Image preview - the first page of the document
>> Download Exploded View & Part List documenatation <<
Text preview - extract from the document
5. Exploded View & Part List
5. Exploded View & Part List
5-1. Exploded View
M0013
M0013
M0013
M0014
M0006
T0514
M0174
M0215
T0003
5-1
5. Exploded View & Part List
5-1-1. LS19PMASF/EDC Parts List
Location No. Code No. Description & Specification Q'ty SA/SNA Remark
T0003 BN96-05678A ASSY COVER P-FRONT;LS19PE,MFM,ABS HB,BK2 1 S.A
M0215 BN07-00351A LCD-PANEL;LTM190M2-L31,Haydn,6bit Hi-FRC 1 S.A
M0174 BN44-00177B IP BOARD;SIP-1920,PEBBLE 19" MFM,3.0 ~5. 1 S.A
M0014 BN94-01366A ASSY PCB MAIN-STZ;LS19PMASF/EDC 1 S.N.A
T0514 BN61-03302A BRACKET-SUPPORT;20"W(2032MW),SPTE,0.3 1 S.N.A
M0006 BN96-05680A ASSY SHIELD P-COVER;LS19PE,SECC,T0.8,MFM 1 S.A
M0013 BN96-05679A ASSY COVER P-REAR;LS19PE,MFM,ABS HB,BK26 1 S.A
M0013 BN96-04150D ASSY STAND P-BAR;-,PEBBLE17,-,ABS HB,BK2 1 S.A
5-2
5. Exploded View & Part List
5-2. LS19PMASF/EDC Parts List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
LS19PMASF/
932MW,WGD1/S19M0-LPM,19,LCD-MO,NETHERLAN
EDC
0.1 M0001 BN90-01325A ASSY COVER FRONT;LS19PMASF/EDC,MFM 1 S.N.A
..2 T0003 BN96-05678A ASSY COVER P-FRONT;LS19PE,MFM,ABS HB,BK2 1 S.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 3 S.A
...3 BN61-02829A GUIDE-PANEL;PEBBLE,SECC,0.5,LS19PEB 1 S.N.A
...3 CCM1 BN63-02183E COVER-SHEET;Rhcm,PE Vinyl,T0.05,750mm,20 0.5 S.N.A
...3 M0112 BN63-03610A COVER-FRONT;19"W(932MW),ABS,HB,BK26,H/GL 1 S.N.A
....4 BN81-00204C RESIN-H/GLOSS;UK006,SF-0503,ABS HB,BK26, 0.25 S.N.A
...3 T0023 BN64-00597B KNOB POWER;PEBBLE,black highglossy 1 S.N.A
....4 BN81-00204C RESIN-H/GLOSS;UK006,SF-0503,ABS HB,BK26, 0.006 S.N.A
...3 T0022 BN64-00641A KNOB CONTROL;20"W(2032MW),ABS,HB,BK26,H/ 1 S.N.A
...3 T0299 BN64-00642A WINDOW-RMC LED;20"W(2032MW),ACRYL,CLEAR 1 S.N.A
...3 M0145 BN96-05586A ASSY BOARD P-FUNCTION;LS20PMASF,CT5000-5 1 S.A
...3 T0603 BN64-00711A WINDOW-RMC;932MW,PC,V0,VIOLET,DIFFUSER(5 1 S.N.A
..2 T0175 BN96-05501B ASSY SPEAKER P;16##,PEBBLE,Right/Left,3W 1 S.A
0.1 M0002 BN90-01326A ASSY COVER REAR;LS19PMASF/EDC,MFM 1 S.N.A
..2 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 2 S.N.A
..2 M0013 BN96-05679A ASSY COVER P-REAR;LS19PE,MFM,ABS HB,BK26 1 S.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 4 S.N.A
...3 T0060 BN61-02830A SPRING ETC;PEBBLE,SK5,1.0,LS19PEB,HRC 45 1 S.N.A
...3 CCM1 BN63-02183E COVER-SHEET;Rhcm,PE Vinyl,T0.05,750mm,20 0.5 S.N.A
...3 M0014 BN63-02880B COVER-STAND BAR;PEBBLE,ABS HB,T2.6,BK26, 1 S.N.A
....4 BN81-00204L RESIN;HF-0680U,UK006,ABS HB,BK26,-,-,- 6.7 S.N.A
...3 BN63-02883B COVER-HINGE;PEBBLE,ABS HB,T2.6,BK26,HF-0 1 S.N.A
....4 BN81-00204L RESIN;HF-0680U,UK006,ABS HB,BK26,-,-,- 25.9 S.N.A
...3 M0006 BN63-03612A COVER-REAR;19"W(932MW),ABS,HB,BK26,H/GLO 1 S.N.A
....4 BN81-00204C RESIN-H/GLOSS;UK006,SF-0503,ABS HB,BK26, 0.7 S.N.A
...3 T0071 BN64-00650A INLAY-TERMINAL;19"W(932MW),PS SHEET,T0.3 1 S.N.A
...3 T0102 BN73-00132B RUBBER-CAP;PEBBLE,ELASTOMER,BK07,HB 1 S.N.A
0.1 M0106 BN91-01035Y ASSY LCD-STZ;LS19MEW* 1 S.N.A
..2 M0215 BN07-00351A LCD-PANEL;LTM190M2-L31,Haydn,6bit Hi-FRC 1 S.A
0.1 M0017 BN91-01653A ASSY CHASSIS-STZ;LS19PMASF/EDC,W/W 1 S.A
..2 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 2 S.N.A
..2 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 4 S.N.A
..2 M0081 6003-001439 SCREW-TAPTITE;BH,+,-,S,M4,L8,ZPC(WHT),SW 2 S.N.A
..2 T0562 6046-001013 STAND OFF;M3,L5,Ni PLT,SUM24L,#4-40 4 S.N.A
..2 M2893 BN39-00785A LEAD CONNECTOR;LS19PLMTSQ,UL1007#26,UL/C 1 S.A
..2 M0174 BN44-00177B IP BOARD;SIP-1920,PEBBLE 19" MFM,3.0 ~5. 1 S.A
..2 T0514 BN61-03302A BRACKET-SUPPORT;20"W(2032MW),SPTE,0.3 1 S.N.A
..2 M0014 BN94-01366A ASSY PCB MAIN-STZ;LS19PMASF/EDC 1 S.N.A
