BN63-01151A FELT-NON WOVEN;MM17NS,-,T0.5,393,10,BLK, 1 S.N.A
...3 BN81-01805B A/S-TAPE-FILAMENT;ELMATIT,T0.1,W12,L1200 0.06 S.N.A
..2 T0175 BN96-08732A ASSY SPEAKER P;16ohm,4pin,cream 18.5",3W 1 S.A
0.1 M0002 BN90-01794A ASSY COVER REAR;CREAM-MFM 19" 1 S.N.A
..2 M0013 BN96-08517A ASSY COVER P-REAR;CREAM 18.5"(933HD),ABS 1 S.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 4 S.N.A
...3 M0113 BN61-01581A BRACKET-VESA;BI17/19BS,SECC,T1.0 2 S.N.A
...3 T0060 BN61-02830A SPRING ETC;PEBBLE,SK5,1.0,LS19PEB,HRC 45 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.5 S.N.A
...3 M0014 BN63-04687A COVER-STAND BAR;2233BW,ABS,HB,BK23 1 S.N.A
...3 BN63-04688A COVER-HINGE;2233BW,ABS,HB,BK23 1 S.N.A
...3 M0006 BN63-04959A COVER-REAR;933HD,PMMA ABS,HB,BK23,H/GLOS 1 S.N.A
...3 T0071 BN64-00957A INLAY-TERMINAL;933HD,PS SHEET,T0.3,-,-,- 1 S.N.A
...3 T0102 BN73-00179A RUBBER-CAP;2233BW,ELASTOMER HB,BK07 1 S.N.A
...3 T0530 BN96-08518A ASSY COVER P-DOOR;CREAM 18.5"(933HD),ABS 1 S.A
....4 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.07 S.N.A
....4 T0151 BN64-00955A DOOR-CONTROL;933HD,PMMA ABS,BK23,H/GLOSS 1 S.N.A
...3 BN61-03947A GUIDE-CONTROL;T200D / T220D / T240D / T2 2 S.N.A
0.1 M0107 BN91-02618A ASSY LCD-CTZ;LS18CF,CHIMEI,M185B1-L01,Cr 1 S.N.A
..2 M0215 BN07-00583A LCD-PANEL;M185B1-L01 1 S.A
0.1 M0017 BN91-02619A ASSY CHASSIS;LS18CFEKB/EN 1 S.N.A
..2 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 3 S.N.A
..2 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 4 S.N.A
..2 M0081 6003-001439 SCREW-TAPTITE;BH,+,-,S,M4,L8,ZPC(WHT),SW 1 S.N.A
..2 T0562 6046-001014 STAND OFF;#4-40,L6,NI PLT,C3601,- 4 S.N.A
..2 M0174 BN44-00177D IP BOARD;PWI2204ST(A),T 20" MFM,1.4 ~2.8 1 S.A
..2 T0514 BN61-04468A BRACKET-SUPPORT;933HD,SPTE,T0.3 1 S.N.A
..2 CCMM1 BN73-00192A SILICON/RUBBER;T-MFM,GAPPAD1500,20X20X8 1 S.N.A
..2 M0014 BN94-02119A ASSY PCB MAIN;LS18CFEKB/EN 1 S.A
5-3
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
TUNER_
...3 AA63-01388A GASKET-EMI,SPONGE;SP-P300M,Conductive Fa 1 S.N.A
GASK
...3 M0014 BN94-02212A ASSY PCB MISC-MAIN;DP, LS19CFEKF/EN,BN94 1 S.N.A
...3 CIS3 BN40-00080A TUNER;DNOS403ZH261B(S),DNOS403ZH261B(S), 1 S.A
..2 M0006 BN96-08519A ASSY SHIELD P-COVER;CREAM 18.5"(933HD),S 1 S.N.A
...3 M0162 6502-001067 CABLE CLAMP;DAFC-1300,ID2.2,T5.2,NYLIN6/ 1 S.N.A
...3 T0527 AA65-30105C CLAMPER CORE-WIRE;ALL MODEL,NYLON 66,V2, 1 S.N.A
...3 BN61-02429D STUD-PEM;PNB,M2.8,D7,L20,ZPC(SIL),SUM24L 2 S.N.A
...3 T0073 AA63-00822A GASKET-EMI;71TSVK-15-5-15-13,Conductive 1 S.N.A
...3 M0131 BH63-00104A GASKET;POSEIDON,CONDUCTIVE FABRIC,2MM,10 4 S.N.A
...3 M0131 BN63-02837A GASKET;Vivaldi,Conductive Fabric,4,13,65 1 S.N.A
...3 T0073 BN63-04800A GASKET-EMI;T-MFM,Fabric Type,1.5mm,20mm, 1 S.N.A
...3 M0107 BN63-04958A SHIELD-COVER;933HD,SECC,0.8 1 S.N.A
..2 M0230 BN96-08740A ASSY CABLE P-FFC;LS19CME,FFC Cable,85,30 1 S.A
..2 CCMM1 BN73-00125A SILICON/RUBBER;SPL07,SILICON+ALUMINA,W20 1 S.N.A
..2 CCMM1 BN73-00197A SILICON/RUBBER;T-MFM,SILICON,13X13X5 2 S.N.A
0.1 M0112 BN91-02641A ASSY SHIELD;CREAM-MFM 19" 1 S.N.A
