Service Manuals, User Guides, Schematic Diagrams or docs for : Samsung LED TV LE37D550K1WXXN Samsung LE37D550K1WXXN

<< Back | Home

Most service manuals and schematics are PDF files, so You will need Adobre Acrobat Reader to view : Acrobat Download Some of the files are DjVu format. Readers and resources available here : DjVu Resources
For the compressed files, most common are zip and rar. Please, extract files with Your favorite compression software ( WinZip, WinRAR ... ) before viewing. If a document has multiple parts, You should download all, before extracting.
Good luck. Repair on Your own risk. Make sure You know what You are doing.



Image preview - the first page of the document



>> Download Samsung LE37D550K1WXXN documenatation <<

Text preview - extract from the document

                        LCD-TV
     Chassis    :   U56A                      U56B
     Model      :   LE32D55*K*W   LE32D58*K*K LE19D45*G*W
                    LE37D55*K*W   LE37D58*K*K LE22D45*G*W
                    LE40D55*K*W   LE40D58*K*K
                    LE46D55*K*W   LE46D58*K*K
                    LE32D57*K*S   LE26D45*G*W
                    LE37D57*K*S   LE32D45*G*W
                    LE40D57*K*S
                    LE46D57*K*S




SERVICE                                Manual

  TFT-LCD TV                                 Contents

                                  1. Precautions

                                  2. Product Specifications

                                  3. Disassembly and Reassembly

                                  4. Troubleshooting

                                  5. Wiring Diagram




  LE32D550K1W
                                                             Contents
1. Precautions .............................................................................................................. 1-1
   1-1. Safety Precautions ......................................................................................................... 1-1
   1-2. Servicing Precautions ..................................................................................................... 1-2
   1-3. Electrostatically Sensitive Devices (ESD) Precautions .................................................. 1-2
   1-4. Installation Precautions .................................................................................................. 1-3
2. Product Specifications............................................................................................ 2-1
   2-1. Feature & Specifications ................................................................................................. 2-1
   2-2. Detail Factory Option ...................................................................................................... 2-9
   2-3. Specification Comparison to Old Models ...................................................................... 2-13
   2-4. New Features Explanation ........................................................................................... 2-15
   2-5. Accessories .................................................................................................................. 2-27
3. Disassembly and Reassembly ............................................................................... 3-1
   3-1. Disassembly and Reassembly ....................................................................................... 3-1
4. Troubleshooting ...................................................................................................... 4-1
   4-1. Troubleshooting .............................................................................................................. 4-1
   4-2. Alignments and Adjustments ........................................................................................ 4-58
   4-3. Factory Mode Adjustments ........................................................................................... 4-59
   4-4. White Balance - Calibration .......................................................................................... 4-67
   4-5. White Ratio (Balance) Adjustment ................................................................................ 4-67
   4-6. Servicing Information .................................................................................................... 4-68
   4-7. How To Upgrade Sub Micom ........................................................................................ 4-69
   4-8. Mechanical Diagram ..................................................................................................... 4-71
   4-9. PCB Diagram ................................................................................................................ 4-73
5. Wiring Diagram ........................................................................................................ 5-1
   5-1. Wiring Diagram ............................................................................................................... 5-1
   5-2. Connector ....................................................................................................................... 5-3
   5-3. Connector Functions ...................................................................................................... 5-8
   5-4. Cables ............................................................................................................................ 5-8
This Service Manual is a property of Samsung Electronics Co.,Ltd.