...3 CIS3 BN40-00099A TUNER;HTM-6C/235S,HTM-6C/235S,PAL BG,DK, 1 S.A
...3 M0014 BN94-01366E ASSY PCB MAIN-STZ;LS19PMASFSEDC,SKD 1 S.N.A
....4 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.025 S.N.A
5-3
5. Exploded View & Part List
....4 CN101 3701-001385 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,AU 1 S.A
....4 CN102 3701-001386 CONNECTOR-DVI;24P,3R,FEMALE,AU 1 S.A
....4 CN330 3711-000058 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5MM,AN 1 S.A
....4 JA330 3722-000143 JACK-PHONE;1P(VER),AG,BLK,ANGLE 1 S.A
....4 CN703 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 S.A
....4 JA333 3722-002143 JACK-PIN;5P,NI,GRN/BLU/RED/WHT/RED,STRAI 1 S.A
....4 JA330 3722-002176 JACK-PHONE;7P/4C,-,SN,L-BLU,- 1 S.A
....4 JA333 3722-002267 JACK-PIN;3P,AU,RED/WHT/YEL,ANGLE 1 S.A
....4 CN701 3722-002275 JACK-DIN;4P,-,SN,BLK,- 1 S.A
....4 CIS3 BN40-00099A TUNER;HTM-6C/235S,HTM-6C/235S,PAL BG,DK, 1 S.A
....4 T0174 BN97-01668A ASSY SMD;LS19PMASF/EDC 1 S.N.A
.....5 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45##,96.5Sn/ 2.049 S.N.A
.....5 D105 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
.....5 D106 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
.....5 D107 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
.....5 D108 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
.....5 D109 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
.....5 D110 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
.....5 D111 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
.....5 D112 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
.....5 D129 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
.....5 D130 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
.....5 D100 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
.....5 D101 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
.....5 D102 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
.....5 D121 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
.....5 D122 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
.....5 D123 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
.....5 D124 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
.....5 D125 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
.....5 D126 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
.....5 D127 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
.....5 D128 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
.....5 D523 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
.....5 D700 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
.....5 D701 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
.....5 D702 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
.....5 D703 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
.....5 D801 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
.....5 D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 1 S.A
.....5 D600 0402-001098 DIODE-RECTIFIER;SK34,40V,3A,SMC,TP 1 S.A
.....5 D602 0402-001098 DIODE-RECTIFIER;SK34,40V,3A,SMC,TP 1 S.A
.....5 D103 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
.....5 D104 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
.....5 D113 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
.....5 D114 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
.....5 ZD100 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
.....5 ZD103 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
.....5 ZD105 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
.....5 ZD108 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
.....5 ZD110 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
5-4
5. Exploded View & Part List
.....5 ZD111 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
.....5 ZD500 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
