Image preview - the first page of the document
product_specification


>> Download product_specification documenatation <<

Text preview - extract from the document
                                                                                               2. Product specifications

2. Product specifications
2-1. Feature & Specifications
               Model                                                     933HD

                                                        Feature

 Supreme Digital Interface & Networking
 - With a built-in HD digital tuner, it supports HD broadcasting with no particular set-top box and provides simple
   access with a single remote control.
 Dynamic Contrast
 - Automatically detects the input visual signal and adjusts to create optimum contrast.
 Convenience
 -The TV utilizes the HDMI system to implement perfect digital sound and picture quality.

                                                    Specifications

                  Item                                                    Description
LCD Panel                               TFT-LCD Panel, RGB Vertical strip, normaly White, 18.5-Inch viewable,
                                        0.3(H) x 0.3(V) mm Pixel Pitch
Scanning Frequency                      Horizontal : 30KHz ~ 81KHz(Automatic)
                                        Vertical: 56Hz ~ 75Hz(Automatic)
Display Colors                          16.7 Million colors
Maximum resolution                      Horizontal: 1366 pixels
                                        Vertical: 768 pixels
Input Signal                            Analog 0.7Vp-p