..2 BN81-01805A A/S-TAPE FILAMENT;ELMATIT,T0.1,W49,L1200 0.06 S.N.A
..2 M0081 6003-001023 SCREW-TAPTITE;PWH,+,-,B,M3,L10,ZPC(WHT), 4 S.N.A
..2 BN63-04960A SHIELD-LAMP;933HD,SPTE,T0.3 1 S.N.A
..2 T0279 BN63-04961A COVER-JACK;933HD,PC+ABS,5V,BK23,H/GLOSSY 1 S.N.A
0.1 M0045 BN92-03745A ASSY ACCESSORY;LS18CFEKB/EN 1 S.N.A
..2 M0114 BN39-00244G CBF SIGNAL;D-sub cable,15P/15P,20276N,15 1 S.A
..2 T0074 BN59-00624A REMOCON;CURIE,TM86,24PMCU+EEPROM,45,BLAC 1 S.A
..2 M0045 BN96-08603A ASSY ACCESSORY;LS18CFEKB/EN 1 S.A
...3 T0076 BH68-00633B MANUAL FLYER-02,WARRANTY CARD;comm,Samsu 1 S.N.A
...3 BH68-70448A CARD-01;TFT LCD,SRC,RUSSIA,S/W,120,W210* 1 S.N.A
...3 T0128 BN39-00061C CBF SIGNAL-STEREO;Mckinley,1,male,1.5m,B 1 S.A
...3 BN68-00907A MANUAL FLYER-01,CARD;COMM,SAMSUNG,18 LAN 1 S.N.A
...3 M0215 BN96-08614A ASSY MANUAL P-IB+QSG;933HD,SyncMaster,W/ 1 S.N.A
....4 CCM1 BN59-00785A S/W DRIVER-02,IB;933HD,W/W,SyncMaster,Cr 1 S.N.A
....4 BN68-01718A MANUAL FLYER-01,QSG;933HD,SyncMaster,14L 1 S.N.A
...3 BN96-08769A ASSY HOLDER P-CABLE;CREAM,ELASTOMER HB,Y 1 S.N.A
....4 6902-000336 BAG ZIPPER;LDPE,T0.05,W70,L80,TRP,-,-,-, 1 S.N.A
....4 BN61-04324A HOLDER-CABLE;CREAM,Urethane,YL01 1 S.N.A
...3 T0268 3903-000042 CBF-POWER CORD;DT,EU,FP3/YES,IEC320 C13/ 1 S.A
...3 M9889 BN63-01798B CLOTH-CLEAN;cloth,180,200,sea blue,ToC 1 S.A
...3 BN68-00907D MANUAL FLYER-WEEE BATTERY;COMM,SAMSUNG,2 1 S.N.A
..2 BN68-01660A MANUAL FLYER-QSG;COMM,SyncMaster,W/W,Moj 1 S.N.A
..2 M0028 BN96-08101A ASSY STAND P-BAR;2233BW,,ABS HB,BK23,GLO 1 S.A
...3 T0524 6902-000023 BAG PE;LDPE,T0.08,W150,L120,TRP,-,-,-,1. 1 S.N.A
...3 BN61-02786A BRACKET-PLATE;PEBBLE,SECC,1.0 1 S.N.A
...3 BN61-04251A STAND-BAR;2233BW,ABS,HB,BK23,Glossy 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.2 S.N.A
...3 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 2 S.N.A
..2 M0027 BN96-08556A ASSY STAND P-BASE;Cream-MFM 18.5,ABS HB, 1 S.A
...3 CIS4 BN61-01717A HOLDER-STAND;BIZET,NI PLT,CH,+,M4,L11(5) 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 1 S.N.A
...3 T0132 BN73-00077A RUBBER FOOT;MATISSE,BUMPON,13.5,T2.0,6 4 S.N.A
5-4
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 4 S.N.A
...3 BN61-02785A BRACKET-STAND BODY;PEBBLE,SECC,0.8 1 S.N.A
...3 T0004 BN63-02881C COVER-STAND BASE;LS19CF,ABS,HB,BK23 1 S.N.A
...3 T0524 6902-000389 BAG PE;HDPE/NITRON/HDPE,T0.015/T0.5/T0.0 1 S.N.A
0.1 M0113 BN92-03746A ASSY P/MATERIAL;LS18CFEKB/EN 1 S.N.A
..2 T0081 HA83-00057B LP-TAPE-CELLULOSE;,HA02-030010,T0,046,W7 1.28 S.N.A
..2 T0376 BH69-00260A BAG AIR;LDPE,0.2,1000,1800,NATURAL,-,-,- 0.006 S.N.A
..2 HA83-00056A LP-COVER;0.0001,WHT,STRECH FOIL 0.75 S.N.A
..2 T0524 6902-000241 BAG PE;HDPE/NITRON,T0.5/T0.012,W600,L600 1 S.N.A
0.1 M0019 BN92-03747A ASSY LABEL;LS18CFEKB/EN 1 S.N.A
0.1 M0003 BN92-03748A ASSY BOX;LS18CFEKB/EN 1 S.N.A
..2 BN69-02949A BOX-01,SET;933HD-SIMPLE,CB,A1,SW-50,YEL, 1 S.N.A
..2 BN96-02895A ASSY MISC P-01,HANDLE PACKING;ALL MODEL, 1 S.N.A
...3 M0103 BN66-00007A LEVER-TOP;ALL MODEL,LDPE,WHITE 1 S.N.A
...3 M0102 BN66-00008A LEVER-BOTTOM;ALL MODEL,LDPE,WHITE 1 S.N.A
5-5