.....5 ZD700 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
.....5 ZD701 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
.....5 ZD703 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
.....5 D118 0403-000579 DIODE-ZENER;BZX84C5V1,4.8-5.4V,200mW,SOT 1 S.A
.....5 D119 0403-000579 DIODE-ZENER;BZX84C5V1,4.8-5.4V,200mW,SOT 1 S.A
.....5 D120 0403-000579 DIODE-ZENER;BZX84C5V1,4.8-5.4V,200mW,SOT 1 S.A
.....5 D115 0403-001411 DIODE-ZENER;-,5.49-5.73V,200mW,SOD-323,T 1 S.A
.....5 D800 0403-001425 DIODE-ZENER;BZX84C33,31-35V,350mW,SOT-23 1 S.A
.....5 D133 0403-001435 DIODE-ZENER;QZX363C5V6,5.32-5.88V,200MW, 1 S.A
.....5 ZD200 0403-001435 DIODE-ZENER;QZX363C5V6,5.32-5.88V,200MW, 1 S.A
.....5 D0254 0404-001020 DIODE-SCHOTTKY;BAT54C,30V,200mA,SOT-23,T 1 S.A
.....5 D0254 0404-001020 DIODE-SCHOTTKY;BAT54C,30V,200mA,SOT-23,T 1 S.A
.....5 D504 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D505 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D511 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D512 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D704 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D705 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D706 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D707 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D708 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D709 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D710 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D711 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D712 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D713 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D714 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D715 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D716 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D717 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D718 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D719 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D720 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
.....5 D522 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
.....5 Q101 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
.....5 Q102 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
.....5 Q105 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
.....5 Q106 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
.....5 Q107 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
.....5 Q108 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
.....5 Q109 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
.....5 Q502 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
.....5 Q507 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
.....5 Q800 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
.....5 Q700 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 1 S.A
.....5 Q100 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
.....5 Q103 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
.....5 Q201 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
.....5 Q600 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
5-5
5. Exploded View & Part List
.....5 Q601 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
.....5 Q602 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
.....5 Q603 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
.....5 Q701 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
.....5 Q409 0505-001170 FET-SILICON;SI9933ADY-T1,P,-20V,3.4A,0.0 1 S.A
.....5 IC106 1001-001363 IC-VIDEO SWITCH;PI3HDMI412FT,HDMI TMDS S 1 S.A
.....5 IC107 1002-001399 IC-D/A CONVERTER;PCM1754,24BIT,SSOP,16P, 1 S.A
.....5 IC112 1103-001279 IC-EEPROM;24C32,32Kbit,4Kx8Bit,SOP,8P,5x 1 S.A
.....5 IC112 1103-001310 IC-EEPROM;24LC02B,256X8BIT,SOIC,8P,3.91X 1 S.N.A
.....5 IC112 1103-001310 IC-EEPROM;24LC02B,256X8BIT,SOIC,8P,3.91X 1 S.N.A
.....5 IC112 1103-001310 IC-EEPROM;24LC02B,256X8BIT,SOIC,8P,3.91X 1 S.N.A
.....5 IC301 1105-001715 IC-VIDEO RAM;M13S128168,K4D261638,GDDR,1 1 S.A
.....5 T0085 1201-001980 IC-AUDIO AMP;TDA7266D,SO,20P,16X11.1MM,- 1 S.A
.....5 T0085 1201-002136 IC-AUDIO AMP;LM4810,MSOP,8P,3x3mm,DUAL,- 1 S.A
.....5 IC304 1203-001824 IC-VOL. DETECTOR;7042,SOT-89,3P,-,PLASTI 1 S.A
.....5 T0087 1203-002351 IC-POSI.FIXED REG.;LF25C,DPAK,3P,240MIL, 1 S.A
.....5 T0087 1203-002835 IC-POSI.FIXED REG.;KIA7805AF,DPAK,3P,6.6 1 S.A
.....5 T0087 1203-002842 IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P 1 S.A
.....5 IC109 1203-003015 IC-DC/DC CONVERTER;MP1410ES,SOIC,8P,4.9x 1 S.A
.....5 T0170 1203-003059 IC-SWITCH VOL. REG.;MP1583,SOIC,8P,4.9x3 1 S.A
.....5 T0170 1203-003059 IC-SWITCH VOL. REG.;MP1583,SOIC,8P,4.9x3 1 S.A
.....5 T0087 1203-003561 IC-POSI.FIXED REG.;NCP551SN15T1G,TSOP-5, 1 S.A
.....5 IC109 1205-003155 IC-LCD CONTROLLER;MST67889ALD-LF,LQFP,25 1 S.A
.....5 R110 2007-000040 R-CHIP;150ohm,1%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000067 R-CHIP;15Kohm,1%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
5-6
5. Exploded View & Part List
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
5-7
5. Exploded View & Part List
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000080 R-CHIP;2Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000080 R-CHIP;2Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000080 R-CHIP;2Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000081 R-CHIP;2.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000081 R-CHIP;2.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
5-8
5. Exploded View & Part List
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
5-9
5. Exploded View & Part List
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000093 R-CHIP;20Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000103 R-CHIP;120Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000106 R-CHIP;220Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000116 R-CHIP;120ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000239 R-CHIP;1.5Kohm,1%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
5-10
5. Exploded View & Part List
.....5 R110 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000643 R-CHIP;270ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000708 R-CHIP;3.9Kohm,1%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000821 R-CHIP;390ohm,1%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000965 R-CHIP;5.1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000965 R-CHIP;5.1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000965 R-CHIP;5.1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001044 R-CHIP;56ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-001240 R-CHIP;910ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-002906 R-CHIP;200Kohm,1%,1/10W,TP,1608 1 S.A
.....5 R110 2007-007004 R-CHIP;12Kohm,1%,1/10W,TP,1608 1 S.A
.....5 R110 2007-007352 R-CHIP;130Kohm,1%,1/10W,TP,1608 1 S.A
.....5 RA301 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
.....5 RA302 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
.....5 RA303 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
.....5 RA304 2011-000686 R-NETWORK;56ohm,5%,1/16W,L,CHIP,8P,TP,3. 1 S.A
.....5 RA305 2011-000686 R-NETWORK;56ohm,5%,1/16W,L,CHIP,8P,TP,3. 1 S.A
.....5 RA400 2011-000881 R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,3. 1 S.A
.....5 RA401 2011-000881 R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,3. 1 S.A
5-11
5. Exploded View & Part List
.....5 RA402 2011-000881 R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,3. 1 S.A
.....5 RA403 2011-000881 R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,3. 1 S.A
.....5 RA404 2011-000881 R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,3. 1 S.A
.....5 C120 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000140 C-CER,CHIP;1.5nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.....5 C120 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
.....5 C120 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
.....5 C120 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
.....5 C120 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
.....5 C120 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
.....5 C120 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
.....5 C120 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 S.A
.....5 C120 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 S.A
.....5 C120 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 S.A
.....5 C120 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 S.A
.....5 C120 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 S.A
.....5 C120 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 S.A
.....5 C120 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 S.A
.....5 C120 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 S.A
.....5 C120 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 S.A
.....5 C120 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 S.A
.....5 C120 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 S.A
.....5 C120 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 1 S.A
.....5 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
5-12
5. Exploded View & Part List
.....5 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000604 C-CER,CHIP;22nF,10%,25V,X7R,1608 1 S.A
.....5 C120 2203-000604 C-CER,CHIP;22nF,10%,25V,X7R,1608 1 S.A
.....5 C120 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 1 S.A
.....5 C120 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 1 S.A
.....5 C120 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 1 S.A
.....5 C120 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 1 S.A
.....5 C120 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,- 1 S.A
.....5 C120 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,- 1 S.A
.....5 C120 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,- 1 S.A
.....5 C120 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,- 1 S.A
5-13
5. Exploded View & Part List
.....5 C120 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,- 1 S.A
.....5 C120 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,- 1 S.A
.....5 C120 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,- 1 S.A
.....5 C120 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,- 1 S.A
.....5 C120 2203-000998 C-CER,CHIP;0.047nF,5%,50V,C0G,1608 1 S.A
.....5 C120 2203-000998 C-CER,CHIP;0.047nF,5%,50V,C0G,1608 1 S.A
.....5 C120 2203-000998 C-CER,CHIP;0.047nF,5%,50V,C0G,1608 1 S.A
.....5 C120 2203-000998 C-CER,CHIP;0.047nF,5%,50V,C0G,1608 1 S.A
.....5 C120 2203-000998 C-CER,CHIP;0.047nF,5%,50V,C0G,1608 1 S.A
.....5 C120 2203-000998 C-CER,CHIP;0.047nF,5%,50V,C0G,1608 1 S.A
.....5 C120 2203-000998 C-CER,CHIP;0.047nF,5%,50V,C0G,1608 1 S.A
.....5 C120 2203-001071 C-CER,CHIP;0.056nF,5%,50V,C0G,1608 1 S.A
.....5 C120 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,1608 1 S.A
.....5 C120 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,1608 1 S.A
.....5 C120 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
5-14
5. Exploded View & Part List
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
.....5 C120 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
5-15
5. Exploded View & Part List
.....5 C120 2203-005261 C-CER,CHIP;1000nF,10%,25V,X7R,3216 1 S.A
.....5 C120 2203-005261 C-CER,CHIP;1000nF,10%,25V,X7R,3216 1 S.A
.....5 C120 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
.....5 C120 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
.....5 C120 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
.....5 C120 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
.....5 C120 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
.....5 C120 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
.....5 C120 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
.....5 C120 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
.....5 C120 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
.....5 C120 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
.....5 C120 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
.....5 C603 2402-000108 C-AL,SMD;10uF,20%,16V,WT,TP,4.3x4.3x5.2m 1 S.A
.....5 C615 2402-001081 C-AL,SMD;100uF,20%,25V,WT,TP,8.3x8.3x10 1 S.A
.....5 C632 2402-001081 C-AL,SMD;100uF,20%,25V,WT,TP,8.3x8.3x10 1 S.A
.....5 C400 2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 1 S.A
.....5 C649 2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 1 S.A
.....5 C528 2402-001128 C-AL,SMD;100##F,20%,16V,-,TP,6.3X5.7mm 1 S.A
.....5 C529 2402-001128 C-AL,SMD;100##F,20%,16V,-,TP,6.3X5.7mm 1 S.A
.....5 C550 2402-001128 C-AL,SMD;100##F,20%,16V,-,TP,6.3X5.7mm 1 S.A
.....5 C605 2402-001128 C-AL,SMD;100##F,20%,16V,-,TP,6.3X5.7mm 1 S.A
.....5 C613 2402-001128 C-AL,SMD;100##F,20%,16V,-,TP,6.3X5.7mm 1 S.A
.....5 C617 2402-001128 C-AL,SMD;100##F,20%,16V,-,TP,6.3X5.7mm 1 S.A
.....5 C645 2402-001128 C-AL,SMD;100##F,20%,16V,-,TP,6.3X5.7mm 1 S.A
.....5 C816 2402-001128 C-AL,SMD;100##F,20%,16V,-,TP,6.3X5.7mm 1 S.A
.....5 C538 2402-001129 C-AL,SMD;47UF,20%,16V,WT,TP,6.3X5.2MM 1 S.A
.....5 C558 2402-001129 C-AL,SMD;47UF,20%,16V,WT,TP,6.3X5.2MM 1 S.A
.....5 C367 2402-001178 C-AL,SMD;10uF,20%,16V,WT,TP,4.3x4.3x5.8m 1 S.A
.....5 C502 2402-001178 C-AL,SMD;10uF,20%,16V,WT,TP,4.3x4.3x5.8m 1 S.A
.....5 C503 2402-001178 C-AL,SMD;10uF,20%,16V,WT,TP,4.3x4.3x5.8m 1 S.A
.....5 C556 2402-001178 C-AL,SMD;10uF,20%,16V,WT,TP,4.3x4.3x5.8m 1 S.A
.....5 C557 2402-001178 C-AL,SMD;10uF,20%,16V,WT,TP,4.3x4.3x5.8m 1 S.A
.....5 C720 2402-001183 C-AL,SMD;22UF,20%,16V,WT,TP,5.3X5.3X6MM 1 S.A
.....5 C800 2402-001183 C-AL,SMD;22UF,20%,16V,WT,TP,5.3X5.3X6MM 1 S.A
.....5 C802 2402-001183 C-AL,SMD;22UF,20%,16V,WT,TP,5.3X5.3X6MM 1 S.A
.....5 C560 2402-001218 C-AL,SMD;22UF,20%,35V,WT,TP,6.6X6.6X5.8M 1 S.A
.....5 C373 2402-001226 C-AL,SMD;4.7UF,20%,35V,HR,TP,4.3X4.3X5.8 1 S.A
.....5 C525 2402-001230 C-AL,SMD;2.2uF,##20%,35V,WT,TP,3*5.2 1 S.A
.....5 C359 2402-001238 C-AL,SMD;1uF,20%,50V,HR,TP,4.3x4.3x5.2mm 1 S.A
.....5 C360 2402-001238 C-AL,SMD;1uF,20%,50V,HR,TP,4.3x4.3x5.2mm 1 S.A
.....5 C361 2402-001238 C-AL,SMD;1uF,20%,50V,HR,TP,4.3x4.3x5.2mm 1 S.A
.....5 C362 2402-001238 C-AL,SMD;1uF,20%,50V,HR,TP,4.3x4.3x5.2mm 1 S.A
.....5 C363 2402-001238 C-AL,SMD;1uF,20%,50V,HR,TP,4.3x4.3x5.2mm 1 S.A
.....5 C364 2402-001238 C-AL,SMD;1uF,20%,50V,HR,TP,4.3x4.3x5.2mm 1 S.A
.....5 C365 2402-001238 C-AL,SMD;1uF,20%,50V,HR,TP,4.3x4.3x5.2mm 1 S.A
.....5 C366 2402-001238 C-AL,SMD;1uF,20%,50V,HR,TP,4.3x4.3x5.2mm 1 S.A
.....5 C817 2402-001238 C-AL,SMD;1uF,20%,50V,HR,TP,4.3x4.3x5.2mm 1 S.A
.....5 C639 2402-001257 C-AL,SMD;470uF,20%,16V,-,TP,8.3*10 1 S.A
.....5 C650 2402-001257 C-AL,SMD;470uF,20%,16V,-,TP,8.3*10 1 S.A
.....5 C820 2402-001257 C-AL,SMD;470uF,20%,16V,-,TP,8.3*10 1 S.A
5-16
5. Exploded View & Part List
.....5 C821 2402-001257 C-AL,SMD;470uF,20%,16V,-,TP,8.3*10 1 S.A
.....5 C618 2402-001273 C-AL,SMD;220uF,20%,35V,WT,REEL,10X10mm 1 S.A
.....5 C638 2402-001273 C-AL,SMD;220uF,20%,35V,WT,REEL,10X10mm 1 S.A
.....5 T0052 2703-000185 INDUCTOR-SMD;3.3uH,10%,2012 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
